ATAGO PAL-pH User manual

Important: Please Read and Follow Instructions Carefully Before Initial Use
Place plenty of tap water and leave it for a while.
※Dry electrodes will result in abnormal measurement values.
Press to set date, time,
and delete data history.
START button & CAL button
tap water
PAL-pH
Cat.No. 4321
Digital Hand-held "Pocket" pH Meter R
ATAGO instruments are rigorously inspected to ensure each unit meets the highest standards of quality assurance.
●Safety Instructions
Read and follow all safety instructions before operating the instrument. Failure to comply with the following instructions may
result in personal injury or property damage.
WARNING
◇Ensure safety when handling hazardous materials. Observe precautionary measures and use protective equipment, Be
aware of the hazards of such chemicals and emergency response guidelines.
◇ATAGO may not be held liable for any injury or damage arising in connection with handling of hazardous materials during
the use of the instrument.
◇Do not drop the instrument or subject it to strong physical shock.
◇Do not attempt to repair, modify, or disassemble the instrument.
Thank you for purchasing the instrument. Carefully read and follow all instructions. Keep this manual for future reference.
A small amount of solution may leak from the reference electrode. This is normal and does not affect the unit's performance.
〈International Protection Classification IP65〉
◇The instrument is water-resistant, not waterproof, and should not be submerged.
〈Chemical Resistance of Body Case〉
◇The body case is made of PBT. Do not expose it to water vapor or solvents.
◇Do not use metal tools, such as a spoon, as they may scratch
the glass electrode, resulting in erroneous measurements.
◇Do not measure organic solvents, adhesives, cement, alcohol
or hydrogen flouride.
◇Do not use water above 50℃ to rinse the instrument.
◇Only use the specified battery type. Observe proper polarities,
properly aligning the anodes and cathodes.
◇Store the instrument away from direct sunlight/heat sources
and excessive amounts of dust/debris.
◇Do not expose the instrument to a rapid change in ambient
temperature.
◇Do not subject the instrument to strong vibration.
◇Do not subject the instrument to extreme cold temperature.
◇Do not place the instrument under anything heavy.
◇Loosen the battery compartment cover for air transportation.
CAUTION
◇Carefully read this manual to have basic knowledge of
the function of each component.
◇ATAGO is not liable for any loss and damage caused by
the measurement and use of this instrument.
◇ATAGO shall not be held responsible for any or all
damages that may result from using the instrument for
those other than its intended purpose (measurement of
pH level of a liquid sample).
◇If the standard solution for calibration comes in contact
with hands or skin, immediately rinse with plenty of
water.
◇The glass electrode is fragile; be careful not to damage
it. Glass shards may cause injury.
Measurement results and remaining
battery charge are displayed.
Press to perform calibration.
Reference electrode
Glass electrode
Sample stage
CAL button
Lanyard hole
LCD
START button (Power button)
Place and remove batteries from here.
Battery compartment
Apply samples on the electrode in
the center of the sample stage.
Press to take measurements and hold
down to turn off the display.
Instruction Manual
Parts
Contents
Introduction
⇑
Access now
4321-E02
In just - a - minute
1. It requires only 1 minute! Simply by answering questions, warranty period is extended from 1 year
to 2 years.
2. ATAGO Logger NFC can also be downloaded at the same time.
(The registration page can be accessed from ATAGO website.)
From 1year to2years Free Extended Warranty
Main unit…1 Instruction Manual (this book)…1 Calibration Report …1 AAA batteries…2
Standard solution for calibration……… pH4.01…1 pH6.86…1 pH9.18…1 PAL Silicone Cover…1
Calibration points -1-
Calibration can be done at 3 points (pH 4.01, pH 6.86, and pH 9.18).
If the sample is above pH 6.9, calibration can be done at 2 points (pH 6.86 and pH 9.18).
If the sample is less than pH 6.9, calibration can be done at 2 points (pH 4.01 and pH 6.86).
Press the CAL button to perform calibration for either pH 4.01, pH 6.86, or pH 9.18.
＊If the power is not turned on, press the START button to turn on the power, then perform the following procedure.
Calibration points -2-
Calibration can be done at 3 points (pH 4.01, pH 7.00, and pH 10.01).
If the sample is above pH 7.0, calibration can be done at 2 points (pH 7.00 and pH 10.01).
If the sample is less than pH 7.0, calibration can be done at 2 points (pH 4.01 and pH 7.00).
Press the CAL button to perform calibration for either pH 4.01, pH 7.00, or pH 10.01.
＊If the power is not turned on, press the START button to turn on the power, then perform the following procedure.
*Turning excessively may
cause malfunction.
Open Close
O
P
E
N
C
L
O
S
E
O
P
E
N
C
L
O
S
E
【Caution】
◇ Do not scratch the electrode.
◇ The instrument is water-resistant, not waterproof, and
should not be submerged.
CAL
Place plenty of tap water
and leave it for a while.
◇The insufficient amount of sample will result
in abnormal measurement or calibration.
O
P
E
N
C
L
O
S
E
O
P
E
N
C
L
O
S
E
At least 0.6mL.
１．Wipe off the sample. ２．Apply tap water. Wipe off the tap water.
（Remove the sample （Repeat several times.）
with a plastic pipette.）
１．Wipe off the sample. ２．Rinse with tap water. 3．Wipe off the tap water.
（Remove the sample
with a plastic pipette.）
Or
【Caution】
◇Perform calibration before initial use and at least once a month to maintain precision and accuracy.
◇Measure a standard calibration solution. When the measurement value falls outside of the expected range, perform
calibration.
◇When the time lapsed since last measurement is more than 2 weeks, it is recommended to calibrate the instrument.
◇If the ambient temperature changes during the daily work with this instrument, it needs the calibration again.
【Caution】
◇Do not splash water above 50℃. The plastic may warp, which may compromise the water resistance.
・When measuring hot samples, place only the necessary amount and do not let it overflow from the sample stage well.
・When hot water is necessary to clean off hardened samples, use water-soaked gauze around the sample stage and keep
hot water away from the body case.
◇In rare cases, a measurement value may be displayed even if there is not sample placed on the electrode section. In such
instances, simply place some sample on the electrode section and press the START button. Measurements will be taken normally.
◇When measuring samples such as strong acids and high alkaline, take a quick measurement and rinse off any remaining
sample with tap water.
<LCD Auto Shut-off>
The instrument will turn itself off after 5 minutes of inactivity. To manually turn it off, hold down the START button for more
than 2 seconds.
The following messages alert the user when an operation has failed.
L o
The battery is low.
Display will turn off after 10 seconds.
L L L
The sample measured is outside the
measurement range.
The START button was pressed with nothing
on the electrode section.
H H H
The sample measured is outside the
measurement range.
The START button was pressed with nothing
on the electrode section.
A A A
The CAL button was pressed with nothing
on the electrode section.
E E E
The START button was pressed with nothing
on the electrode section.
The detection temperature was over 45℃. A
pH value was displayed (accuracy is not
guaranteed).
The detection temperature was less than
5℃. A pH value was displayed (accuracy is
not guaranteed).
H H H
LLL
【Caution】
◇ Please remove the tape in the battery compartment before first use.
◇ Fasten the battery compartment cover tightly to prevent water ingress or poor connection,
which will cause erroneous measurements. Push the cover in firmly and turn.
◇ When the O-ring on the cover is dirty or damaged, the water resistance may be compromised.
◇ When the battery icon indicates the low power level ( ), replace both batteries with a
brand new set of AAA alkaline batteries (1.5V).
◇ Static images may occasionally appear on LCD. Such retained pixel charges do not indicate a
faulty display, consume the battery power, or affect the instrument’s performance in any way.
◇ Check the expiration dates on batteries before purchase.
◇Calibrate the instrument after the batteries are replaced.
O-ring
1. Insert a coin in the
groove on the battery
compartment cover. Turn
the coin counterclockwise
to remove the cover.
2. Insert batteries,
observing the correct
polarity.
3. Align the cover and push
it down.
4. Close the battery
compartment cover by
pushing the cover in with a
coin in the groove and
turning it clockwise until it
stops.
Groove
Measurement
Calibration
Replacing the Batteries
Cleaning
Error Messages
For samples containing oils or fats:
Clean oily residues on the electrode section with
ethyl alcohol. Then rinse the electrode section with
tap water throughly.
Ethyl
alcohol
3. After the
display flashes
"---",the
measurement
value is displayed.
2. Press the
START button.
＊If the power is not turned on, press the START button to turn on the power, then perform the following procedure.
Repeat until measurement
values are stabilized.
1. Place enough sample to
cover the entire electrode
section.
At least 0.6ｍL of sample
＜When measuring with higher precision＞
b. Place the sample so
as to cover the entire
electrode section again.
a. Wipe away the
sample.
At least 0.6ｍL of sample
Perform the following procedure (a) and
(b) before step 2.
At least 0.6mL of standard
solution for calibration.
1. Place enough
standard calibration
solution to cover the
entire electrode
section.
2. Press the
CAL button. 3.
After the display flashes "---",the
standard calibration solution value will
flash approx 10 times, then change to
a fixed display of the value.
Calibrate at another point.
Flash Light up
（The displayed value is an example.）
Calibration is complete
Perform the following procedure (a) and
(b) before step 2.
＜When performing more accurate calibration＞
b. Place the standard
solution for calibration so as
to cover the entire electrode
section again and leave it for
approx. 30 seconds.
a. Wipe away the
standard calibration
solution.
At least 0.6mL of standard
solution for calibration.
Calibration and Measurement Guidelines
◇When the electrodes are dry after long
period of not being used ◇Do not damage the electrodes.
Do not use metal tools.
◇ Be careful not to
scratch the electrodes.
Tap water
Additional refills of standard solutions for calibration can be purchased from ATAGO (sold separately).
Contact ATAGO for recommended standard solutions.
[Part No.] Standard solution for calibration
RE-99210 pH4.01 (volume: 500mL per bottle)
RE-99211 pH6.86 (volume: 500mL per bottle)
RE-99213 pH9.18 (volume: 500mL per bottle)
RE-99230 10mL pH4.01/pH6.86/pH9.18
[Part No.] Standard solution for calibration
RE-99210 pH4.01 (volume: 500mL per bottle)
RE-99212 pH7.00 (volume: 500mL per bottle)
RE-99214 pH10.01 (volume: 500mL per bottle)
10mL pH4.01/pH7.00/pH10.01
CAL CAL
-1- -1-
6.86
7.00
1. Press and hold the
CAL button for 5 seconds
(while the unit is powered on).
2. Press the START button to Select
a Calibration point.
3. Press the CAL button
to confirm the selection.
-2- End
4. Calibration.
Calibration points
-1-
4.01 6.86 9.18
Calibration points
-2-
4.01 7.00 10.01
Select the Calibration option, either 1 or 2, according to values of the standards.
Calibration point display
How to Select a Calibration Option
END display
Now you can
proceed to
Calibration.
◇ Initial measurements may fluctuate with hot or cold samples.
Wait for the instrument to acclimate to the sample
temperature, then press the START button. Alternatively,
press the START button multiple times until measurements
become stable.

About Data Transmission Function
:
:
:
2017/08/17 09:30:45,12.3,20.4
2017/08/17 09:30:50,12.3,20.4
2017/08/17 09:30:55,12.4,20.4
20.4
12.3
dEL
y_n
dEL
dEL
dEL
End
CAL CAL
CAL
0～9 0～9 0～9 0～901～12 0～3 00～23 0～5
20.4
12.3
dAt
End
CAL CAL CAL CAL CAL CAL CAL CAL CAL
This instrument stores maximum number of 100 measurement data. This instrument is equipped with NFC （Near
Field Communication）technology.
Data history can be accessed by bringing PAL-NFC to any Android devices, iPhone or PC-linked USB NFC
Reader/Writer* (in conformance to PC/SC specification).
* Operation tested with SONY USB NFC Reader
PaSoRi RC-S380.
【Caution】
Data history exceeding 100 will overwrite old activity with new data, replacing the oldest recorded information first.
(((● NFC
(((● NFC
2104K Printed in Japan
The instrument is warranted for one year from the date of purchase.
This warranty is void if the instrument shows evidence of the following. Send the included batteries as well if they are still in
use.
・Having been disassembled by unauthorized personnel
・Damages to the electrode section
・Water damage or having been dropped
・Having been misused and/or operated outside the environmental specifications
・Leakage from batteries other than those included with the unit
Repair services are available for a fee after the warranty expires.
Contact an ATAGO authorized service center for service and support.
Please have the serial number information ready when contacting a service center.
Repair and Warranty
Store the instrument in a dry place away from direct sunlight. Exposure to humidity and heat may damage the
instrument.
Gently wipe away any excess moisture on the instrument.
Store the unit away from direct sunlight at a stable temperature with as little fluctuation as possible.
Storage and Maintenance
Headquarters: The Front Tower Shiba Koen,
23rd Floor 2-6-3 Shiba-koen, Minato-ku,
Tokyo 105-0011, Japan
TEL: [phone] [email protected]
http://www.atago.net/
TEL: [phone]
[email protected]
TEL: [phone]
[email protected]
TEL: [phone]
[email protected]
TEL: [phone]
[email protected]
TEL: [phone]
[email protected]
TEL: [phone]
[email protected]
TEL: [phone]
[email protected]
TEL: [phone]
[email protected]
TEL: [phone]
[email protected]
Measurement range
Resolution
Accuracy
Automatic temperature compensation range
Ambient temperature range
Sample volume
Calibration
Backlight
Maximum number of data history
Output
Measurement time
Power supply
International Protection class
Dimensions and weight
Specifications
pH0.00 to 14.0 Temperature 10 to 40 ℃
pH0.01 Temperature 0.1 ℃
pH±0.10 Temperature ±1 ℃
10 to 40℃
10 to 40℃
At least 0.6mL
Calibrate at 3 points (6.86, 4.01, 9.18) (7.00, 4.01, 10.01)
The backlight stays on for 30 seconds after any button is pressed.
100
NFC Forum Type 4 Tag
ISO/IEC 14443 Type A
Output category : Date Time, pH, Temp [degC]
(e.g.) 2019/01/17 09:30:45, 3.71, 21.3
Approx. 3 seconds
Size AAA alkaline battery × 2
IP65 Water resistant
55(W) × 31(D) × 109(H)mm, 100g (main unit only)
Maximum of 100 measurement
results are recorded with
time stamps.
Android devices / iPhone
Laptop or PC +
USB NFC Reader/Writer
Example of
data history
Install a software to readout the NFC tag ahead of time.
Preparation
(1) Software installation
(2) Date and time setting
NReset the date and time when batteries are removed for 24hours or more.
h Year hYear h Month h Day h Day h Hour h Minute h Minute
Confirm Confirm Confirm Confirm Confirm Confirm Confirm
Press the START
button and CAL
button for more
than 2 seconds.
10's place 10's place 10's place1's place 1's place 1's place
While powered on…
(Example image)
Press the CAL button until the desired number is displayed.
*For "time", set the time in
24 hour notation
Confirm
99
17
99 12 31
24 60 （Seconds : Fixed 00）
Top right screen display during date and time set up
Year ：Month ：Day ：
Hour ：Minute ：
Pressing the CAL button will change the number.
【Caution】 Bring PAL and Android devices, PAL and iPhone or PAL and USB NFC Reader/writer as close to each
other as possible. (Position it so that the distance between both devices are 5mm or less.)
N Data history can be read out while PAL is powered off.
NData history readout will not delete the stored data history.
Data history readout
All recorded data stored in this instrument are read out.
* If data history is not read out, bring both in contact and move the one that is over the other device in
a forward and back or left and right in a small motion.
All data history will be deleted from this instrument.
【Caution】Deleted data history can not be restored.
N A data history can not be selected.
(a) While pressing the START
button, press the CAL button
two times.
(b) Quickly release
the START button.
START
button
CAL
button
0 second 1 second 2 seconds 3 seconds 2. Press the
START button. Delete data
history
Delete data history
If not deleting
the data history.
* Press two times
within one second.
1. Quickly (3 seconds or less) do the following button operation.
While powered
on…
(Example image)
Press the
CAL button.
Set the date and time (year [the last two digits of the western calendar], month, date, time and minute) prior to data
history readout.
Android devices / iPhone Laptop or PC +
USB NFC Reader/Writer
1. Launch NFC Reader (or other NFC tag reading app).
2. Position NFC on Android device or iPhone to the 'NFC'
logo at the bottom portion of the PAL then bring in
contact.
*Do not move it.
(Hold for 1 second or more.)
*Do not move it.
(Hold for 1 second or more.)
1. Launch ATAGO Logger.
2. Bring the bottom part (where the "NFC" logo is) of
PAL in contact with the NFC mark on the IC card
reader/writer.
* Be sure to establish the PC and IC card reader/writer
connection in advance by setting up (and installing the
driver) IC card reader/writer.
* Data history can be read out by holding up the USB NFC
Reader/writer to the PAL unit.
*NFC position on Android device or iPhone differs to the model.
End without deleting the data history.
履歴の転送と消去
LLL
8.31
8.25
AAA
c6.86
c4.01
5.89
5.92
2019/01/17 09:30:45
2019/01/17 09:31:50
2019/01/17 09:32:12
2019/01/17 09:34:26
2019/01/17 09:43:07
2019/01/17 09:43:18
2019/01/17 09:45:39
2019/01/17 09:46:07
20.4
20.5
21.0
21.2
22.3
22.5
25.1
HHH
LLL : Lower limit error.
HHH : Upper limit error.
AAA : Calibration error.
EEE : Error.
c6.86 : pH 6.86 Calibration completes
c4.01 : pH 4.01 Calibration completes
c9.18 : pH 9.18 Calibration completes
c7.00 : pH 7.00 Calibration completes
c10.01: pH 10.01 Calibration completes
Android devices / iPhone
Applicable Application Software (app)
"NFC Reader"
* If an NFC tag reader app is already
installed on the Android devices or iPhone,
this app can be used.
Laptop or PC + USB NFC Reader/Writer
Data history can be exported to Microsoft(R)
Excel (R)(for Windows(R)) using a PAL NFC
software "ATAGO Logger (NFC)."
* The app "ATAGO Logger (NFC)" is available
for download : http://www.atago.net/ur/
Example of data history read out
Ａ0135897
667937Ｅ581
Back side of the body
Instrument’s serial number
UniqueID = Last 10 digits of NFC chip number (NFC’S serial number)
You can use the NFC’S serial number to identify which instrument the readings correspond to.
You can check the NFC chip number (serial number) by using an app that can read the serial number.
Note: Not all NFC apps capture the NFC’S serial number
Suggested app: “NFC Tools”
