Atlantic EPIC 1D Guide

ENGLISH
CONTROL
POWER
CONTROL
W
W
W
.
A
T
L
A
N
T
I
C
O
N
T
R
O
L
.
C
O
M
Installation
ad use
manual
RANGE
EPIC 1D
0,37÷15 kW
0,50÷20 Hp
MADE IN ITALY

2
EPIC 1D
Index
EPIC 1D
Introduction
1.1 PRESENTATION pag. 3
1.2 DESCRIPTION pag. 3
1.3 HANDLING pag. 3
Safety informations
2.1 WARNINGS pag. 4
2.2 CAUTION pag. 4
Installation
3.1 ASSEMBLING pag. 5
3.2 ELECTRICAL CONNECTIONS pag. 6
3.3 ADJUSTMENTS AND SETTINGS pag. 8
(INITIALIZATION)
3.4 ADJUSTMENTS AND SETTINGS pag. 10
(ADVANCED MENU)
3.5 TRIMMER SETTINGS pag. 26
3.6 CONTACT ALARM OUTPUTS pag. 26
General use
4.1 KEYPAD AND LIGHTS INDICATIONS pag. 27
4.2 ALARMS pag. 28
4.3 TYPICAL INSTALLATIONS pag. 30
Maintenance
5.1 PUMPS STOP pag. 32
5.2 SERVICE pag. 32
5.3 SPARE PARTS pag. 32
5.4 WASTE DISPOSAL pag. 32
Certifications
6.1 CERTIFICATE OF CONFORMITY pag. 33

3
EPIC 1D
Introduction
1.1 PRESENTATION
The purpose of this manual is to provide the
necessary information for the proper installation,
use and maintenance of EPIC 1D.
The user should read this manual before operating
the unit. Improper use may cause damage to
the machine and lead to the forfeiture of the
warranty coverage. Always specify the model
identification code and the construction number
when requesting technical information or spare
parts from our Sales and Service department.
The instruction and warnings given below
concern the standard version; refer to the sale
contract documentation for modifications and
special version characteristics. For instructions,
situations and events not considered in this
manual or in the sale documents, please contact
our customer service.
Our units must be installed in sheltered, well-
ventilated, non-hazardous environments and
must be used at a maximum temperature of
+40°C and minimum of -5°C.
These control panels are designed for controlling
1 motor or electric pump used in pressurization
systems or in applications for emptying wells or
water tanks. In case of any failure of the main
pump, the reserve pump start automatically.
Atlantic Power Control S.r.l.s. shall not be
liable for any damage caused or suffered by
the unit as a result of its unauthorised or
improper use.
TECHNICAL FEATURES
Self learning of the motor data; min-max
amperage protection (A); dry running protection
made by cosφamd min Amperage; min and max
voltage protection (V); phase failure protection;
start and stop delay; delay network restore,
protection delay, frequency 50-60Hz.
OUTPUT ALARMS AND PROTECTIONS
Acoustic alarm; light alarm, alarm output Relais
220 V - 400 V CA, alarm output Relais 12 V CC,
alarm output with Buzzer 12 V; min-max water
level; min-max Voltage; phase failure; frequency
failure alarm; min-max motor Amperage; min
cosφ; motor klixon alarm; water in oil chamber
alarm.
1.2 DESCRIPTION
The control panel must be handled with
care, as falls and knocks can cause damage
without any visible external signs.
PRELIMINARY INSPECTION
After you have removed the external packaging,
visually inspect the control panel to make sure it
has suffered no damage during shipping.
If any damage is visible, inform an Atlantic dealer
as soon as possible, no later then five days from
the delivery date.
STORED
If for any reason the unit is not installed and
starter immediately after it has reached its
destination it must be stored properly. The
external packaging and the separately packed
accessories must remain intact, and the whole
must be protected from the weather, especially
from freezing temperatures, and from any
knocks or falls.
1.3 HANDLING

4
EPIC 1D
Warnings
2.1 SAFETY INFORMATION
RISK OF ELECTRIC SHOCK
Failure to follow the instructions in this manual, carries a risk of electric shock.
RISK FOR PEOPLE AND PROPERTY
Failure to follow the prescriptions in this manual, carries a risk of damage to persons
and/or property.
WARNING
Failure to observe the prescriptions in this manual, cause damage to the pump, the
unit or the system.
2.2 CAUTION
Connect the unit at ground before carrying
out any other operation.
The voltage input corresponds to the data
written on the panel and on the pump:
• (400V ± 10% 50/60Hz x il EPIC 1D -400/...)
• (230V ± 10% 50/60Hz x il EPIC 1D -230)
Make sure that the power-supply-cable can bear
the nominal current and connect it to the terminals
of the general switch of the control panel. If the
cables are exposed, they must be appropriately
protected. The line must be protected with an
Earth leackage and magnetic switch measured in
accordance with the regulations locally in force.
LINE OF SUPPLY CURRENT
The voltage input corresponds to the data
written on the motor:
• (400V±10% 50/60Hz three-phase)
• (230V±10% 50/60Hz single-phase)
Doing some starting make sure that the motor
respects the right direction of rotation usually
indicated by an arrow printed on the motor.
LINE OF MOTOR POWER SUPPLY
ATTENTION: PUMP
• Make sure the pump is fully primed before you start it.
• Make sure the pump is running with the correct rotation.
• The electric pump or the motor can start up automatically.
ATTENTION: ELECTRICAL CONNECTION
• The control panel must be connected by a qualified electrician in compliance with
the electrical regulations in force.
• The electric pump or the motor and the panel must be connected to an efficient
grounding system in compliance with the electrical regulations locally in force.
• Ground the unit before carrying out any other operation.
ATTENTION: SERVICE
As a general rule, always disconnect the power supply before proceeding to carry out
any operation on the electrical or mechanical components of the unit or system.

5
EPIC 1D
Installation
3.1 ASSEMBLING
Fix the control panel for a stable support with
screws and screw anchor using the holes
arranged in the box.
To fix the cables in their terminals use a tool
of the proper sizeto avoid the damaging of the
screws or of their seat.
If use an electric screwier pay attention not to
spoil the thread or the screws.
After the fixing, remove every plastic or metallic
surplus (ex. pieces of copper of the cables or
plastic shavings of the box) inside the box before
suppling power.
330 mm
414 mm
150 mm
140 mm300 mm
300 mm
300 mm
250 mm
250 mm
300 mm
330 mm
280 mm
414 mm
434 mm
260 mm
240 mm
133 mm 260 mm
191 mm
240 mm
257 mm

6
EPIC 1D
Installation
3.2 ELECTRICAL CONNECTIONS
EPIC 1D 230
230 V
50÷60 Hz
N L C
M
1 2 3
LN
H2O water in oil chamber
G1 float switch min level
G2 float switch 2 G3 float switch 3
G4 float switch max level
K klixon
12 Vcc output alarm
/ N.O.
230 V output alarm
2 3 C
CLC
buzzer alarm
SW1 dip-switch
trimmer 1
4÷20 mA sensor
capacitor

7
EPIC 1D
Installation
EPIC 1D 400
400 V
50÷60 Hz
TR SU V W
M
H2O water in oil chamber
G1 float switch min level
G2 float switch 2 G3 float switch 3
G4 float switch max level
K klixon
12 Vcc output alarm
/ N.O.
400 V output alarm
2 3 C
CLC
buzzer alarm
SW1 dip-switch
trimmer 1
4÷20 mA sensor

8
EPIC 1D
Installation
3.3 ADJUSTMENTS AND SETTINGS (INITIALIZATION)
After making all the electrical connections,
switch on the control panel and wait for the
initial message to appear on the display.
To proceed with self-learning procedure , the
pump must first be triggered.
Do not press confirm, but start the pumps,
keeping the “MAN” button pressed (for 3 sec.).
Select the display language by scrolling the menu
with the appropriate arrows (step 1 and 2).
When completed, press the confirm button (step 3)
to continue.
LANGUAGE SETTING (OBLIGATORY)
>LANGUAGE
>ITA
>LANGUAGE
>ITA
>LANGUAGE
>ENG
Step 1 Step 2 Step 3
PUMP TRIGGER
AUTOTUNING: P1
PUSH CONFIRM
MANUAL P1
COSφ: x.xx
Step 4 P1
3 sec.
CONTROL PANEL TURN ON
>LANGUAGE
>ITA

9
EPIC 1D
IMPORTANT!
After pressing the final confirmation button, self-learning is no longer possible.
To perform the self-learning again it is necessary to access the advanced menu
(3.4).
Installation
To start the self-learning of the pump data,
type reply (step 5).
For the final confirmation of the data (step 7) type
“YES”, or enter “NO” to go back (to step 5).
AUTOTUNING (OBLIGATORY)
AUTOTUNING: P1
PUSH CONFIRM
AUTOTUNING: P1
xxxV xxA 09
CONFIRM DATA?
YES no
Step 5 Step 6 Step 7
Before starting the self-learning
procedure, it is necessary to
check with a tester that the
mains voltage corresponds to
the nominal one or at least to
the mains voltage.
Once the self-learning phase is completed, the
display of the panel displays the data learned.
By pressing the “AUT” P1 button the panel
becomes operational.
CONTROL PANEL OPERATIVITY
xxxV xxHZ
POTABLE EMPTY
Step 8 P1
PRESET PARAMETERS
LANGUAGE: selected STOP DELAY: 1 sec.
TURN ON DELAY: 2 sec. OPERATION: emptying
MANUAL KEY: unstable TYPE: potable
START DELAY: 4 sec. SELF HOLDING: on

10
EPIC 1D
3.4 ADJUSTMENTS AND SETTINGS (ADVANCED MENU)
Installation
ACCESS TO ADVANCED MENU
54321
ON
DIP-SWITCH 2
The control panel is set as standard with the dip-switch
2 in the “OFF” position. To access the “ADVANCED
MENU” and modify the various parameters, switch
off the control panel and set dip-switch 2 to “ON”.
Then turn the control panel back on to display the
message on the “ADVANCED MENU” on the display.
>SETTING
>PARAMETERS [OK]
SETTING PARAMETERS
To access the advanced menu and set the various
parameters, enter confirmation. On the display will appear
in cascade all the fuctions. To enter each individual function,
select it with the arrows and enter the confirmation button.
EXIT M06 PROGRAM
M01 UTILITY M07 SENSOR
M02 GENERAL M08 TIMER
M03 NET CONTROL EXIT
M04 PUMP 1
CONFIRM MODIFICATIONS AND EXIT FROM ADVANCED MENU (EXAMPLE)
LANGUAGE
>ENG
M01 UTILITY
>LANGUAGE
>M01 UTILITY
LANGUAGE
>M01 UTILITY
M02 GENERAL
>EXIT
M01 UTILITY
>SETTING
>PARAMETER [OK]
54321
ON
DIP-SWITCH 2
Once the setting of the various parameters has been
confirmed (for example the LANGUAGE parameter), to
exit the “ADVANCED MENU” bring the dip-switch 2
back to the “OFF” position.

11
EPIC 1D
ACCESS TO FUNCTION MODIFIED PARAMETERS
>M01 UTILITY
M02 GENERAL
LANGUAGE (default: as selected)
Language selection
START DELAY (default: 2 sec.)
Control panel switch-on delay after restart (in sec.)
MANUAL KEYPAD (default: OFF)
Possibility of operating the “MAN” button in stable or
unstable mode (ON: stable / OFF: unstable)
MAX LEVEL ALARM DELAY (default: OFF)
Possibility to delay 15 minutes. (not modifiable) the
maximum level alarm. The display will show the alarm
and the pump will start (if available), only the alarm
relay and the buzzer will be delayed.
M01 UTILITY
CHANGE LANGUAGE
LINGUA
>ENG
M01 UTILITY
>LANGUAGE >EXIT
M01 UTILITA’
>LINGUA
>LINGUA
ITA
LINGUA
>ITA
CHANGE START DELAY
START DELAY
>102 SEC
M01 UTILITY
>START DELAY >EXIT
M01 UTILITY
>START DELAY
>START DELAY
002 SEC
START DELAY
>002 SEC
Installation

12
EPIC 1D
CHANGE “MAN” BUTTON (STABLE/UNSTABILE)
M01 UTILITY
>MAN. MODALITY
>MAN. MODALITY
OFF
MAN. MODALITY
>OFF
MAN. MODALITY
>ON
M01 UTILITY
>MAN. MODALITY >EXIT
Installation
CHANGE MAX LEVEL ALARM DELAY
M01 UTILITY
>MAX LEV ALL.DEL
>MAX LEV ALL.DEL
OFF
MAX LEV ALL.DEL
>OFF
MAX LEV ALL.DEL
>ON
M01 UTILITY
>MAX LEV ALL.DEL >EXIT

13
EPIC 1D
M02 GENERAL
CHANGE START DELAY
START DELAY
>04
M02 GENERAL
>START DELAY >EXIT
M02 GENERAL
>START DELAY
>START DELAY
04
START DELAY
>04
CHANGE STOP DELAY
STOP DELAY
>01
M02 GENERAL
>STOP DELAY >EXIT
M02 GENERAL
>STOP DELAY
>STOP DELAY
01
STOP DELAY
>01
Installation
ACCESS TO FUNCTION MODIFIED PARAMETERS
M01 UTILITY
>M02 GENERAL
PUMP START DELAY (default: 4 sec.)
Set the pump start delay
PUMP STOP DELAY (default: 1 sec.)
Set the pump stop delay

14
EPIC 1D
Installation
M03 NET CONTROL
CHANGE NOMINAL VOLTAGE
NOM. VOLTAGE
>XXX VOLT
M03 NET CONTROL
>NOM. VOLTAGE >EXIT
M03 NET CONTROL
>NOM. VOLTAGE
>NOM. VOLTAGE
XXX VOLT
NOM. VOLTAGE
>XXX VOLT
CHANGE MINIMUM VOLTAGE
MIN VOLTAGE
>090 %
M03 NET CONTROL
>MIN VOLTAGE >EXIT
M03 NET CONTROL
>MIN VOLTAGE
>MIN VOLTAGE
090 %
MIN VOLTAGE
>090 %
ACCESS TO FUNCTION MODIFIED PARAMETERS
M02 GENERAL
>M03 NET CONTROL
NOMINAL VOLTAGE (default: autotuning read)
Set the nominal voltage
MINIMUM VOLTAGE (default: 90%)
Set the minimum voltage
MAXIMUM VOLTAGE (default: 110%)
Set the maximum voltage
NOMINAL FREQUENCY (default: autotuning read)
Set the nominal frequency
FREQUENCY RANGE (default: 10%)
Set the frequency range

15
EPIC 1D
Installation
CHANGE MAXIMUM VOLTAGE
MAX VOLTAGE
>110 %
M03 NET CONTROL
>MAX VOLTAGE >EXIT
M03 NET CONTROL
>MAX VOLTAGE
>MAX VOLTAGE
110 %
MAX VOLTAGE
>110 %
CHANGE NOMINAL FREQUENCY
NOM. FREQUENCY
>50 HZ
M03 NET CONTROL
>NOM. FREQUENCY >EXIT
M03 NET CONTROL
>NOM. FREQUENCY
>NOM. FREQUENCY
50 HZ
NOM. FREQUENCY
>50 HZ
CHANGE FREQUENCY RANGE
FREQ. RANGE
>10 %
M03 NET CONTROL
>FREQ. RANGE >EXIT
M03 NET CONTROL
>FREQ. RANGE
>FREQ. RANGE
10 %
FREQ. RANGE
>10 %

16
EPIC 1D
Installation
M04 PUMP 1
AUTOTUNING
AUTOSET: P1
XXXV XXA 09S
M04 PUMP 1
>AUTOTUNING >EXIT
M04 PUMP 1
>AUTOTUNING
>AUTOTUNING
ON
AUTOTUNING
>ON
CHANGE NOMINAL CURRENT
NOM. CURRENT
>XXX.X
M04 PUMP 1
>NOM. CURRENT >EXIT
M04 PUMP 1
>NOM. CURRENT
>NOM. CURRENT
000.1
NOM. CURRENT
>000.0
ACCESS TO FUNCTION MODIFIED PARAMETERS
>M04 PUMP 1
M06 PROGRAM
The amperage value and cosφ shown on the display
may differ ±5% from the nominal value of the pump
(nameplate data) since the control panel is not a
measuring instrument. The same value may differ
depending on the operating conditions of the installation.
AUTOTUNING
It allows the self-learning of the data to be carried out again
NOMINAL CURRENT (default: autotuning read)
Set nominal/operating current of the pump
MINIMUM AMPERAGE (default: 85%)
Current setting min. for dry running protection
MAXIMUM AMPERAGE (default: 130%)
Max current setting for overcurrent protection
START PER HOUR (default: 30)
Set max number of pump starts per hour
MIN COSφ(default: 75% of value read in autotuning)
Set min. cosφfor dry running protection

17
EPIC 1D
Installation
CHANGE MINIMUM AMPERAGE
MIN AMPERAGE
>XXX %
M04 PUMP 1
>MIN AMPERAGE >EXIT
M04 PUMP 1
>MIN AMPERAGE
>MIN AMPERAGE
085 %
MIN AMPERAGE
>085 %
CHANGE MAXIMUM AMPERAGE
MAX AMPERAGE
>XXX %
M04 PUMP 1
>MAX AMPERAGE >EXIT
M04 PUMP 1
>MAX AMPERAGE
>MAX AMPERAGE
130 %
MAX AMPERAGE
>130 %
CHANGE START PER HOUR
START PER HOUR
>XX
M04 PUMP 1
>START PER HOUR >EXIT
M04 PUMP 1
>START PER HOUR
>START PER HOUR
06
START PER HOUR
>06

18
EPIC 1D
Installation
CHANGE MIN COSφ
MIN. COSφ
>X.XX
M04 PUMP 1
>MIN. COSφ>EXIT
M04 PUMP 1
>MIN. COSφ
>MIN. COSφ
X.XX
MIN. COSφ
>X.XX

19
EPIC 1D
Installation
OPERATION (EMPTY/FILL)
OPERATION
>FILL
M06 PROGRAM
>OPERATION >EXIT
M06 PROGRAM
>OPERATION
>OPERATION
EMPTY
OPERATION
>EMPTY
M06 PROGRAM
TYPE (POTABLE/WASTE WATER)
TYPE
>WASTE
M06 PROGRAM
>TYPE >EXIT
M06 PROGRAM
>TYPE
>TYPE
POTABLE
TYPE
>POTABLE
ACCESS TO FUNCTION MODIFIED PARAMETERS
M04 PUMP 1
>M06 PROGRAM
For “waste water” type, only “EMPTY” function is available.
SELF HOLDING OPERATION (WASTE WATER)
When “self holding“ is on and “waste water“ selected,
the float G1 is the STOP for both pumps (P1-P2).
Conseguently G2 and G3 floats in only starts
OPERATION (default: EMPTY)
Emptying selection “EMPTY” or filling ”FILL“
TYPE (default: POTABLE)
Selection between clear (potable) and waste water
SELF HOLDING (default: ON)
Possibility to carry out a rapid emptying of the tank,
mostly used for waste water applications
BMS (remote emergency start/stop) (default: OFF)
Possibility to start/stop the panel by remote button. The
use of “BMS” function works thanks to G4 input (closed
contact: pumps enabled / contact open: pumps disabled)

20
EPIC 1D
Installation
SELF HOLDING
SELF HOLDING
>OFF
M06 PROGRAM
>SELF HOLDING >EXIT
M06 PROGRAM
>SELF HOLDING
>SELF HOLDING
ON
SELF HOLDING
>ON
BMS SETTING
BMS
>ON
M06 PROGRAM
>BMS >EXIT
M06 PROGRAM
>BMS
>BMS
OFF
BMS
>OFF
