Asus ZenBook UX333F User manual

E14772
Revised Edition V2 / September 2018
User Guide
E14772_UX333_433_533_UM_V2_16pages.indd 1 2018/8/30 �� 02:04:50

2
Notebook PC User Guide
NOTE: The keyboard's layout may vary per region or country. The top view may also
vary in appearance depending on the Notebook PC model.
Top View
Touchpad/
Touch numeric keypad
(13” and 14” model)
Camera/IR Camera
Array microphones
Display panel
Keyboard
Function key lock
indicator
Capital lock indicator
Power button
Power indicator
Fingerprint sensor
(on selected models)
13” model
E14772_UX333_433_533_UM_V2_16pages.indd 2 2018/8/30 �� 02:04:51

Notebook PC User Guide
3
Touchpad/
Touch numeric keypad
(13” and 14” model)
Camera/IR Camera
Array microphones
Display panel
Keyboard
Function key lock
indicator
Capital lock indicator
Power button
Power indicator
Fingerprint sensor
(on selected models)
14” model
E14772_UX333_433_533_UM_V2_16pages.indd 3 2018/8/30 �� 02:04:51

4
Notebook PC User Guide
Touchpad
Camera/IR Camera
Array microphones
Display panel
Numeric keypad
Function key lock
indicator
Capital lock indicator
Power button
Power indicator
Fingerprint sensor
(on selected models)
15” model
Keyboard
E14772_UX333_433_533_UM_V2_16pages.indd 4 2018/8/30 �� 02:04:52

Notebook PC User Guide
5
I/O ports and slots
Headphone/Headset/Microphone jack USB 3.1 Gen 1 port (supports up to
10Gbit/s)
USB 2.0 port USB 3.1 Gen 2 Type-C™ port
MicroSD card slot Memory card reader
Power (DC) input port USB 3.1 Gen 2 Type-C™/
DisplayPort combo port
HDMI port USB 3.1 Gen 1 port
13” and 14” model
15” model
E14772_UX333_433_533_UM_V2_16pages.indd 5 2018/8/30 �� 02:04:52

6
Notebook PC User Guide
Getting started
1. Charge your Notebook PC
A. Connect the DC power connector into your Notebook PC’s power (DC) input port.
B. Plug the AC power adapter into a 100V~240V power source.
2. Lift to open the display panel
3. Press the power button
NOTE: The power adapter may vary in appearance, depending on models and your
region.
Charge the Notebook PC
for 3 hours before using
it in battery mode for the
rst time.
IMPORTANT! Use only the bundled power adapter to charge the battery pack and
supply power to your Notebook PC.
E14772_UX333_433_533_UM_V2_16pages.indd 6 2018/8/30 �� 02:04:52

Notebook PC User Guide
7
WARNING!
The bottom of the Notebook PC can get warm to hot while in use or while charging the battery
pack. When working on your Notebook PC, do not place it on surfaces that can block the vents.
CAUTION!
• ThisNotebookPCshouldonlybeusedinenvironmentswithambienttemperaturesbetween
5°C (41°F) and 35°C (95°F).
• RefertotheratinglabelonthebottomofyourNotebookPCandensurethatyourpower
adapter complies with this rating.
• Thepoweradaptermaybecomewarmtohotwhileinuse.Donotcovertheadapterandkeep
it away from your body while it is connected to a power source.
IMPORTANT!
• EnsurethatyourNotebookPCisconnectedtoagroundedpoweradapterbeforeturningit
on for the rst time.
• WhenusingyourNotebookPConpoweradaptermode,thesocketoutletmustbeneartothe
unit and easily accessible.
• Locatetheinput/outputratinglabelonyourNotebookPCandensurethatitmatchesthe
input/output rating information on your power adapter. Some Notebook PC models may
have multiple rating output currents based on the available SKU.
• Poweradapterinformation:
 -Inputvoltage:100-240Vac
 -Inputfrequency:50-60Hz
 -Ratingoutputcurrent:13”/14”:2.37A(45W)/3.42A(65W)
15”:4.74A(90W)
 -Ratingoutputvoltage:19V
Safety notices for your Notebook PC
WARNING!
ReadthefollowingprecautionsforyourNotebookPC’sbattery:
• OnlyASUS-authorizedtechniciansshould
remove the battery inside the device
(for non-removable battery only).
• Thebatteryusedinthisdevicemaypresent
a risk of re or chemical burn if removed or
disassembled.
• Followthewarninglabelsforyourpersonal
safety.
• Riskofexplosionifbatteryisreplacedbyan
incorrect type.
• Donotdisposeofinre.
• Neverattempttoshort-circuityour
Notebook PC’s battery.
• Neverattempttodisassembleand
reassemble the battery
(for non-removable battery only).
• Discontinueusageifleakageisfound.
• Thisbatteryanditscomponentsmustbe
recycled or disposed of properly.
• Keepthebatteryandothersmall
components away from children.
E14772_UX333_433_533_UM_V2_16pages.indd 7 2018/8/30 �� 02:04:53

8
Notebook PC User Guide
Avis concernant les batteries remplaçables
• Labatteriedel’appareilpeutprésenterunrisqued’incendieoudebrûluresicelle-ciest
retiréeoudésassemblée.
• Labatterieetsescomposantsdoiventêtrerecyclésdefaçonappropriée.
Copyright Information
You acknowledge that all rights of this Manual remain with ASUS. Any and all rights, including without
limitation,intheManualorwebsite,areandshallremaintheexclusivepropertyofASUSand/orits
licensors. Nothing in this Manual intends to transfer any such rights, or to vest any such rights to you.
ASUSPROVIDESTHISMANUAL“ASIS”WITHOUTWARRANTYOFANYKIND.SPECIFICATIONSAND
INFORMATIONCONTAINEDINTHISMANUALAREFURNISHEDFORINFORMATIONALUSEONLY,AND
ARESUBJECTTOCHANGEATANYTIMEWITHOUTNOTICE,ANDSHOULDNOTBECONSTRUEDASA
COMMITMENTBYASUS.
Copyright © 2018 ASUSTeK COMPUTER INC. All Rights Reserved.
Limitation of Liability
Circumstances may arise where because of a default on ASUS’part or other liability, you are entitled to
recover damages from ASUS. In each such instance, regardless of the basis on which you are entitled to
claim damages from ASUS, ASUS is liable for no more than damages for bodily injury (including death)
and damage to real property and tangible personal property; or any other actual and direct damages
resulted from omission or failure of performing legal duties under this Warranty Statement, up to the
listed contract price of each product.
ASUS will only be responsible for or indemnify you for loss, damages or claims based in contract, tort or
infringement under this Warranty Statement.
ThislimitalsoappliestoASUS’suppliersanditsreseller.ItisthemaximumforwhichASUS,itssuppliers,
and your reseller are collectively responsible.
UNDERNOCIRCUMSTANCESISASUSLIABLEFORANYOFTHEFOLLOWING:(1)THIRD-PARTYCLAIMS
AGAINSTYOUFORDAMAGES;(2)LOSSOF,ORDAMAGETO,YOURRECORDSORDATA;OR(3)SPECIAL,
INCIDENTAL,ORINDIRECTDAMAGESORFORANYECONOMICCONSEQUENTIALDAMAGES(INCLUDING
LOSTPROFITSORSAVINGS),EVENIFASUS,ITSSUPPLIERSORYOURRESELLERISINFORMEDOFTHEIR
POSSIBILITY.
Service and Support
ForcompleteE-Manualversion,refertoourmulti-languagewebsiteat:
https://www.asus.com/support/
