AT&T CRL81112 User manual

Complete user’s manual
CRL81112/CRL81212
DECT 6.0 cordless telephone
with caller ID/call waiting

Congratulations
on your purchase of this AT&T product. Before using this AT&T product, please
read the Important safety information section on pages 56-57 of this manual.
Please thoroughly read this user’s manual for all the feature operations and
troubleshooting information necessary to install and operate your new AT&T
product. You can also visit our website at www.telephones.att.com or
call 1 [phone]. In Canada, dial 1 [phone].
This telephone system is compatible with certain AT&T DECT 6.0 cordless
headsets. Visit www.telephones.att.com/headsets for a list of
compatible cordless headsets.
Model number: CRL81112 (one handset)
CRL81212 (two handsets)
Type: DECT 6.0 cordless telephone with caller ID/call waiting
Serial number: ____________________________________________________________
Purchase date: ____________________________________________________________
Place of purchase: _________________________________________________________________
Both the model and serial numbers of your AT&T product can be found on the
bottom of the telephone base.
Save your sales receipt and original packaging in case it is necessary to return
your telephone for warranty service.
T
Compatible with
Hearing Aid T-Coil
TIA-1083
Telephones identified with this logo have reduced noise and interference when
used with most T-coil equipped hearing aids and cochlear implants. The TIA-1083
Compliant Logo is a trademark of the Telecommunications Industry Association.
Used under license.
© 2012 Advanced American Telephones. All Rights Reserved. AT&T and
the AT&T logo are trademarks of AT&T Intellectual Property licensed to
Advanced American Telephones, San Antonio, TX 78219. Printed in China.
The ENERGY STAR® program (www.energystar.gov) recognizes and encourages
the use of products that save energy and help protect our environment. We are
proud to mark this product with the ENERGY STAR® label indicating it meets the
latest energy efficiency guidelines.

Parts checklist
Your telephone package contains the following items. Save your sales receipt
and original packaging in the event warranty service is necessary.
Battery for cordless handset
(1 for CRL81112)
(2 for CRL81212)
Cordless handset
(1 for CRL81112)
(2 for CRL81212)
Charger for cordless handset
with power adapter installed
(1 for CRL81212)
Battery compartment cover
(1 for CRL81112)
(2 for CRL81212)
Abridged
user’s manual
Quick start guide Telephone base
Telephone line cord Power adapter for
telephone base
Wall mount bracket
BY 1021
BT183342/BT283342
2.4V 400mAh Ni-MH
Abridged user’s manual
CRL81112/CRL81212
DECT 6.0 cordless telephone
with caller ID/call waiting

Complete user’s manual
CRL81112/CRL81212
DECT 6.0 cordless telephone
with caller ID/call waiting
Table of contents
Getting started
Quick reference guide - handset........ 1
Quick reference guide - telephone
base.............................................................3
Installation..................................................... 4
Telephone base and charger
installation ...............................................5
Telephone base installation ............ 5
Charger installation............................. 5
Battery installation and charging.......6
Installation options....................................8
Tabletop to wall mount
installation............................................. 8
Wall mount to tabletop
installation............................................. 9
Telephone settings
Handset settings...................................... 10
Ringer volume..................................... 10
Ringer tone........................................... 11
Set date/time ...................................... 12
LCD language ...................................... 13
Set speed dial voicemail
number................................................. 13
Voicemail (visual message
waiting) indicator............................ 14
Clear voicemail indicator............... 14
Rename handset................................ 15
Key tone................................................. 15
Use caller ID to automatically
set date and time........................... 16
Home area code................................. 16
Dial mode.............................................. 17
Web address ........................................ 17
QUIET mode ......................................... 18
Telephone operation
Handset operation.................................. 19
Making a call........................................ 19
On hook dialing (predialing) ........ 19
Answering a call ................................ 19
Ending a call ........................................ 19
Auto off .................................................. 19
Temporary ringer silencing........... 19
Speakerphone ..................................... 20
Last number redial............................ 20
Equalizer................................................. 21
Options while on calls.......................... 22
Volume control ................................... 22
Call waiting........................................... 22
Mute ......................................................... 22
Chain dialing........................................ 23
Audio Assist®........................................ 24
Temporary tone dialing .................. 24
Blind transfer....................................... 25
Multiple handset use
Multiple handset use............................. 26
Handset locator.................................. 26
Join a call in progress..................... 26

Intercom....................................................... 27
Answer an incoming call during
an intercom call .............................. 27
Call transfer using intercom .............. 28
Directory
About the directory................................ 29
Shared directory................................. 29
Capacity.................................................. 29
Create directory entries....................... 30
Create a new directory entry ...... 30
Add a predialed telephone
number to the directory.............. 31
Review the directory.............................. 32
Review directory entries ................ 32
Search by name.................................. 32
Dial, delete or edit directory entries... 33
Display dial ........................................... 33
Delete a directory entry................. 33
Edit a directory entry....................... 33
Speed dial ................................................... 34
Assign a speed dial number......... 34
Reassign a speed dial number.... 34
Delete a speed dial number......... 35
Assign your speed dial
voicemail number........................... 35
Make a call using speed dial ....... 35
Check your voicemail using
speed dial........................................... 35
Caller ID
About caller ID ......................................... 36
Information about caller ID
with call waiting.............................. 36
Caller ID history....................................... 37
How the caller ID history
(caller ID log) works...................... 37
Missed (new) call indicator........... 37
Caller ID operation................................. 38
Memory match.................................... 38
Review the caller ID history......... 38
View dialing options......................... 39
Dial a caller ID log entry ............... 39
Delete caller ID log entries .......... 39
Save a caller ID log entry to
the directory...................................... 40
Reasons for missing caller ID
information ........................................... 41
Appendix
Adding and registering handsets/
headsets................................................. 42
Register a handset to your
telephone base................................ 42
Deregistering handsets ........................ 43
Deregister all handsets from
your telephone base..................... 43
Alert tones and lights ........................... 44
Screen icons......................................... 44
Handset alert tones.......................... 44
Lights ....................................................... 45
Handset display screen messages... 46
Screen display messages............... 46
Troubleshooting......................................... 48
Maintenance............................................... 55
Important safety information ............ 56
Safety information............................. 56
Especially about cordless
telephones ......................................... 57
Precautions for users of
implanted cardiac pacemakers... 57
Pacemaker patients.......................... 57
FCC Part 68 and ACTA.......................... 58
FCC Part 15................................................ 59
Limited warranty...................................... 60
Technical specifications ....................... 63
DECT 6.0 digital technology......... 63
Telephone operating range.......... 63
Redefining long range coverage
and clarity .......................................... 63
HD audio ................................................ 63
Index
Index.............................................................. 64

1
CHARGE indicator
On when the handset is charging
in the telephone base or charger.
qCID/VOLUME
Press qCID to show caller ID
history (page 38).
Press to scroll down while in menus.
While entering names or numbers,
press to move the cursor to the left.
Press to decrease the listening
volume when on a call (page 22).
PHONE/FLASH
Press to make or answer a call.
During a call, press to answer an
incoming call when you receive a
call waiting alert (page 22).
1
While reviewing a caller ID log
entry, press repeatedly to add or
remove 1 in front of the telephone
number before dialing or saving it
in the directory (page 39).
Press and hold to set (page 13)
or dial your voicemail number
(page 35).
MUTE/DELETE
During a call, press to mute the microphone (page 22).
While reviewing the caller ID history, the directory or the
redial memory, press to delete an individual entry (page 39,
page 33 and page 20 respectively).
While predialing (page 19), press to delete digits.
/SPEA�ERSPEA�ER
Press to switch between the
speakerphone and the handset
(page 20).
Quick reference guide - handset
QUIET # (pound key)
Press repeatedly to display other
dialing options when reviewing a
caller ID log entry (page 39).
Press and hold to enter the
QUIET mode setting screen, or to
deactivate QUIET mode (page 18).
OFF/CANCELOFF/CANCEL
During a call, press to hang up.
While in a menu, press to cancel
an operation, back up to the
previous menu, or exit the menu
display, or press and hold this
button to exit to idle mode.
Press and hold while the telephone
is not in use to erase the missed
call indicator.
MENU/SELECT
Press to show the menu.
While in the menu, press to
select an item or save an
entry or setting.
pDIR/VOLUME
Press pDIR to show
directory entries (page 32).
Press to scroll up while in menus.
While entering names or
numbers, press to move the
cursor to the right.
Press to increase the listening
volume when on a call (page 22).
TONE
Press to switch to tone dialing
temporarily during a call if you
have pulse service (page 24).
Getting started
Audio Assist®is a registered trademark of Advanced American Telephones.
AUDIO ASSIST®
Voices will sound louder and
clearer when you press AUDIO
ASSIST®while on a call using the
handset (page 24).
REDIAL/PAUSE
Press repeatedly to view the last
10 numbers dialed (page 20).
While entering numbers, press
and hold to insert a dialing pause
(page 30).

2
Getting started
Quick reference guide - handset
Main menu
The >symbol highlights
a menu item.
Main menu
Directory (page 29)
Caller ID log (page 36)
Intercom (page 27)
Ringers (page 10)
Set date/time (page 12)
Settings (page 13)
Web address (page 17)
Using menus:
Press MENU/SELECT to show the menu.
Press qCID or pDIR to scroll through
menu items.
Press MENU/SELECT to confirm or save
changes to a highlighted menu item.
Press OFF/CANCEL to cancel an
operation, back up to the previous menu,
or exit the menu display.
•
•
•
•
>Directory
Caller ID log
Handset
side view
EQ
During an outside or intercom
call, press to change the
audio quality to best suit
your hearing (page 21).

Getting started
3
Quick reference guide - telephone base
IN USE indicator
On when the handset is in use.
On when a handset is being registered.
Flashes when there is an incoming call or
when handsets are being deregistered.
Flashes when another telephone is in use
on the same line.
/HANDSET LOCATOR
While the telephone is idle, press to page
all handsets (page 26).
Press and hold to begin handset
deregistration (page 43).

4
Getting started
See pages 6-7 for
easy instructions.
You must install and
charge the battery before
using the telephone. STOP!
Installation
Install the telephone base close to a telephone jack and a power outlet not
controlled by a wall switch. The telephone base can be placed on a flat surface
or vertically mounted on the wall (see page 8). For optimum range and better
reception, place the telephone base in a central and open location.
If you subscribe to high-speed Internet service (DSL - digital subscriber line) through
your telephone line, you must install a DSL filter between the telephone line cord
and the telephone wall jack (see the following page). The filter prevents noise and
caller ID problems caused by DSL interference. Please contact your DSL service
provider for more information about DSL filters.
Your product may be shipped with a protective sticker covering the handset
display - remove it before use.
For customer service or product information, visit our website at
www.telephones.att.com or call 1 [phone]. In Canada, dial
1 [phone].
Avoid placing the telephone base too close to:
Communication devices such as television sets, VCRs, or other
cordless telephones.
Excessive heat sources.
Noise sources such as a window with traffic outside, motors, microwave
ovens, refrigerators, or fluorescent lighting.
Excessive dust sources such as a workshop or garage.
Excessive moisture.
Extremely low temperature.
Mechanical vibration or shock such as on top of a washing machine
or workbench.
•
•
•
•
•
•
•

Getting started
5
Telephone base and charger installation
Install the telephone base and charger as shown below.
The telephone base is ready for tabletop use. If you want to change to wall
mounting, see Installation options on page 8 for details.
IMPORTANT INFORMATION
1. Use only the power adapter(s) supplied with this product. To
order a replacement power adapter, visit our website at
www.telephones.att.com or call
1 [phone]. In Canada, dial 1 [phone].
2. The power adapters are intended to be correctly oriented in
a vertical or floor mount position. The prongs are not designed
to hold the plug in place if it is plugged into a ceiling,
under-the-table or cabinet outlet.
Plug the power adapter into a power
outlet not controlled by a wall switch.
Charger installation
Telephone base installation
Raise the antenna.•Plug the other end
of the telephone line
cord into the telephone
jack on the back of the
telephone base.
•
Route the power
adapter cord and the
telephone line cord
through these slots.
•
Plug the small end of the telephone base power adapter into
the power adapter jack on the back of the telephone base.
•
Plug the large end of the
telephone base power
adapter into a power
outlet not controlled by
a wall switch.
•Plug one end of the
telephone line cord
into a telephone jack
or a DSL filter.
•
Telephone
line cord
If you have DSL high-speed
Internet service, a DSL filter
(not included) is required.
The DSL filter must be
plugged into the telephone
wall jack.

6
Getting started
Battery installation and charging
Install the battery as shown below. Once you have installed the battery, the
screen indicates the battery status (see the table below). If necessary, place
the handset in the telephone base or charger to charge the battery. For best
performance, keep the handset in the telephone base or charger when not in
use. The battery is fully charged after 10 hours of continuous charging. See the
table on page 63 for battery operating times.
If the screen shows Place in charger and flashes, you need to charge the
handset without interruption for at least 30 minutes to give the handset
enough charge to use the telephone for a short time. The following table
summarizes the battery charge indicators and actions to take.
Battery indicators Battery status Action
The screen is blank, or
shows Place in charger
and (flashing).
Battery has no or very little
charge. The handset cannot
be used.
Charge without interruption
(at least 30 minutes).
The screen shows
Low battery and
(flashing).
Battery has enough charge
to be used for a short time.
Charge without interruption
(at least 30 minutes).
The screen shows
HANDSET X.
Battery is charged. To keep the battery charged,
place it in the telephone base
or charger when not in use.
Battery Pack BT183342 2.4V 400mAh Ni-MH WARNING: DO NOT BURN OR PUNCTURE BATTERIES MADE IN CHINA MANUFACTURED BY BYD BYYYWW
Step 1
Plug the battery
connector securely
into the socket inside
the handset battery
compartment. Insert
the supplied battery
with the label THIS
SIDE UP facing up as
indicated.
Step 2
Align the cover flat
against the battery
compartment, then slide
it upwards until
it clicks into place.
NOTE: If you are on a phone call in low battery mode, you hear four short beeps every minute.

Getting started
7
Battery installation and charging
Step 3
Charge the handset by placing it face forward in the
telephone base or charger. The CHARGE light on
the handset is on during charging.
IMPORTANT INFORMATION
1. Use only the supplied rechargeable battery or replacement battery (model BT183342).
To order, visit our website at www.telephones.att.com or call
1 [phone]. In Canada, dial 1 [phone].
2. If you do not use the handset for a long time, disconnect and remove the battery to
prevent possible leakage.
CHARGE light
After you install your telephone or power returns following a
power outage, the handset will prompt you to set the date and
time. For instructions, see Set date/time on page 12. To skip
setting the date and time, press OFF/CANCEL.
SET DATE
MM/DD/YY
SET TIME
HH:MM __

8
Getting started
2
4
Installation options
Your telephone base is ready for tabletop use. If you want to mount your
telephone on a wall, use the provided wall mount bracket to connect with
a standard dual-stud telephone wall mounting plate. If you do not have this
mounting plate, you can purchase one from many hardware or consumer electronic
retailers. You might need a professional to install the mounting plate.
Tabletop to wall mount installation
Plug the power cord and telephone line into the telephone base. If you are
using a DSL filter, plug the other end of the telephone line into the filter. Route
the telephone line cord (or DSL filter) through the wall mount bracket hole.
Position the telephone base as shown below. Insert the extended tabs (see
below figure 2) of the wall mount bracket into the slots on the back of
the telephone base (marked B). Push the telephone base down until it is
securely in place.
Plug the telephone line cord (or DSL filter) into the wall jack. Plug the power
adapter into a power outlet not controlled by a wall switch.
Align the holes on the wall mount bracket with the standard wall plate
and slide the wall mount bracket down until it locks securely. Bundle the
telephone line cord and power adapter cord neatly with twist ties.
1.
2.
3.
4.
1
3
Raise the
antenna

Getting started
9
Installation options
Wall mount to tabletop installation
If the telephone line cord and power adapter cord are bundled, untie
them first.
Push the telephone base up to detach it from the wall mount bracket.
Unplug the telephone line cord (or DSL filter) from the wall. Unplug the
power adapter from the power outlet.
Push the wall mount bracket up to remove it from the wall.
See Telephone base and charger installation on page 5.
1.
2.
3.
4.

10
Handset settings
Use the menu to change the telephone settings.
1. Press MENU/SELECT when in idle mode (when the phone
is not in use) to enter the main menu.
2. Press qCID or pDIR to scroll to the feature to be changed.
When scrolling through the menu, the >symbol indicates the selected menu
item.
3. Press MENU/SELECT to select the highlighted item.
NOTE: Press OFF/CANCEL to cancel an operation, back up to the previous menu or exit
the menu display. Press and hold OFF/CANCEL to return to idle mode.
Ringer volume
You can set the ringer volume level (1-6) to one of six levels or
turn the ringer off. When the ringer is off, appears on the
screen.
1. Press MENU/SELECT in idle mode to enter the main menu.
2. Use qCID or pDIR to scroll to >Ringers, then press
MENU/SELECT.
3. Press MENU/SELECT again to select >Ringer volume.
4. Press qCID or pDIR to sample each volume level.
5. Press MENU/SELECT to save your preference. There is a
confirmation tone and the screen returns to the previous menu.
NOTES:
The handset ringer volume also determines the ringer volume for
intercom calls.
If the ringer volume is set to off, that handset is silenced for all incoming calls.
However, the handset still plays the paging tone when responding to the
handset locator.
•
•
>Directory
Caller ID log
Telephone settings
> Ringer volume
Ringer tone
>Ringers
Intercom
RINGER VOLUME

> Ringer tone
Ringer volume
RINGER TONE
> Tone 1
11
Telephone settings
Handset settings
Ringer tone
You can choose one of 10 ringer tones.
1. Press MENU/SELECT in idle mode to enter the main menu.
2. Use qCID or pDIR to scroll to >Ringers, then press
MENU/SELECT.
3. Press qCID or pDIR to scroll to >Ringer tone, then press
MENU/SELECT.
4. Press qCID or pDIR to sample each ringer tone.
5. Press MENU/SELECT to save your preference. There is
a confirmation tone and the screen returns to the
previous menu.
NOTE: If you turn off the ringer volume, you do not hear ringer tone samples.

Telephone settings
12
Handset settings
Set date/time
If you subscribe to caller ID service, the day, month and time are set
automatically with each incoming call. You can turn off the date and time
settings of the caller ID service and set the date and time manually (see Use
caller ID to automatically set date and time on page 16).
After a power failure or handset registration, the system reminds you to set the
date and time.
Follow the steps below to set the month, day, year and time.
When the handset is in idle mode, press MENU/SELECT to
enter the main menu.
Press qCID or pDIR to scroll to >Set date/time and then
press MENU/SELECT.
Press qCID or pDIR to select the month, then press
MENU/SELECT, or enter the number using the dialing keys.
Press qCID or pDIR to select the day, then press
MENU/SELECT, or enter the number using the dialing keys.
Press qCID or pDIR to select the year, then press
MENU/SELECT, or enter the number using the dialing keys,
then press MENU/SELECT to move on to set the time.
Press qCID or pDIR to select the hour, then press
MENU/SELECT, or enter the number using the dialing keys.
Press qCID or pDIR to select the minute, then press
MENU/SELECT, or enter the number using the dialing keys.
Press qCID or pDIR to highlight AM or PM,or press 2for AM or 7for PM.
Then press MENU/SELECT to confirm. There is a confirmation tone and the
screen returns to the previous menu.
1.
2.
3.
4.
5.
6.
7.
8.
SET DATE
MM/DD/YY
SET TIME
HH:MM --
Ringers
>Set date/time

Handset settings
LCD language
You can select English, French, or Spanish to be used for all screen displays.
1. Press MENU/SELECT in idle mode to enter the main menu.
2. Use qCID or pDIR to scroll to >Settings, then press MENU/SELECT.
3. Press MENU/SELECT to choose >LCD language.
4. Press qCID or pDIR to highlight >English, >Français or
>Español, then press MENU/SELECT. The screen prompts
you with the message Set English/Français/Español as
LCD language?
5. Press MENU/SELECT to save. There is a confirmation tone
and the screen returns to the previous menu.
NOTE: If you accidentally change the LCD language to French or Spanish,
you can reset it back to English without going through the French or
Spanish menus. Press MENU/SELECT in idle mode, then enter 364#. There is a confirmation tone.
Set speed dial voicemail number
This feature lets you save your voicemail number for quick access when you
press and hold the 1key.
1. Press MENU/SELECT in idle mode to enter the main menu.
2. Use qCID or pDIR to scroll to >Settings, then press
MENU/SELECT.
3. Use qCID or pDIR to scroll to >Voicemail #, then press
MENU/SELECT.
4. Use the dialing keys to enter the voicemail access number
provided by your telephone service provider (up to 30 digits)
when prompted.
Press qCID or pDIR to move the cursor to the left or right.
Press MUTE/DELETE to erase a digit.
Press and hold MUTE/DELETE to erase all digits.
Press REDIAL/PAUSE to enter a three-second dialing pause
(a pappears).
5. Press MENU/SELECT to save. Voicemail # saved shows on
the handset.
•
•
•
•
> LCD language
Voicemail #
LCD LANGUAGE
> English
13
Telephone settings
VOICEMAIL #
_
LCD language
>Voicemail #
Set date/time
>Settings

Telephone settings
14
Handset settings
Voicemail (visual message waiting) indicator
If you subscribe to a voicemail service offered by your telephone
service provider, this feature provides a visual indicator when
you have new voicemail messages.
New voicemail and the icon appear on the handset screen.
Clear voicemail indicator
Use this feature when the telephone indicates there is new voicemail but there
is none. For example, when you have accessed your voicemail while away from
home. This feature only turns off the displayed New voicemail and the icon;
it does not delete your voicemail messages. As long as you have new voicemail
messages, your telephone service provider continues to send the signal to turn
on the indicators.
To manually turn off the new voicemail indicators:
1. Press MENU/SELECT when in idle mode to enter the main menu.
2. Use qCID or pDIR to scroll to >Settings, then press MENU/SELECT.
3. Use qCID or pDIR to scroll to >Clr voicemail, then press
MENU/SELECT. The screen shows Reset Voicemail Indicator?
4. Press MENU/SELECT again to turn the voicemail indicator off.
There is a confirmation tone and the screen returns to the
previous menu.
NOTES:
Your telephone service provider voicemail might alert you to new messages with a stutter (broken)
dial tone. Contact your telephone service provider for more details.
For information about using your voicemail service, contact your telephone service provider.
•
•
Reset Voicemail
Indicator?
> Clr voicemail
Rename handset
HANDSET 1
New voicemail
10:21 AM 2/11

15
Telephone settings
Handset settings
Rename handset
You can create a handset name for each system handset.
When the handset is idle, press MENU/SELECT.
Use qCID or pDIR to scroll to >Settings, then press
MENU/SELECT.
Use qCID or pDIR to scroll to >Rename handset, then press
MENU/SELECT.
Change the handset name when prompted.
Press qCID or pDIR to move the cursor to the left or right.
Use the dialing keys to enter a name (up to 11 characters).
Each time you press a key, a character on that key appears. Additional key
presses produce other characters on that key. See the chart on page 31.
Press MUTE/DELETE to backspace and delete characters.
Press and hold MUTE/DELETE to delete all characters.
Press MENU/SELECT to save the setting and return to the previous menu.
There is a confirmation tone.
�ey tone
The handset is set to beep with each key press. You can adjust the key tone
volume or turn it off. If you turn off the key tone, there are no beeps when you
press keys.
1. Press MENU/SELECT in idle mode to enter the main menu.
2. Use qCID or pDIR to scroll to >Settings, then press
MENU/SELECT.
3. Use qCID or pDIR to scroll to >�ey tone, then press
MENU/SELECT.
4. Use qCID or pDIR to select the desired volume or Off.
5. Press MENU/SELECT to save your preference. There is a
confirmation tone and the screen returns to the previous menu.
1.
2.
3.
4.
•
•
•
•
5.
Clr voicemail
> Rename handset
RENAME HANDSET
HANDSET____
Rename handset
> Key tone
KEY TONE
