AT&T BTS01 User manual

User’s Manual
LoudSpeak’r
BTS01
Portable Bluetooth® Speaker

Page 2
Welcome |Thank you for buying LoudSpeak’r (BTS01)
Introduction
Features
- Bluetooth 2.1 + EDR - Rechargeable Li-ion battery
- Hands free speakerphone with up to 5 hours of calls/
- Wireless range of up to 30 .* playback
- ProTune Speaker System with - Auxiliary input to play music
RealBass Technology from any device with a
- Answer calls & control your headphone jack
music from the speaker - Voice notications
- Easy USB charging - Battery indicator on
- Noise cancelling microphone smart phones

Page 3
What’s Included
Unpack LoudSpeak’r and make sure all accessories are put
aside so they will not be lost.
Mini USB Cable
Portable Speaker

Page 4
Content
Introduction
Features 2
What’s Included 3
Safety Information
Important Safety Instructions 5
Getting Started
Location of Main Unit Controls 6
Operational Instructions
Charging 8
Power Up 8
Using the Audio Line in Connection 8
Pairing Your Bluetooth Device 9
Connecting to a Paired Bluetooth Device 10
Music Playback Functions 10
Hands Free Speakerphone 11
LED Light Indicator 11
Troubleshooting 12
Compliance with FCC Regulations 13
Warranty Information
Limited Warranty 14
Specications 16

Page 5
Safety Information
Important Safety Instructions
Please read all safety and operating instructions carefully before
installation and use. Keep these instructions handy for future
reference. Take special note of all warnings listed in this user’s
manual and on LoudSpeak’r.
1. Water and Moisture - LoudSpeak’r should not be used near water. For
example: near a bathtub, washbowl, kitchen sink, laundry tub, swimming
pool or in a wet basement.
2. Objects and Liquid Entry - Care should be taken so that external objects
do not fall into and liquids are not spilled onto any openings or vents
located on the product.
3. Heat - LoudSpeak’r should be situated away from heat sources such as
radiators, heat registers, stoves or other appliances (including ampliers)
that produce heat.
4. Damage Requiring Service - LoudSpeak’r should be serviced by qualied
service personnel when:
A. Objects have fallen into or liquid has been spilled onto the enclosure.
B. LoudSpeak’r has been exposed to rain.
C. LoudSpeak’r has been dropped or the enclosure damaged.
D. LoudSpeak’r exhibits a marked change in performance or does not
operate normally.
5. Servicing - The user should not attempt to service LoudSpeak’r beyond
those methods described in the user’s manual. Opening or removing
covers will expose you to dangerous voltage and other hazards. Service
methods not covered in the user’s manual should be referred to qualied
service personnel.
6. Safety Check - Upon completion of any service or repair to LoudSpeak’r,
ask the service technician to perform safety checks to determine that
the product is in proper working condition.
7. Battery - This device contains a rechargeable Lithium-ion battery. Please
do not attempt to replace the battery yourself. The battery may only be
replaced by our authorized service centers.

Page 6
Getting Started
Location of Main Unit Controls
1. Previous track
2. Play/Pause
3. Next track
4. Volume up
5. Power ON/OFF
6. LED indicators
7. Volume down
8. Microphone
11 12 13
9. Stereo speaker
10. Passive radiator
subwoofer
11. AUX-in jack
12. USB charging jack
13. OFF /ON switch

Page 7
During Bluetooth Music Playback
1. Previous track
2. Play/Pause
3. Next track
During Phone Calls
1. and 3. Mute/Unmute the microphone
2. During ringing: Answer incoming call/Reject incoming call
(long press)
During the call: End current call/Toggle audio between the phone
and speaker (long press)
General
4. Volume up
5. Power ON/OFF; Enter
Bluetooth paring mode
(Long hold while device is
o)
6. LED indicator
7. Volume down
8. Microphone
9. Stereo speaker
10. Passive radiator subwoofer
11. AUX-in jack
12. USB charging jack
13. OFF /ON switch

Page 8
Operational Instructions
Charging
- Charge your LoudSpeak’r through any USB jack or wall charger.
- The LED indicator will begin to blink blue.
- Full charge time is two hours and the LED indicator will stop
blinking.
Power Up
- Slide the switch on the back of the speaker to the ON position.
- Press and hold the until the front LED indicator turns on blue.
- To power down your speaker, hold down the button until the
speaker says “Goodbye”
- On the back of the speaker, slide the main power switch to the
OFF position to prevent accidental button presses.
Using the Audio Line in Connection (aux-input)
To playback your music via the AUX-IN port, plug a standard stereo
headphone cable (3.5 mm) from your audio device to LoudSpeak’r
and begin playback on your audio device.

Page 9
Operational Instructions
Pairing Your Bluetooth Device
Note: Please see page 16 of this manual for Bluetooth compatibility information.
Step 1: On your Loudspeak’r:
-Make sure the speaker is powered o, and the master switch on
the rear is in the ON position.
-Press and hold the button until the front LED indicator ashes
RED/BLUE.
-The speaker will say “Discovering”.
-Your speaker is now in pairing mode and is ready to connect to
your Bluetooth device.
Note: The speaker will stay in pairing mode for up to 3 minutes.
Step 2: On your compatible Bluetooth device:
-Navigate to the Bluetooth menu on your device.
-Turn on Bluetooth and begin searching for available devices
to pair.
-Select “LoudSpeak’r” from the list of results, and your device will
begin to pair.
-If your device asks for a pairing pass code, enter “0000”.
-Once paired, you will hear a voice prompt and the LED indicator on
the speaker will only ash blue.
-The LoudSpeak’r has a wireless range of up to 30 feet, and your
media device will stay connected to the speaker within that range.
Note: Many Bluetooth devices, including iPhone® devices & iPad® devices, will not require you to
enter a pairing pass code.

Page 10
Operational Instructions
Connecting to a Paired Bluetooth Device
-You will only need to pair your Bluetooth device with the speaker
one time.
-The next time your Bluetooth device and the speaker are in range
of each other, and the Bluetooth feature is turned on, they will
automatically connect.
-The speaker will only automatically connect to the last Bluetooth
device.
-If your paired device does not automatically connect, navigate to
the Bluetooth menu on your device and select LoudSpeak’r from
the list.
Note: Your LoudSpeak’r can pair with and remember multiple devices, however it can only connect
with one device at a time.
Music Playback Functions
-Once your media device is connected to the speaker, simply start
playing your music, movie or game. All the audio will automatically
be played through LoudSpeak’r.
-Press to Play/Pause the audio.
-Press to skip to the next track.
-Press to skip to the previous track.
-Press + or - to adjust the volume level of the speaker.
-When maximum or minimum volume level is reached, you will hear
an alert tone.
-During an incoming call, the music will automatically pause
playback and you can answer/reject the call using the button
controls.
Note: The volume controls on your media device work separately from the volume controls on the
LoudSpeak’r.

Page 11
Operational Instructions
Hands Free Speakerphone
Outgoing calls
To place a call, simply initiate the call from your compatible
Bluetooth phone and the call will automatically be routed through
your paired LoudSpeak’r.
Incoming calls
- Press to answer the call on your speaker.
- Press and hold to reject the call.
During a call
- Press to hang up.
- Press and hold to route the call back and forth between your
phone and the speaker.
- Double press to answer call waiting.
- Double press to toggle between the original call and the new
call.
- Press or at anytime during the call to mute your
microphone. The light indicator will blink blue.
LED Light Indicator (on front of speaker)
Symptom Solution
No light Power OFF
Flashing blue & red Pairing Mode
Solid blue Power ON (Battery level>30%)
Solid red Power ON (Battery level<30%)
Blinking red/Auto power OFF in 5 mins Power ON (Battery level<10%)
Flashing blue Charging
No light Power OFF + fully charged

Page 12
Troubleshooting
Symptom Solution
Music is not streaming over
Bluetooth
-Make sure your Bluetooth device has
A2DP prole.
-Check if both devices are paired and
connected over Bluetooth.
-Restart the LoudSpeak’r to auto-
connect with your Bluetooth device.
No power -Make sure LoudSpeak’r is fully
charged.
LoudSpeak’r doesn’t
answer phone calls
-Make sure your mobile device has
HSP/HFP prole.
-Check if both devices are paired and
connected over Bluetooth.
-Restart the LoudSpeak’r to auto-
connect with your Bluetooth device.
Music doesn’t resume aer
hanging up a call
-Press play to resume music.
No music control by
LoudSpeak’r
-Make sure your Bluetooth device has
AVRCP prole.
Remarks:
If troubleshooting does not eliminate the problem, shut down the speaker by sliding the switch on
the back to OFF . In case the problem still exists, see warranty information on page 14 and page
15 to obtain service.

Page 13
Compliance with FCC Regulations
Caution!
The user is cautioned that changes or modications not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
The equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses,
and can radiate Radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to Radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to Radio or television reception, which can be
determined by turning the equipment o and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit dierent from which the receiver is
connected.
-Consult the dealer or an experienced Radio/television technician for assistance.
This equipment complies with FCC’s RF radiation exposure limits set forth for an uncontrolled
environment. The antenna(s) used for this transmitter must be installed and operated to
provide a separation distance of at least 20 cm from all persons and must not be collocated
or operating in conjunction with any other antenna or transmitter. Installers must ensure that
20 cm separation distance will be maintained between the device (excluding its handset) and
users.
THE SPECIFICATION AND EXTERNAL APPEARANCE OF THE UNIT ARE SUBJECT TO CHANGE
WITHOUT PRIOR NOTICE.
If at any time in the future you should need to dispose of this
product, please note that waste electrical products should not be
disposed of with household waste. Please recycle where facilities
exist. Check with your local authority or retailer for recycling advice.

Page 14
Warranty Information
Limited Warranty
The AT&T brands are used under license. Any repair, replacement, or warranty
service, and all questions about this product should be directed to Concept
101 LLC at www.att.com/electronics or call 1 [phone] from the USA or
Canada.
Concept 101 LLC warrants to the original purchaser that the product will be free from defects
in material, parts and workmanship for the period designated for this product. The warranty
commences the day the product is purchased and covers up to a period of one (1) year. Concept
101 LLC agrees that it will, at its option, replace the defective product with either a new or
remanufactured headset equivalent to your original purchase during the warranty period.
Should the Parts warranty period exceed the Labor warranty period, Concept 101 LLC will supply
at no charge for the remainder of the Parts warranty, any new or remanufactured replacement
parts as required by the product. During this period all labor and service charges will become the
responsibility of the customer.
Exclusions: This warranty does not apply to the appearance or exterior of the product
which may have been damaged or defaced, altered or modied in design or
construction. This warranty does not apply if the serial number is altered or
removed, or if there is any damage due to power line surge, user damage to
the AC power cord, connection to improper voltage source, general misuse,
accidents, or repair attempts by unauthorized service agents. Other exclusions
include ear pads, rechargeable and non-rechargeable batteries.
REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS THE
EXCLUSIVE REMEDY OF THE CUSTOMER; Concept 101 LLC SHALL NOT BE
LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES FOR BREACH
OF ANY EXPRESS OR IMPLIED WARRANTY ON THIS PRODUCT, EXCEPT TO
THE EXTENT PROHIBITED BY APPLICABLE LAW. ANY IMPLIED WARRANTY
OF MERCHANTABILITY OF FITNESS FOR A PARTICULAR PURPOSE ON THIS
PRODUCT IS LIMITED TO THE DURATION OF THE WARRANTY.
Some states do not allow the exclusion or limitations of incidental or
consequential damages, or limitations on how long the warranty lasts. In
these cases the above exclusions or limitations may not apply to you. This
warranty gives you specic legal rights and you may also have other rights
which vary from state to state.

Page 15
Obtaining Service: To obtain service, product literature, supplies or accessories please
call 1 888-920-8680, or visit our website, www.att.com/electronics,
to create a ticket for exchange/repair. Please make sure to provide
the date of purchase, model number and a brief description of the
problem. Our customer service representative will contact you or
send detailed return instructions.
Concept 101 LLC does not warrant that the unit will work properly in all environmental
conditions, and makes no warranty and representation, either implied or expressed, with
respect to the quality, performance, merchantability, or tness for a particular purpose
other than the purpose identied within this user’s manual. Concept 101 LLC has made
every eort to ensure that this user’s manual is accurate and disclaims liability for any
inaccuracies or omissions that may have occurred. Information in this user’s manual is
subject to change without notice and does not represent a commitment on the part of
Concept 101 LLC. Concept 101 LLC reserves the right to make improvements to this user’s
manual and/or to the products described in this user’s manual at any time without notice.
If you nd information in this manual that is incorrect, misleading, or incomplete, please
contact us through our website.

Page 16
Specications
-Full-range dual 35mm driver + passive radiator
-Distortion <= 10%
-Frequency response: 200 Hz - 15k Hz
-Li-ion battery: 700mAh
-Playtime: up to 5 hours
-Charging time: 2 hours
-Bluetooth 2.1 + EDR
-Bluetooth compatibility: Bluetooth 2.0 or above device with A2DP/
AVRCP/HFP/HSP
* Up to 30 . wireless range as determined by Bluetooth SIG. Range may vary depending on the
line of sight obstacles.

www.att.com/electronics
© 2017 Concept 101 LLC. All Rights Reserved. AT&T and the AT&T logo are trademarks
of AT&T Intellectual Property licensed to Concept 101 LLC, New York, New York 10018.
D Issue 10.1 AT&T 9/2017.
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc.
iPhone and iPad are registered trademarks of Apple Inc., registered in the U.S. and other
countries. Other trademarks and trade names are those of their respective owners.
