Atag Mx4211auu User manual

manual

MX4211AUU

MX4292AUU

MX4211AUU_A01-03208V_EN.indd 1

2009-12-25  1:01:19

MX4211AUU_A01-03208V_EN.indd 2 2009-12-25  1:01:19

Contents

Control Panel ............................................................4

OvenFeatures...........................................................5

Accessories..............................................................6

UsingThisManual........................................................7

ImportantSafetyInstructions................................................7

Installation and Connection.................................................11

SettingtheClock ........................................................12

Types of Heating.........................................................13

Using Oven Mode........................................................14

Setting Oven Mode .....................................................14

DualConvectionSetting.................................................16

CookingGuide ........................................................16

Convection + Top Heat Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

CookingGuide ........................................................17

ConventionalHeatSetting ...............................................18

CookingGuide ........................................................18

GrillSetting...........................................................19

CookingGuide ........................................................19

Grill Setting & Rotisserie.................................................20

Convection+BottomHeatSetting.........................................21

CookingGuide ........................................................21

Setting Cook Time........................................................22

Setting End Time.........................................................23

Cooking Time Reservation Function..........................................24

UsingAutoMenuMode ...................................................25

Setting Auto Menu Mode.................................................25

GuidetoAutoMenuSettings .............................................26

Using Speed Defrost Mode.................................................28

Setting Speed Defrost Mode..............................................28

GuidetoAutoSpeedDefrostSettings ......................................29

How a Microwave Oven Works..............................................30

Using Microwave Mode....................................................31

Setting Microwave Mode.................................................31

Guide to Microwave Power Levels .........................................32

MicrowaveCookwareGuide .............................................33

Microwave Cooking Guide ...............................................35

SwitchingOfftheBeeper..................................................40

Combi-functions.........................................................41

Select hot air circulation + microwave function................................41

Select grill + microwave function...........................................42

ChildSafetyLock........................................................43

Using the Steam Clean Feature .............................................44

CleaningYourMicrowaveOven.............................................45

Storing and Repairing Your Microwave Oven...................................45

Troubleshooting .........................................................46

Error Codes.............................................................47

Technical Specications ...................................................48

MX4211AUU_A01-03208V_EN.indd 3 2009-12-25  1:01:19

268

318145712

910111314151617

1. OFF

2. AUTO MENU MODE

3. OVEN MODE

4. SPEED DEFROST MODE

5. MICROWAVE MODE

6. MODE SELECTOR

7. HOTAIR CIRCULATION +

MICROWAVE

8. GRILL + MICROWAVE

9. STEAM CLEAN

10. CLOCK

11. COOK TIME

12. DISPLAY

13. END TIME

14. TEMPERATURE

15. WEIGHT/MICROWAVE POWER

16. MULTI-FUNCTION SELECTOR

17. STOP / CANCEL

18. START

Control Panel

MX4211AUU_A01-03208V_EN.indd 4 2009-12-25  1:01:20

Note

●Shelf levels are numbered from the bottom up.

●The levels 4 and 5 are mainly used for grill function.

●The microwave level is mainly used for microwave function, in combination with

the ceramic tray.

●Please refer to Cooking Guides provided throughout this booklet to determine

appropriate shelf level for your dishes.

Oven Features

Control Panel

Top Heating

Elements

Level 5

Level 4

Level 3

Level 2

Oven

Levels

Microwave Level 1

Safety Door

Lock

Oven Light

Door

Door Handle

MX4211AUU_A01-03208V_EN.indd 5 2009-12-25  1:01:21

The following accessories are provided with your microwave oven:

Ceramic Tray

(Useful for Microwave Mode) Two Baking Trays

(DO NOT use for Microwave Mode.)

Ceramic Tray

Grill insert

Grill Insert for Ceramic Tray

(Useful for Speed Menu and Grill

Mode)

Oven Rack

(DO NOT use for Microwave Mode.)

Rotisserie

Note

Please refer to Cooking Guides provided throughout this booklet to determine appropriate

accessory for your dishes.

1 2

Accessories

MX4211AUU_A01-03208V_EN.indd 6 2009-12-25  1:01:21

Using This Manual

Thank you for purchasing a ATAG speed cook oven.

Your Owner’s Manual contains important safety instructions and essential

information on using and caring for your new speed cook oven.

Before using your oven, please read all the information in this manual and keep

it for future reference.

Important Safety Instructions

PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE

MICROWAVE

Failure to observe the following safety precautions may result in harmful exposure to

microwave energy.

(a) Under no circumstances should any attempt be made to operate the oven with the door

open or to tamper with the safety interlocks (door latches) or to insert anything into the

safety interlock holes.

(b) Do not place any object between the oven door and front face, or allow food or cleaner

residues to accumulate on sealing surfaces. Ensure that the door and door sealing

surfaces are kept clean by wiping after use with rst a damp cloth and nally with a soft

dry cloth.

wave service technician trained by the manufacturer. It is particularly important that the

oven door closes properly and that there is no damage to the:

(1) door, door seals and sealing surfaces,

(2) door hinges (broken or loose), or

(3) power cable.

(d) The oven should not be adjusted or repaired by anyone other than a properly qualied

microwave service technician trained by the manufacturer.

MX4211AUU_A01-03208V_EN.indd 7 2009-12-25  1:01:21

Important Safety Instructions (Continued)

Read carefully and keep for future reference.

Before cooking food or liquids in your oven, please check that the following

safety precautions are taken.

1. DO NOT use any metallic cookware when using microwave function:

●Metallic containers

●Dinnerware with gold or silver trimmings

●Skewers, forks, etc.

Reason Electric arcing or sparking may occur and may damage the oven.

2. DO NOT heat:

●Airtight or vacuum-sealed bottles, jars, containers. Ex) Baby food jars

●Airtight food. Ex) Eggs, nuts in shells, tomatoes

Reason The increase in pressure may cause them to explode.

Tip Remove lids and pierce skins, bags, etc.

3. DO NOT operate the microwave function when it is empty.

Reason The oven walls may be damaged.

Tip Leave a glass of water inside the oven at all times. The water will absorb

the microwaves if you accidentally set the oven going when it is empty.

4. DO NOT cover the rear ventilation slots with cloths or paper.

Reason The cloths or paper may catch re as hot air is evacuated from the oven.

5. ALWAYS use oven gloves when removing a dish from the oven.

Reason Some dishes absorb microwaves and heat is always transferred from the

food to the dish. The dishes are therefore hot.

6. DO NOT touch heating elements or interior oven walls.

Reason These walls may be hot enough to burn skin even after cooking is

nished, oven though they do not appear to be so. Keep away from

hot spot. Do not allow inammable materials to come into contact

with any interior area of the oven. Let the oven cool down rst.

7. To reduce the risk of re in the oven cavity

● Do not store ammable materials in the oven

●Remove wire twist ties from paper or plastic bags

●Do not use your microwave oven to dry newspapers

●If smoke is observed, keep the oven door closed and switch off or disconnect the

oven from the power supply.

MX4211AUU_A01-03208V_EN.indd 8 2009-12-25  1:01:22

8. Take particular care when heating liquids and baby foods using microwaves function.

●ALWAYS allow a standing time of at least 20 seconds after the oven has been

switched off to allow the temperature to equalize.

●Stir during heating if necessary and ALWAYS stir after heating.

●To prevent eruptive boiling and possible scalding, you should stir before, during,

and after heating.

● NEVER ll the container to the top and choose a container that is wider at the top

than at the bottom to prevent the liquid from boiling over. Bottles with narrow neck

may also explode if overheated.

●ALWAYS check the temperature of baby food or milk before giving it to the baby.

●NEVER heat a baby’s bottle with the teat on, as the bottle may explode if overheated.

●During microwave heating of beverages, there is the possibility of delayed eruptive

boiling, therefore care has to be taken when handling the container.

9. Be careful not to damage the power cable.

●Do not immerse power cable or plug in water and keep power cable away from

heated surfaces.

●Do not operate this appliance if it has a damaged power cable or plug.

10. Keep the inside of the oven clean.

●Clean the inside of the oven right after each use with a mild detergent solution,

but let the microwave oven cool down before cleaning in order to avoid injury.

Reason Food particles or spattered oils stuck to oven walls or oor can cause damage

to the ceramic nish and reduce the efciency of the oven.

11. “Clicking” sound might be noticed while operating, especially in defrosting mode.

Reason When the power output is changing electrically, you may hear that sound.

This is normal.

12. If the microwave mode is operating without any load, the power will cut off automatically

for safety. After standing for over 30 min, you can operate the oven normally.

● Do not worry if the oven continues to work after cooking has nished.

Reason This product is designed to run the cooling fan for 5 minutes after the cooking

has nished to cool down internal electronic parts. When cooking has nished,

the oven will beep and ash “0” four times. The oven will then beep one time

per minute.

Important Safety Instructions (Continued)

MX4211AUU_A01-03208V_EN.indd 9 2009-12-25  1:01:22

IMPORTANT SAFETY INSTRUCTIONS

During cooking, you should look into the oven from time to time when food is being

heated or cooked in disposable containers made of plastic, paper or other combustible

materials.

IMPORTANT

Young children should NEVER be allowed to use or play with the microwave oven. Nor should

they be left unattended near the microwave oven when it is in use. Items of interest to children

should not be stored or hidden just above the oven.

WARNING

If the door or door seals are damaged, the oven must not be operated until it has been

repaired by a competent person.

WARNING

It is hazardous for anyone other than a competent person to carry out any service or

repair operation which involves the removal of a cover which gives protection against

exposure to microwave energy.

WARNING

Liquids and other foods must not be heated in sealed containers since they are liable

to explode.

WARNING

Only allow children to use the oven without supervision when adequate instructions

have been given so that the child is able to use the oven in a safe way and understands the

hazards of improper use.

WARNING

When heating food in plastic or paper containers, keep an eye on the oven due to the

possibility of ignition;

WARNING

Ensure that the appliance is switched off before replacing the lamp to avoid the possibility of

electric shock.

Please recycle or dispose of the packaging material for this product in an environmentally

responsible manner.

Please contact your local authorities in regard to the enviromentally safe disposal of this

product.

Important Safety Instructions (Continued)

MX4211AUU_A01-03208V_EN.indd 10 2009-12-25  1:01:22

●This appliance is NOT intended for use in a commercial environment.

●Please observe the installation instructions provided and note that this appliance should

only be installed by a qualied technician.

● The appliance is tted with a plug and must only be connected to a properly installed

earthed socket. The fuse protection must be rated at 16 amps (L or B-type miniature circuit

breakers).

●In case a new socket is needed, installation and cable connection must only be done by a

qualied electrician. If the plug is no longer accessible following installation, a pole discon-

necting device must be present on the installation site with a contact gap of at least 3 mm.

●Adapters, multiway strips and extension cords must not be used. Overloading can result in

re.

●Plug in

When the appliance has been connected for the rst time, all segments are lit for a second.

After 3 seconds, 12:00 ashes in the display prompting you to select the clock. Do not

forget to reset the clock when you switch to and from summer or winter.

Installation and Connection

MX4211AUU_A01-03208V_EN.indd 11 2009-12-25  1:01:22

When the appliance is rst plugged in, the DISPLAY lights up. After three sec-

onds, the Clock symbol and “12:00” blink on the DISPLAY.

Setting the Clock

Press CLOCK . The “12” starts

blinking. Turn MULTI-FUNCTION SELECTOR

to set hour.

Press CLOCK again. The “00” starts

blinking. Turn MULTI-FUNCTION SELECTOR

to set minute.

Press CLOCK again. The clock sets

by itself within 5 seconds.

1 2

3 4

Setting the Clock

MX4211AUU_A01-03208V_EN.indd 12 2009-12-25  1:01:36

The following chart summarizes the various heating modes and settings avail-

able on your oven. Use the Cooking Guides in the pages that follow to determine

the appropriate mode and setting for all your recipes.

OVEN MODE

Dual Convection Setting

Food is heated by hot air from the left and right sides of the oven. This

setting provides uniform heating and is ideal for baking.

Convection + Top Heat Setting

Hot air and top heating element combine, making this setting ideal for

crisping and browning. Especially recommended for meats.

Conventional Heat Setting

Heat comes from top and bottom heating elements. This setting is

suitable for baking and roasting.

Grill Setting & Rotisserie

Food is heated by the top heating element. The rotisserie motor is

activated during grilling, to enable the use of the rotisserie. This function

can also be used without using the rotisserie.

Convection + Bottom Heat Setting

Hot air and the bottom heating element combine so food can be crisped

and browned.

AUTO MENU MODE

Choose from twelve pre-programmed speed menu settings to

conveniently cook, roast or bake your favorite foods. Cooking time and

power level are automatically set. Simply select the programme and

weight to start cooking.

SPEED DEFROST MODE

Choose from ve pre-programmed speed defrost settings for defrosting.

Defrosting time and power level are automatically set. Simply select the

programme and weight to start defrosting.

MICROWAVE MODE

Microwave energy is used to cook and defrost foods. It provides fast ef-

cient cooking without changing the colour or form of food. Power level

and cooking time are manually set to suit various dishes.

Types of Heating

MX4211AUU_A01-03208V_EN.indd 13 2009-12-25  1:01:38

Using Oven Mode

Five settings are available under this mode. Check Cooking Guides on pages

16 - 21 to determine appropriate setting.

Setting Oven Mode

Turn MODE SELECTOR Dial to oven

mode position. Turn MULTI-FUNCTION SELECTOR

Dial to desired oven mode. The oven

mode and recommended temperature

will be displayed .

Dual Convection

Convection + Top Heat

Conventional Heat

Grill

Convection + Bottom Heat

1 2

Types of Heating (Continued)

COMBI-FUNCTIONS

HOTAIR CIRCULATION + MICROWAVE

This functions is suitable for baking fruit tarts, bread or dishes au gratin (dishes

which normally require a longer cooking time).

GRILL + MICROWAVE

This function is suitable for roasting or baking larger cuts of meat, half a large

chicken or a whole small chicken, whole sh and dishes au gratin.

MX4211AUU_A01-03208V_EN.indd 14 2009-12-25  1:01:42

Using Oven Mode (Continued)

Press START.

►The ‘°C’ icon on display will blink

and it will be lit after the tempera-

ture is reached.

Note

1) During cooking, COOK TIME and TEMPERATURE are available to change the setting.

2) In Oven Mode settings, the convection heater and top and bottom heating elements switch

off and on throughout cooking to regulate the temperature.

3) During cooking, the inside temperature is displayed by pressing TEMPERATURE and

WEIGHT/MICROWAVE POWER at the same time.

To set cooking time, press COOK

TIME and turn MULTI-FUNCTION

SELECTOR to set desired cooking

time.

To change temperature, press

TEMPERATURE and turn MULTI-

FUNCTION SELECTOR to set

desired temperature.

3 4

Note

The convection heater and grill heater switch on and off constantly to regulate the tempera-

ture.

MX4211AUU_A01-03208V_EN.indd 15 2009-12-25  1:01:46

Dual Convection Setting

Food is heated by hot air from the left and right sides of the oven. This setting

provides uniform heating and is ideal for baking.

When you cook on two baking trays at the

same time, place the trays on level 2, and

level 4.

*Please ensure that glass baking dishes are suitable for 40 - 250 °C cooking temperatures.

Cooking Guide

Use temperatures and times in this table as guidelines for baking.

We recommend to preheat the oven with dual convection mode.

Food Item Shelf Level Temperature (°C) Accessory Time (h)

Hazelnut Cake

Square Mould 2 160 - 170 Oven rack 1:00 - 1:10

Lemon Cake

Ring-Shaped or

Bowl Mould 2 150 - 160 Oven rack 0:50 - 1:00

Sponge Cake 3 150 - 160 Oven rack 0:35 - 0:45

Fruit Flan Base 3 150 - 170 Oven rack 0:25 - 0:35

Flat Streusel Fruit

Cake (Yeast Dough) 3 150 - 170 Baking tray 0:30 - 0:40

Croissants 3 170 - 180 Baking tray 0:10 - 0:15

Bread Rolls 2 180 - 190 Baking tray 0:10 - 0:15

Cookies 3 / 4 160 - 180 Two baking trays 0:10 - 0:20

Using Oven Mode (Continued)

MX4211AUU_A01-03208V_EN.indd 16 2009-12-25  1:01:47

Convection + Top Heat Setting

Hot air and top heating element combine, making this setting ideal for crisping

and browning. This setting is especially recommended for cooking meats.

When cooking meat, place on rack on Level 3

and set baking tray on Level 1 to catch drip-

pings.

*Please ensure that glass baking dishes are suitable for 40 - 250 °C cooking temperatures.

Cooking Guide

Use temperatures and times in this table as guidelines for roasting.

We recommend to preheat the oven using Convection + Top Heat mode.

Put meat on oven rack, follow shelf level advice in the table and use baking tray as oil

pan on level 1.

Food Item Shelf Level Temperature

(°C) Accessory Time (h)

Beef Roast Beef /

1 kg Medium 3 / 1 170 - 190 Oven rack /

Baking tray 1:00 - 1:30

Pork Shoulder Joint /

Roll 1 kg 3 / 1 180 - 200 Oven rack /

Baking tray 1:30 - 2:00

Lamb Roast Lamb /

Leg of Lamb 0.8 kg 2 / 1 190 - 210 Oven rack /

Baking tray 0:50 - 1:20

Chicken Whole

Chicken 1.0 kg 3 / 1 170 - 190 Oven rack /

Baking tray 0:50 - 1:10

Fish Whole Trouts

2 pcs / 0.5 kg 4 / 1 170 - 180 Oven rack /

Baking tray 0:30 - 0:40

Duck Breast 0.3 kg 4 / 1 180 - 200 Oven rack /

Baking tray 0:25 - 0:35

Note

Preheating is recommended.

Using Oven Mode (Continued)

MX4211AUU_A01-03208V_EN.indd 17 2009-12-25  1:01:48

Conventional Heat Setting

Heat comes from top and bottom heating elements. This setting is suitable for

baking and roasting.

Baking tray or oven rack is usually placed on

Level 3.

*Please ensure that glass baking dishes are suitable for 40 - 250 °C cooking temperatures.

Cooking Guide

Use temperatures and times in this table as guidelines for baking. We recommend to preheat

the oven with Conventional Heat mode.

Food Item Shelf Level Temperature (°C) Accessory Time (h)

Lasagne 3 200 - 220 Oven rack 0:25 - 00:35

Vegetables Gratin 3 180 - 200 Oven rack 0:20 - 00:30

Potato Gratin 3 180 - 200 Oven rack 0:25 - 00:35

Frozen Pizza

Baguettes 3 160 - 180 Baking tray 0:10 - 00:15

Oven Chips 3 200 - 220 Baking tray 0:15 - 00:20

Marble Cake 3 180 - 200 Oven rack 0:50 - 1:10

Mufns 3 180 - 200 Oven rack 0:10 - 00:15

Cookies 4 180 - 200 Baking tray 0:08 - 00:15

Using Oven Mode (Continued)

MX4211AUU_A01-03208V_EN.indd 18 2009-12-25  1:01:48

Grill Setting

Food is heated by the top heating elements.

For grilling, ceramic tray with grill insert is

usually placed on Level 4.

Cooking Guide

Use temperatures and times in this table as guidelines for grilling. Set 220 °C grill temperature,

preheat for 3 minutes.

Food Item Shelf Level Time (Min) 1st

side Time (Min)

2nd side Accessory

Kebab Spits 4 8 - 10 6 - 8 Grill insert with

ceramic tray

Pork Steaks 4 7 - 9 5 - 7 Grill insert with

ceramic tray

Sausages 4 4 - 6 3 - 5 Baking tray

Chicken Pieces 4 10 - 15 8 - 10 Grill insert with

ceramic tray

Salmon Steaks 4 8 - 12 6 - 10 Grill insert with

ceramic tray

Sliced Vegetables 5 5 - 7 3 - 5 Baking tray

Toast 5 2 - 3 1 - 2 Oven rack

Cheese Toasts 5 4 - 5 - Oven rack

Using Oven Mode (Continued)

MX4211AUU_A01-03208V_EN.indd 19 2009-12-25  1:01:48

Grill Setting & Rotisserie

Food is heated by the top heating elements.

For grilling with the rotisserie, the rotisserie

holder is placed on level 5. The rotisserie is

placed in the holder, the central spit must be

inserted in the slot in the back of the oven. The

rotisserie can be used with 6 small spits, as

shown in the illustration. For bigger pieces of

meat, remove the 6 small spits and the discs,

and use only the big central spit.

The 6 small spits turn automatically during grill-

ing. Make sure the rotisserie is positioned right

by visually checking it rotates correctly for the

rst minute of operation.

The rotisserie set contains a handle, which

can be screwed into the central spit for easier

handling. Remove the handle before closing

the oven door.

Note

Recommended temperature for grilling is 220 °C.

Preheating for three minutes is recommended.

Using Oven Mode (Continued)

MX4211AUU_A01-03208V_EN.indd 20 2009-12-25  1:01:49

This manual suits for next models

Table of contents

Popular Oven manuals by other brands

Bosch

Bosch HBN311.1J instruction manual

Beko

Beko BBIS13300DXPSE-1 user manual

ikitchening

ikitchening YKZ-5D user manual

Smeg

Smeg LEV135X LEV 135X Mode d'emploi

Frigidaire

Frigidaire FEB789WC Factory parts catalog

Kernau

Kernau KBOS 641 B G user manual

Acunto Mario

Acunto Mario Classico 2 Installation, use and maintenance

Samsung

Samsung BQ1D6T144 user manual

SCHOLTES

SCHOLTES FNG 66 operating instructions

Zigmund & Shtain

Zigmund & Shtain EN 118.511 S user manual

Zanussi

Zanussi ZBF 260 Instruction booklet

Frigidaire

Frigidaire FEB30S7FCB Service data sheet

Diamond

Diamond DFV-411/S INSTRUCTIONS FOR THE INSTALLATION, USE AND MAINTENANCE

NEFF

NEFF B48FT78 1B Series instruction manual

EarthStone

EarthStone 110 Modular installation instructions

eka

eka MKF 464 BM Installation and maintenance manual

Johnson

Johnson F60 Instructions for use

KitchenAid

KitchenAid KEBC167MSS - Architect Series 36'' Single Electric Wall... Dimensions

Atag MX4211AUU User manual

Popular Oven manuals by other brands
