ASUSTeK COMPUTER Galaxy mini 5 Installation instructions

Doc. No:
Date: 2008.9.23
Revision:
ASUSTeK
COMPUTER INC.
alaxy mini 5 Assembly &
Disassembly SOP
Page: rade:
Authorize
by
Review
by
Originator
by
Form No : D2-001-11 Rev.01
Rev.
Modification
Modify description Issue div. Originator
V101
English CSC
alaxy mini 5 Assembly & Disassembly
SOP

Doc. No:
ASUSTeK COMPUTER INC.
alaxy mini 5 Assembly &
Disassembly SOP
Date:
Rev.: Page:
1
Disassembly / Assembly Procedure
Introduction
This section describes how to disassemble PDA G 2. any of the integrated devices used in
this phone are vulnerable to damage. Ensure adequate static protection is in place when
handling, shipping, and servicing any internal components.
Recommended Tools
 Anti-Static at (Ground Cord included)
 Anti-Static Wrist Strap
 Torque Screw Driver (T5 type, torque is set to 1.2kg-cm)
 Tweezers
 Plastic blade

Doc. No:
ASUSTeK COMPUTER INC.
alaxy mini 5 Assembly &
Disassembly SOP
Date:
Rev.: Page:
2
Disassembly procedure
The following set of diagrams will demonstrate the correct sequence and action to disassemble P565.
 Step 1
Take the stylus away from the PDA PHONE.
 Step 2
Remove the battery case and take the battery away.
 Step 3
Pry the edges of the RF cover. Pay attention to the hooks in the cover. Then remove the RF cover
from the device.
Hooks
Hooks

Doc. No:
ASUSTeK COMPUTER INC.
alaxy mini 5 Assembly &
Disassembly SOP
Date:
Rev.: Page:
3
 Step 4
Remove the antenna rubber. And remove 4 screws on the middle case assy. Then remove the
middle case assy from the I/O side.
1
3
2
4

Doc. No:
ASUSTeK COMPUTER INC.
alaxy mini 5 Assembly &
Disassembly SOP
Date:
Rev.: Page:
4
 Step 5
Pry the speaker box by a plastic blade and then remove the speaker box. Pay attention to the
speaker net and the GS /GPS antenna on the middle case assy. Do not tear them up when removing
the speaker box.
1
2
Speaker Set
GPS/GS Antenna

Doc. No:
ASUSTeK COMPUTER INC.
alaxy mini 5 Assembly &
Disassembly SOP
Date:
Rev.: Page:
5
 Step 6
Carefully tear off the GS /GPS antenna on the middle case assy.
 Step 7
Disconnect the LCD panel FPC and keypad FPC from the main board.
 Step 8
Separate the main board from the top case assy. Release the main board from the hooks first.
Hooks

Doc. No:
ASUSTeK COMPUTER INC.
alaxy mini 5 Assembly &
Disassembly SOP
Date:
Rev.: Page:
6
 Step 9
Remove 2 screws on the SI board and then remove the SI board.
 Step 10
Separate the C OS camera module from the SI board. Then disassemble the camera rubbers.
2
1

Doc. No:
ASUSTeK COMPUTER INC.
alaxy mini 5 Assembly &
Disassembly SOP
Date:
Rev.: Page:
7
 Step11
Remove the speaker box rubber. Open the VGA camera connector and remove the VGA camera.
Then remove the IC rubber.

Doc. No:
ASUSTeK COMPUTER INC.
alaxy mini 5 Assembly &
Disassembly SOP
Date:
Rev.: Page:
8
 Step12
Open the touch lens FPC connector and remove the keypad FPC. Then remove the keypad.
 Step13
Release the LCD panel from the hooks and then remove the panel from the top case assy. Remove
the receiver from the top case assy.
Touch Lens FPC
Hooks

Doc. No:
ASUSTeK COMPUTER INC.
alaxy mini 5 Assembly &
Disassembly SOP
Date:
Rev.: Page:
9
