Asus W90V Instructions for use

Notebook PC
Hardware User’s Manual
E4022/ September 2008

2
Contents
Table of Contents
Tableof Contents
1. Introducing the Notebook PC
About This User’s Manual ������������������������������������������������������������������������������������������ 6
Notes For This Manual�������������������������������������������������������������������������������������������6
Preparing your Notebook PC�������������������������������������������������������������������������������������� 9
2. Knowing the Parts
Top Side��������������������������������������������������������������������������������������������������������������������12
Bottom Side��������������������������������������������������������������������������������������������������������������15
Left Side �������������������������������������������������������������������������������������������������������������������18
Right Side�����������������������������������������������������������������������������������������������������������������20
Rear Side������������������������������������������������������������������������������������������������������������������22
Front Side�����������������������������������������������������������������������������������������������������������������24
3. Getting Started
Power System ����������������������������������������������������������������������������������������������������������26
Using AC Power��������������������������������������������������������������������������������������������������� 26
Using Battery Power �������������������������������������������������������������������������������������������� 27
Battery Care��������������������������������������������������������������������������������������������������������� 27
Powering ON the Notebook PC ��������������������������������������������������������������������������� 28
The Power-On Self Test (POST)��������������������������������������������������������������������������28
Checking Battery Power ��������������������������������������������������������������������������������������29
Charging the Battery Pack����������������������������������������������������������������������������������� 29
Power Options ����������������������������������������������������������������������������������������������������� 30
Power Management Modes��������������������������������������������������������������������������������� 31
Sleep and Hibernate ��������������������������������������������������������������������������������������������31
Thermal Power Control���������������������������������������������������������������������������������������� 31
Special Keyboard Functions������������������������������������������������������������������������������������� 32
Colored Hot Keys�������������������������������������������������������������������������������������������������32
Microsoft Windows Keys�������������������������������������������������������������������������������������� 33
Extended Keyboard ��������������������������������������������������������������������������������������������� 33
Switches and Status Indicators �������������������������������������������������������������������������������� 34
Switches���������������������������������������������������������������������������������������������������������������34
Status Indicators �������������������������������������������������������������������������������������������������� 36

3
Contents
Table of Contents (Cont.)
Multimedia Control Keys (on selected models) ���������������������������������������������������38
4. Using the Notebook PC
Pointing Device���������������������������������������������������������������������������������������������������������40
Using the Touchpad ��������������������������������������������������������������������������������������������� 40
Touchpad Usage Illustrations�������������������������������������������������������������������������������41
Caring for the Touchpad���������������������������������������������������������������������������������������42
Automatic Touchpad Disabling (Synaptics)����������������������������������������������������������42
Storage Devices �������������������������������������������������������������������������������������������������������43
Expansion Card ��������������������������������������������������������������������������������������������������� 43
Optical Drive ��������������������������������������������������������������������������������������������������������44
Flash Memory Card Reader ��������������������������������������������������������������������������������46
Hard Disk Drive���������������������������������������������������������������������������������������������������� 47
Memory (RAM)����������������������������������������������������������������������������������������������������� 49
Connections��������������������������������������������������������������������������������������������������������������50
Modem Connection (on selected models) �����������������������������������������������������������50
Network Connection �������������������������������������������������������������������������������������������� 51
Wireless LAN Connection (on selected models) �������������������������������������������������52
Windows Wireless Network Connection �������������������������������������������������������������� 53
Bluetooth Wireless Connection (on selected models) �����������������������������������������54
Antenna Connections (on selected models) �������������������������������������������������������� 55
Media Center Remote Controller (on selected models)��������������������������������������� 56
Trusted Platform Module (TPM) (on selected models)��������������������������������������������� 57
Appendix
Optional Accessories���������������������������������������������������������������������������������������������� A-2
Optional Connections ���������������������������������������������������������������������������������������� A-3
Bluetooth Mouse Setup (optional) ��������������������������������������������������������������������� A-4
Operating System and Software����������������������������������������������������������������������������� A-6
System BIOS Settings ��������������������������������������������������������������������������������������� A-7
Common Problems and Solutions ��������������������������������������������������������������������A-11
Windows Vista Software Recovery������������������������������������������������������������������ A-17
Glossary ��������������������������������������������������������������������������������������������������������������� A-19
Declarations and Safety Statements �������������������������������������������������������������������� A-23
Notebook PC Information ������������������������������������������������������������������������������������� A-34

4
Contents

5
1. Introducing the Notebook PC
About This User’s Manual
Notes For This Manual
Safety Precautions
Preparing your Notebook PC
Photos and icons in this manual are used for artistic purposes only and do not
show what is actually used in the product itself.
There may be differences between your Notebook PC and the drawings shown in
this manual. Please accept your Notebook PC as being correct.

6
1Introducing the Notebook PC
About This User’s Manual
You are reading the Notebook PC User’s Manual. This User’s Manual provides
information on the various components in the Notebook PC and how to use them. The
following are major sections of this User’s Manuals:
1. Introducing the Notebook PC
Introduces you to the Notebook PC and this User’s Manual.
2. Knowing the Parts
Gives you information on the Notebook PC’s components.
3. Getting Started
Gives you information on getting started with the Notebook PC.
4. Using the Notebook PC
Gives you information on using the Notebook PC’s components.
5. Appendix
Introduces you to optional accessories and gives additional information.
Notes For This Manual
A few notes and warnings in bold are used throughout this guide that you should be aware of in order
to complete certain tasks safely and completely. These notes have different degrees of importance as
described below:
NOTE: Tips and information for special situations.
TIP: Tips and useful information for completing tasks.
IMPORTANT! Vital information that must be followed to prevent damage to data,
components, or persons.
WARNING! Important information that must be followed for safe operation.
Text enclosed in < > or [ ] represents a key on the keyboard; do not actually type the
< > or [ ] and the enclosed letters.
< >
[ ]

7
Introducing the Notebook PC 1
Safety Precautions
The following safety precautions will increase the life of the Notebook PC. Follow all precautions and
instructions. Except as described in this manual, refer all servicing to qualied personnel. Do not use
damaged power cords, accessories, or other peripherals. Do not use strong solvents such as thinners,
benzene, or other chemicals on or near the surface.
IMPORTANT! Disconnect the AC power and remove the battery pack(s) before
cleaning. Wipe the Notebook PC using a clean cellulose sponge or chamois cloth
dampened with a solution of nonabrasive detergent and a few drops of warm water
and remove any extra moisture with a dry cloth.
DO NOT expose to or use near liquids,
rain, or moisture. DO NOT use the
modem during an electrical storm.
DO NOT expose to dirty or dusty en-
vironments. DO NOT operate during
a gas leak.
SAFE TEMP: This Notebook PC
should only be used in environments
with ambient temperatures between
5°C (41°F) and 35°C (95°F)
Battery safety warning:
DO NOT throw the battery in re.
DO NOT short circuit the contacts.
DO NOT disassemble the battery.
DO NOT expose to strong magnetic
or electrical elds.
DO NOT place on uneven or unstable
work surfaces. Seek servicing if the
casing has been damaged.
DO NOT place or drop objects on
top and do not shove any foreign
objects into the Notebook PC.
DO NOT press or touch the display
panel. Do not place together with
small items that may scratch or enter
the Notebook PC.
DO NOT leave the Notebook PC on
your lap or any part of the body in
order to prevent discomfort or injury
from heat exposure.
DO NOT throw the Notebook PC in municipal waste. This product has been designed
to enable proper reuse of parts and recycling. The symbol of the crossed out wheeled
bin indicates that the product (electrical, electronic equipment and mercury-containing
button cell battery) should not be placed in municipal waste. Check local regulations for
disposal of electronic products.
DO NOT carry or cover a Notebook PC that is powered ON with any materials that will
reduce air circulation such as a carrying bag.
INPUT RATING: Refer to the rating
label on the bottom of the Notebook
PC and be sure that your power adapter
complies with the rating.
DO NOT throw the battery in municipal waste. The symbol of the crossed out wheeled
bin indicates that the battery should not be placed in municipal waste.

8
1Introducing the Notebook PC
CAUTION! There are three main types of airport security devices: X-ray machines
(used on items placed on conveyor belts), magnetic detectors (used on people
walking through security checks), and magnetic wands (hand-held devices used on
people or individual items). You can send your Notebook PC and diskettes through
airport X-ray machines. However, it is recommended that you do not send your
Notebook PC or diskettes through airport magnetic detectors or expose them to
magnetic wands.
Charge Your Batteries
If you intend to use battery power, be sure to fully charge your battery pack and any optional battery
packs before going on long trips. Remember that the power adapter charges the battery pack as long as
it is plugged into the computer and an AC power source. Be aware that it takes much longer to charge
the battery pack when the Notebook PC is in use.
Airplane Precautions
Contact your airline if you want to use the Notebook PC on the airplane. Most airlines will have
restrictions for using electronic devices. Most airlines will allow electronic use only between and not
during takeoffs and landings.
Transportation Precautions
To prepare the Notebook PC for transport, you should turn it OFF and disconnect all external pe-
ripherals to prevent damage to the connectors. The hard disk drive’s head retracts when the power
is turned OFF to prevent scratching of the hard disk surface during transport. Therefore, you should
not transport the Notebook PC while the power is still ON. Close the display panel and check that it is
latched securely in the closed position to protect the keyboard and display panel.
CAUTION! The Notebook PC’s surface is easily dulled if not properly cared for. Be
careful not to rub or scrape the Notebook PC surfaces.
Cover Your Notebook PC
Purchase a carrying bag to protect the Notebook PC from dirt, water, shock, and scratches.

9
Introducing the Notebook PC 1
Preparing your Notebook PC
These are only quick instructions for using your Notebook PC. Read the later pages for detailed infor-
mation on using your Notebook PC.
1. Install the battery pack 2. Connect the AC Power Adapter
IMPORTANT! When opening, DO NOT
force the display panel down to the table
or else the hinges may break! Never lift
the Notebook PC by the display panel!
-2
-1
3
2
1
-1
-1
2.0
MEGA
PIXLS
AF
3. Open the Display Panel 4. Turn ON the Notebook PC
The power switch turns ON and OFF the Note-
book PC or putting the Notebook PC into sleep
or hibernation modes. Actual behavior of the
power switch can be customized in Windows
Control Panel > Power Options > System Set-
tings.
HDMI
1
2
3

10
1Introducing the Notebook PC

11
2. Knowing the Parts
Basic sides of the Notebook PC
Photos and icons in this manual are used for artistic purposes only and do not
show what is actually used in the product itself.
There may be differences between your Notebook PC and the drawings shown in
this manual. Please accept your Notebook PC as being correct.

12
2Knowing the Parts
3
5
4
6
8
7
10
1
2
11
9
Top Side
Refer to the illustration below to identify the components on this side of the Notebook PC.
The keyboard differs for each territory.

13
Knowing the Parts 2
Display Panel
The display panel functions the same as a desktop monitor. The Notebook PC uses an
active matrix TFT LCD, which provides excellent viewing like that of desktop monitors.
Unlike desktop monitors, the LCD panel does not produce any radiation or ickering, so it
is easier on the eyes. Use a soft cloth without chemical liquids (use plain water if necessary)
to clean the display panel.
Status Indicators (top)
Status indicators represent various hardware/software conditions. See indicator details in section 3.
Instant Keys (touch sensitive)
Instant keys allow you to launch frequently used applications with one push of a button.
Details are described in section 3.
Camera (on selected models)
The built-in camera allows picture taking or video recording. Can be used with video confer-
encing and other interactive applications.
2
3
4
5
6
7
1
8
Power Switch
The power switch turns ON and OFF the Notebook PC or putting the Notebook PC into
sleep or hibernation modes. Actual behavior of the power switch can be customized in
Windows Control Panel “Power Options.”
Express Gate Key
Pressing this button will launch Express Gate. Refer to the Express Gate User’s Manual
for details.
Array Microphone (on selected models)
The built-in array microphone is more clear and echo-free compared with traditional single micro-
phones and can be used for video conferencing, voice narrations, audio recordings, and multimedia
applications.
Keyboard
The keyboard provides full-sized keys with comfortable travel (depth at which the keys
can be depressed) and palm rest for both hands. Two Windows function keys are provided
to help ease navigation in the Windows operating system.

14
2Knowing the Parts
Touchpad and Buttons
The touchpad with its buttons is a pointing device that provides the same functions as a
desktop mouse. A software-controlled scrolling function is available after setting up the
included touchpad utility to allow easy Windows or web navigation.
9
10
Fingerprint Scanner (on selected models)
The ngerprint scanner allows use of security software using your ngerprint as your
identication key.
11
Multimedia Control Panel
The multimedia control panel allows for convenient controlling of the multimedia applica-
tion.

15
Knowing the Parts 2
Bottom Side
Refer to the illustration below to identify the components on this side of the Notebook PC.
-2 -1
1 2
5
3
4
67
WARNING! The bottom of the Notebook PC can get very hot. Be careful when han-
dling the Notebook PC while it is in operation or recently been in operation. High
temperatures are normal during charging or operation. Do not use on soft surfaces
such as beds or sofas which may block the vents. DO NOT PUT THE NOTEBOOK
PC ON YOUR LAP OR OTHER PARTS OF THE BODY TO AVOID INJURY FROM THE
HEAT.
The bottom side may vary in appearance depending on model.
The battery pack size varies depending on model.

16
2Knowing the Parts
1
2
3
4
Shutdown Button (Emergency)
In case your operating system cannot properly turn OFF or restart, the shutdown button can
be pressed with a straightened paper clip to shutdown the Notebook PC.
5
Central Processor Unit (CPU) Compartment
Some Notebook PC models feature a socketed-processor design to allow upgrading to faster
processors in the future. Some models feature a ULV design for compactness and may not
be upgraded. Visit an authorized service center or retailer for information on upgrades.
WARNING! End-user removal of the CPU or hard disk drive will void the warranty.
Memory (RAM) Compartment
The memory compartment provides expansion capabilities for additional memory. Additional
memory will increase application performance by decreasing hard disk access. The BIOS au-
tomatically detects the amount of memory in the system and congures accordingly. There is
no hardware or software (including BIOS) setup required after the memory is installed. Visit an
authorized service center or retailer for information on memory upgrades for your Notebook PC. Only purchase ex-
pansion modules from authorized retailers of this Notebook PC to ensure maximum compatibility and reliability.
Primary Hard Disk Drive Compartment
The hard disk drive is secured in a compartment. Visit an authorized service center or retailer for
information on hard disk drive upgrades for your Notebook PC. Only purchase hard disk drives
from authorized retailers of this Notebook PC to ensure maximum compatibility and reliability.
Battery Lock - Manual
The manual battery lock is used to keep the battery pack secured. Move the manual lock to the
unlocked position to insert or remove the battery pack. Move the manual lock to the locked posi-
tion after inserting the battery pack.
Audio Sub-Woofer (on selected models)
The built-in sub-woofer speaker allows you to enjoy amazing bass (low frequency)
sounds in your multimedia applications.
Secondary Hard Disk Drive Compartment (on selected models)
The hard disk drive is secured in a compartment. Visit an authorized service center or retailer for
information on hard disk drive upgrades for your Notebook PC. Only purchase hard disk drives
from authorized retailers of this Notebook PC to ensure maximum compatibility and reliability.
The secondary hard disk drive is optional. This hard disk drive bay may be empty or
contain an optional hard disk drive depending on your purchase.

17
Knowing the Parts 2
Battery Lock - Spring
The spring battery lock is used to keep the battery pack secured. When the battery pack is inserted, it will
automatically lock. To remove the battery pack, this spring lock must be held in the unlocked position.
Battery Pack
The battery pack is automatically charged when the Notebook PC is connected to an AC power
source and maintains power to the Notebook PC when AC power is not connected. This allows use
when moving temporarily between locations. Battery time varies by usage and by the specications
for this Notebook PC. The battery pack cannot be disassembled and must be purchased as a single
unit.
6
7

18
2Knowing the Parts
Left Side
Refer to the illustration below to identify the components on this side of the Notebook PC.
1 2 3 4 56
1
2
3
4
2.0
USB Port (2.0/1.1)
The USB (Universal Serial Bus) port is compatible with USB 2.0 or USB 1.1 devices such as
keyboards, pointing devices, cameras, hard disk drives, printers, and scanners connected in a
series up to 12Mbits/sec (USB 1.1) and 480Mbits/sec (USB 2.0). USB allows many devices to
run simultaneously on a single computer, with some peripherals acting as additional plug-in sites or
hubs. USB supports hot-swapping of devices so that most peripherals can be connected or disconnected
without restarting the computer.
Kensington®Lock Port
The Kensington®lock port allows the Notebook PC to be secured using Kensington®com-
patible Notebook PC security products. These security products usually include a metal
cable and lock that prevent the Notebook PC to be removed from a xed object.
Some may also include a motion detector to sound an alarm when moved.
SPDIF Output Jack
This jack provides connection to SPDIF (Sony/Philips Digital Interface) compliant de-
vices for digital audio output. Use this feature to turn the Notebook PC into a hi- home
entertainment system.
Headphone Output Jack
The stereo headphone jack (1/8 inch) is used to connect the Notebook PC’s audio out signal to
amplied speakers or headphones. Using this jack automatically disables the built-in speakers.
Combo
Microphone Input Jack
The mono microphone jack (1/8 inch) can be used to connect an external microphone or out-
put signals from audio devices. Using this jack automatically disables the built-in microphone.
Use this feature for video conferencing, voice narrations, or simple audio recordings.

19
Knowing the Parts 2
5
6
Air Vents
The air vents allow cool air to enter and warm air to exit the Notebook PC.
IMPORTANT! Make sure that paper, books, clothing, cables, or other ob-
jects do not block any of the air vents or else overheating may occur.
Air Vents
The air vents allow cool air to enter and warm air to exit the Notebook PC.
IMPORTANT! Make sure that paper, books, clothing, cables, or other ob-
jects do not block any of the air vents or else overheating may occur.

20
2Knowing the Parts
Right Side
Refer to the illustration below to identify the components on this side of the Notebook PC.
1 2 4 5 7 8 96 103 11
Optical Drive
The Notebook PC comes in various models with different optical drives. The Note-
book PC’s optical drive may support compact discs (CD) and/or digital video discs
(DVD) and may have recordable (R) or re-writable (RW) capabilities. See the market-
ing specications for details on each model.
Optical Drive Electronic Eject
The optical drive eject has an electronic eject button for opening the tray. You can also eject the optical
drive tray through any software player or by right clicking the optical drive in Windows “Computer”
and selecting Eject. This eject also functions as the optical drive activity indicator which shows when
data is being transferred by the optical disk drive. This indicator will light in proportion to the data
size transferred.
1
2
3
4
5
ExpressCard Slot
One 26pin Express card slot is available to support one ExpressCard/34mm or one
ExpressCard/54mm expansion card. This new interface is faster by using a serial bus
supporting USB 2.0 and PCI Express instead of the slower parallel bus used in the PC
card slot. (Not compatible with previous PCMCIA cards.)
Flash Memory Slot
Normally an external memory card reader must be purchased separately in order to use
memory cards from devices such as digital cameras, MP3 players, mobile phones, and PDAs.
This Notebook PC has a built-in high-speed memory card reader that can conveniently read
from and write to many ash memory cards as mentioned later in this manual.
Optical Drive Activity Indicator (location varies by model)
The optical drive activity indicator shows when data is being transferred by the optical disk drive.
This indicator will light in proportion to the data size transferred.
This manual suits for next models
2
Table of contents
Other Asus Laptop manuals

Asus
Asus Eee PC 701SD Series Mounting instructions

Asus
Asus Eee PC 8G Instruction manual

Asus
Asus Eee PC 1201N User manual

Asus
Asus S7F User manual

Asus
Asus Q502L Guide

Asus
Asus G series User manual

Asus
Asus VivoBook Max X541UV XX040T Guide

Asus
Asus Eee PC 1001PX User manual

Asus
Asus A9Rp User manual

Asus
Asus E10295 User manual
