AT&T Axia User manual

1
Mobile Phone
Quick Guide

2
Instructions.
Thank you for purchasing this product.For your cellular
phone to work properly, please follow the instructions in the
manual. To prevent any possible incidents or malfunction,
please follow all safety warnings. If the function upgrade
described in the manual content does not agree with your
actual products, please refer to our company subsequent
release of information.

3
Contents
For Your Safety........................................................4
General Safety.....................................................4
Product Handling................................................5
General Statement on Handling and Use.....5
Electrostatic Discharge (ESD).......................7
Antenna...........................................................7
Normal Use Position......................................7
Phone Heating................................................7
Getting Started.........................................................8
Overview..............................................................8
Keys Explained ...................................................9
Install the SIM card / SD card........................9
Charging the Battery.............................................10
Switching Your Phone On/Off...............................10
Waking Up Your Phone.........................................10
Getting Around Your Phone.............................11
Home Screen................................................11
Use the phone as a USB memory.........................11
Turning On Wi-Fi....................................................12
Turning On Data Services.....................................12
HAC warning …………………………………………13
IEEE1725 WARNING…………………………………15

4
For Your Safety
General Safety
Don’t make or receive
handheld calls while
driving. And never text
while driving.
Don’t use at petrol
stations.
Keep your phone at
least 10 mm away from
your ear or body while
making calls.
Your phone may produce
a bright or flashing light.
Do not leave your
phone and its
accessories within the
reach of small children
or allow them to play
with it.
Small parts may cause
a choking.
Don’t dispose of your
phone in fire.
Your phone can
produce a loud sound.
Avoid contacting with
anything magnetic.

5
Keep away from
pacemakers and other
electronic medical
devices.
The phone's normal
operating temperature is
-10℃~ 50℃.In order to
ensure the normal phone
functions, do not use this
phone outside the
temperature range
Switch off when asked
to in hospitals and
medical facilities.
Avoid contacting with
liquids. Keep your phone
dry.
Switch off when told to
in aircrafts and airports.
Don’t take your phone
apart.
Switch off when near
explosive materials or
liquids.
Only use approved
accessories.
Don’t rely on your
phone for emergency
communications.
To prevent possible
hearing damage, do not
listen at high volume
levels for long periods.
Product Handling
General Statement on Handling and Use
You alone are responsible for how you use your phone and
any consequences of its use.

6
You must always switch off your phone wherever the use of a
phone is prohibited. Use of your phone is subject to safety
measures designed to protect users and their environment.
Always treat your phone and its accessories with care
and keep it in a clean and dust-free place.
Do not expose your phone or its accessories to open
flames or lit tobacco products.
Do not expose your phone or its accessories to liquid,
moisture or high humidity.
Do not drop, throw or try to bend your phone or its
accessories.
Do not use harsh chemicals, cleaning solvents, or
aerosols to clean the device or its accessories.
Do not paint your phone or its accessories.
Do not attempt to disassemble your phone or its
accessories, only authorized personnel can do so.
Please check local regulations for disposal of electronic
products.
Do not carry your phone in your back pocket as it could
break when you sit down.
Use careful with the earphone maybe possible excessive
sound pressure from earphones and headphones can
cause hearing loss.
Adapter：adapter shall be installed near the equipment
and shall be easily accessible.

7
CAUTION : RISK OF EXPLOSION IF BATTERY IS
REPLACED BY AN INCORRECT TYPE. DISPOSE OF
USED BATTERIES ACCORDING TO THE
INSTRUCTIONS.
Electrostatic Discharge (ESD)
Do not touch the SIM card’s metal connectors.
Antenna
Do not touch the antenna unnecessarily.
Normal Use Position
When placing or receiving a phone call, hold your phone to
your ear, with the bottom towards your mouth.
Phone Heating
Your phone may become warm during charging and during
normal use.

8
Getting Started
Overview
1、Headphone insertion hole 2、Front camera
3、Receiver 4、Light/Proximity sensor
5、Up volume button 6、Down volume button
7、Power 8、Data port
9、Microphone 10、Rear camera
11、Rear flash 12、Speaker

9
Keys Explained
Key
Function
Power Key
Hold to switch audio profiles, or to turn on
or off Airplane mode, or to power off.
Press to switch your phone to Sleep
mode.
Press to wake up your phone.
Home Key
Press to return to the Home Screen from any
application or screen.
Menu Key
Press to get the options for the current
screen.
Back Key
Press to go to the previous screen.
Volume Keys
Press or hold to turn the volume up or down.
Install the SIM card / SD card
1. To ensure that the phone off, use the card to take out the
card care;
2. Insert the Nano-SIM card and the Micro SD card as
instructed on the card

10
Charging the Battery
When you first get your new phone you’ll need to charge the
battery.
1. Connect the adapter to the charger jack. Ensure that the
adapter is inserted with the correct orientation. Do not
force the connector into the charger jack.
2. Connect the charger to a standard AC wall outlet.
3. Disconnect the charger when the battery is fully charged.
Switching Your Phone On/Off
Make sure the SIM card is in your device and the battery is
charged.
Hold Power Key to switch on your phone.
To switch it off, hold Power Key to get the phone options.
Select Power off, and then tap OK.
Waking Up Your Phone
1. Press the power key to activate the screen display.
2. Drag the main screen to the right to unlock the screen.
3. Slide the camera up to go to the camera application.

11
NOTE: If you have set an unlock pattern, PIN or password for
your phone (see chapter Sorting out Your Phone Settings –
Security Settings) you’ll need to draw the pattern or enter the
PIN/password to unlock your screen.
Getting Around Your Phone
Home Screen
In the Home screen, besides the shortcut icon is displayed,
you can also set your own wallpaper, add the widgets or
application shortcuts you need, or remove them as you like.
Choosing Your Wallpaper
1. Press Home Key to return to the Home Screen.
2. Tap Menu Key and select WALLPAPERS.
3. Choose the image or animation you want to use as
the wallpaper. Some cropping may be needed for
Gallery images.
4. Tap Set wallpaper.
Use the phone as a USB memory
1. Connect the phone and computer with the USB cable.
2. In the drop-down notification bar, tab Charge via USB
for this device, select Transfer File.

12
Turning On Wi-Fi
1. Press Home key > tap> Settings.
2. Click next to the Wi-Fi menu to turn it on,click you can
turn off the Wi-Fi function.
Turning On Data Services
Press Home key > tap Settings > SIM management >
Data connection, then tap ON/Off.

13
HAC warning
US Information Concerning the Federal Communications
Commission (“FCC”) Requirements for Hearing Aid
Compatibility with Wireless Devices When wireless
devices are used near hearing devices (such as hearing
aids and cochlear implants), users may detect a buzzing,
humming, or whining noise. Some hearing devices are
more immune than others to this interference, and
wireless devices also vary in the amount of interference
that they generate.
The wireless telephone industry has developed ratings
to assist hearing device users in findingwireless devices
that may be compatible with their hearing devices. Not
all wireless devices have been rated. Wireless devices
that are rated will have the rating displayed on the box
together with other relevant approval markings.
The ratings are not guarantees. Results will vary
depending on the user’s hearing device and hearing loss.
If your hearing device is vulnerable to interference, you
may not be able to use a rated wireless device
successfully.
Consulting with your hearing health professional and
testing the wireless device with your hearing device is
the best way to evaluate it for your personal needs.
This smartphone has been tested and rated for use with
hearing aids for some of the wireless technologies that
the smartphone uses. However, other wireless

14
technologies may be used in this smartphone that have
not been tested for use with hearing aids. It is important
to try the different features of your smartphone
thoroughly and in different locations to determine if you
hear any interfering noise when using this smartphone
with your hearing aid or cochlear implant. Consult your
wireless service provider about its return and exchange
policies, and for
information about hearing aid compatibility.
Hearing aid compatibility rating for this smartphone:
M4/T4.
How the ratings work
M-Ratings: Wireless devices rated M3 or M4 meet FCC
requirements and are likely to
generate less interference to hearing devices than
wireless devices that are not labeled. M4 is
the better or higher of the two ratings.
T-Ratings: Wireless devices rated T3 or T4 meet FCC
requirements and are likely to be more usable with a
hearing device’s telecoil (“T Switch” or “Telephone
Switch”) than unrated wireless devices. T4 is the better
or higher of the two ratings. (Note that not all hearing
devices have telecoils in them.)
Hearing devices may also be measured for immunity to
this type of interference. Your hearing device
manufacturer or hearing health professional may help
you find results for your hearing device. The more

15
immune your hearing aid is, the less likely you are to
experience interference noise from wireless devices.
For more information about the actions that the FCC has
taken with regard to hearing aid compatibility with
wireless devices and other steps that the FCC has taken
to ensure that individuals with disabilities have access to
telecommunications services, visit www.fcc.gov/cgb/dro.
a) Section 20.19(f)(1): an explanation of the ANSI
C63.19 rating system.
b) Section 20.91(f)(3): disclosure statement for
HAC-rated handsets operating over the GSM air
interface in the 1900 MHz band with a user-selectable
mode or a special mode necessary to meet the hearing
aid compatibility standard for reducing the power under
the provisions of Section 20.19(c)(1).
IEEE1725 WARNING
a) Do not disassemble or open crush, bend or deform,
puncture or shred
b) Do not modify or remanufacture, attempt to insert
foreign objects into the battery,
immerse or expose to water or other liquids, expose to
fire, explosion or other
hazard.
c) Only use the battery for the system for which it is
specified
d) Only use the battery with a charging system that has
been qualified with the

16
system per CTIA Certification Requirements for Battery
System Compliance to IEEE
1 725. Use of an unqualified battery or charger may
present a risk of fire, explosion,
leakage, or other hazard.
e) Do not short circuit a battery or allow metallic
conductive objects to contact battery
terminals.
f) Replace the battery only with another battery that has
been qualified with the
system per this standard, IEEE-Std-1725. Use of an
unqualified battery may present
a risk of fire, explosion, leakage or other hazard.
Only authorized service providers shall replace battery.
(If the battery is non-user
replaceable).
g) Promptly dispose of used batteries in accordance with
local regulations
h) Battery usage by children should be supervised.
j) Avoid dropping the phone or battery. If the phone or
battery is dropped, especially
on a hard surface, and the user suspects damage, take it
to a service center for
inspection.
k) Improper battery use may result in a fire, explosion or
other hazard.

17
Exposure to radio frequency signals
The smart phone radio is a low-power radio transmitter
and receiver. It is designed to comply with the following:
•Federal Communications Commission (FCC) guidelines
and limits
•Other relevant international guidelines regarding safety
levels of radio frequency exposure for wireless devices
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful
interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to
radio or television reception, which can be determined
by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or
more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and
receiver.
-- Connect the equipment into an outlet on a circuit

18
different from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV
technician for help.
This equipment complies with FCC radiation exposure
limits set forth for an uncontrolled environment. End user
must follow the specific operating instructions for
satisfying RF exposure compliance. This transmitter
must not be co-located or operating in conjunction with
any other antenna or transmitter.
This device complies with Part 15 of the FCC Rules and
Innovation, Science and Economic Development
Canada licence-exempt RSS standard(s). Operation is
subject to the following two conditions:
(1) this device may not cause harmful interference
(2) this device must accept any interference received,
including interference that may cause undesired
operation.
Changes or modifications not expressly approved by the
party responsible for compliance could void the user’s
authority to operate the equipment.
The portable device is designed to meet the
requirements for exposure to radio waves established by
the Federal Communications Commission (USA). These
requirements set a SAR limit of 1.6 W/kg averaged over
one gram of tissue. The highest SAR value reported
under this standard during product certification for use
when properly worn on the body.

19
The highest SAR value :Head 0.56W/kg ;Body-worn 0.75
W/kg
The National Council on Radiation Protection and
Measurements (NCRP)10
To maintain compliance with radio frequency exposure
guidelines and limits, keep the smartphone at least 10 mm
away from your body. When you carry the smartphone on
your body, use only accessories equipped with an integrated
belt clip that are supplied or approved by the manufacturer. If
you use a body-worn accessory not supplied by the
manufacturer, verify that the accessory does not contain
metal and keep the smartphone at least 10mm from your
body.
