ATI Technologies AT-009 Series User manual

AT-009 SERIES
GRAPHIC CARD
USER
MANUAL
For any driver updates, please refer to ATI’s website:
www.ati.com
DOC No. : M02501
Rev. : A0
Date : 7, 2002
Part No. : 25-12164-00

i
i
Chapter 1 Overview
AT-009 Series Card...................................................... 1-1
1.1 Performance............................................................ 1-3
1.2 Software Compatibility.......................................... 1-3
1.3 Monitor Compatibility........................................... 1-3
Chapter 2 Installation
2.1 What’s Included In the Package.............................. 2-1
2.2 Installing the Card................................................... 2-1
2.3 AT-009 Card Layout.............................................. 2-3
Chapter 3 Software Utility
3.1 Installing on Windows 95/98/ME........................... 3-2
3.2 Installing on Windows 2000................................... 3-5
3.3 To enable/disable a display device.......................... 3-8
3.3.1 To adjust your monitor screen size............ 3-9
3.3.2 To adjust your monitor synchronization.... 3-10
3.4 Dual display Device Options................................. 3-11
3.5 Using the CRT/TV Features................................... 3-12
3.5.1 How to use TV-out cables correctly........... 3-12
3.5.2 How to change TV setting.......................... 3-12
Chapter 4 Using HydraVisionTM
Appendix ASpecifications
A.1 Hardware Specificatoins........................................ A-1
A.2 Programming Information...................................... A-2
A.3 Resolution Table.................................................... A-2
Table of Contents

AT-009 SERIES GRAPHIC CARD USER MANUAL
ii
This Page Left Blank for Note

Handling Precautions
Warning :
1. Static electricity may cause damage to the integrated circuits on the
card.
Before handling any card outside of its protective packaging,
ensure that there is no static electric charge in your body.
2. There is a danger of explosion if the battery is incorrectly replaced.
Replace only with the same or an equivalent type recommended by
|||||the manufacturer.
Observe the following basic precautions when handling the card or
other computer components:
nWear a static wrist strap which fits around your wrist and is
connected to a natural earth ground.
nTouch a grounded or anti-static surface or a metal fixture such as a
water pipe.
nAvoid contacting the components on add-on cards, boards and
modules with the “gold finger” connectors plugged into the
expansion slot. It is best to handle system components by their
mounting bracket.
The above methods prevent static build-up and cause it to be
discharged properly.
Trademark
All trademarks mentioned in this manual are registered properly of
the respective owners.
Copyright
This manual may not, in whole or in part, be photocopied,
reproduced, transcribed, translated, or transmitted in whatsoever
form without the written consent of the manufacturer, except for
copies retained by the purchaser for personal archival purposes.
Notice

1-1
Overview
AT-009 Series Card
RADEON™ 9000/9000 Pro is a powerful and versatile graphic
solution. RV250 graphics technology from ATI delivers high-end
performance and features to the mainstream market.From 3D gaming or
business multimedia applications, to DVD and streaming video, RV250
has the horsepower and advanced technology to deliver a cutting-edge
experience. It is the perfect solution for those that hunger for all the
features one would expect in a top-of-the-line product, but need them at
an affordable price.
Features:
•Powered by the RADEONTM 9000/9000 Pro graphics
processing unit (GPU)
•Supports DirectX 8.1 ® and OpenGL®; also, 3D resolutions
(32-bit color) up to 2048x1536
•AGP universal bus (for AGP 2X/4X systems)
•Features ATI’s innovative TRUFORM™technology that makes
the outlines of 3D characters and objects look smoother and
more natural than ever before
•SMARTSHADER™technology takes advantage of the
DirectX®8.1 features to enable more complex and realistic
texture and lighting effects
•SMOOTHVISION™anti-aliasing –the most advanced anti-
aliasing to eliminate distracting visual artifacts for smoother
looking images and without serious performance compromise
•CHARISMA ENGINE™ II supports full Transformation,
Clipping and Lighting (T&L) at 50 million triangles/second peak
processing capability
Chapter 1

AT-009 SERIES GRAPHIC CARD USER MANUAL
1-2
•HYPER Z™ II technology conserves memory bandwidth for
improved in demanding applications and boosts effective
bandwidth by over 25%
•PIXEL TAPESTRY™ II, the RADEON 9000/9000 Pro™3D
rendering engine, power an incredible 2.4 Gigatexels per
second for the highest fill rates in 32-bit at high resolutions
•VIDEO IMMERSION™ II technology enables integration of
industry-leading digital video features, including advanced
deinterlacing algorithms for unprecedented video quality and
integrated digital TV decode capability
•Integrated Transformation, Clipping and Lighting
•Twin Cache Architecture
•SuperScalar Rendering
•Single-Pass Multi-Texturing
•True Color Rendering
•Triangle Setup Engine
•Texture Cache
•Bilinear/Trilinear Filtering
•Line & Edge Anti-Aliasing
•Full-Screen Anti-Aliasing
•Texture Compositing
•Texture Decompression
•Specular Highlights
•Perspectively Correct Texture
•Mapping
•Mip-Mapping
•Z-Buffering and Double-Buffering
•Emboss, Dot Product 3 and Environment bump mapping
•Spherical, Dual-Paraboloid and Cubic environment mapping
•Fog effects, texture lighting, video textures, reflections,
shadows, spotlights, LOD biasing and texture
•Dual independent displays (DVI/CRT, DVI/TV, CRT/TV)
∗Provides S-videio connect (optional)
∗Provides DVI (Digital Visual Interface) output port (optional)
∗HydraVision™software (optional)

Overview
1-3
1.1 Performance
The card is a graphics accelerator. Computer functions like disk access
and numerical calculation are not accelerated by the card. Because
these operations also occur as Windows programs are running, the
overall speed will depend on the mix of graphics operations and the
other types of operations. It is not unusual to obtain an overall system
speed increase of 2 times after installing the card. The speed of pure
graphics operations, like dragging objects with a mouse, scrolling, and
resizing, will be remarkably improved.
1.2 Software Compatibility
The key function of the card is its VGA compatibility. Unlike
coprocessor-based, or IBM8514A-type display cards, the card is 100%
compatible with your DOS computer. This means that all DOS software
will run correctly with the VGAcard without modification.
The VGA compatibility includes backward compatibility with the EGA,
CGA and MDA standards. All DOS software will include drivers for at
least one of these display types and will be fully compatible with the
card. The card is also fully compatible with AGP BIOS extensions for
resolutions higher than 640 by 480.
When the card is used in VGA, backward compatibility, 16-color AGP
modes, or the graphics engine of the ATI RADEON 9000/9000 Pro
card is not used. The speed in these modes will be comparable to the
fastest type of standard VGA card.
1.3 Monitor Compatibility
The card will work with any VGA, Super VGA or Multisync monitor.

AT-009 SERIES GRAPHIC CARD USER MANUAL
1-4
Super VGA monitors can support IBM standard VGA plus the 800x600
extended mode used by most VGA cards, and the 1024x768 interlaced
mode used by most VGA cards and the IBM 8514A.
Multisync monitors are more expensive and will work at all Super VGA
resolutions plus additional higher resolutions or refresh rates. The most
useful multisync monitor specification for determining maximum
resolution and refresh capability is the horizontal frequency range. For
PC use, the lower limit of the range must be no less than 30KHz. The
upper limit is usually 48K Hz, 57K Hz or 64K Hz. These correspond to a
maximum resolution of 1024 x 768, 60 Hz refresh, 1024 x768, 72 Hz refresh
rate; and 1280x1024, 60 Hz refresh rate, respectively.
By default, the card will drive your monitor at a screen refresh rate of 60
Hz. In other words, it repaints the screen 60 times per second. If the
screen is not displayed properly when you boot your system, your
monitor may not support this refresh rate for the resolution chosen. In
this case, you must either lower the resolution to one that can be
supported at 60Hz or lower the refresh rate. The maximum refresh rate
supported by your monitor is specified with the Refresh Rate utility.
Refer to your manual for information on the monitor capabilities. If you
are not sure what refresh rate is supported, you can always try a higher
rate. If the screen looks good, the rate is supported (and will be easier
on your eyes).

2-1
Installation
2.1 What’s Included in the Package
The VGA card package includes the following:
1. VGA card accelerator card
2. Software diskettes which contain the necessary files
3. This manual
2.2 Installing the Card
1. Unplug the computer and remove the cover.
Shut down the computer and turn off any attached equipment (such as
a monitor or printer).
Unplug the power cord.
Remove the cover.
2. Remove the current graphics card.
If there is a graphics card currently in the computer, use the following
guidelines to remove it:
Detach any cables which are attached to the current graphics card and
remove the bracket screw locking the card down.
Grasp the card by the edges and pull it
straight out of the motherboard slot. If
the card sticks in the slot, rock it gently
from end to end to dislodge it.
Remember to save the screw.
Chapter 2

AT-009 SERIES GRAPHIC CARD USER MANUAL
2-2
Note:
If the computer has a graphics chip soldered down on the
motherboard, refer to the manual for the system or motherboard
for information on how to disable it.
3. Insert the Graphics Accelerator card.
Locate the empty AGP socket on the
motherboard and use the following
instructions to insert the Graphics
Accelerator reference card into that
socket:
Grasp the Graphics Accelerator
reference card by its edges.
Align it with the empty AGP socket on
the motherboard, and gently insert it into place.
Make sure that the card is pressed evenly and completely into the
socket.
Fasten the card with the bracket screw.
Note:
Use the figure above to help locate the Accelerated Graphics Port
(AGP) socket on your motherboard. The exact configuration of the
components on your motherboard may differ from the figure. Look
for a single, smaller socket between the set of PCI sockets and
the processor.
4. Reconnect all cable and Replace the cover.
Plug the cable from your
computer monitor into the back
of the Graphics Accelerator
reference card. Make sure it is
securely fastened. Carefully
replace the computer cover and
plug the power cord back in.

Installation
2-3

AT-009 SERIES GRAPHIC CARD USER MANUAL
2-4
Caution!
Before you turn on your system, you have to be sure the
VGA card is setup already and all the cables are connected.
DO NOT connect / disconnect TV-out cable when your TV or
PC is Power On.
2.3AT-009 Card Layout

Installation
2-5
This Page Left Blank for Note

3-1
Software Utility
The card is 100% VGA compatible and as such needs no special display
drivers to run application software correctly at standard VGA
resolutions and color depths. However, enhanced display drivers are
supplied with the VGA card because they provide accelerated
performance, higher color depths and higher resolutions for software
applications. The VGA card supports resolutions as high as 1600x1200
pixels, and color depths of up to 32 bits per pixel. Higher graphics
resolutions and higher color depths provide greater clarity and detail
when using the supplied drivers for graphics programs. When
configuring your software to work with the board, it may help to bear in
mind that the drivers compatible with the VGA card fall into four
categories.
Driver Installation Procedure
General Installation Notes:
1. Before install Windows 95 Driver, please install Windows 95
OSR2.0 ”USBSUPP.EXE” first (brings it up to OSR2.1 level).
2. The operating system and DirectX* must be installed on the
system prior to installation.
To install Windows 95 OSR2.0 with USB, you must have OSR2.0
installed already. Otherwise, first install OSR2.0 and then use the USB
support update (your must use the same update language of your
Windows language).
<Install USBSUPP
1. Start Windows Explorer.
2. Click on the CD ROM drive to display the contents of the CD ROM
disk.
3. Double click on D:\USBSUPP\USBSUPP.EXE (English)
(If D is not your CD-ROM drive, substitute D with the correct drive letter.)
Chapter 3

AT-009 SERIES GRAPHIC CARD USER MANUAL
3-2
OSR2.0 with USB has:
Version “Windows 95” and Version Number “4.03.1212” or
“4.03.1214”.
3.1 Installing on Windows 95/98/ME
General Installation Notes:
•If your motherboard does not support Intel processor, please
install the AGP Driver provided by the motherboard company
before you install VGA Driver.
•Before installing our user-friendly VGA configuration utility, please
set up the VGA display as ”standard PCI Graphics Adapter” mode.
•Microsoft DircetX allows 3D hardware acceleration support in
Windows 95/98. For software MPEG support in Windows 95/98,
you must first install the Microsoft DirectX, and then an MPEG
Video Player.
1. Start Windows.
2. Switch display to Windows’ Standard Display Adapter (VGA)
mode and then restart Windows.
3. Insert the CD installation disc into your CD-ROM drive.
4. The CD should autorun andthe following screen will appear.

Software Utility
3-3
5. When the Welcome box appears. Click on the "Next" button to go
to the next step.
6. The License Agreement dialog box appears. Click on “Yes”
button.

AT-009 SERIES GRAPHIC CARD USER MANUAL
3-4
7. When the Windows SETUP has completed copying the files to the
computer. Windows will prompt you to restart Windows with the
“Yes” option. Thenclick on “Finish” button.

Software Utility
3-5
3.2 Installing on Windows 2000
1. Start Windows.
2. When Windows detects your graphics card, the Found New
Hardware Wizarddialog box appears.
3. Click Cancel to enter the Windows desktop.
4. Insert the CD installation disc into your CD-ROM drive.
5. The CD should autorun andthe following screen will appear.

AT-009 SERIES GRAPHIC CARD USER MANUAL
3-6
6. When the Welcome box appears. Click on the "Next" button to go
to the next step.
7. The License Agreement dialog box appears. Click on “Yes”
button.

Software Utility
3-7
8. The “Digital Signature Not Found” dialog box appears. Click on
“Yes” button.
9. When the Windows SETUP has completed copying the files to the
computer. Windows will prompt you to restart Windows with the
“Yes” option. ThenClick “Finish” button.
