Atom AT9032 Assembly instructions

Product range
Code Colour temperature Finish
AT9032/WH/WW Warm white White
AT9032/WH/CW Cool white White
AT9032/WH/DL Daylight White
10W LED Plastic trim downlight with dimmable driver.
INSTALLATION SHEET
LED DOWNLIGHT
AT9032
This product may contain substances that can be hazardous to the environment if not disposed of properly. Electrical and
electronic equipment should never be disposed of with general household waste but must be separated of it’s correct
SAFETY INFORMATION
• Luminaires must be installed and tted by a qualied
electrician ensuring the installation complies to the current
wiring regulations.
• Ensure all electrical connections are secure and that there are
no loose strands.
• Do not install this product on damp or newly plastered ceilings.
• Always ensure there is adequate ventilation around the driver
at all times.
Ø110mm
Ø90mm
31.5mm
Product specication
Voltage 230V~ 50Hz
Power consumption 10W
Light colour options Warm white Cool white Daylight
Lumen output 800lm 830lm 850lm
Colour temperature 3000K 4000K 5000K
Colour rendering index >80
Beam angle 90°
Dimmable Yes
Warranty 3 Years
Working temperature 50°C
IP Rating IP44
IC Rating IC-4
Electrical classication Class II
Max. daily usage TBA
Installation
Read instructions and check you have all the tools and accessories to
complete the installation correctly.
1. A. Isolate the mains power supply before commencing installation.
B. Cut Ø90mm hole in desired position.
2. Feed mains cable through cut-out and plug into mains supply.
3. Connect tting to LED driver.
4. Fold spring clips and push into cut-out.
5. Downlight fully installed into ceiling cut-out.
6. Restore mains power.
1
Isolate mains power.
BA
Cut hole in the desired position.
2 3
Feed mains cable
through cut-out and
plug into mains supply.
4
Fold back spring clips and push into cut-out.
5
Downlight fully installed into ceiling cut-out.
6
Restore mains power.
Click
Connect tting to LED Driver.

Atom is a registered brand of Evolt Pty Limited
IMPORTANT: THIS PRODUCT MUST BE INSTALLED BY A LICENSED ELECTRICIAN
Due to changes in industry standards and Evolt’s policy of continual product development,
product specications are subject to change without notice.
Images are for illustrative purposes only.
For further information please call Evolt’s head ofce on 1300 4EVOLT (438 658).
Evolt Pty Limited PO BOX 271 KINGSGROVE NSW 1480
ABN 83 112 123 529
www.evolt.com.au
0000005_V1.0
Warranty
Atom products are distributed in Australia by Evolt Pty Limited ('us', 'our', or 'we').
Our contact information is set out in the bottom right hand corner of this page.
Our goods come with guarantees that cannot be excluded under the Australian
Consumer Law. You are entitled to a replacement or refund for a major failure
and compensation for any other reasonably foreseeable loss or damage. You
are also entitled to have the goods repaired or replaced if the goods fail to be of
acceptable quality and the failure does not amount to a major failure.
In addition to your guarantees under the Australian Consumer Law, our goods
also come with a contractual warranty, which is described below. This warranty is
additional to your rights under the Australian Consumer Law (and any other rights
or remedies you may have under a law in relation to the products) and is not
intended to modify or exclude those rights.
Subject to the terms of this contractual warranty, if your Atom products are
defective, we will (at our election) repair or replace the Atom products. Once
we make this election (and take the relevant action), we will have honored our
obligations under this contractual warranty.
Our total liability under this warranty is limited to the cost of repair or replacement
of the defective product (at our election). We otherwise exclude all liability in
relation to the product to the fullest extent permitted by law (noting our comments
above regarding the Australian Consumer Law and any other rights or remedies
you may have).
If you wish to claim under this warranty, you must, at your own expense, return
the product or that part of the product which you believe is defective, together
with proof of original purchase, your name, address and telephone number
and a certicate of installation (or other document required by the law for the
installation of electrical products in the place in which the product was installed)
to Evolt at the address set out in the bottom right hand corner of this page
within the warranty period. You bear all costs associated with claiming under
this warranty (including, but not limited to, postage costs). Without limiting the
preceding sentence, this warranty does not apply to the costs of the removal or
re-installation of the defective product.
The warranty period for this product is three years from the date of purchase.
This warranty is not transferable and is only given to the original purchaser of
the product, provided the purchaser has purchased the product from us. Proof of
purchase must be provided to us with any warranty claim. We recommend that
you attach your proof of purchase to your product manual.
This warranty does not apply to consumable items within your product (including,
but not limited to, lamps or batteries). This warranty does not apply to products
that have been improperly stored, installed, or used. This warranty does
not apply to products that have not been maintained in accordance with the
instructions contained within this product manual.
This warranty does not apply to loss or damage caused by wear and tear, misuse,
incorrect installation or operation, failure to clean and maintain, incorrect voltage
or non-authorised electrical connections, adverse external conditions (such as
power surges and dips, acts of God, exposure to heat, corrosion, insect or vermin
infestation), use of non-authorised or defective parts or globes, or to items that
have been repaired than by a person other than us or a repairer approved by us.
Risk of re
CAN BE COVERED AND ABUTTED
HCB = Minimum distance between the top of the recessed luminaire
and any building element above it.
MIC = Minimum distance between the top of the recessed luminaire
and the building insulation above it.
SCB = Minimum distance between the side of the recessed luminaire
and any building element.
SCI = Minimum distance between the recessed luminaire and any
building insulation.
HCB: 0mm MIC: 0mm SCB: 0mm SCI: 0mm
Risk of Fire - Required clearance from structural members and
building elements.
Joist
SCB
HCB
building element
