Atlas Copco LBB16 EP024 User manual

LBB16 EP024
Printed Matter No. 9839 0928 01 Pistol-grip Drills
Valid from Serial No. B9600001
2017-08-21 Product Instructions
LBB16 EP-024 (2400 r/min) 8421010820
WARNING
Read all safety warnings and instructions
Failure to follow the safety warnings and instructions may result in
electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference

2© Atlas Copco Industrial Technique AB - 9839 0928 01
Table of Contents
Product information..................................................................... 4
General information................................................................. 4
Safety signal words........................................................ 4
Warranty ........................................................................ 4
ServAid .......................................................................... 5
Website .......................................................................... 5
Safety Data Sheets MSDS/SDS .................................... 5
Country of origin............................................................. 5
Dimensional drawings.................................................... 5
Overview ................................................................................. 5
Applications.................................................................... 5
Main components and functions .................................... 6
Technical data................................................................ 6
Service overview ..................................................................... 7
Maintenance and service instructions............................ 7
Service recommendations ............................................. 8
Preventive maintenance ................................................ 8
Installation .................................................................................... 9
Installation requirements ......................................................... 9
Air quality ....................................................................... 9
Air lubrication guide ....................................................... 9
Compressed air connection ........................................... 9
Installation instructions.......................................................... 10
Installing the drill .......................................................... 10
Operation .................................................................................... 11
Ergonomic guidelines............................................................ 11
Operating instructions ........................................................... 12
Operating the drill......................................................... 12
Service ........................................................................................ 14
Maintenance instructions....................................................... 14
Maintenance and service instructions.......................... 14
Preparations for service and maintenance .................. 14
Service recommendations ........................................... 14
Preventive maintenance .............................................. 15
Lubrication instructions.......................................................... 15
Rust protection and cleaning ....................................... 15
Lubrication guide.......................................................... 15
Maintenance and lubrication ........................................ 15

3
© Atlas Copco Industrial Technique AB - 9839 0928 01
Dismantling/Assembling instructions..................................... 16
Instructions for vane motor .......................................... 16
Disassembly of trigger ................................................. 18
Assembly of motor ....................................................... 18
Assembling of spacer ring on the chuck ...................... 18
Dismantling/Assembling of the chuck .......................... 19
Troubleshooting......................................................................... 20
Troubleshooting..................................................................... 20
Recycling .................................................................................... 21
Recycling instruction ............................................................. 21
Recycling information ............................................................ 21

Product information EN LBB16 EP024
4© Atlas Copco Industrial Technique AB - 9839 0928 01
Product information
General information
WARNING Risk of Property Damage or Severe Injury
Ensure that you read, understand and follow all instructions before operating
the tool. Failure to follow all the instructions may result in electric shock,
fire, property damage and/or severe bodily injury.
►Read all Safety Information delivered together with the different parts of
the system.
►Read all Product Instructions for installation, operation and maintenance
of the different parts of the system.
►Read all locally legislated safety regulations regarding the system and
parts thereof.
►Save all Safety Information and instructions for future reference.
Safety signal words
The safety signal words Danger, Warning, Caution, and Notice have the follow-
ing meanings:
DANGER DANGER indicates a hazardous situation which, if not avoided, will result in death or
serious injury.
WARNING WARNING indicates a hazardous situation which, if not avoided, could result in death
or serious injury.
CAUTION CAUTION, used with the safety alert symbol, indicates a hazardous situation which, if
not avoided, could result in minor or moderate injury.
NOTICE NOTICE is used to address practices not related to personal injury.
Warranty
• Product warranty will expire 12 months after the product is first taken into
use, but will in any case expire at the latest 13 months after delivery.
• Normal wear and tear on parts is not included within the warranty.
• Normal wear and tear is that which requires a part change or other ad-
justment/overhaul during standard tools maintenance typical for that pe-
riod (expressed in time, operation hours or otherwise).
• The product warranty relies on the correct use, maintenance, and repair of
the tool and its component parts.
• Damage to parts that occurs as a result of inadequate maintenance or per-
formed by parties other than Atlas Copco or their Certified Service Partners
during the warranty period is not covered by the warranty.
• To avoid damage or destruction of tool parts, service the tool according to
the recommended maintenance schedules and follow the correct instruc-
tions.
• Warranty repairs are only performed in Atlas Copco workshops or by Certi-
fied Service Partners.
Atlas Copco offers extended warranty and state of the art preventive mainte-
nance through its ToolCover contracts. For further information contact your lo-
cal Service representative.

LBB16 EP024 EN Product information
© Atlas Copco Industrial Technique AB - 9839 0928 01 5
For electrical motors:
• Warranty will only apply when the electric motor has not been opened.
ServAid
ServAid is a portal that contains the most up-to-date product information such
as:
- Safety Information
- Installation, Operation and Service Instructions
- Exploded views
It is also possible to order spare parts, service tools and accessories for the
product of your choice directly from ServAid. It is continuously updated with
information about new and redesigned products.
If translations exist, you can view content in the language of your choice. Ser-
vAid offers advanced search functionality of our entire product range and can
also be used to display information about obsolete products.
ServAid is available on DVD and on the website:
https://servaid.atlascopco.com
For further information contact your Atlas Copco sales representative or e-mail
us at:
[email protected]
Website
Log in to Atlas Copco: www.atlascopco.com.
You can find information concerning our products, accessories, spare parts and
published matters on our website.
Safety Data Sheets MSDS/SDS
The safety data sheets describes chemical products sold by Atlas Copco.
For more information, consult the website:
www.atlascopco.com
Choose Products - Safety Data Sheets, and follow the instructions on the
page.
Country of origin
Please refer to the information on the product label.
Dimensional drawings
For information about the dimensions of a product, see the Dimensional draw-
ings archive:
http://webbox.atlascopco.com/webbox/dimdrw
Overview
Applications
This is a drill used for all applications and industry segments.

Product information EN LBB16 EP024
6© Atlas Copco Industrial Technique AB - 9839 0928 01
Main components and functions
This product, its attachments and accessories are intended to be used for
drilling, reaming, and countersinking.
Pos Component Function
1 Chuck guard Secures the precision while main-
taining a comfortable grip.
2 Chuck Inserts and keeps the drill bit (cut-
ter) in position.
3 Spacer ring Used for dismantling the chuck.
4 Gear unit Gears up the torque from the air
motor.
5 Trigger Starts the drill with slow start func-
tion.
6 Lubrication free air motor Gives a cleaner working environ-
ment.
7 Handle Gives a comfortable rubber grip.
8 Inlet adapter Connects the drill to the air prepa-
ration unit (pressurized air).
9 Adjustable air exhaust Guides the cool air away from the
operator.
Technical data
Ordering No 8421010820
Model LBB16 EP-024
Free speed 2400 r/min
Chuck capacity - mm
Power level 290 W
0.4 hp
Stall torque Nm
in lb
Weight 0.6 kg
1.2 lb

LBB16 EP024 EN Product information
© Atlas Copco Industrial Technique AB - 9839 0928 01 7
Air consumption at free speed 8.0 l/s
17.0 cfm
Recommended hose size 6.3 mm
1/4 in
Air inlet thread (BSP) - in
Maximum working pressure 7.0 bar
100 psig
Sound pressure 80 dB(A)
Sound standard ISO15744
Sound uncertainty 3 dB(A)
Vibration standard ISO28927-5
Vibration value <2.5 m/s2
Height (H) mm
in
Length (L) mm
in
Service overview
Maintenance and service instructions
The service must only be done by authorized workshops or qualified ser-
vice technicians.

Product information EN LBB16 EP024
8© Atlas Copco Industrial Technique AB - 9839 0928 01
WARNING Polymer hazard
The vanes in this product contain PTFE (a synthetic fluoropolymer). Due to
wear, there might be PTFE particles inside the product. Heated PTFE can
produce fumes which may cause polymer fume fever with flu-like symp-
toms, especially when smoking contaminated tobacco.
Health and Safety recommendations for PTFE must be followed when han-
dling vanes and other components:
►Do not smoke when servicing this product
►PTFE-particles must not come in contact with open fire, glow or heat
►Motor components must be washed with cleaning fluid and not blown
clear with an air line
►Wash your hands before starting any other activity
Service recommendations
Preventive maintenance is recommended at regular intervals. See the detailed
information on preventive maintenance. If the product is not working properly,
take it out of service and inspect it.
If no detailed information about preventive maintenance is included, follow
these general guidelines:
• Clean appropriate parts accurately
• Replace any defective or worn parts
Preventive maintenance
Make sure to perform a preventive maintenance every 6 months. If it is used in
heavy duty conditions or not running properly, it should be removed from oper-
ation for inspection more often.

LBB16 EP024 EN Installation
© Atlas Copco Industrial Technique AB - 9839 0928 01 9
Installation
Installation requirements
Air quality
• For optimum performance and maximum product life we recommend the
use of compressed air with a maximum dew point of +10°C (50°F). We also
recommend to install an Atlas Copco refrigeration type air dryer.
• Use a separate air filter which removes solid particles larger than 30 mi-
crons and more than 90% of liquid water. Install the filter as close as possi-
ble to the product and prior to any other air preparation units to avoid pres-
sure drop.
Make sure that the hose and couplings are clean and free from dust before
connecting to the tool.
Both lubricated and lubrication free products will benefit from a small
quantity of oil supplied from a lubricator.
Air lubrication guide
Brand Air lubrication
Atlas Copco Optimizer (1 liter) 9090 0000 04
Q8 Chopin 46
Shell Shell Air Tool Oil S2 A 320
Compressed air connection
WARNING Compressed air can cause serious injury
►Always shut off the air supply, drain hose of air pressure and disconnect
the tool from air supply; when not in use, before making any adjustments
to the product - for example changing accessories, or when making re-
pairs.
WARNING Whipping hoses can cause serious injury
►Always make sure that there are no damaged or loose hoses or fittings.
WARNING Compressed Air
High air pressure can cause severe damage and injury.
►Do not exceed maximum air pressure.
For correct air pressure and hose size, see section Technical data.
Make sure that the hose and couplings are clean and free from dust before
connecting to the tool.

Installation EN LBB16 EP024
10 © Atlas Copco Industrial Technique AB - 9839 0928 01
Installation instructions
Installing the drill
WARNING Risk of severe injury
Air under pressure can cause injury.
►Always shut off the air supply when not in use or before any adjustments.
►Drain the hose of air pressure and disconnect the tool from air supply
when not in use or before any adjustments.
►Always use the correct hose size and air pressure for the tool.
WARNING Always wear impact-resistant eye and face protection when
involved with or near the operation, repair or maintenance of the tool or
when changing accessories on the tool.
CAUTION Cutting Hazard
Protect hands from drill bits and other sharp objects when changing acces-
sories or during repair work. Sharp objects can cut and cause injuries.
►Always wear protective gloves when changing accessories or during re-
pair work.
►Remove the protective gloves before starting the tool.
1. Position the support handle for either right- or left handed operation.
2. Drain the hose of air pressure before connecting to air supply.
3. Tighten the drill bit in place with a chuck. A keyed chuck uses a rotary key
to tighten and loosen the chuck. A keyless chuck is operated by hand.
Never drill a hole that is larger than the rated capacity for the drill.
The motor requires no additional lubrication during operation.
4. Connect the tool to the air supply.
5. Use the appropriate drilling speed for the application.
6. To start the tool, press the trigger.
When lubrication is recommended - only use lubricants recommended
by Atlas Copco.

LBB16 EP024 EN Operation
© Atlas Copco Industrial Technique AB - 9839 0928 01 11
Operation
Ergonomic guidelines
Consider your workstation as you read through this list of general ergonomic
guidelines and see if you can identify areas for improvement in posture, compo-
nent placement, or work environment.
• Take frequent breaks and change work positions frequently.
• Adapt the workstation area to your needs and the work task.
• Adjust for convenient reach range by determining where parts or tools
should be located to avoid static load.
• Use workstation equipment such as tables and chairs appropriate for the
work task.
• Avoid work positions above shoulder level or with static holding during as-
sembly operations.
• When working above shoulder level, reduce the load on the static mus-
cles by reducing the weight of the tool, using for example torque arms,
hose reels or weight balancers. You can also reduce the load on the static
muscles by holding the tool close to the body.
• Make sure to take frequent breaks.
• Avoid extreme arm or wrist postures, particularly for operations requir-
ing a degree of force.
• Adjust for convenient field of vision by minimizing movement of the eyes
and head during the work task.
• Use the appropriate lighting for the work task.
• Select the appropriate tool for the work task.
• Use ear protection equipment in noisy environments.
• Use high-quality inserted tools or consumables to minimize exposure to ex-
cessive levels of vibration.
• Minimize exposure to reaction forces.
• When cutting:
A cut-off wheel can get stuck if the wheel is either bent or if it is not
guided properly. Make sure to use the correct flanges for cut-off wheels
and avoid bending the wheel during cut-off operation.
• When drilling:
The drill might stall when the drill bit breaks through. Makes sure you
use support handles if the stall torque is too high. The safety standard
ISO11148 part 3 recommends using something to absorb the reaction
torque above 10 Nm for pistol grip tools and 4 Nm for straight tools.
• When using direct-driven screw or nutrunners:
Reaction forces depend on tool setting and joint characteristics. The abil-
ity to bear reaction forces depends on the operator’s strength and pos-
ture. Adapt the torque setting to the operator's strength and posture and
use a torque arm or reaction bar if the torque is too high.
• Use dust extraction system or mouth protection mask in dusty environments.

Operation EN LBB16 EP024
12 © Atlas Copco Industrial Technique AB - 9839 0928 01
Operating instructions
Operating the drill
WARNING Risk of severe injury
Air under pressure can cause injury.
►Always shut off the air supply when not in use or before any adjustments.
►Drain the hose of air pressure and disconnect the tool from air supply
when not in use or before any adjustments.
►Always use the correct hose size and air pressure for the tool.
WARNING Risk of Severe Injury
Never operate the tool wearing loose objects. Choking, scalping or other se-
vere bodily injuries can occur if loose clothing, jewellery, neck ware and hair
is not kept away from tool or accessories.
►Never wear gloves when operating the tool.
►Keep loose clothing, jewellery, neck ware and hair away from rotating
drive or accessories.
WARNING Always wear impact-resistant eye and face protection when
involved with or near the operation, repair or maintenance of the tool or
when changing accessories on the tool.
1. Use the approriate drill for the application.
2. Tighten the drill bit in place with a chuck. A keyed chuck uses a rotary key
to tighten and loosen the chuck. A keyless chuck is operated by hand.
WARNING Risk of Injury
The drill bit must fit tightly in the chuck before starting the drill. A drill
bit that does not fit properly into the chuck may come loose and cause
bodily injury.
►Check that the drill bit fits tightly in the chuck before starting the
drill.
3. Remove the rotary key before starting the tool.
4. Make sure the workpiece is securely fixed.
5. Always have a firm footing when drilling. Brace and position yourself
carefully when drilling.
6. Always make sure there are no electrical wires or water lines behind the
surface you are drilling into.
Never drill a hole that is larger than the rated capacity for the drill.
7. Use the appropriate drilling speed for the application.
8. Start the tool by pressing the trigger.
9. Do not force the drill. If the drill slows down, change to a drill with more
power, so that the drill bit can continue cutting smoothly.

LBB16 EP024 EN Operation
© Atlas Copco Industrial Technique AB - 9839 0928 01 13
10. If the drill gets caught in the material, release the trigger immediately, un-
plug the drill and remove the bit from the material.
When lubrication is recommended - only use lubricants recommended by
Atlas Copco.

Service EN LBB16 EP024
14 © Atlas Copco Industrial Technique AB - 9839 0928 01
Service
Maintenance instructions
Maintenance and service instructions
The service must only be done by authorized workshops or qualified ser-
vice technicians.
WARNING Polymer hazard
The vanes in this product contain PTFE (a synthetic fluoropolymer). Due to
wear, there might be PTFE particles inside the product. Heated PTFE can
produce fumes which may cause polymer fume fever with flu-like symp-
toms, especially when smoking contaminated tobacco.
Health and Safety recommendations for PTFE must be followed when han-
dling vanes and other components:
►Do not smoke when servicing this product
►PTFE-particles must not come in contact with open fire, glow or heat
►Motor components must be washed with cleaning fluid and not blown
clear with an air line
►Wash your hands before starting any other activity
Preparations for service and maintenance
WARNING Risk of severe injury
Air under pressure can cause injury.
►Always shut off the air supply when not in use or before any adjustments.
►Drain the hose of air pressure and disconnect the tool from air supply
when not in use or before any adjustments.
►Always use the correct hose size and air pressure for the tool.
CAUTION Cutting Hazard
Protect hands from drill bits and other sharp objects when changing acces-
sories or during repair work. Sharp objects can cut and cause injuries.
►Always wear protective gloves when changing accessories or during re-
pair work.
►Remove the protective gloves before starting the tool.
Service recommendations
Preventive maintenance is recommended at regular intervals. See the detailed
information on preventive maintenance. If the product is not working properly,
take it out of service and inspect it.
If no detailed information about preventive maintenance is included, follow
these general guidelines:
• Clean appropriate parts accurately
• Replace any defective or worn parts

LBB16 EP024 EN Service
© Atlas Copco Industrial Technique AB - 9839 0928 01 15
Preventive maintenance
Make sure to perform a preventive maintenance every 6 months. If it is used in
heavy duty conditions or not running properly, it should be removed from oper-
ation for inspection more often.
Lubrication instructions
Rust protection and cleaning
Water in the compressed air can cause rust. To prevent rust we strongly recom-
mend to install an air dryer.
Water and particles can cause sticking of vanes and valves. This can be pre-
vented by installing an air filter close to the product to avoid pressure drop.
Before longer standstills always protect your tool by adding a few drops of oil
into the air inlet. Run the tool for 5–10 seconds and absorb any access oil at the
air outlet in a cloth.
NOTICE Do not try to clear the air path using sharp tools.
The air inlet is equipped with a strainer. If this is punctured, foreign objects
may harm the valves, resulting in overspeed.
Lubrication guide
Brand General purpose, Bearings and Gears*
BP Energrease LS-EP2
Castrol OBEEn UF 1
Esso Beacon EP2
Q8 Rembrandt EP2
Mobil Mobilegrease XHP 222 NLG 2
Klüber Lub. Klübersynth UH 1 14-151
Texaco Multifak EP2
Molykote BR2 Plus
* Not for angle gears.
Brand Angle gears
Molykote Longterm 2 Plus
Maintenance and lubrication
The throttle valve, planetary gears, needle bearings and ball bearings must be
lubricated with grease when the tool is dismantled at the regular maintenance.
Molycote BR2 Plus gives long intervals between lubrications.
1. Dismantle the motor, see the Dismantling and assembly section.
2. Clean the motor parts and apply a thin layer of air lubrication oil onto the
vanes and inner surface of cylinder and end plates.
3. Assemble the motor and make sure that it is running free. Add two drops
of oil through the air inlet and run the motor at idling speed for 5-10 sec-
onds.

Service EN LBB16 EP024
16 © Atlas Copco Industrial Technique AB - 9839 0928 01
The strainer in the adapter should be cleaned regularly to prevent choking
which will lead to a loss in capacity.
Dismantling/Assembling instructions
Instructions for vane motor
WARNING Polymer hazard
The vanes in this product contain PTFE (a synthetic fluoropolymer). Due to
wear, there might be PTFE particles inside the product. Heated PTFE can
produce fumes which may cause polymer fume fever with flu-like symp-
toms, especially when smoking contaminated tobacco.
Health and Safety recommendations for PTFE must be followed when han-
dling vanes and other components:
►Do not smoke when servicing this product
►PTFE-particles must not come in contact with open fire, glow or heat
►Motor components must be washed with cleaning fluid and not blown
clear with an air line
►Wash your hands before starting any other activity
Dismantling
Service tools are also included in the Basic Service Tools set. For further infor-
mation see ordering No. 9835 5485 00
Ordering No. Ø D Ø C
4080 0182 01 7 3.5
4080 0182 02 8 4.5
4080 0182 03 9 5.5
4080 0182 04 10 6.5
4080 0182 05 13 8.5
4080 0182 06 16 10.5
4080 0182 07 19 12.5
4080 0182 08 22 15.5
4080 0182 09 24 17.5
4080 0182 10 26 20.5
4080 0182 11 30 25.5

LBB16 EP024 EN Service
© Atlas Copco Industrial Technique AB - 9839 0928 01 17
Ordering No. Ø D Ø C
4080 0182 12 35 30.5
4080 0182 13 40 35.5
4080 0182 14 47 40.5
Table1: Dismantling tool Mandrel A
Inspection of motor parts
Assembling - According to Bäckströms method
Service tools are also included in the Basic Service Tools set. For further infor-
mation see ordering No. 9835 5485 00
Ordering No. Ø D Ø C
4080 0567 04 12.5 5.2
4080 0567 11 14.5 6.5
4080 0567 01 15.5 5.2
4080 0567 05 18.5 6.2
4080 0567 02 18.5 8.2
4080 0567 06 21.5 7.5
4080 0567 03 21.5 8.2

Service EN LBB16 EP024
18 © Atlas Copco Industrial Technique AB - 9839 0928 01
Ordering No. Ø D Ø C
4080 0567 07 25.5 10.5
4080 0567 08 27.5 12.5
4080 0567 09 31.5 15.5
4080 0567 10 34.5 18.5
Table2: Dismantling tool Mandrel B
E: Ball bearing
Disassembly of trigger
Assembly of motor
Assembling of spacer ring on the chuck

LBB16 EP024 EN Service
© Atlas Copco Industrial Technique AB - 9839 0928 01 19
1. Attach the tool handle to a vise.
2. Unscrew the chuck and gear unit.
3. Put the chuck and gear unit in the collar. Attach the collar in a vise.
4. Remove the chuck with a chuck key.
5. Assemble the spacer ring to the gear unit.
6. Assemble the chuck and tighten with a chuck key.
Dismantling/Assembling of the chuck
1. Put a 15 mm open end spanner over the spacer ring.
2. Remove or assemble the chuck using a chuck key.

Troubleshooting EN LBB16 EP024
20 © Atlas Copco Industrial Technique AB - 9839 0928 01
Troubleshooting
Troubleshooting
The table describes the most common problems, possible reasons and how to
fix them. Note that some actions must be carried out by authorized workshops
or qualified service technicians.
Problem Possible reason Action
Free speed is too slow, pressure
never reaches the target.
Too low air flow in the pressurized
air system.
Shorter hose to the FRL unit and/or
larger diameter is needed. See In-
stallation proposal for more infor-
mation.
The tool has been in contact with
water.
The pressurized air system con-
tains condensed water.
See Service recommendations for
specific environments.
The tool does not start. No air flow to the tool. Make sure that the air connection
is correctly set.
Motor jammed. *
Inconsistent idling speed. Unstable air pressure. Make sure that the air pressure reg-
ulator is working correctly.
Worn governor (LBB45). *
Low power Low air pressure. Make sure that the air pressure is
correctly set.
Wrong lenght or dimension of air
supply hose.
Make sure that the air connection
is correctly set.
Blocked filters. Clean or change the corse and fine
filter
The humidity in the air is high. Make sure that the compressor is
working correctly.
Too much grease in the gear box. Make sure that the amount of
grease is correct.
Worn throttle valve *
Worn vanes/motor? *
Worn governor (LBB45) *
Tool starts unexpectedly Damaged throttle valve *
Valve pin jammed in start position. Change pin and guide
Vibrations Worn or damage drill bit. Change drill bit
The motor housing istoo hot. Too much grease in the gear box. Make sure that the amount of
grease is correct.
Abnormal sound Not enough grease in gear housing. Make sure that the amount of
grease is correct.
Damaged gear. *
Worn motor bearings. *
*) This service must only be carried out by authorized workshop or qualified
service technician.
