Power on the modem, and then wait
about 2 minutes for it to restart.
2
Set Up the Network
1. Connect your device to the router wirelessly
or with an Ethernet cable.
New Password:
Let’s Get Started
Conrm Password:
http://tplinkwi.net
Method TWO: Via a Web Browser
2. Launch a web browser, and enter
http://tplinkwifi.net or http://192.168.0.1 in
the address bar. Create a password to log in.
3. Follow the step-by-step instructions to
set up the internet connection and
register for the TP-Link Cloud service.
Note: If the login window does not appear, please refer to Q1 of
Need Help in this guide.
Method ONE: Via TP-Link Tether App
1. Download the Tether app.
To enjoy a more complete service from TP-Link,
bind your TP-Link ID to the router.
Scan for Tether Tether
or
2. Open the Tether app and log in with your
TP-Link ID.
3. Tap the button in the Tether app and
select Wireless Router > Standard
Routers. Follow the steps to complete
the setup and connect to the internet.
Note: If you don’t have an account, create one first.
The default wireless network names (SSIDs) and password
are printed on the label at the bottom of the router.
Model: Archer AX3000
AX3000 Gigabit Wi-Fi Router
Wireless Password/PIN:XXXXXXXX
SSID:TP-Link_XXXX
SSID:TP-Link_XXXX_5G
2
Set up with videos:
Scan QR code or visit
https://www.tp-link.com/support/setup-video/#wi--routers
Choose Your Device Type
Gaming Router
Range Extender
Wireless Router
Connect the power adapter to
the router and turn it on.
3
Connect the Hardware
Note: If the 2.4 GHz LED and 5 GHz LED are off, press and hold the Wi-Fi button on the back for more than 2 seconds.
Both the LEDs should turn solid on.
Power
On
Internet
On
2.4 GHz
On
5 GHz
On
If your internet comes from an Ethernet outlet instead of a DSL / Cable / Satellite modem, connect the
router’s 2.5 Gbps WAN/LAN port to it, then follow steps 3 and 4 to complete the hardware connection.
*Image may dier from actual product.
• Unplug the power to turn o your modem, if any, and remove
the backup battery if it has one.
• Refer to Q5 of Need Help to place the router for optimal
Wi-Fi performance. Modem
Unplug the power
Verify that the hardware connection is correct by checking the following LEDs.
4
1
Internet
1
Connect the powered-off
modem to the router’s 2.5
Gbps WAN/LAN port with
an Ethernet cable.
Note: If you want to use the 1 Gbps WAN/LAN
port as the WAN port instead, please refer to
Q1 of Need Help? in this guide.

Q1. What should I do if I want to use 1 Gbps WAN/LAN port for
internet service?
• Connect to the 1 Gbps WAN/LAN port with an Ethernet cable.
During the quick network setup, select the 1 Gbps WAN/LAN port
as the Internet port. Or after the network setup, you can go to
Tools
> Internet Connection > Internet Port
(Tether app) or Internet >
Internet Port
(web management page) to change it.
Q2. What should I do if I can’t access the web management page?
• Reboot your router and try again.
• If the computer is set to a static IP, change its settings to obtain an
IP address automatically.
• Verify that http://tplinkwifi.net is correctly entered in the web
browser. Alternatively, enter http://192.168.0.1 or
http://192.168.1.1 in the web browser.
• Use another web browser and try again.
• Disable and enable the network adapter in use.
Q3. What should I do if I can’t access the internet?
• Power off your modem for about 5 minutes, then power it on and
check the internet. If your modem has more than one Ethernet
port, keep other ports unconnected.
• Check if the internet is working normally by connecting a computer
directly to the modem via an Ethernet cable. If it is not, contact your
internet service provider.
• L og in to the web management page, and go to the Network Map
page to check whether the internet IP address is valid or not. If it’s
valid, go to Advanced > Network > Internet, click Advanced Settings,
select Use the Following DNS Addresses, set the primary DNS to
8.8.8.8, and set the secondary DNS to 8.8.4.4. If it is not, check the
hardware connection or contact your internet service provider.
•
For cable modem users, log in to the web management page of the
router and go to Advanced > Network > Internet > MAC Clone.
Select Clone Current Device MAC and click SAVE. Then reboot
both the modem and the router.
Q4. What should I do if I forget my wireless password?
• If you have not changed the default wireless password, it can be
found on the label at the bottom of the router.
• Connect a computer directly to the router using an Ethernet cable.
Log in to the router’s web management page at http://tplinkwi.net,
and go to the Wireless page to retrieve or reset your wireless
password
.
Q5. How should I position my router for optimal Wi-Fi performance?
• Don’t place your router in a corner or in a closet.
• Avoid obstacles and high-powered appliances.
• Keep your router in a central location at a certain height.
• Keep the antennas vertical when the router is placed on a desktop.
Keep the antennas upright when the router is hanging on a wall.
Quality of Service (QoS)
Prioritize your bandwidth
needs to get a better
networking experience.
Parental Controls
Manage online time and block
inappropriate content to keep
families healthy online.
Network Protection
Detect cyber threats to keep
your privacy and connected
devices well protected.
Comprehensive Reports
Gain full statistics and insights
to help you know your home
network better.
TP-Link HomeShield premium security services keep your home
network safe with cutting-edge features for network.
Download the Tether app to enjoy HomeShield features.
For more details, visit https://www.tp-link.com/homeshield.
TP-Link HomeShield
USB Applications
With the USB port, it’s easy to share les and media with
multiple devices. Visit https://www.tp-link.com/app/usb to
learn more about the USB applications.
Local Storage Sharing: Share les from the USB drive with
devices on your home network
Media Server: Play media from the USB drive on your
computer and smart devices
Remote Access: Access the USB drive when you are away
from home
©2022 TP-Link 7106509766 REV1.0.0
Need Help?
Button Explanation
AX5400 Multi-Gigabit Wi-Fi 6 Router
Quick Installation Guide
LED Button: Press the button for 1 second to turn on or o the
LEDs of your router.
WPS Button: Press the button for 1 second, and immediately
press the WPS button on your client to start the WPS process.
Wi-Fi Button: Press and hold the button for more than 2
seconds to turn on or o the wireless function of your router.
Reset Button: Press and hold the button for about 6 seconds
until the Power LED blinks to reset the router to its factory
default settings.
For technical support, replacement services, user guides, and
other information, please visit https://www.tp-link.com/support.
· Keep the device away from water, re, humidity or hot environments.
· Do not attempt to disassemble, repair, or modify the device. If you need
service, please contact us.
· Do not use any other chargers than those recommended.
· Do not use damaged charger or USB cable to charge the device.
· Do not use the device where wireless devices are not allowed.
· Adapter shall be installed near the equipment and shall be easily accessible.
