Atoll Electronique ST300 SIGNATURE User manual

STREAMER
ST300 SIGNATURE
OWNER’S MANUAL
ELECTRONIQUE

OWNER’S MANUAL ~ STREAMER
ATOLL ELECTRONIQUE
Page 2
INDEX
You have just bought a product with exceptional audiophile performances. We really thank you for
your confidence in our products. To get the best part of your streamer, please read carefully this
manual.
1 – General information
2 – Connections
3 – ATOLL remote control
4 – Connecting setup
5 – Uses
Getting started
Settings
Playlists
Internet Radio
Front and rear USB
Media server
Streaming services
Bluetooth®
6 – Preamp / BYPASS functions
7 – Applications
8 – Troubleshooting table
– An ST300 Signature streamer.
– A power lead.
– A RCA chord.
– A remote control.
– Two antennas.
– This manual with the certificate
of guarantee.
• Do not make any connections when your device is turned on.
• Install your appliance in a dry, well-ventilated place away from any source of heat.
• Do not put anything on your Streamer.
• Avoid any short circuits.
• Never connect two speakers in parallel to the same output.
SAFETY INSTRUCTIONS
• It is recommended to choose good quality cords to connect this appliance to the other
devices. Feel free to take advice from your specialist dealer.
USER ADVICES
YOU WILL FIND ENCLOSED
..............................................p3
..............................................p4
..............................................p5
..............................................p6
..............................................p7
..............................................p8
..............................................p9
............................................p10
............................................p11
............................................p12

ST300 Sig
ATOLL ELECTRONIQUE
Page 3
Supply:
Total of capacitors:
Audio Outputs:
Audio Inputs:
Output Stages:
Dynamic:
Output Impedance:
Output level:
Signal/Noise Ratio:
Distorsion at 1 kHz:
Bandwidth:
Rising time:
Digital/analog Converter:
Dimensions:
Weight:
30 + 10 + 10 VA
69 000 µF
1 Analog Stereo Output
1 XLR Stereo Output
2 Digital Outputs: 1 Coaxial & 1 Optical
2 Analog Stereo Inputs
Digital Inputs: 2 Coaxial, 2 Optical Toslink
1 Bluetooth®
2 USB-A Inputs
4 discrete stages with no feed-back
132 dB
5,6 Ω
2,6 Vrms
132 dB
0,0004 %
5 Hz - 20 kHz
1,5 µs
2×Burr-Brown 24 bits/192 kHz
440×255×90mm
7,0 Kg
1 - GENERAL INFORMATION
GENERAL INFORMATION AND ADVICES
Your ATOLL Streamer is DLNA and UPnP compatible, it can run in a network with other devices.
Take the time to read carefully the section “getting started” of this manual (page 7) before putting your unit
under voltage.
The display shows the selected radio station logo and has information about the files on the network and USB
type sockets. It indicates the level of the volume from 0 to 100.
ACCEPTED FORMATS
– MP3 (8-48 kHz 16 bits).
– AAC (24-96 kHz 16 bits).
– AAC+ v1/HE-AAC.
– FLAC (44,1-96 kHz 16/24 bits).
– FLAC 192 kHz/16-24 bits; available on USB-A
inputs, RJ45 link and Wifi.
– WAV (22-96 kHz 16/24 bits).
– AIFF & ALAC.
– DSD64 & DSD128.
CLEANING
WARRANTY
Before any cleaning, switch off your appliance. Use a soft and dry rag to clean up the appliance. Never use
acetone, white-spirit, ammoniac, or any kind of product containing abrasive agents. Never try to clean up
inside the appliance.
The guarantee is two years long from the date of purchase. We recommend you ask your dealer to fill the
guarantee and to conserve it with your invoice. The guarantee is only available for the appliance which has
been used correctly regarding this owner’s manual.
To use your device as easily as possible, download the ATOLL Signature app from the Apple Store or
the Google Play store.
TECHNICAL DATA

OWNER’S MANUAL ~ STREAMER
ATOLL ELECTRONIQUE
Page 4
1) Analog stereo Output (XLR line).
2) Input Analog 1.
3) Input Analog 2.
4) Optical Output.
5) Coaxial Output.
6) Optical 1 Input.
7) Optical 2 Input.
8) Coaxial 1 Input.
9) Trigger Output(a).
10) Coaxial 2 Input.
11) Ethernet Input (RJ45).
12) USB Input (A type).
13) Power Input.
14) ON/OFF switch.
15) WIFI connection antenna.
16) Bluetooth® connection
antenna.
17) Menus control keys.
18) USB A type Input.
19) Display.
a) BYPASS led indicator
20) Headphones Outputs (jack 3.5) (1)
21) Volumen control down and up +& .
22) On/Off key & stand-by led indicator.
DETAIL OF FONCTIONS
CONNECTING WIFI AND BLUETOOTH®ANTENNAS
1 2 3 8 10 11 12 13 14
9
17 18 19 21 2220
a)
4 5 6 7 15 16
(1) To avoid electrostatic shock, we recommend connecting the headset when the device is switched off or on standby.
While using headphones, turn off the amplifier.
You will find the antennas in the bag of the remote control.
Make sure that the WIFI and Bluetooth® antennas are correctly installed before any
connection and use.
Please use the 2 supplied antennas (identical) or an antenna with male connector.
2 - CONNECTIONS
(a)
Trigger output: this output is used to control the switching off/on of any device equipped with a compatible
trigger input (see instructions for use).

ST300 Sig
ATOLL ELECTRONIQUE
Page 5
22
23
24
27
29
40
41
17
31
32
34
36
21
33
25
28
35
37
38
30
26
39
The remote control uses 2 lithium CR2032 (3V) batteries. Make sure to place +upside.
Warning: some keys may have different uses depending on the menus or context.
Keys already available from the front panel:
17) Menus control keys.
21) Volume control +& .
22) Stand-by mode.
23) ALPHANUMERIC KEYS (from 0 to 9 and from A to Z).
By quick press on key (2) i.e. select a, b, c, 2, A, B, C
24) HOME: allows to come back to the main menu.
25) PLAY/PAUSE.
26) FAST FORWARDS:inactive.
27) PLAY NEXT TRACK.
28) STOP.
29) PLAY: allows to show the track or radio which is playing.
30) WPS: quick WIFI connection: press simultaneously on this key
and the key of the internet receiver.
31) BACK: return on menus.
32) FAST BACK: inactive.
33) OK: validation key in menus.
34) Access to the beginning of the track or previous track with a
double press. In menus: cancels the last character.
35) SHUF: shuffle.
36) REP: repeats track (symbol with 1) or of the album.
37) DISP: changes of the display mode.
38) MUTE: mute key (not active on BYPASS).
39) Inputs selection keys: Coaxial 1; Coaxial 2; Optical 1; Optical 2;
Line1; Line2; BYPASS (hold 5 seconds).
40) FAV: add or remove a track or radio.
41) Keys IN/PR: they allow to control ATOLL Integrated or Preamp.
3 - ATOLL REMOTE CONTROL
REMOTE CONTROL FONTIONS

OWNER’S MANUAL ~ STREAMER
ATOLL ELECTRONIQUE
Page 6
Source
From then on, each time the Streamer comes out of standby, the amplifier will turn on. It will also turn off each time
it goes to sleep.
When the system is operating, the ON/OFF button of your Amplier must remain in position OFF (0). If the
switch is in the ON position (1), the amplier will work but not the Trigger function.
Trigger cable must be a Male to Male jack plug 3.5mm (1/8”).
ST300 SIGNATURE
4 - CONNECTING SETUP
SOURCE MODE OR PREAMPLIFIER (BYPASS)
This device can be used as a source (like a CD player) or as a preamplifier which gives the ability to control
the volume.
The schemes below show how to connect correctly depending on your choice.
Preamp
TRIGGER LINK
This appliance is equipped with a Trigger that allows the switch ON/OFF of any amplifier equipped with the
same kind of trigger inputs (ATOLL amplifier).
Integrated IN300 type
NB.: You can switch on every line IN of the integrated.
Amplier AM300 Sig type
Using ST300 Signature as a source directly
linked to an Integrated or preamp. BYPASS
mode should be active and the BYPASS
led (16) switch on.
Using the Streamer as a preamplifier directly
connected to a power amplifier (or active
speakers). BYPASS mode should be not active
and BYPASS led (16) off.
Streamer type
ST300 Sig
Ampli type
AM300
Appliances must be linked as
shown below:

ST300 Sig
ATOLL ELECTRONIQUE
Page 7
Before switching ON your appliance, connect the network cable (RJ45) to input (11).
For much better results and best performances, we highly recommend to uses a wired connection better than
a WIFI connection.
Wait for the start-up screen to appear before any manipulation.
You can use the buttons of navigation (17) of the remote control or the front panel to select the different
menus.
On the first connection (or changes in the network configurations) you will have to check the network settings
of your appliance. If this setup is not perfectly settled, some of the functions of the streamer (internet radios or
reading music of your server) will not be operated.
Available menus:
5 - USES
GETTING STARTED
SETTINGS
NETWORK CONFIGURATION:
NOTE.: Network configuration starts immediately when an RJ45 cable is linked (11).
– Go to the “Settings” menu then to “Network connection”.
– Select the “Network Wizard” menu.
– You will have to choose the type of network. Press “Network type” and choose “Automatic”, “Wired”,
“Wireless”, or “Hybrid”.
WIRED:
If you already plugged the network cable, the device will indicate that the appliance is connected
The symbol indicates that the wired link is established.
If not, configure the network while choosing “Configure Wired” and then “Manual”. Here you can enter the IP
address directly.

OWNER’S MANUAL ~ STREAMER
ATOLL ELECTRONIQUE
Page 8
In this menu, you’ll find all information about the network: type of network, IP address, Mask, Gateway, DNS…
WIRELESS:
In this case, your appliance will be able to find the Wireless connections available in your home.
Advice: We advise you to use the WPS button to connect your appliance to your WIFI network.
Press on the WPS button of your internet receiver and then on the WPS button of the remote control (30).
Display shows “WPS in progress” then when the connection is made display shows “connected”.
If the WPS is not possible, press on “scan”. You’ll see the possible WIFI network available in your place. Select
yours and, if needed enter the WIFI key.
NB.: In some environments (buildings), several networks can be present. Make sure you choose yours.
This symbol indicates the link wireless as well as the strength of the signal.
NETWORK INFO:
LANGUAGES:
This menu allows you to select the language of all menus. You can choose between:
English, German, Spanish, French, Italian, Nederland, Russian, Polish.
This menu allows toy yo make an update your appliance. Select “Check for update” some time to time. If there
is no update, the display will show “No new updates”.
If an update is available, the devices will automatically launch it. This may take several times so let the device
run until it starts again.
FIRMWARE UPDATE:
VERSION:
This menu displays the software version installed in the device.
FACTORY RESET:
STREAM AUDIO QUALITY:
This menu allows you to restart the device with the factory settings. If you press it, the appliance will start again
and in the English version. Note that some menus will be refreshed such as PlayQueue or the Favorites Internet
radios.
This menu allows you to choose the quality of the audio files between 24 bits/192 kHz or 24 bits/96 kHz.
In the case of low internet, bandwidth prefers 24 bits/96 kHz quality to avoid any cuts during reading files.
DISPLAY:
POWER MANAGEMENT:
This menu allows you to choose the intensity of the display between Off, Low, Medium, or High.
If you select “Off“ the display will always get off after few seconds. The display will always get on while
pressing any keys or buttons.
This function is also available directly from the key DISP (37) of the remote control.
This menu allows to choose the standby timeout:
– When the device is not working (choice between 5,10, 15, or 30 minutes).
– When the device is working (choice between 1, 8, or 24 hours).

ST300 Sig
ATOLL ELECTRONIQUE
Page 9
PLAYLISTS
This device allows you to create Playlists with all music tracks or albums that are available in your network.
Note that it is not possible to add tracks from Streaming services to those Playlists.
You have 3 different menus available:
PlayQueue: The PlayQueue is a temporary playlist where you can place all tracks one after the other. The
places of each track can be changed in the queue line.
Select a track (present on the network or on any medium connected to the front or rear USB inputs).
Note: All tracks placed in this playlist will be deleted if the device is switched off.
Playlists: You can create all kinds of playlists.
You can create all kinds of playlists.
Press on “Create new playlist“, name it, and press “OK”. All Playlists will appear in the menu.
You’ll be able to put all tracks in any playlist of your choice.
With the app, you can change the name of them, activate a random or repeat play, cancel it or add it to a
collection.
Collection : A collection allows you to gather one or several Playlists.
First, create a collection and then with the app choose a playlist and add it to a collection.
Note.: If your device is not connected to the network or if the source of music (computer, NAS…) is not
linked to the network, tracks won’t be readable.
To remove a track or radio from Favorites, select it and then press on REM FAV (40) of the front panel.
INTERNET RADIO
This menu allows to access about 100 000 radio stations and also to podcasts.
Favorite: This menu offers the possibility to have a selection of radio easily accessible.
While playing a radio, you can add it to Favorites by pressing ou directement avec le bouton :
To remove the radio from Favorites, press again on .
Those functions are directly accessible also from the remote control with keys ADD FAV and REM FAV (40).
It is possible to choose also radios with other criteria: History / Recommendations / Local stations / Popular
stations / Trending / High quality / New stations / Filter / Search / Podcasts.
If you want to search a station by location, by language, or by genre, select “filter“.
Podcasts : This menu allows to get a selection of podcasts available:
Favorites / history / popular podcasts / trend / filter / search.
FRONT USB / REAR USB
Select one of those inputs to read all music files from a USB key or Hard Disk.
Readable files system can be FAT32, NTFS, EXT 2/3/4.

OWNER’S MANUAL ~ STREAMER
ATOLL ELECTRONIQUE
Page 10
MEDIA SERVER
This menu allows you to get access to all the music files on your network.
While entering this menu, you’ll find all different sources available in the network (could be NAS, computer,
router…).
While selecting them, you’ll have the choice of Music / photo / video.
Only music les can be read on this device.
Music: You can select music files depending on several criteria : (note that this is depending on the information
placed on the original files). Selection can be done:
Files / All music / Playlists / Album / Artist / Genre / Composer.
Placing tracks in “Playlists” is always possible while pressing keys.
STREAMING SERVICES
You can access Spotify from ATOLL Signature App: Use your phone, tablet, or computer as a remote control
for Spotify. Go to spotify.com/connect to learn how.
The Spotify Software is subject to third party licenses found here:
https://www.spotify.com/connect/third-party-licenses.
You also have direct access from the app to those streaming services:
Qobuz / Tidal / Deezer
On first use, you will have to enter your login and password.
For Tidal use the ATOLL Signature App.
Press on Username, fill it, and valid by pressing OK.
Press on Password, fill it, and valid by pressing OK. Finally press on “log in” to valid.
Once your account is valid, you’ll be able to get access to all services related to your account:
– Playlists that could be created.
– Favorites (albums, tracks, artists).
– Purchases (by albums or tracks).
BLUETOOTH®
Your device can receive audio files with a Bluetooth® connection from a smartphone, tab, computer.
First association: Go on the Bluetooth® menu of the Streamer and activate Bluetooth® on the source device. Then
select the ATOLL streamer on your source device. This device name should appear on the display (ATOLL Signature
by default). On the streamer, select your device and then press on “Play”.
From this moment, all audio files from your device will be played on the streamer.
Your source device will be connected as soon as the streamer will stay On. You can disconnect your device by
pressing “Disconnect”.
Associate another device: Before connecting a new device, disconnect the previous one. Run the Bluetooth®
connection of the new device then go again on the Bluetooth® menu of the streamer and connect it.
The quality of reception of the signal can be dependent on the power of the Bluetooth® emitter and the distance
between the 2 devices. Avoid being up to more than 5 meters of your SDA for a correct reception without any risks
of signal cuts.

ST300 Sig
ATOLL ELECTRONIQUE
Page 11
Your appliance can be used as a preamplifier allowing you to manage the volume control and selection of the
different sources. It can also be used as a single source (BYPASS led switch on).
To use the streamer as a preamp on BYPASS mode, press key BYPASS (39) of the remote for about 4 seconds. You
can do the same directly from the front panel while pressing about 4 seconds on keys VOL +& (21).
VOLUME :
Volume management is done through the keys (21) of the front panel or on the remote control. The volume
level is displayed a few seconds on the display. The level is always shown at the top of the display.
Particular case: Affect line1 or line2 as the only BYPASS input (for home cinema system insertion):
In PRE-AMP mode you can choose to assign a line input (line1 or line2) as an exclusive BYPASS input. Simply
select one of these inputs and then activates the BYPASS mode, inputs remain in preamp mode except that
particular line input.
Connect: as a preamplifier, the streamer can be directly connected to a power amplifier. In that case, ensure
you never turn your device on BYPASS mode. (check scheme p6)
In BYPASS mode where the indicated volume is no longer active, the actual volume then remains frozen at its
maximum value.
Your appliance has 6 inputs:
NB.: selected source always follows on the display of (*).
SOURCES :
6 - PREAMP / BYPASS FUNCTIONS
– Line 1
– Line 2
– Coaxial 1
– Coaxial 2
– Optical 1
– Optical 2
When you need to search for a special track or radio, you’ll need to press on “search”, then “Searching for”,
then indicate it, valid while pressing “OK” and then press “search”.
On music web services (Tidal, Qobuz, Deezer) you can add filters on your research (All / Title / Albums /
Artists / Playlists). Use your phone, tablet or computer as a remote control for Spotify.
“SEARCH” OPTION:
These sources can be renamed from the ATOLL Signature application.
7 - APPLICATIONS
A free application for iPad, iPhone, and Android
is available to drive your Streamer named ATOLL
Signature. You can download it freely online.
As a first step, make sure that your Smartphone is
well connected to WIFI on the same network as your
Streamer. In this case, your device will appear on
the screen of your Smartphone just after starting the
application, just select it.
The application will resume the data displayed on the
screen the Streamer: logo of the radio station, audio,
volume, covers of albums, and images.
You can navigate through the menus and adjust the
analog volume level.
Our applications can be regularly updated so can be improved in their functionalities.
It is possible to control your network drive from a computer screen by typing in the search bar of your internet
browser the IP address of your network drive followed by / webclient:
192.168.xxx.xxx/webclient
The IP address of your network drive is available in the “Settings / Network info” menu.
It is possible to rename your network drive by typing only the IP address of the latter in the search bar of your
internet browser.

OWNER’S MANUAL ~ STREAMER
ATOLL ELECTRONIQUE
Page 12
ATOLL ELECTRONIQUE®
is a French Company that designs, manufactures, and commercializes all its products.
WARRANTY ~ ST300 Sig
to present to your dealer and to join with your purchase invoice when sending back the appliance to the service
center or the address below:
This device was made to give you complete satisfaction.
ATOLL Electonique warranty is two years from the date of purchase of the equipment, date, and stamp of the
seller being authentic. We recommend you keep your proof of purchase (invoice) with this coupon properly filled.
The warranty, as well as the terms of service, should be specified at the time of purchase by your dealer who will
advise you, in case of faulty behavior or failure.
This warranty covers labor and replacement of parts acknowledged to be faulty and not their normal wear
and tear caused. Devices with traces of disassembly, drop, immersion, or abnormal voltage or any cause of
degradation in the appliance and damage resulting from use contrary to the indications included in the operating
instructions, automatically lose the benefit of the guarantee.
WARRANTY CONDITIONS
Dealer’s Stamp
ATOLL ELECTRONIQUE®
Bd des Merisiers
50370 BRECEY
FRANCE
Date of purchase:
Place of purchase:
Buyer signature:
No sound.
Impossible to access the
Network.
No recognition of the USB stick.
Frequent loss of the WIFI
network.
The device stops responding.
Problem encountered Possible Solutions
– Check your RCA connections.
– Have you selected the correct source?
– The volume might be at zero level.
– Enter the WAP key again.
– Make sure that the antenna is the supplied
template (male connector) and that it is well
screwed on its base.
– Check if the format is compatible.
– Make sure your box and your Streamer are not
confined or too far apart.
– Choose a wired connection or with Powerline
adapters for example.
– Press 2 times on key HOME (24).
– Turn off the power switch level before restarting.
8 - TROUBLESHOOTING TABLE
