Atek AWP 110 Series User manual

KK-AWP.001 23.06.21 Rev No:3
1
AWP 110
DRAW WIRE SENSOR USER MANUAL
Never make or undo electrical connections to the sensor when voltage is applied, otherwise this may result in damage to
devices.
M12 5 Pin Male Socket
•The installation of the product is carried out by the customer who purchases the product, according to the wiring diagrams,
installation information, etc. in this manual.
•Maintenance and repair should be done by the technicians authorized by the manufacturer firm.
•There must be minimum distance between the sensor and control unit. Avoid additions except the suitable connector unless it
needs.
•Keep away the sensor cable from as high power energy cables, contactor, motor, switched power supplies, inductive and capacitive
noisy supplies.
•Shielding edge of the sensor cable must be ground connected.
•Not to damage the sensor, supply directions and voltage must be paid attention. Don’t energize before all connections completed.
•Transport and storage should be at their original packaging and an ambient temperature of -25°C / + 85°C in such a way that they
will not be exposed to dust, humudity, impact, vibration, falling or water.
•Chemicals such as alcohol, thinner etc. should not be used for cleaning the product. The product should be wiped with a damp
cloth.
•The product may be damaged and may become unusable if used outside of the specifications in the user manual.
•The product will be out of warranty if used outside of the specifications in the user manual and opened or repaired other
than authorized services.
•
AWP 110 series draw wire sensors; consists of a rotary potentiometer which is
controled by stainless steel wire. They make measurement by pulling and rewinding
stainless steel wire.
Different measuring lengths from 200 mm to 1200 mm are available. They converts
linear motion to potentiometric output.
The “A” series, works with 24VDC supply and gives of 4-20 mA analog output with the
help of the converter card.
The “V” series, works with 24VDC supply and gives of 0-10 VDC analog output with the
help of the converter card.
Optionally, different non-standard measuring lengths, cable length or socket model
can be requested.
WARNINGS
GENERAL INFORMATION
ELECTRICAL CONNECTIONS
4-20 mA Connection
Signal
Cable Color
M12 5 pin male socket
Earth
Silver
Pin 1
+V
Red
Pin 2
-
-
Pin 3
4-20 mA
Yellow
Pin 4
-
-
Pin 5
0-10V or POTENTIOMETER Connection
Signal
Cable Color
M12 5 pin male socket
Earth
Silver
Pin 1
+V
Red
Pin 2
0V
Black
Pin 3
0-10V / Pot
Yellow
Pin 4
-
-
Pin 5

KK-AWP.001 23.06.21 Rev No:3
2
*Stroke (measuring)
length
Different measuring lengths from 200
mm to 1200 mm
Required Force
5 N
Linearity
±0.25% FS
Operating Temperature
-25°C … +85°C
*Supply Voltage
‘A‘ and ‘V’ models: 12…30 VDC
Potentiometric output model: 42V max.
Relative Humidity
%95
*Signal Output Type
Potentiometric
0-10 VDC
4-20 mA
Materials
Housing: Aluminum/steel /
plastic
Measuring Wire: Stainless steel
Measuring Type
Potentiometric
*Connection cable
length
3m (standard), 5m, 10m
*Resistance
5 KΩ (standard), 10 KΩ
IP Protection Class
IP53 (optional IP67)
Maximum Speed
2 m/s
Weight
≈550 gr
Note: The technical specifications indicated by (*) vary according to the selected model. The detailed code table is shown on page 4.
MECHANICAL MOUNTING
1- The product should be mounted to the relevant area with 2 units
M4 bolts(1) and nuts(5) from the mounting holes (2) according to the
mounting directions shown on page 3.
2- The sensor wire should be pulled towards the position to be
connected with the barrel bolt (4).
3- The sensor wire should be mounted on the device to be connected
by using the setting nut (3).
DIMENSIONS
TECHNICAL SPECIFICATIONS

KK-AWP.001 23.06.21 Rev No:3
3
2. The wire sensor must be mounted vertically in position, not be horizontally.
3. If there is a trickle of water (like a rain), the wire outlet must not be a drip of water upstream. If needed please use guide
rollers.
4. The wire should not be pulled in angular. If needed, please use guide rollers.
1. Never release the wire after pulling. Otherwise, the coil spring will be damaged.
Guide Roller
Guide Roller
Important Note(!): Failure to comply with these recommendations, the malfunctions that may occur will not be
under the warranty.
Product
Description
AWP 110
Draw Wire Sensor
Mounting Equipment
2 pcs. M4 bolts and nuts
User Manual
1 pcs.
BOX CONTENTS
MOUNTING AND USAGE WARNINGS
Guide Roller

KK-AWP.001 23.06.21 Rev No:3
4
Stroke Length (1)
Different measuring lengths
from 200 mm to 1200 mm
(1) For other (special production) stroke lengths, please contact us.
(2) For other resistance options, please contact us.
(3) Please contact us for other cable length and socket model requests.
Sample Code 1: AWP-110-300-5K-S13-A
Explanation: AWP 110 series, 300 mm stroke, 5K resistance, 1 pcs M12 5 pin male socket, current output
Electrical Connection(3)
3M : 3 m
5M : 5 m
10M : 10 m
S13: M12 5 pin male socket
AWP 110 XXX XX XXX
PRODUCT CODE TABLE
Model
AWP 110
Output Signals
No Code : Potentiometric
V : 0-10 VDC
A : 4-20 mA
Disposal of Packagings: Packaging materials consist of recyclable materials. For providing
recycling, please dispose waste packagings to collecting points of authorized recycling facilities.
Disposal of E-Waste: This device is in conformity with WEEE Directive and consists of recyclable
materials. This product should not be disposed with general waste for preventing negative effects
on enviroment and human health. This product should be disposed to collecting points of
authorized recycling facilities. Further information can be reached from authorized unit.
Manufacturer Firm’s Title, Address Details
Manufacturer Firm: ATEK ELEKTRONİK SENSÖR TEKNOLOJİLERİ SANAYİ VE TİCARET A.Ş.
Address: Gebze OSB, 800. Sokak, No:814 Gebze/KOCAELİ/TURKEY
TEL: [phone] FAX: [phone]
Web: www.ateksensor.com E-mail: [e-mail]
Authorized Service’s Title, Address Details
Authorized Service: ATEK ELEKTRONİK SENSÖR TEKNOLOJİLERİ SANAYİ VE TİCARET A.Ş.
Address: Gebze OSB, 800. Sokak, No:814, Gebze/KOCAELİ/TURKEY
TEL: [phone] FAX: [phone]
Web:www.ateksensor.com E-mail: [e-mail]
Resistance (2)
5K: 5 KΩ (standard)
10K: 10 KΩ
