BR-HD3 Wireless HDMI Kit
Supplementary Guide
ASUS BR-HD3 receiver
ASUS BR-HD3 transmitter
¤

BR-HD3 Wireless HDMI Kit Supplementary Guide
2
Setting up PS3 and XBox to 1080i output
Setting up PS3 to 1080i output
To set up PS3 to 1080i output:
1. UsinganHDMIcable,connectthePS3toahigh-denitionexternaldisplay.
2. Go to My PS3 > System Settings > Display > Video output settings > HDMI
> Customer, then choose 1080i or 720P.
3. Turn off the PS3.
4. ConnecttheHDMItransmittertothePS3andtheHDMIreceivertotheexternal
display.
5. Turn on all the devices.
Setting up XBox 360 to 1080i output
1. Using an HDMI cable, connect theXBox360toahigh-definitionexternal
display.
2. Go to My XBOX > System Settings > Console Settings > Display > HDTV
Settings, then choose 1080i or 720P.
3. TurnofftheXBox360.
4. Using the bundled HDMI cables, connect the HDMI transmittertotheXBox360
and the HDMI receivertotheexternaldisplay.
5. Turn on all the devices.
Before using the BR-HD3 Wireless HDMI Kit, ensure that yourPS3orXBox360’s screen
resolution is set to 1080i. Refer to the following sections for more details.

BR-HD3 Wireless HDMI Kit Supplementary Guide
3
Setting up your computer to 1080i output
Using Windows®utility
To use Windows utility:
1. Right-click anywhere on the Windows
desktop,andclick Screen resolution.
2. Click Advanced settings.
• Ensurethatyourcomputerisconnectedtoahigh-denitionexternaldisplayusingan
HDMI cable.
• BeforeusingtheBR-HD3WirelessHDMIKit,ensurethatyourcomputer’sscreen
resolution is set to 1080i. Refer to the following sections for more details.

BR-HD3 Wireless HDMI Kit Supplementary Guide
4
3. Click List All Modes.
4. Select 1920 by 1080, True
color (32 Bit), 30Hertz
(Interlaced).

BR-HD3 Wireless HDMI Kit Supplementary Guide
5
Using NVIDIA®utility
To use NVIDIA utility:
1. Launch the NVIDIA Control Panel. Select Video &Television.
2. Select Change the signal or HD format
3. Select 1080i HDTV signal format.
Using ATI®utility
To use ATI utility:
1. L a u n c h t h e ATi C o n t r o l
Center. Select Advanced.

BR-HD3 Wireless HDMI Kit Supplementary Guide
6
2. Click Graphics.
3. Select Desktop Properties.
4. From the Desktop area field,
select 1920 X 1080.
5. FromtheRefreshratedropdown
list, select 30i Hz.

BR-HD3 Wireless HDMI Kit Supplementary Guide
7
Troubleshooting
IR relay does not work.
1. Check the IR cable connection.
 a. The part of the IR Blaster with the Player side sticker on it must be
connected to the BR-HD3 transmitter.
Player Side
2. EnsurethattheIRReceiverandIRBlasterarenotplaceddirectlyfacingeach
other.
Placing the IR Receiver and IR Blaster directly facing each other results to an
innitesignalloop,whichcausestheIRrelayfunctiontofail.
 b. ThepartoftheIRReceiverwiththeTV sidestickeronitmustbeplaced
on the BR-HD3 receiver.
TV Side

BR-HD3 Wireless HDMI Kit Supplementary Guide
8
