Atmotube Pro User manual

GET TO KNOW YOUR

ATMOTUBE PRO

Atmotube PRO was created to raise awareness

about both indoor and outdoor air quality, so you

can make the right choices every day and live a

healthier life.

INSTALL THE ATMOTUBE APP

Itʼs free on the App Store

and Google Play store.

atmotube.com/app

It supports devices running iOS 9.3+ and Android 4.3+ with Bluetooth LE

support.

Download on the

App Store Get it on

Google Play

ATMOTUBE PRO AT A GLANCE

• Real-time detection:

- PM1/PM2.5/PM10 particles

- Volatile Organic Compounds

- Atmospheric pressure

- Temperature and relative humidity

• 2000 mAh Li-ion

• Bluetooth 5.0 LE

• USB Type-C

WEIGHT: 104 GRAMS

(3.66 OZ)

DIMENSIONS: 86 Х 50 X 22 MM

(3.4 X 2 X 0.9 INCHES)

The symbol on the product or its packaging signifies that this product must be disposed of separately from ordinary

householdwastesatitsendoflife.Please kindly be awarethatitisyourresponsibilitytodisposeofelectronicequipment

at recycling centers to help conserve natural resources.

Each country should have its collection centers for electrical/electronic equipment recycling. For detailed information

about your recycling drop off point, contact the retailer where you bought the product or your local recycling authority.

• Do not dispose your product with household waste.

• Disposal of the packaging and your product should be done in accordance with local regulations.

Representative office address: 100 Pine St. Suite 1250 San Francisco, CA 94111

RF INFORMATION

TX Frequency:

Bluetooth: 2402-2480 MHz

Bluetooth: +4 dBm

RX Frequenvcy:

Maximum Output Power:

COMPATIBLE DEVICES

iPhone 4S with iOS 9.3 or higher.

iPod Touch 5th Generation

iPad 3rd Generation with iOS 9.3

and higher.

Android OS 4.3 and higher with

Bluetooth 4.0 low energy (BLE)

support.

WARRANTY

Atmotube Limited Warranty — the Limited

Warranty extends only to the first consumer

purchase of the product and is not

transferable.

The warranty covers:

With the subject to the exclusions contained below,company warrants

the Atmotube and in-box accessories,accompanying the Product

against defects in workmanship and material, under the normal

consumer use.

The warranty does not extend to:

- Natural wear/tear (scratches,alteration of the color and/or the

materials of the Atmotube, peeling of the Atmotube color plating)

- Any damage to the Device/its parts resulting from accident,misuse,

liquid contact,fire, earthquake or any other external caused,abnormal

or abusive use,negligence or lack of care,or accidental damage (such

as dents).

- Indirect damages of any kind.

For more information about Atmotube warranty and return policy, visit

atmotube.com/warranty

USAGE AND STORAGE

REGULATIONS

• Product can be used at a temperatures between -5°C and 45°C (23°F

and 113°F). Avoid any extreme temperature changes.Recommended

conditions for accurate readings are: 0°C to 30°C at less than 85% RH.

• Product can be stored at temperatures between -40°C and 85°C

(-40°F and 185°F) and less than 85% humidity.

• Avoid any prolonged exposure to chemical products and dust – they

may damage the Atmotube sensors.In particular avoid exposure to:

- Silicone vapours from sources such as silicone adhesives, silica gel,

silicone rubber, silicone sealant,silicone gel, HMDS, oils including hair

gels and oils.

- Corrosive gases and vapours such as chlorine, hydrochloric acid,

sulphur oxides for example some flux vapours

- Acids,solvents and other liquids, including water, especially where the

water contains ionic contamination such as salts

- Particulates and dust

• Avoid any kind of shocks,be they physical, thermal or otherwise. They

may damage internal and external components of your Atmotube

• Atmotube is not a water-resistant device; keep the Atmotube away

from water or any moisture

• Keep your Atmotube and its accessories out of reach from children, as

it contains small parts and may present a choking hazard.

REGULATORY INFO

FCC Radiation Exposure Statement:

This equipment complies with FCC radiation exposure limits set forth for

an uncontrolled environment.

This transmitter must not be co-located or operating in conjunction with

any other antenna or transmitter.

Note: This equipment has been tested and found to comply with the

limits for a Class B digital device,pursuant to part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against

harmful interference in a residential installation.This equipment

generates,uses and can radiate radio frequency energy and, if not

installed and used in accordance with the instructions,may cause

harmful interference to radio communications.However, there is no

guarantee that interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or television

reception,which can be determined by turning the equipment off and on,

the user is encouraged to try to correct the interference by one or more of

the following measures:

— Reorient or relocate the receiving antenna.

— Increase the separation between the equipment and receiver.

— Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

Any Changes or modifications not expressly approved by the party

responsible for compliance could void the userʼs authority to operate the

equipment.

This device complies with part 15 of the FCC Rules. Operation is subject

to the following two conditions: (1) This device may not cause harmful

interference, and (2) this device must accept any interference received,

including interference that may cause undesired operation.

The Portable

Air Pollution Monitor

IMPORTANT! Do not try to modify or repair the

Atmotube PRO.All procedures, related to Service

and Maintenance should be performed by

professional technicians.

SAFETY INSTRUCTIONS

By using Atmotube PRO you agree to the

Services Terms and Conditions available at

atmotube.com/terms

Atmotube PRO is not a medical device.It is not a professional air

quality monitoring device; it provides estimates intended for personal

use and informational purposes only. The Atmotube PRO is a subject

to certain limitations and must be used in accordance with

specifications and quick start guide.Users should review the

information contained in quick start guide and available at

atmotube.com,to learn more.

All the screenshots/drawings in this quick start guide are provided for

explanatory purposes only. Device manufacturer has a right to update

application UI/device functionality without any prior notice.

FCC ID: 2AHGD-ATMO-PR1

This device complies with R&TTE Directive.

A copy of the EU Declaration of Conformity and Regulatory Information is available

online at atmotube.com/regulatory or in the Atmotube app (Settings Regulatory)

Please, follow in-app instructions to pair the

Atmotube with your smartphone.

Device bonding is disabled by default. If device

bonding is enabled, Atmotube would only able

to connect to a single smartphone it has been

paired to.To unpair Atmotube quickly press its

button five times. If unpairing has been

successful, Atmotube's LED light will blink blue

10 times.

PAIRING/UNPAIRING

THE ATMOTUBE

You can turn the Atmotube on by connecting

Atmotube to a 5V power source via a USB cable.

After the device has been switched on for the

first time or after prolonged inactivity, the VOC

sensor requires approximately three minutes to

preheat.While in preheating mode, the LED will

blink orange; during this period,the device will

be unresponsive and will not take any measure-

ments.

FIRST POWER ON

MEASUREMENTS

Atmotube starts measuring air quality immedi-

ately after the switch, but the measurements

become more accurate after the first 12 hours

of use after proper calibration.

Atmotube PRO takes readings every few

seconds while ON. In order to extend your

Atmotubeʼs battery life you can select one of

the few interval modes for PM sensor readings

in Settings Mode.

Apart from the selected intervals for PM sensor

readings,pressing the button on Atmotube or

opening your mobile app will automatically

start the PM sensor measurements.

AUTOMATIC RE-CALIBRATION

Atmotube PRO automatically re-calibrates itself,

ensuring measurement accuracy over time.

PERSONAL DATA

Review the Atmotube privacy policy at

atmotube.com/privacy

AQS INDICATOR

The LED light color represents the current Air

Quality Score,from Red (severely polluted) to Blue

(clean). When you press the button, the LED lights

up to show the current AQS level.

GOOD

MODERATE

POLLUTED

VERY

POLLUTED

SEVERELY

POLLUTED

SETTING UP

Charge your device

Make sure your device is

fully charged.To charge

Atmotube,connect it to a

power supply for at least

2 hours using the USB

Type-C cable from the

box.The LED light will

change its color from

orange to green once the

Atmotube is fully charged.

RGB LED

Multicolor LED

indicates the

current status of

Atmotube PRO.

BUTTON

Push the button to

see the current Air

Quality Score

indicated by the

color of the LED

light on the device.

CARABINER

MOUNT

Elegant and

functional solution

for a carabiner clip.

AIRFLOW

MESH

Air is sampled

through holes on

the device exterior.
