Asus G75VW User manual

Notebook PC User Manual
January 2012
E7093

2 Notebook PC User Manual
Table of Contents
Table of Contents ............................................................................................... 2
Chapter 1: Introducing the Notebook PC
About This User’s Manual................................................................................ 6
Notes for This Manual ....................................................................................... 6
Safety Precautions ............................................................................................. 7
Preparing your Notebook PC.......................................................................11
Chapter 2: Knowing the parts
Top Side ...............................................................................................................14
Bottom Side........................................................................................................17
Right Side............................................................................................................20
Left Side...............................................................................................................22
Rear Side..............................................................................................................24
Front Side............................................................................................................24
Chapter 3: Getting Started
Power System ....................................................................................................26
Using AC Power...............................................................................................26
Using Battery Power ......................................................................................28
Battery Care ......................................................................................................29
Powering ON the Notebook PC.................................................................30
The Power-On Self Test (POST) ..................................................................30
Checking Battery Power...............................................................................32
Charging the Battery Pack...........................................................................33
Power Options.................................................................................................34
Power Management Modes .......................................................................36
Sleep and Hibernate......................................................................................36
Thermal Power Control.................................................................................38
Special Keyboard Functions.........................................................................39
Hot Keys .............................................................................................................39
Microsoft Windows Keys..............................................................................41
Multimedia Control Keys (on selected models)...................................44
Switches and Status Indicators ...................................................................45
Switches.............................................................................................................45

Notebook PC User Manual 3
Status Indicators .............................................................................................46
Chapter 4: Using the Notebook PC
Pointing Device.................................................................................................50
Using the Touchpad.......................................................................................51
Touchpad Usage Illustrations.....................................................................52
Caring for the Touchpad ..............................................................................56
Automatic Touchpad Disabling.................................................................56
Storage Devices ................................................................................................58
Optical Drive ....................................................................................................58
Flash Memory Card Reader.........................................................................62
Hard Disk Drive................................................................................................63
Memory (RAM).................................................................................................66
Cleaning the Fan Filters..................................................................................68
Removing the Filters......................................................................................68
Connections.......................................................................................................69
Network Connection.....................................................................................69
Wireless LAN Connection ............................................................................71
Windows Wireless Network Connection................................................73
Bluetooth Wireless Connection(on selected models).......................75
Appendix
Optional Accessories.....................................................................................A-2
Optional Connections.................................................................................A-2
Operating System and Software...............................................................A-3
System BIOS Settings ..................................................................................A-4
Common Problems and Solutions ...................................................... A-10
Recovering Your Notebook PC ............................................................... A-16
Using Recovery Partition ....................................................................... A-16
Using Recovery DVD (on selected models)...................................... A-17
Creating a RAID Set .................................................................................... A-20
RAID definitions ......................................................................................... A-20
Setting the RAID item in BIOS............................................................... A-20
Creating the RAID volume...................................................................... A-21
Intel®Rapid Start Technology.................................................................. A-25

4 Notebook PC User Manual
DVD-ROM Drive Information .................................................................. A-33
Blu-ray ROM Drive Information(on selected models) .................... A-35
Internal Modem Compliancy .................................................................. A-36
Declarations and Safety Statements.................................................... A-40
Federal Communications Commission Statement........................ A-40
FCC Radio Frequency (RF) Exposure Caution Statement............ A-41
Declaration of Conformity(R&TTE directive 1999/5/EC).............. A-41
CE Marking................................................................................................... A-42
IC Radiation Exposure Statement for Canada ................................. A-42
Wireless Operation Channel for Different Domains...................... A-43
France Restricted Wireless Frequency Bands .................................. A-43
UL Safety Notices....................................................................................... A-45
Power Safety Requirement .................................................................... A-46
TV Tuner Notices........................................................................................ A-46
REACH ........................................................................................................ A-46
Nordic Lithium Cautions (for lithium-ion batteries)...................... A-47
Optical Drive Safety Information ......................................................... A-48
Laser Safety Information......................................................................... A-48
Service warning label............................................................................... A-48
CDRH Regulations ..................................................................................... A-48
Macrovision Corporation Product Notice......................................... A-49
Sound Pressure warning......................................................................... A-49
DC Fan warning.......................................................................................... A-49
Adapter Information................................................................................. A-49
CTR 21 Approval(for Notebook PC with built-in Modem) .......... A-50
European Union Eco-label...................................................................... A-52
ENERGY STAR complied product ......................................................... A-52
Global Environmental Regulation Compliance
and Declaration ......................................................................................... A-53
ASUS Recycling/Takeback Services..................................................... A-53
Copyright Information .............................................................................. A-54
Limitation of Liability................................................................................. A-55
Service and Support................................................................................... A-55

1
Chapter 1:
Introducing the
Notebook PC

6 Notebook PC User Manual
About This User’s Manual
You are reading the Notebook PC User’s Manual.This User’s Manual
provides information regarding the various components in the
Notebook PC and how to use them.The following are major sections
of this User’s Manual:
1. Introducing the Notebook PC
Introduces you to the Notebook PC and this User’s Manual.
2. Knowing the Parts
Gives you information on the Notebook PC’s components.
3. Getting Started
Gives you information on getting started with the Notebook PC.
4. Using the Notebook PC
Gives you information on using the Notebook PC’s components.
5. Appendix
Introduces you to optional accessories and gives additional
information.
The actual bundled operating system and applications differ by
models and territories.There may be differences between your
Notebook PC and the pictures shown in this manual. Please
accept your Notebook PC as being correct.
Notes for This Manual
A few notes and warnings are used throughout this guide, allowing
you to complete certain tasks safely and effectively.These notes have
different degrees of importance as follows:
WARNING! Important information that must be followed for safe
operation.
IMPORTANT! Vital information that must be followed to prevent
damage to data, components, or persons.
TIP: Tips for completing tasks.
NOTE: Information for special situations.

Notebook PC User Manual 7
Safety Precautions
The following safety precautions will increase the life of the
Notebook PC. Follow all precautions and instructions. Except as
described in this manual, refer all servicing to qualified personnel.
Battery safety warning:
DO NOT throw the
battery in fire. DO NOT
short circuit the contacts.
DO NOT disassemble the
battery.
DO NOT leave the
Notebook PC on your lap
or any part of the body
to prevent discomfort
or injury from heat
exposure.
DO NOT expose to dirty
or dusty environments.
DO NOT operate during a
gas leak.
DO NOT expose to
strong magnetic or
electrical fields.
DO NOT expose to or
use near liquids, rain,
or moisture. DO NOT
use the modem during
electrical storms.
DO NOT press or touch
the display panel. Do not
place together with small
items that may scratch or
enter the Notebook PC.
DO NOT place on
uneven or unstable work
surfaces. Seek servicing
if the casing has been
damaged.
DO NOT place or drop
objects on top and
do not shove any
foreign objects into the
Notebook PC.
Disconnect the AC power and remove the battery pack(s) before
cleaning.Wipe the Notebook PC using a clean cellulose sponge
or chamois cloth dampened with a solution of nonabrasive
detergent and a few drops of warm water and remove any extra
moisture with a dry cloth.

8 Notebook PC User Manual
SAFE TEMP:This
Notebook PC should
only be used in
environments with
ambient temperatures
between 5°C (41°F) and
35°C (95°F).
DO NOT carry or cover
a Notebook PC that
is powered ON with
any materials that will
reduce air circulation
such as a carrying bag.
DO NOT throw the Notebook PC in municipal waste.This
product has been designed to enable proper reuse of parts
and recycling.The symbol of the crossed out wheeled bin
indicates that the product (electrical, electronic equipment
and mercury-containing button cell battery) should not
be placed in municipal waste.Check local regulations for
disposal of electronic products.
DO NOT throw the battery in municipal waste.The symbol
of the crossed out wheeled bin indicates that the battery
should not be placed in municipal waste.
INPUT RATING: Refer to
the rating label on the
bottom of the Notebook
PC and be sure that your
power adapter complies
with the rating.
Incorrect installation
of battery may cause
explosion and damage
the Notebook PC.
DO NOT use damaged
power cords, accessories,
or other peripherals.
DO NOT use strong
solvents such as
thinners, benzene, or
other chemicals on or
near the surface.

Notebook PC User Manual 9
Transportation Precautions
To prepare the Notebook PC for transport, you should turn it OFF
and disconnect all external peripherals to prevent damage to
the connectors.The hard disk drive’s head retracts when the power
is turned OFF to prevent scratching of the hard disk surface during
transport.Therefore, you should not transport the Notebook PC
while the power is still ON. Close the display panel and check that
it is latched securely in the closed position to protect the keyboard
and display panel.
CAUTION! The Notebook PC’s surface is easily dulled if not
properly cared for. Be careful not to rub or scrape the Notebook
PC surfaces.
Sound Pressure warning
Excessive sound pressure from earphones or headphones can cause
hearing damage or loss. Adjustment of the volume control as well as
the equalizer to settings other than the center position may increase
the earphones or headphones output voltage and the sound
pressure level.
DC Fan warning
Please note that the DC fan is a moving part that may cause DANGER.
Ensure to keep your body from the moving fan blades.
Adapter Information
Input voltage: 100-240Vac
Input frequency: 50-60Hz
Rating output current: 9.5A (180W)/ 7.7A (150W)
Rating output voltage: 19Vdc or 19.5Vdc

10 Notebook PC User Manual
Covering Your Notebook PC
Purchase a carrying bag to protect the Notebook PC from dirt, water,
shock, and scratches.
Charging Your Batteries
If you intend to use battery power, be sure to fully charge your
battery pack and any optional battery packs before going on long
trips. Remember that the power adapter charges the battery pack as
long as it is plugged into the computer and an AC power source. Be
aware that it takes much longer to charge the battery pack when the
Notebook PC is in use.
Airplane Precautions
Contact your airline if you want to use the Notebook PC on the
airplane. Most airlines will have restrictions for using electronic
devices. Most airlines will allow electronic use only between and not
during takeoffs and landings.
CAUTION! There are three main types of airport security
devices: X-ray machines (used on items placed on conveyor
belts), magnetic detectors (used on people walking through
security checks), and magnetic wands (hand-held devices used
on people or individual items).You can send your Notebook
PC and diskettes through airport X-ray machines. However, it
is recommended that you do not send your Notebook PC or
diskettes through airport magnetic detectors or expose them to
magnetic wands.

Notebook PC User Manual 11
Preparing your Notebook PC
These are only quick instructions for using your Notebook PC.
Installing the Battery Pack
Connecting the Power Adapter
12
2
3
1
1
1. Align the pins of the battery pack to the notches of the battery
slot.
2. Close down the battery into the slot and press.The battery will
automatically click into place.
HDMI
HDMI
1
3
110V-220V
2

12 Notebook PC User Manual
Opening the LCD display panel
1. Carefully lift up the display panel with your thumb.
2. Slowly tilt the display panel forward or backward to a
comfortable viewing angle.
Turning on the Power
1. Push and release the power button located beneath the LCD
display panel.
2. Use [Fn]+[F5] or [Fn]+[F6] to adjust the LCD brightness.

2
Chapter 2:
Knowing the parts

14 Notebook PC User Manual
Top Side
The keyboard differs by territory.
esc
f1 f2 f3 f4 f5 f6 f7 f8 f9
f10
f11
f12
pause
prt sc
sysrq
delete
backspace
home
home
num lK
scr lK
pgup
pgup
pgdn
pgdn
enter
enter
shift
shift
ctrl
alt
ctrl fn alt
end
end
insert
delete
insert
break
7
8
9
4
56
1
2
0
3
tab
caps lock
1
2
3
5
8
9
7
6
4

Notebook PC User Manual 15
3D Vision IR port (on selected models)
The 3D Vision IR port transmits 3D Vision signals to the
3D glasses when you play a 3D video game or watch 3D
movies.
Camera
The built-in camera allows picture taking or video
recording. Can be used with video conferencing and other
interactive applications.
Microphone (Built-in)
The built-in mono microphone can be used for video
conferencing, voice narrations, or simple audio recordings.
Camera Indicator
The camera indicator shows when the built-in camera is in
use.
Display Panel
The display panel functions the same as a desktop monitor.
The Notebook PC uses an active matrix TFT LCD, which
provides excellent viewing like that of desktop monitors.
Unlike desktop monitors, the LCD panel does not produce
any radiation or flickering, so it is easier on the eyes. Use
a soft cloth without chemical liquids (use plain water if
necessary) to clean the display panel.
Power Switch
The power switch allows powering ON and OFF the
Notebook PC and recovering from suspend mode. Use the
switch once to turn ON and once to turn OFF the Notebook
PC.The power switch only works when the display panel is
opened.
1
2
3
4
5
6

16 Notebook PC User Manual
7
8
3D Mode Switch Key (on 3D models)
Toggles to activate the 3D mode function and again to
switch back to 2D mode.This function is only available
when playing a 3D video game or watching a 3D movie.
Power4Gear Key (on non-3D models)
Under the Windows OS, this key functions as the
Power4Gear Hybrid key.The key toggles power savings
between various power saving modes.The power saving
modes control many aspects of the Notebook PC to
maximize performance versus battery time. Applying or
removing the power adapter will automatically switch the
system between AC mode and battery mode.The selected
mode is shown on the display.
Keyboard
The keyboard provides full-sized keys with comfortable
travel (depth at which the keys can be depressed) and
palm rest for both hands.Two Windows function keys are
provided to help ease navigation in the Windows operating
system.
Touchpad and Buttons
The touchpad with its buttons is a pointing device that
provides the same functions as a desktop mouse. A
software-controlled scrolling function is available after
setting up the included touchpad utility to allow easy
Windows or web navigation.
9

Notebook PC User Manual 17
Bottom Side
The bottom side may vary in appearance depending on model.
The battery pack size varies depending on model.
WARNING! The bottom of the Notebook PC can get very hot. Be
careful when handling the Notebook PC while it is in operation
or recently been in operation.High temperatures are normal
during charging or operation. Do not use on soft surfaces such
as beds or sofas which may block the vents. Do not put the
Notebook PC on your lap or other parts of the body to avoid
injury from the heat.
123
3
4
5
6

18 Notebook PC User Manual
Battery Pack
The battery pack is automatically charged when the
Notebook PC is connected to an AC power source and
maintains power to the Notebook PC when AC power is
not connected.This allows use when moving temporarily
between locations. Battery time varies by usage and by
the specifications for this Notebook PC.The battery pack
cannot be disassembled and must be purchased as a single
unit.
Battery Lock - Spring
The spring battery lock is used to keep the battery
pack secured.When the battery pack is inserted, it will
automatically lock.To remove the battery pack, this spring
lock must be held in the unlocked position.
Cooling Fans
The coolings fans draw air into the Notebook PC to lower
the temperature generated from the system’s operation.
Subwoofer
The subwoofer speaker produces low-pitched audio
frequencies for fuller and richer bass sounds.Feel the
dramatic booming experience when playing PC games or
watching movies on your Notebook PC.
1
2
3
4

Notebook PC User Manual 19
Memory (RAM) Compartment
The memory compartment provides expansion capabilities
for additional memory. Additional memory will increase
application performance by decreasing hard disk access.
The BIOS automatically detects the amount of memory in
the system and configures CMOS accordingly during the
POST (Power-On-Self-Test) process.There is no hardware or
software (including BIOS) setup required after the memory
is installed.Visit an authorized service center or retailer for
information on memory upgrades for your Notebook PC.
Only purchase expansion modules from authorized retailers
of this Notebook PC to ensure maximum compatibility and
reliability.
Hard Disk Drive Compartment
The hard disk drive is secured in a compartment.Visit an
authorized service center or retailer for information on hard
disk drive upgrades for your Notebook PC. Only purchase
hard disk drives from authorized retailers of this Notebook
PC to ensure maximum compatibility and reliability.
5
6

20 Notebook PC User Manual
Right Side
HDMI
HDMI
123 4 5 6 7
1
2
USB Port (3.0)
The USB (Universal Serial Bus) port is compatible with USB 3.0,
2.0, or USB 1.1 devices such as keyboards, pointing devices,
cameras, hard disk drives, printers, and scanners connected
in a series up to 4.8Gbits/sec (USB 3.0), 480Mbits/sec (USB
2.0), and 12Mbits/sec (USB 1.1). USB allows many devices
to run simultaneously on a single computer, with some
peripherals acting as additional plug-in sites or hubs. USB
supports hot-swapping of devices so that most peripherals
can be connected or disconnected without restarting the
computer.
USB Charger+
Allows you to charge your mobile phones or digital audio
players while your Notebook PC is sleeping, hibernating or
shut down.
USB Port (3.0)
Mini DisplayPort/ Thunderbolt Port (varies by model)
This 20-pin connector is used either as a Mini DisplayPort
(mDP) or Thunderbolt port, depending on the model.The
mDP is a compact version of the DisplayPort digital audio-
visual interface that supports visual devices with VGA, DVI,
or HDMI.Thunderbolt is based on Mini DisplayPort with PCI
Express lanes included for driving any interconnect, such as
USB.
3
