ATD AIR ATD-2114 User manual
- 1 -
1/4" MINI AIR RATCHET WRENCH
ATD-2114
FreeSpeed................................. 260RPM
Maximum Torque . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 ft./lbs.
Air Inlet.................................1/4"-18 NPT
Hose Size ..................................3/8" I.D.
Rec. Air Pressure . . . . . . . . . . . . . . . . . . . . . . . .90 psig (6.2 bar)
Avg. Air Consumption.......................... 4.12 cfm
SoundLevel ................................. 97dBA
Length ........................................6.8"
ShippingWeight ..............................2.3Lbs.
SPECIFICATIONS
Some dust created by power
sanding, sawing, grinding, drilling,
and other construction activities
contains chemicals known to cause
cancer, birth defects or other
reproductive harm. Some examples
of these chemicals are:
• leadfromlead-basedpaints,
• crystallinesilicafrombricks
and cement and other
masonry products, and
• arsenicandchromiumfrom
chemically-treatedlumber.
Your risk from these exposures
varies, depending on how often you
do this type of work. To reduce your
exposure to these chemicals: work
in a well ventilated area, and work
with approved safety equipment,
such as those dust masks that are
specially designed to filter out
microscopic particles.
ALWAYS READ
INSTRUCTIONS
BEFORE USING
POWER TOOLS
• ALWAYSWEARAPPROVEDEAR
AND EYE PROTECTION.
• ALWAYSOPERATEATMAX.AIR
PRESSURE OF 90 PSIG, 6.2 BAR.
• REPETITIVEMOTION/EXTENDED
EXPOSURETOVIBRATIONMAY
HARMHANDS/ARMS.
This insTrucTion Manual
conTains iMporTanT
safeTy inforMaTion
read carefully and
undersTand all
inforMaTion BEFORE
operaTing This Tool!
save This Manual
for fuTure reference.
WARNING
WARNING
WARNING
WARNING
WARNING
WARNING
- 2 -
tool.
operating air tools can be a major
cause of serious injury or death. Be
sharp objects and heat.
Secure long hair. Scalping can occur
and accessories.
labels.
Institute Safety Code of Portable Air Tools (ANSI
B186.1) and any other applicable safety codes and
regulations.
performing maintenance on this tool.
using this tool.
condition.
injury. Never direct air at yourself or
drain hose of air pressure and detach
removing or adjusting any accessory
maintenance on this tool. Failure to do so could
result in injury. Whip hoses can cause serious injury.
detach couplings at tool. See instructions for correct
set-up.
repetitive motions or uncomfortable positions
over extended periods of time may be harmful
to your hands and arms. Discontinue use of tool
▲
!
WARNING!
FAILURE TO OBSERVE THESE WARNINGS COULD RESULT IN INJURY.
- 3 -
Operating Instructions • Warning Information • Parts Break down
Nipple
Operating Instructions…
Lubrication & Maintenance…
oil can be squirted into the tool air inlet or into the hose at
Air Supply...
pressures.
It is recommended that air pressure of these tools measures
90 psig; 6.2 bar) raises performance beyond the rated
1/4" NPT. Line pressure should be increased to compensate
for unusually long air hoses (over 25 feet). Minimum hose
diameter should be 3/8" I.D. and fittings should have the
same inside dimensions and be tightly secured.
- 4 -
ATD-2114
1/4" Mini Air
Ratchet Wrench
Ref. No. Part No. Description Qty.
1 RS2114HA Housing (incl. #37) 1
2 RS25102 Air Inlet Bushing 1
3 RS25103 Exhaust Deflector 1
4 RS15104 Throttle Lever 1
5 RS25005A Trigger Pin 1
11 RS106211 Ball Bearing 1
12 RS15112 Rear End Plate 1
13 RS15114 Rotor 1
14 RS15115 Rotor Blade 4
15 RS15113 Cylinder 1
16 RS15116 Front End Plate 1
17 RS15141 Pin 1
18 RS30524 Ball Bearing 1
20 RS15121 Internal Gear 1
21 RS15120 Idle Gear Plate (incl. #22) 1
23 RS15118 Planet Gear 3
Ref. No. Part No. Description Qty.
24 RS25124 Clamp Nut 1
26 RS25126 Bushing 1
27 RS25127 Ratchet Housing 1
28 RS15143 Washer 1
29 RS15124 Drive Bushing 1
31 *Ratchet Anvil (1/4") 1
32 *1/4") 1
33 *
34 *Spring 1
35 *
36 *Pin 1
38 *Thrust Washer (1/4") 1
39 *Retaining Ring 1
40 *Spring 2
41 *Steel Ball 2
42 *Washer 1
43 RS15144 Washer 1
44 *Spring (1/4") 1
45 *Steel Ball (1/4") 1
*
