Atlas Copco D2160-Q Instruction sheet

D2160-Q
Printed Matter No. 9839 1477 01 Straight drill
Publication Date 2018-11-14
Valid from Serial No. A0770001 Product Instructions
D2160-Q (2400 r/min) 8421041020
WARNING
Read all safety warnings and instructions
Failure to follow the safety warnings and instructions may result in
electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference

2© Atlas Copco Industrial Technique AB - 9839 1477 01
Table of Contents
Product information................................................................................................3
General information ..........................................................................................3
Safety signal words ...............................................................................3
Warranty ................................................................................................3
ServAid ..................................................................................................3
Website..................................................................................................4
Safety Data Sheets MSDS/SDS............................................................4
Country of origin ....................................................................................4
Dimensional drawings ...........................................................................4
Overview...........................................................................................................4
Applications ...........................................................................................4
Service overview...............................................................................................4
Maintenance and service instructions ...................................................4
Service recommendations .....................................................................5
Preventive maintenance ........................................................................5
Installation ...............................................................................................................6
Installation requirements...................................................................................6
Air quality...............................................................................................6
Air lubrication guide ...............................................................................6
Compressed air connection...................................................................6
Installation instructions .....................................................................................7
Installing the drill....................................................................................7
Operation .................................................................................................................8
Ergonomic guidelines .......................................................................................8
Operating instructions.......................................................................................8
Operating the drill ..................................................................................8
Service ...................................................................................................................10
Maintenance instructions ................................................................................10
Maintenance and service instructions .................................................10
Service recommendations ...................................................................10
Preventive maintenance ......................................................................10
Lubrication instructions ...................................................................................10
Rust protection and cleaning ...............................................................10
Lubrication guide .................................................................................10
Maintenance and lubrication................................................................11
Dismantling/Assembling instructions ..............................................................11
Instructions for vane motor ..................................................................11
Assembly of vane motor according to Bäckströms method.................14
Troubleshooting....................................................................................................15
Troubleshooting ..............................................................................................15
Recycling ...............................................................................................................16
Recycling instruction.......................................................................................16

D2160-Q EN Product information
© Atlas Copco Industrial Technique AB - 9839 1477 01 3
Product information
General information
WARNING Risk of Property Damage or Severe Injury
Ensure that you read, understand and follow all instructions before operating the tool. Failure to follow
all the instructions may result in electric shock, fire, property damage and/or severe bodily injury.
►Read all Safety Information delivered together with the different parts of the system.
►Read all Product Instructions for installation, operation and maintenance of the different parts of
the system.
►Read all locally legislated safety regulations regarding the system and parts thereof.
►Save all Safety Information and instructions for future reference.
Safety signal words
The safety signal words Danger, Warning, Caution, and Notice have the following meanings:
DANGER DANGER indicates a hazardous situation which, if not avoided, will result in death or se-
rious injury.
WARNING WARNING indicates a hazardous situation which, if not avoided, could result in death or
serious injury.
CAUTION CAUTION, used with the safety alert symbol, indicates a hazardous situation which, if
not avoided, could result in minor or moderate injury.
NOTICE NOTICE is used to address practices not related to personal injury.
Warranty
■Product warranty will expire 12 months after the product is first taken into use, but will in any case ex-
pire at the latest 13 months after delivery.
■Normal wear and tear on parts is not included within the warranty.
■Normal wear and tear is that which requires a part change or other adjustment/overhaul during
standard tools maintenance typical for that period (expressed in time, operation hours or other-
wise).
■The product warranty relies on the correct use, maintenance, and repair of the tool and its component
parts.
■Damage to parts that occurs as a result of inadequate maintenance or performed by parties other
than Atlas Copco or their Certified Service Partners during the warranty period is not covered by the
warranty.
■To avoid damage or destruction of tool parts, service the tool according to the recommended mainte-
nance schedules and follow the correct instructions.
■Warranty repairs are only performed in Atlas Copco workshops or by Certified Service Partners.
Atlas Copco offers extended warranty and state of the art preventive maintenance through its ToolCover
contracts. For further information contact your local Service representative.
For electrical motors:
■Warranty will only apply when the electric motor has not been opened.
ServAid
ServAid is a portal that contains technical information for all hardware and software products such as:
- Safety Information including declarations, standards and directives
- Technical data

Product information EN D2160-Q
4© Atlas Copco Industrial Technique AB - 9839 1477 01
- Installation, Operation and Service Instructions
- Spare parts lists
- Accessories
ServAid is continuously updated and is available at:
https://servaid.atlascopco.com
For further information contact your local Atlas Copco representative.
Website
Log in to Atlas Copco: www.atlascopco.com.
You can find information concerning our products, accessories, spare parts and published matters on our
website.
Safety Data Sheets MSDS/SDS
The safety data sheets describes chemical products sold by Atlas Copco.
For more information, consult the website:
www.atlascopco.com/sds
Country of origin
Please refer to the information on the product label.
Dimensional drawings
For information about the dimensions of a product, see the Dimensional drawings archive:
http://webbox.atlascopco.com/webbox/dimdrw
Overview
Applications
This is a drill used for all applications and industry segments.
Service overview
Maintenance and service instructions
The service must only be done by authorized workshops or qualified service technicians.
WARNING Polymer hazard
The vanes in this product contain PTFE (a synthetic fluoropolymer). Due to wear, there might be
PTFE particles inside the product. Heated PTFE can produce fumes which may cause polymer fume
fever with flu-like symptoms, especially when smoking contaminated tobacco.
Health and Safety recommendations for PTFE must be followed when handling vanes and other com-
ponents:
►Do not smoke when servicing this product
►PTFE-particles must not come in contact with open fire, glow or heat
►Motor components must be washed with cleaning fluid and not blown clear with an air line
►Wash your hands before starting any other activity

D2160-Q EN Product information
© Atlas Copco Industrial Technique AB - 9839 1477 01 5
Service recommendations
Preventive maintenance is recommended at regular intervals. See the detailed information on preventive
maintenance. If the product is not working properly, take it out of service and inspect it.
If no detailed information about preventive maintenance is included, follow these general guidelines:
■Clean appropriate parts accurately
■Replace any defective or worn parts
Preventive maintenance
Make sure to perform a preventive maintenance every 6 months. If it is used in heavy duty conditions or
not running properly, it should be removed from operation for inspection more often.

Installation EN D2160-Q
6© Atlas Copco Industrial Technique AB - 9839 1477 01
Installation
Installation requirements
Air quality
■For optimum performance and maximum product life we recommend the use of compressed air with
a maximum dew point of +10°C (50°F). We also recommend to install an Atlas Copco refrigeration
type air dryer.
■Use a separate air filter which removes solid particles larger than 30 microns and more than 90% of
liquid water. Install the filter as close as possible to the product and prior to any other air preparation
units to avoid pressure drop.
For impulse/impact tools make sure to use lubricators adjusted for these tools. Regular lubricators
will add too much oil and therefore decrease the tool performance due to too much oil in the motor.
Make sure that the hose and couplings are clean and free from dust before connecting to the tool.
Both lubricated and lubrication free products will benefit from a small quantity of oil supplied from a
lubricator.
Air lubrication guide
Brand Air lubrication
Atlas Copco Optimizer (1 liter) 9090 0000 04
Q8 Chopin 46
Shell Shell Air Tool Oil S2 A 320
Compressed air connection
WARNING Risk of severe injury
Air under pressure can cause injury.
►Always shut off the air supply when not in use or before any adjustments.
►Drain the hose of air pressure and disconnect the tool from air supply when not in use or before
any adjustments.
►Always use the correct hose size and air pressure for the tool.
WARNING Compressed Air
High air pressure can cause severe damage and bodily injury.
►Do not exceed maximum air pressure.
►Make sure that there are no damaged or loose hoses or fittings.
For correct air pressure and hose size, see section Technical data.
Make sure that the hose and couplings are clean and free from dust before connecting to the tool.

D2160-Q EN Installation
© Atlas Copco Industrial Technique AB - 9839 1477 01 7
Installation instructions
Installing the drill
WARNING Risk of severe injury
Air under pressure can cause injury.
►Always shut off the air supply when not in use or before any adjustments.
►Drain the hose of air pressure and disconnect the tool from air supply when not in use or before
any adjustments.
►Always use the correct hose size and air pressure for the tool.
WARNING Always wear impact-resistant eye and face protection when involved with or near
the operation, repair or maintenance of the tool or when changing accessories on the tool.
CAUTION Cutting Hazard
Protect hands from drill bits and other sharp objects when changing accessories or during repair
work. Sharp objects can cut and cause injuries.
►Always wear protective gloves when changing accessories or during repair work.
►Remove the protective gloves before starting the tool.
1. Position the support handle for either right- or left handed operation.
2. Drain the hose of air pressure before connecting to air supply.
3. Tighten the drill bit in place with a chuck. A keyed chuck uses a rotary key to tighten and loosen the
chuck. A keyless chuck is operated by hand.
Never drill a hole that is larger than the rated capacity for the drill.
The motor requires no additional lubrication during operation.
4. Connect the tool to the air supply.
5. Use the appropriate drilling speed for the application.
6. To start the tool, press the trigger.
When lubrication is recommended - only use lubricants recommended by Atlas Copco.

Operation EN D2160-Q
8© Atlas Copco Industrial Technique AB - 9839 1477 01
Operation
Ergonomic guidelines
Consider your workstation as you read through this list of general ergonomic guidelines and see if you can
identify areas for improvement in posture, component placement, or work environment.
■Take frequent breaks and change work positions frequently.
■Adapt the workstation area to your needs and the work task.
■Adjust for convenient reach range by determining where parts or tools should be located to avoid
static load.
■Use workstation equipment such as tables and chairs appropriate for the work task.
■Avoid work positions above shoulder level or with static holding during assembly operations.
■When working above shoulder level, reduce the load on the static muscles by reducing the weight
of the tool, using for example torque arms, hose reels or weight balancers. You can also reduce
the load on the static muscles by holding the tool close to the body.
■Make sure to take frequent breaks.
■Avoid extreme arm or wrist postures, particularly for operations requiring a degree of force.
■Adjust for convenient field of vision by minimizing movement of the eyes and head during the work
task.
■Use the appropriate lighting for the work task.
■Select the appropriate tool for the work task.
■Use ear protection equipment in noisy environments.
■Use high-quality inserted tools or consumables to minimize exposure to excessive levels of vibration.
■Minimize exposure to reaction forces.
■When cutting:
A cut-off wheel can get stuck if the wheel is either bent or if it is not guided properly. Make sure to
use the correct flanges for cut-off wheels and avoid bending the wheel during cut-off operation.
■When drilling:
The drill might stall when the drill bit breaks through. Makes sure you use support handles if the
stall torque is too high. The safety standard ISO11148 part 3 recommends using something to ab-
sorb the reaction torque above 10 Nm for pistol grip tools and 4 Nm for straight tools.
■When using direct-driven screw or nutrunners:
Reaction forces depend on tool setting and joint characteristics. The ability to bear reaction forces
depends on the operator’s strength and posture. Adapt the torque setting to the operator's strength
and posture and use a torque arm or reaction bar if the torque is too high.
■Use dust extraction system or mouth protection mask in dusty environments.
Operating instructions
Operating the drill
WARNING Risk of severe injury
Air under pressure can cause injury.
►Always shut off the air supply when not in use or before any adjustments.
►Drain the hose of air pressure and disconnect the tool from air supply when not in use or before
any adjustments.
►Always use the correct hose size and air pressure for the tool.

D2160-Q EN Operation
© Atlas Copco Industrial Technique AB - 9839 1477 01 9
WARNING Risk of Severe Injury
Never operate the tool wearing loose objects. Choking, scalping or other severe bodily injuries can
occur if loose clothing, jewellery, neck ware and hair is not kept away from tool or accessories.
►Never wear gloves when operating the tool.
►Keep loose clothing, jewellery, neck ware and hair away from rotating drive or accessories.
WARNING Always wear impact-resistant eye and face protection when involved with or near
the operation, repair or maintenance of the tool or when changing accessories on the tool.
1. Use the approriate drill for the application.
2. Tighten the drill bit in place with a chuck. A keyed chuck uses a rotary key to tighten and loosen the
chuck. A keyless chuck is operated by hand.
WARNING Risk of Injury
The drill bit must fit tightly in the chuck before starting the drill. A drill bit that does not fit properly
into the chuck may come loose and cause bodily injury.
►Check that the drill bit fits tightly in the chuck before starting the drill.
3. Remove the rotary key before starting the tool.
4. Make sure the workpiece is securely fixed.
5. Always have a firm footing when drilling. Brace and position yourself carefully when drilling.
6. Always make sure there are no electrical wires or water lines behind the surface you are drilling into.
Never drill a hole that is larger than the rated capacity for the drill.
7. Use the appropriate drilling speed for the application.
8. Start the tool by pressing the trigger.
9. Do not force the drill. If the drill slows down, change to a drill with more power, so that the drill bit can
continue cutting smoothly.
10. If the drill gets caught in the material, release the trigger immediately, unplug the drill and remove the
bit from the material.
When lubrication is recommended - only use lubricants recommended by Atlas Copco.

Service EN D2160-Q
10 © Atlas Copco Industrial Technique AB - 9839 1477 01
Service
Maintenance instructions
Maintenance and service instructions
The service must only be done by authorized workshops or qualified service technicians.
WARNING Polymer hazard
The vanes in this product contain PTFE (a synthetic fluoropolymer). Due to wear, there might be
PTFE particles inside the product. Heated PTFE can produce fumes which may cause polymer fume
fever with flu-like symptoms, especially when smoking contaminated tobacco.
Health and Safety recommendations for PTFE must be followed when handling vanes and other com-
ponents:
►Do not smoke when servicing this product
►PTFE-particles must not come in contact with open fire, glow or heat
►Motor components must be washed with cleaning fluid and not blown clear with an air line
►Wash your hands before starting any other activity
Service recommendations
Preventive maintenance is recommended at regular intervals. See the detailed information on preventive
maintenance. If the product is not working properly, take it out of service and inspect it.
If no detailed information about preventive maintenance is included, follow these general guidelines:
■Clean appropriate parts accurately
■Replace any defective or worn parts
Preventive maintenance
Make sure to perform a preventive maintenance every 6 months. If it is used in heavy duty conditions or
not running properly, it should be removed from operation for inspection more often.
Lubrication instructions
Rust protection and cleaning
Water in the compressed air can cause rust. To prevent rust we strongly recommend to install an air dryer.
Water and particles can cause sticking of vanes and valves. This can be prevented by installing an air fil-
ter close to the product to avoid pressure drop.
Before longer standstills always protect your tool by adding a few drops of oil into the air inlet. Run the tool
for 5–10 seconds and absorb any access oil at the air outlet in a cloth.
NOTICE Do not try to clear the air path using sharp tools.
The air inlet is equipped with a strainer. If this is punctured, foreign objects may harm the valves, resulting
in overspeed.
Lubrication guide
Brand General purpose, Bearings and Gears
BP Energrease LS-EP2
Castrol OBEEn UF 1
Esso Beacon EP2

D2160-Q EN Service
© Atlas Copco Industrial Technique AB - 9839 1477 01 11
Brand General purpose, Bearings and Gears
Q8 Rembrandt EP2
Mobil Mobilegrease XHP 222 NLG 2
Klüber Lub. Klübersynth UH 1 14-151
Texaco Multifak EP2
Molykote BR2 Plus
Maintenance and lubrication
The throttle valve, planetary gears, needle bearings and ball bearings must be lubricated with grease
when the tool is dismantled at the regular maintenance. Rhenus LKR03 gives long intervals between lubri-
cations.
1. Dismantle the motor, see the Dismantling and assembly section.
2. Clean the motor parts and apply a thin layer of air lubrication oil onto the vanes and inner surface of
cylinder and end plates.
3. Assemble the motor and make sure that it is running free. Add two drops of oil through the air inlet
and run the motor at idling speed for 5-10 seconds.
The strainer in the adapter should be cleaned regularly to prevent choking which will lead to a loss in ca-
pacity.
Dismantling/Assembling instructions
Instructions for vane motor
WARNING Polymer hazard
The vanes in this product contain PTFE (a synthetic fluoropolymer). Due to wear, there might be
PTFE particles inside the product. Heated PTFE can produce fumes which may cause polymer fume
fever with flu-like symptoms, especially when smoking contaminated tobacco.
Health and Safety recommendations for PTFE must be followed when handling vanes and other com-
ponents:
►Do not smoke when servicing this product
►PTFE-particles must not come in contact with open fire, glow or heat
►Motor components must be washed with cleaning fluid and not blown clear with an air line
►Wash your hands before starting any other activity
Dismantling

Service EN D2160-Q
12 © Atlas Copco Industrial Technique AB - 9839 1477 01
Service tools are also included in the Basic Service Tools set. For further information see ordering No.
9835 5485 00
Ordering No. Ø D Ø C
4080 0182 01 7 3.5
4080 0182 02 8 4.5
4080 0182 03 9 5.5
4080 0182 04 10 6.5
4080 0182 05 13 8.5
4080 0182 06 16 10.5
4080 0182 07 19 12.5
4080 0182 08 22 15.5
4080 0182 09 24 17.5
4080 0182 10 26 20.5
4080 0182 11 30 25.5
4080 0182 12 35 30.5
4080 0182 13 40 35.5
4080 0182 14 47 40.5
Dismantling tool Mandrel A
Inspection of motor parts

D2160-Q EN Service
© Atlas Copco Industrial Technique AB - 9839 1477 01 13
Assembling - According to Bäckströms method
Service tools are also included in the Basic Service Tools set. For further information see ordering No.
9835 5485 00
Ordering No. Ø D Ø C
4080 0567 04 12.5 5.2
4080 0567 11 14.5 6.5
4080 0567 01 15.5 5.2
4080 0567 05 18.5 6.2
4080 0567 02 18.5 8.2
4080 0567 06 21.5 7.5
4080 0567 03 21.5 8.2
4080 0567 07 25.5 10.5
4080 0567 08 27.5 12.5
4080 0567 09 31.5 15.5
4080 0567 10 34.5 18.5
Dismantling tool Mandrel B
E: Ball bearing

Service EN D2160-Q
14 © Atlas Copco Industrial Technique AB - 9839 1477 01
Assembly of vane motor according to Bäckströms method

D2160-Q EN Troubleshooting
© Atlas Copco Industrial Technique AB - 9839 1477 01 15
Troubleshooting
Troubleshooting
The table describes the most common problems, possible reasons and how to fix them. Note that some
actions must be carried out by authorized workshops or qualified service technicians.
Problem Possible reason Action
Free speed is too slow, pressure
never reaches the target.
Too low air flow in the pressurized
air system.
Shorter hose to the FRL unit and/or
larger diameter is needed. See In-
stallation proposal for more infor-
mation.
The tool has been in contact with
water.
The pressurized air system con-
tains condensed water.
See Service recommendations for
specific environments.
The tool does not start. No air flow to the tool. Make sure that the air connection
is correctly set.
Motor jammed. *
Inconsistent idling speed. Unstable air pressure. Make sure that the air pressure
regulator is working correctly.
Worn governor (LBB45). *
Low power Low air pressure. Make sure that the air pressure is
correctly set.
Wrong lenght or dimension of air
supply hose.
Make sure that the air connection
is correctly set.
Blocked filters. Clean or change the corse and fine
filter
The humidity in the air is high. Make sure that the compressor is
working correctly.
Too much grease in the gear box. Make sure that the amount of
grease is correct.
Worn throttle valve *
Worn vanes/motor? *
Worn governor (LBB45) *
Tool starts unexpectedly Damaged throttle valve *
Valve pin jammed in start position. Change pin and guide
Vibrations Worn or damage drill bit. Change drill bit
The motor housing istoo hot. Too much grease in the gear box. Make sure that the amount of
grease is correct.
Abnormal sound Not enough grease in gear hous-
ing.
Make sure that the amount of
grease is correct.
Damaged gear. *
Worn motor bearings. *
*) This service must only be carried out by authorized workshop or qualified service technician.

Recycling EN D2160-Q
16 © Atlas Copco Industrial Technique AB - 9839 1477 01
Recycling
Recycling instruction
When a product has served its purpose it has to be recycled properly. Dismantle the product and recycle
the components in accordance with local legislation.
Batteries shall be taken care of by your national battery recovery organization.

Original instructions
Atlas Copco Industrial
Technique AB
SE-10523 STOCKHOLM
Sweden
Telephone: [phone]
Telefax: [phone]
www.atlascopco.com
© Copyright 2018, Atlas Copco Industrial Technique AB. All rights reserved. Any
unauthorized use or copying of the contents or part thereof is prohibited. This
applies in particular to trademarks, model denominations, part numbers and
drawings. Use only authorized parts. Any damage or malfunction caused by the
use of unauthorized parts is not covered by Warranty or Product Liability.
Out of respect to wildlife and nature, our technical literature is printed on
environmentally friendly paper.
