Atlona AT-PROHD88M-SR User manual

www.atlona.com | toll free: 1-877-536-3976
For International: 1-408-962-0515
User Manual
AtlonA
8x8 HDMI matrix Switch with
8 x CAT5 Receivers included
AT-PROHD88M-SR
AT-PROHD88M-S
FRONT VIEW
AT-PROHD88M-R
FRONT VIEW
AT-PROHD88M-S
REAR VIEW
AT-PROHD88M-R
REAR VIEW
HDMI MATRIX 8:8:2

www.atlona.com | toll free: 1-877-536-3976
For International: 1-408-962-0515 2
TABLE OF CONTENTS
1. Introduction .................................................. 3
2. Package Contents .................................................. 3
3. Features .................................................. 3
4. Specication .................................................. 4
5. Panel Description .................................................. 4
5.1 Main Unit .................................................. 4
5.1.1. Front Panel .................................................. 4
5.1.2. Rear Panel .................................................. 5
5.2 HDMI Receiver .................................................. 5
6. Connect and Operation .................................................. 6
7. IR Remote Control .................................................. 8
7.1. RS232 Control .................................................. 9
7.2. RS232 Cable Wiring .................................................. 9
8. Safety Information .................................................. 12
9. Warranty .................................................. 13
10. Atlona Product Registration .................................................. 14

www.atlona.com | toll free: 1-877-536-3976
For International: 1-408-962-0515 3
INTRODUCTION
PACKAGE CONTENTS:
Atlona Technologies’ AT-PROHD88M-SR is an 8x8 HDMI Matrix Switcher over Twisted Pair designed to work
as a switcher for multiple Audio/Video sources and displays. The Atlona unit is capable of switching HDMI
signals between eight sources (such as: Blue-Ray player, HD DVD player, satellite receiver, game system, etc.)
and eight displays. Because it is a matrix switch, any or all of the 8 inputs can simultaneously be switched to
any or all of the outputs. Along with supporting HDMI 1.3 and HDCP Compliance, switcher will support high
denition video in multiple resolutions of up to 1080p or 1920x1200. Five switching modes are available includ-
ing front panel buttons, local IR, IR call back from remote locations, RS485 and TCP/IP. The PROHD88 is
capable of routing IR signal from remote locations to the main location where the switcher is. The IR emitters/
receivers can control the switch as well as sources next to it.
The Atlona PROHD88M-SR has 8 dual* outputs.
*Dual Output: HDMI + Dual Twisted Pair output where both are active at the same time. Each output could be
connected to either 2 displays or AVR and a Display; however the signal from both outputs will be identical.
• AT-PROHD88M-SR (main switch)
• 8 x AT-PROHD-REC (CAT5/6/7 receivers)
• 8 x 5 VDC Power Supply (110/240v universal) – for receivers
• 1 x 12 VDC Power Supply (110/240v universal) – for the main switch
• 1 x IR Remote.
• 1x IR receiver extension cable.
• 8x IR (IR emitter cables).
• Rack Ears
• 1 x USB to RS232 adapter cable.
• Manual
FEATURES:
• HDMI 1.3b, HDCP and EDID compatible
• 8 x CAT5/6/7 receivers are included
• Allows up to eight HDMI sources to be independently switched to eight HDMI outputs, where each output is
featured with HDMI and Twisted pair connections and both are active at the same time.
• The eight outputs could show the same or different source simultaneously
• Supports high denition resolutions up to 1920x1200 or 1080p
• Supports all latest HDMI audio formats including Dolby TrueHD and DTS-HD
• Switcher is featured with IR call back function which allows each remote location to send IR signal though
CAT5/6/7 receivers back to the switch and further down to the nearby sources.
• Each CAT5/6/7 output can go up to 165ft @ 1080p on CAT5/6 cables and up to 250ft @ 1080p on the CAT7
cable (tested with Tyco wire). If more distance is required, Atlona offers CAT5/6/7 repeater (AT-PROHD-RP)
unit which can double the distance and allow chain up to 6 units.
• Each input and output port is able to support HDMI or DVI signal. For DVI signal adapter will be required.
• Five switching modes: panel buttons, local IR, IR call back from remote locations, RS485 and TCP/IP.
• Rack Mountable, comes with 19-inch Rack-Ears (4U)

www.atlona.com | toll free: 1-877-536-3976
For International: 1-408-962-0515 4
PANEL DESCRIPTION
1. Power ON/OFF switch
2. SET/ENTER (Push the ‘FN’ button to conrm change of an input channel to an output).
3. Output selection push-buttons (Use it to choose the preferred output channel).
4. Input selection push-buttons (Use it to choose the preferred input channel).
5. IR window.
6. LED indicator of input for output port 1 to 8.
Main Unit
1. Front Panel
SPECIFICATIONS:
Operating Temperature Range -5 to +35°C (-41 to +95 °F)
Operating Humidity Range 5 to 90 % RH (no condensation)
Input Video Signal 0.5-1.0 volts p-p
Input DDC Signal 12v (main unit) and 5v (receivers)
Video Format Supported HDTV: 480p/576p/720p/1080i/1080p (50/60Hz)
Computer: up to 1920x1200
Audio Format Supported All latest HDMI audio formats including Dolby
TrueHD and DTS-HD
HDMI Standard HDMI 1.3c
Maximum Output Distance
(HDM out)
55ft (16m)
Maximum Output Distance
RJ45 outputs
165ft (50m) @ 1080p on CAT5/6 cables and
Up to 250ft (80m) @ 1080p on the CAT7 cable
(Tested with Tyco wire)
Power Consumption 30wtts (Max)
Dimensions (inch) 17.3’’L×11’’W×5.5’’H - 4U
Main Unit Weight/Receiver 12LB/0.3LB (6kg)/(0.1kg)
123
4
56
HDMI MATRIX 8:8:2

www.atlona.com | toll free: 1-877-536-3976
For International: 1-408-962-0515 5
2. Rear Panel
1. IR extension. 7. Input ports 1 to 4.
2. RS485 port. 8. Power input.
3. LAN port. 9. Output 5 and 8 with HDMI and CAT5E.
4. IR emitter, corresponding to the Input port from 1 to 8 10. Input ports 5 to 8.
5. RS232 port. 11. DIP switch setting.
6. Output 1 to 4 with HDMI and CAT5E.
Note: The TCP/IP port has to be connected to the computer via direct Crosswire CAT5/6/7 wire while if connected to the router it needs
to be connected though Straight wire.
HDMI Receiver (8 x Receivers included)
RJ45 inputs – please be careful when connecting RJ45 # 1 and # 2 inputs. They absolutely have to match the
outputs on the switch. Output # 1 should be connected to Input # 1 and Output # 2 should be connected to
Inputs # 2.
1 2 3 4 5
11
6 7 8 9 10
RJ45 Inputs
IR Input RX
Power Input
HDMI Out

www.atlona.com | toll free: 1-877-536-3976
For International: 1-408-962-0515 6
Note: For better functionality of the IR, we suggest to place the IR receiver Eye at the IR Eye of the controlling source.
8) EDID Settings (PLEASE READ, IT IS VERY IMPORTANT):
The functionality of the switch will depend on how you select the Dip Switches below. Please read the instruc-
tions and explanations below to understand the purpose of different congurations.
There are four DIP switches on the back of the 8x8 matrix switcher. Below you will nd the denition of each
one of the dip switches.
Position ID EDID Operational Mode
1 2 3 4
OFF ON OFF OFF AUTO EDID MANAGEMENT (DIP # 1)
OFF ON ON OFF AUTO EDID MANAGEMENT - LONG CABLES(DIP # 2)
ON OFF OFF OFF Up to 1080P with Stereo Audio (no deep-color) ) (DIP#3)
ON OFF ON OFF Up to 1080P with 5.1 Audio (no deep-color) (DIP#4)
ON ON OFF OFF Up to 1080P with Stereo Audio (deep-color) (DIP#5)
ON ON ON OFF Up to 1080P with 5.1 Audio (deep-color) (DIP#6)
Note: 1 – ON and 0 – OFF
EACH TIME DIP SWITCHES ARE CHANGED; THE ATLONA SWITCH HAS TO POWER CYCLED.
1) Connect the HDMI input sources (such as HD-DVD, PS3, AppleTV, DirecTV etc) into the inputs on AT-
PROHD88M-SR.
2) Connect the HDMI outputs from AT-PROHD88M-SR (such as LCD, Plasma, LED, Projector, Monitor)
3) Power on the input source you want to show. (Keep the unused input power OFF, otherwise it may
interfere with the normal display.)
4) Use IR remote, front panel, RS232, TCP/IP or RS485 connections to choose desired input source.
5) IR calls back from remote locations allows controlling the matrix switch as well as nearby sources (such
as DVD, AppleTV, Satellite, Cable and etc…).
6) Instruction on IR Emitter.
The sequence of “IR1, IR2, IR3, IR4, IR5, IR6, IR7, IR8” one-to-one correspond with “HDMI Inputs 1~8”. When
an output chooses certain input, the call-back IR signal of RJ45 on this output will choose the corresponding
“IR” port to send the signal out.
For example, OUTPUT#1 chooses INPUT#3, then the call-back IR signal of RJ45 on OUTPUT#1 will choose
“IR 3” to send the signal out.
CONNECT AND OPERATION

www.atlona.com | toll free: 1-877-536-3976
For International: 1-408-962-0515 7
DIP#1: Auto EDID Management (ADM) is a smart function which will allow users to have matrix switch gure
out the best and most appropriate EDID.
The way it works: Atlona 8x8 matrix acquires EDID from all the outputs and after processing it, chooses the
EDID which will work on all the outputs.
Example # 1: User has 8 outputs connected where 6 of the outputs are 1080P TV’s only and the other 2 loca-
tions are 720P TV’s. The Atlona’s EDID would be 720P with 2-channel Stereo (because most TV’s will only be
able to take stereo audio though HDMI input).
Example # 2: User has 8 outputs connected, where 6 outputs are 1080P TV’s and the remaining are 2 x Sur-
round Sound Receivers (after connected to the TV’s for video only). The Atlona’s EDID would be 1080P with
Stereo or PCM (because most TV’s will only take Stereo Audio though HDMI input).
Remark: If you don’t like the Auto EDID Management functions, switcher has some pre-recorded modes which
will certainly satisfy you.
DIP#2: This function is very similar to Note # 1; however it is designed for users who have very long CAT5/6/7
cables and signal is going in and out. This DIP Switch setting will replace some of the hdmi control signals with
video, which will allow picture to stabilize.
DIP#3: Atlona Switcher has a few built-in EDID modes; this mode is for resolutions up to 1080P with Stereo Au-
dio. When this mode is selected the deep-color will be disabled. Deep-color will only work on new TV’s which
were built after April 2009. If you know that one of the displays doesn’t support deep color, we suggest to use
this setting or DIP # 1 setting for signal to be reliable.
DIP#4: Atlona Switcher has a few built-in EDID modes; this mode is for resolutions up to 1080P with 5.1 Digi-
tal Audio. When this mode is selected the deep-color will be disabled. Deep-color will only work on new TV’s
which were built after April 2009. If you know that one of the displays doesn’t support deep color, we suggest to
use this setting or DIP # 1 setting for signal to be reliable.
This mode is designed for applications where user has AV Receivers in each remote location which are able to
accept Digital Audio from HDMI inputs. If this mode is selected and in even one of the locations user has a TV
without an AV receiver, the TV might “mute” or start outputting garbled audio (because most TV’s don’t support
digital audio though HDMI input)
DIP#5: Atlona Switcher has a few built-in EDID modes; this mode is for resolutions up to 1080P with Stereo Au-
dio. When this mode is selected the switcher will pass deep-color. Deep-color will only work on new TV’s which
were built after April 2009. If you know that one of the displays doesn’t support deep color, we suggest using
DIP # 1 or DIP # 3 setting for signal to be reliable.
DIP#6: Atlona Switcher has a few built-in EDID modes; this mode is for resolutions up to 1080P with 5.1 Digital
Audio. When this mode is selected the switcher will pass deep-color. Deep-color will only work on new TV’s
which were built after April 2009. If you know that one of the displays doesn’t support deep color, we suggest
using DIP # 1 or DIP # 3 setting for signal to be reliable.
This mode is designed for applications where user has AV Receivers in each remote location which are able to
accept Digital Audio from HDMI inputs. If this mode is selected and in even one of the locations user has a TV
without an AV receiver, the TV might “mute” or start outputting garbled audio (because most TV’s don’t support
digital audio though HDMI input)

www.atlona.com | toll free: 1-877-536-3976
For International: 1-408-962-0515 8
IR REMOTE CONTROL
VERY IMPORTANT:
If one of your Output devices is a projector or a display with a unique resolution your sources/source
which are/is connected to the switch might not send out a proper video format which will result image
to intermit or signal not show up on the display.
Solution: Make sure your DIP switch conguration is either DIP # 1 or # 2. Route the device in question
to the output in question. After that’s done, please perform the following operation: (Simultaneously
press and hold the “Output # (in question) and “FN Key” buttons for three seconds). You shall see the
following message to appear on your LED display: “MIX OK”
If you receive a “MIX FL” – please try this operation again.
The AT-PROHD88M-Sr comes with 16 button IR remote control, which could be
used to control the switcher when pointing at it or controlling the switcher from
a remote location by pointing the remote control to the IR Eye connected to the
HDMI receiver.
For users who would like to use a 3rd part IR remote control or IR remote sys-
tem, we recommend either learning IR codes off the remote or copying and
pasting the IR HEX code into the remote control software. The le with HEX
codes could be found on Atlona website under downloads for AT-PROHD88M-
SR.
There are 2 scenarios which codes to use:
• User will need to learn all 64 x codes in order to control each location
when pointing at the switcher
• User will only need to learn 8 x codes if there will be a separate remote
for each remote location
Note: The switcher can only accept and route IR signal which doesn’t exceed 38 KHz.
In other words, if you are trying to send IR signal from the remote location though
out HDMI receiver and the IR signal is higher than 38 KHz, the IR signal will not pass
though.
VERY IMPORTANT:
When connecting IR receivers and IR emitters, be very careful as if they are reversed the IR Eye will
burn-out and also may damage the IR module inside of the switch and Receiver.
TX – Connects to the Switch
RX – Connects to the HDMI Receivers

www.atlona.com | toll free: 1-877-536-3976
For International: 1-408-962-0515 9
RS232 CONTROL:
Baud Rate: 9600 bps
Data bits: 8 bits
Parity: None
Stop bits: 1 bit
Flow control: None
RS232 Cable Wiring:
AT-PROHD88M-SR Controller
Pin Denition Pin Denition
1 NC 1 NC
2 Tx 2 Rx
3 Rx 3 Tx
4 NC 4 NC
5 GND 5 GND
6 NC 6 NC
7 NC 7 NC
8 NC 8 NC
9 NC 9 NC
Note: ‘ ’ is carriage return.
OUTPUT COMMAND ACTION
Output 1
cir 00 Output 1 select Input1
cir 01 Output 1 select Input2
cir 02 Output 1 select Input3
cir 03 Output 1 select Input4
cir 04 Output 1 select Input5
cir 05 Output 1 select Input6
cir 06 Output 1 select Input7
cir 07 Output 1 select Input8
< cir 08 Output 1 select Input previous
> cir 09 Output 1 select Input next
Output 2
cir 10 Output 2 select Input1
cir 11 Output 2 select Input2
cir 12 Output 2 select Input3
cir 13 Output 2 select Input4
cir 14 Output 2 select Input5
cir 15 Output 2 select Input6
cir 16 Output 2 select Input7
cir 17 Output 2 select Input8
< cir 18 Output 2 select Input previous
> cir 19 Output 2 select Input next

www.atlona.com | toll free: 1-877-536-3976
For International: 1-408-962-0515 10
Output 3
cir 20 Output 3 select Input1
cir 21 Output 3 select Input2
cir 22 Output 3 select Input3
cir 23 Output 3 select Input4
cir 24 Output 3 select Input5
cir 25 Output 3 select Input6
cir 26 Output 3 select Input7
cir 27 Output 3 select Input8
< cir 28 Output 3 select Input previous
> cir 29 Output 3 select Input next
Output 4
cir 30 Output 4 select Input1
cir 31 Output 4 select Input2
cir 32 Output 4 select Input3
cir 33 Output 4 select Input4
cir 34 Output 4 select Input5
cir 35 Output 4 select Input6
cir 36 Output 4 select Input7
cir 37 Output 4 select Input8
< cir 38 Output 4 select Input previous
> cir 39 Output 4 select Input next
Output 5
cir 40 Output 5 select Input1
cir 41 Output 5 select Input2
cir 42 Output 5 select Input3
cir 43 Output 5 select Input4
cir 44 Output 5 select Input5
cir 45 Output 5 select Input6
cir 46 Output 5 select Input7
cir 47 Output 5 select Input8
< cir 48 Output 5 select Input previous
> cir 49 Output 5 select Input next
Output 6
cir 50 Output 6 select Input1
cir 51 Output 6 select Input2
cir 52 Output 6 select Input3
cir 53 Output 6 select Input4
cir 54 Output 6 select Input5
cir 55 Output 6 select Input6
cir 56 Output 6 select Input7
cir 57 Output 6 select Input8
< cir 58 Output 6 select Input previous
> cir 59 Output 6 select Input next

www.atlona.com | toll free: 1-877-536-3976
For International: 1-408-962-0515 11
Output 7
cir 60 Output 7 select Input1
cir 61 Output 7 select Input2
cir 62 Output 7 select Input3
cir 63 Output 7 select Input4
cir 64 Output 7 select Input5
cir 65 Output 7 select Input6
cir 66 Output 7 select Input7
cir 67 Output 7 select Input8
< cir 68 Output 7 select Input previous
> cir 69 Output 7 select Input next
Output 8
cir 70 Output 8 select Input1
cir 71 Output 8 select Input2
cir 72 Output 8 select Input3
cir 73 Output 8 select Input4
cir 74 Output 8 select Input5
cir 75 Output 8 select Input6
cir 76 Output 8 select Input7
cir 77 Output 8 select Input8
< cir 78 Output 8 select Input previous
> cir 79 Output 8 select Input next

www.atlona.com | toll free: 1-877-536-3976
For International: 1-408-962-0515 12
SAFETY INFORMATION
Safeguards
To reduce the risk of electric shock, do not
expose this product to rain or moisture.
If the wall plug does not t into your local
power socket, hire an electrician to replace
your obsolete socket.
Do not modify the wall plug.
Doing so will void the warranty and safety
features.
This equipment should be installed near
the socket outlet and the device should
be easily accessible in case it requires
disconnection.
Precautions
FCC Regulations state that any
unauthorized changes or modications to
this equipment not expressly approved by
the manufacturer could void the
user’s authority to operate this
equipment.
Operate this product using only the
included external power supply. Use of
other power supplies could impair
performance, damage the product or cause
res.
In the event of an electrostatic discharge,
this device may automatically turn off. If this
occurs, unplug the device, and plug it back
in.
Protect and route power cords so they will
not be stepped on or pinched by anything
placed on or against them. Be especially
careful of plug-ins, or cord exit points from
this product.
Avoid excessive humidity, sudden
temperature changes or temperature
extremes.
Keep this product away from wet locations
such as bathtubs, sinks, laundries, wet
basements and swimming pools.
Use only accessories recommended by
ATLONA to avoid re, shock or other
hazards.
Unplug the product before cleaning. Use
a damp cloth for cleaning. Do not use
cleaning uid or aerosols, which could
enter the unit and cause damage, re or
electrical shock. Some substances may
also mar the nish of the product.
Never open or remove unit panels or make
any adjustments not described in this
manual. Attempting to do so could expose
you to dangerous electrical shock or other
hazards. It may also cause damage to your
AT-PROHD88M-SR. Opening the product
will void the warranty.
Do not attempt to service the unit. Instead
disconnect it and contact your Authorized
ATLONA reseller or contact ATLONA
directly.

www.atlona.com | toll free: 1-877-536-3976
For International: 1-408-962-0515 13
1. LIMITED WARRANTY
Atlona Technologies warrants that (a) its products (the “Product”) will perform substantially in accordance with the ac-
companying written materials for a period of 3 YEARS from the date of receipt and (b) that the Product will be free from
defects in materials and workmanship under normal use and service for a period of 3 years. In the event applicable law
imposes any implied warranties, the implied warranty period is limited to 3 years from the date of receipt. Some jurisdic-
tions do not allow such limitations on duration of an implied warranty, so the above limitation may not apply to Customer.
2. CUSTOMER REMEDIES
Atlona Technologies and its suppliers’ entire liability and Customer’s exclusive remedy shall be, at Atlona Technologies’
option, either return of the price paid for the Product, or repair or replacement of the Product that does not meet this
Limited Warranty and which is returned to Atlona Technologies with a copy of Customer’s receipt. This Limited Warranty
is void if failure of the Product has resulted from accident, abuse, or misapplication. Any replacement Product will be war-
ranted for the remainder of the original warranty period or 3 year, whichever is longer.
3. NO OTHER WARRANTIES
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, ATLONA TECHNOLOGIES AND ITS SUPPLIERS
DISCLAIM ALL OTHER WARRANTIES, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO IM-
PLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, WITH REGARD TO
THE PRODUCT AND ANY RELATED WRITTEN MATERIALS. THIS LIMITED WARRANTY GIVES CUSTOMER SPE-
CIFIC LEGAL RIGHTS. CUSTOMER MAY HAVE OTHER RIGHTS DEPENDING ON THE JURISDICTION.
4. NO LIABILITY FOR DAMAGES
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT SHALL ATLONA TECHNOLOGIES OR
ITS SUPPLIERS BE LIABLE FOR ANY DAMAGES WHATSOEVER (INCLUDING WITHOUT LIMITATION, SPECIAL, IN-
CIDENTAL, CONSEQUENTIAL, OR INDIRECT DAMAGES FOR PERSONAL INJURY, LOSS OF BUSINESS PROFITS,
BUSINESS INTERRUPTION, LOSS OF BUSINESS INFORMATION, OR ANY OTHER PECUNIARY LOSS) ARISING
OUT OF THE USE OF OR INABILITY TO USE THIS PRODUCT, EVEN IF ATLONA TECHNOLOGIES HAS BEEN AD-
VISED OF THE POSSIBILITY OF SUCH DAMAGES. IN ANY CASE, ATLONA TECHNOLOGIES’ AND ITS SUPPLIERS’
ENTIRE LIABILITY UNDER ANY PROVISION OF THIS AGREEMENT SHALL BE LIMITED TO THE AMOUNT ACTU-
ALLY PAID BY YOU FOR THE PRODUCT. BECAUSE SOME JURISDICTIONS DO NOT ALLOW THE EXCLUSION OR
LIMITATION OF LIABILITY FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES, THE ABOVE LIMITATION MAY NOT
APPLY TO YOU.

www.atlona.com | toll free: 1-877-536-3976
For International: 1-408-962-0515 14
ATLONA PRODUCT REGISTRATION
Thank you for purchasing this Atlona product — we hope you’ll enjoy it.
We also hope that you’ll take a few moments to register your new purchase. Registration creates an ownership
record if your product is lost or stolen and helps ensure you’ll receive notication of performance issues and rmware
updates.
At Atlona, we respect and protect your privacy and assure you that your registration information is completely
secure. Of course, Atlona product registration is totally voluntary and failure to register will not diminish your limited war-
ranty rights.
To register go to www.atlona.com/registration
