Atlona AT-HDVS-210H-TX-WP User manual

1
Installation Guide
AT-HDVS-210H-TX-WP
Two-Input Wallplate Switcher for HDMI with Ethernet-
Enabled HDBaseT Output
AT-HDVS-210H-TX-WP
The Atlona AT-HDVS-210H-TX-WP is a 2x1 switcher and HDBaseT transmitter with two
HDMI inputs. It features a US one-gang, Decora-style wallplate form factor, and includes
interchangeable black and white wallplates and faceplates. Video signals up to 4K/UHD @ 60
Hz with 4:2:0 chroma subsampling, plus embedded audio and control can be transmitted up to
330 feet (100 meters). The HDVS-210H-TX-WP is HDCP 2.2 compliant. It is designed for use with
select HDVS Series receivers and scalers, as well as the AT-UHD-EX-100CE-RX-PSE receiver,
and Atlona switchers and matrix switchers with HDBaseT inputs. This transmitter can serve as
an integral component of a fully automated AV system, with the convenience of automatic input
selection and display control. It is remotely powered by the AT-UHD-EX-100CE-RX-PSE or other
Atlona HDBaseT-equipped devices through Power over Ethernet (PoE).
IMPORTANT: Visit http://www.atlona.com/product/AT-HDVS-210H-TX-WP for the latest
rmware updates and User Manual.
1 x AT-HDVS-210H-TX-WP
1 x White faceplate with RS-232 cover
1 x White wallplate
1 x Black faceplate with RS-232 cover
1 x Black wallplate
1 x 3-pin captive screw connector
1 x Installation Guide
Package Contents

2
Installation Guide
AT-HDVS-210H-TX-WP
Panel Descriptions
18
3
5
2
4
67
HDMI 2 HDMI 1
LINK
HDMI 1
HDMI 2
PWR
RS-232
RX TX
AT-HDVS-210H-TX-WP
HDMI
HDBaseT
OUT
1 HDMI 1
Connect an HDMI cable from this port to a UHD/HD source.
2 RS-232
Connect an RS-232 control system to this port. The RS-232 port is covered by a plate and
must be removed to expose the RS-232 port.
3 PWR
This LED indicator glows solid green when the unit is powered.
4 LINK
This LED indicator glows solid green to indicate the presence of an A/V signal.
5 HDMI 1
This LED indicator glows solid green when the HDMI 1 port is the active port.
6 HDMI 2
This LED indicator glows solid green when the HDMI 2 port is the active port.
7 HDMI 2
Connect an HDMI cable from this port to a UHD/HD source.
8 HDBaseT OUT
Connect an Ethernet cable from this port to a locally-powered HDBaseT receiver such as
the AT-HDVS-200-RX or AT-UHD-EX-100CE-RX-PSE.

3
Installation Guide
AT-HDVS-210H-TX-WP
The AT-HDVS-210H-TX-WP provides an RS-232 port which allows communication between a
control system and an RS-232 device. This step is optional.
1. Remove the small plate covering the RS-232 port on the faceplate.
2. Use wire strippers to remove a portion of the RS-232 cable jacket.
3. Remove at least 3/16” (5 mm) from the insulation of the RX, TX, and GND wires.
4. Insert the TX, RX, and GND wires into correct terminal using the included 3-pin captive
screw connector.
5. Connect the opposite end of the cable to the control system.
NOTE: Typical DB9 connectors use pin 2 for TX, pin 3 for RX, and pin 5 for
ground. On some devices functions of pins 2 and 3 are reversed.
RS-232
GND
RX
TX
HDMI 2
LINK
HDMI 1
HDMI 2
PWR
RS-232
RX TX
HDMI1
AT-HDVS-210H-TX-WP
HDMI 2
LINK
HDMI 1
HDMI 2
PWR
RS-232
RX TX
HDMI1
AT-HDVS-210H-TX-WP
small plate

4
Installation Guide
AT-HDVS-210H-TX-WP
Faceplate Removal and Assembly
1. Unscrew the four Phillips-head screws from the sides of the faceplate, as shown:
2. Gently remove the faceplate by pulling it toward you.
3. Attach the new faceplate, then secure it using the four Phillips-head screws. Do not over-
tighten or apply high-torque devices to the screws. Doing so may damage the faceplate
and/or the screws.
4. Install the AT-HDVS-210H-TX-WP to the electrical box or mud ring.
5. Reattach the wallplate.
Removal of the faceplate requires that the AT-HDVS-210H-TX-WP be disassembled from the
electrical box or mud ring. A small Phillips-head screwdriver is required to remove the faceplate.
HDMI 2
LINK
HDMI 1
HDMI 2
PWR
RS-232
RX TX
HDMI1
AT-HDVS-210H-TX-WP

5
Installation Guide
AT-HDVS-210H-TX-WP
1. Select the desired IP mode. Refer to IP Conguration on the next page.
2. Connect an Ethernet cable, from the HDBaseT OUT port, on the rear of the unit, to one of
the following devices. Ethernet cables should use EIA/TIA-568B termination:
a. PoE-compatible receiver (not included), such as the AT-HDVS-200-RX.
b. Atlona Power Over Ethernet Mid-Span Power Supply (AT-PS-POE). Use this option if
the system endpoint is not capable of supplying power to the AT-HDVS-210H-TX.
Refer to the User Manual for more information.
3. Install the AT-HDVS-210H-TX-WP into a 1-gang electrical box or mud ring.
4. Attach the included Decora® wallplate to secure the AT-HDVS-210H-TX-WP to the wall/
surface.
5. Connect up to two UHD/HD sources using the HDMI 1 and HDMI 2 ports.
6. Optionally connect an control system to the RS-232 port on the AT-HDVS-210H-TX-WP.
Installation
Connection Diagram
AT-HDVS-210H-TX-WP
HDMI 2
LINK
HDMI 1
HDMI 2
PWR
RS-232
RX TX
HDMI 1
AT-HDVS-210H-TX-WP
DC48V LAN HDBaseTIN HDMIOUTFW
C1
C2
COM
Ethernet
Ethernet
Blu-ray player
AT-HDVS-200-RX
1-gang electrical box
or mud ring
Wall cross-section
HDBaseT
Ethernet / PoE
Video
Video
White Decora®-style
wallplate (included)
AV LAN
AT-VTP-550-BL
ETHERNETHDMIOUTMDPOUT DC19V
12
AT-VGW-250
AT-VGW-250
Laptop

6
Installation Guide
AT-HDVS-210H-TX-WP
By default, the AT-HDVS-210H-TX-WP is set to DHCP mode, allowing a DHCP server (if present)
to assign the unit an IP address. If a DHCP server is not found within 15 seconds, the IP address
of the unit will be set to 0.0.0.0. If a static IP address is desired, the IP address of 192.168.1.254
is used by default. Refer to the User Manual for more information on IP conguration.
IP Conguration
Switching the IP mode
Switching the IP mode requires that the faceplate be removed. Refer to Faceplate Removal and
Assembly, for more information.
1. Make sure the AT-HDVS-210H-TX-WP is powered, by connecting it to a PoE-compatible
receiver, such as the AT-HDVS-200-RX. Power is supplied by the receiver over HDBaseT.
2. Remove the faceplate.
3. Press and hold the Reset button for approximately 15 seconds. Release the Reset button
once the PWR LED indicator begins to ash. The number of ashes will indicate the
currently selected IP mode.
4. Once the desired IP mode has been selected, use an IP scanner to locate the AT-HDVS-
210H-TX-WP on the network. Use the MAC address, located on the back of the unit, to
identify the unit within the IP scanner.
PWR LED ashes Description
Two Static IP mode
Four DHCP mode
IP Mode / Reset button
PWR LED indicator

7
Installation Guide
AT-HDVS-210H-TX-WP
Resetting to Factory-Default Settings
Resetting the AT-HDVS-210H-TX-WP requires that the front faceplate be removed. Before
removing the faceplate, the AT-HDVS-210H-TX-WP must be disassembled from the electrical box
or mud ring. A small Phillips-head screwdriver is required to remove the faceplate.
1. Remove the faceplate from the AT-HDVS-210H-TX-WP. Refer to the section Faceplate
Removal and Assembly for more information.
2. Press and release the Reset button.
3. Reassemble the faceplate to the front of the AT-HDVS-210H-TX-WP and reinstall into the
electrical box or mud ring.
Accessing the webGUI
The AT-HDVS-210H-TX-WP includes a built-in webGUI, which allows easy management and
control of all features. Follow the instructions below to access the webGUI.
1. Make sure that an Ethernet cable is connected between the LAN port on the receiver unit
and the network.
2. Launch a web browser and enter the IP address of the AT-HDVS-210H-TX-WP. If the default
static IP address is being used, enter 192.168.1.254.
3. The Login page will be displayed.
4. Enter the following information on the Login page.
Login: root
Password: Atlona
5. Click the Login button.
6. Refer to User Manual for detailed operation of the webGUI.

8
Installation Guide
AT-HDVS-210H-TX-WP
© 2017 Atlona Inc. All rights reserved. “Atlona” and the Atlona logo are registered trademarks of Atlona Inc. All other brand names and trademarks or registered
trademarks are the property of their respective owners. Pricing, specications and availability subject to change without notice. Actual products, product images, and
online product images may vary from images shown here.
atlona.com •408.962.0515 •877.536.3976
Troubleshooting
Problem Solution
The AT-HDVS-210H-TX-
WP is not detecting the
source device.
• If an HDMI cable adapter is being used, then try a
dierent one.
• Check the cable for possible damage or loose
connections.
How do I switch inputs? • The AT-HDVS-210H-TX-WP uses automatic input
selection, which is based upon the most recent device
that is connected. Manual switching can be performed
by disconnecting the device you have most recently
connected, or by disconnecting and re-connecting the
previous input.
The AT-HDVS-210H-TX-
WP is not powering.
• The AT-HDVS-210H-TX-WP receives power from the
receiver through HDBaseT. Make sure that the receiver
(such as the AT-HDVS-200-RX or the AT-UHD-EX-100CE-
RX-PSE) is connected to the HDBaseT OUT port, using
an Ethernet cable. Both the PWR and LINK will be
illuminated on the front of the AT-HDVS-210H-TX-WP
when operating correctly.
• Check the Ethernet cable for possible damage or loose
connections.
