Atom AT9501 Assembly instructions

Installation
Read instructions and check you have all the tools and accessories to
complete the installation correctly.
1. Isolate the mains power supply before commencing installation.
2. Cut 100mm x 62mm hole in desired position.
3. Feed mains cable through cut-out and plug into mains supply.
4. ConnectttingtoLEDdriver.
5. Ensurewalllightispressedcarefullyintotheaperature.
6. Restore mains power.
Thisproductmaycontainsubstancesthatcanbehazardoustotheenvironmentifnotdisposedofproperly.Electrical
and electronic equipment should never be disposed of with general household waste but must be separated of its correct
treatment and recovery. Where possible recycle your packaging. Please keep these instructions safe for future reference.
SAFETY INFORMATION
• Luminaires must be installed and tted by a qualied
electrician ensuring the installation complies to the current
wiring regulations.
• Ensure all electrical connections are secure and that there are
no loose strands.
• Do not install this product on damp or newly plastered walls.
• Always ensure there is adequate ventilation around the driver
at all times.
Product Specication
Voltage 220-240V~ 50/60Hz
Power Consumption 3W
Light Colour Options Warm White (WW) Cool White (CW)
Lumen Output 185lm 190lm
Colour Temperature 3000K 4000K
Colour Rendering Index >80
Beam Angle 100°
Dimmable No
Warranty 3 Years
Working Temperature -10°C – 45°C
IP Rating (Front face only) IP44
Electrical Classication Class II
3WLEDRectangularrecessedsteplight.
INSTALLATION SHEET
LED STEP LIGHT
AT9501
1 2
Isolate mains power. Cut hole in desired
position.
Feed cables through
cut-out and plug into
mains supply.
3
Product Range
Atom Code Finish Colour Temp.
AT9501/SC/CW/C SatinChrome/ClearLens Cool White
AT9501/SC/CW/O SatinChrome/OpalLens Cool White
AT9501/SC/WW/C SatinChrome/ClearLens Warm White
AT9501/SC/WW/O SatinChrome/OpalLens Warm White
AT9501/WH/CW/C White/ClearLens Cool White
AT9501/WH/CW/O White/OpalLens Cool White
AT9501/WH/WW/C White/ClearLens Warm White
AT9501/WH/WW/O White/OpalLens Warm White
70mm
Cut out 100 x 62mm
25.6mm
110mm 96mm
ConnectttingtoLED
driver.
A
4

Press wall light into cut
out carefully.
56
Restore mains power.
Risk of Fire
CANBECOVEREDANDABUTTED
HCB = Minimum distance between the top of the recessed luminaire
and any building element above it.
MIC = Minimum distance between the top of the recessed luminaire
and the building insulation above it.
SCB = Minimum distance between the side of the recessed luminaire
and any building element.
SCI = Minimum distance between the recessed luminaire and any
building insulaation.
SCG = Side clearance to auxiliary equipment [control gear (CG)]
HCB: 0mm MIC: 0mm SCB: 0mm SCI: 0mm SCG: 50mm
Risk of Fire - Required clearance from structural members and
building elements.
Warranty
AtomproductsaredistributedinAustraliabyEvoltPtyLimited('us','our',or'we').
Our contact information is set out in the bottom right hand corner of this page.
Our goods come with guarantees that cannot be excluded under the Australian
ConsumerLaw.Youareentitledtoareplacementorrefundforamajorfailure
and compensation for any other reasonably foreseeable loss or damage. You
are also entitled to have the goods repaired or replaced if the goods fail to be of
acceptablequalityandthefailuredoesnotamounttoamajorfailure.
InadditiontoyourguaranteesundertheAustralianConsumerLaw,ourgoods
alsocomewithacontractualwarranty,whichisdescribedbelow.Thiswarrantyis
additionaltoyourrightsundertheAustralianConsumerLaw(andanyotherrights
or remedies you may have under a law in relation to the products) and is not
intended to modify or exclude those rights.
Subjecttothetermsofthiscontractualwarranty,ifyourAtomproductsare
defective,wewill(atourelection)repairorreplacetheAtomproducts.Once
wemakethiselection(andtaketherelevantaction),wewillhavehonoredour
obligations under this contractual warranty.
Our total liability under this warranty is limited to the cost of repair or replacement
of the defective product (at our election). We otherwise exclude all liability in
relation to the product to the fullest extent permitted by law (noting our comments
aboveregardingtheAustralianConsumerLawandanyotherrightsorremedies
you may have).
Ifyouwishtoclaimunderthiswarranty,youmust,atyourownexpense,return
theproductorthatpartoftheproductwhichyoubelieveisdefective,together
withproofoforiginalpurchase,yourname,addressandtelephonenumber
andacerticateofinstallation(orotherdocumentrequiredbythelawforthe
installation of electrical products in the place in which the product was installed)
toEvoltattheaddresssetoutinthebottomrighthandcornerofthispage
within the warranty period. You bear all costs associated with claiming under
thiswarranty(including,butnotlimitedto,postagecosts).Withoutlimitingthe
precedingsentence,thiswarrantydoesnotapplytothecostsoftheremovalor
re-installation of the defective product.
The warranty period for this product is three years from the date of purchase.
This warranty is not transferable and is only given to the original purchaser of
theproduct,providedthepurchaserhaspurchasedtheproductfromus.Proofof
purchase must be provided to us with any warranty claim. We recommend that
you attach your proof of purchase to your product manual.
Thiswarrantydoesnotapplytoconsumableitemswithinyourproduct(including,
butnotlimitedto,lampsorbatteries).Thiswarrantydoesnotapplytoproducts
thathavebeenimproperlystored,installed,orused.Thiswarrantydoes
not apply to products that have not been maintained in accordance with the
instructions contained within this product manual.
Thiswarrantydoesnotapplytolossordamagecausedbywearandtear,misuse,
incorrectinstallationoroperation,failuretocleanandmaintain,incorrectvoltage
ornon-authorisedelectricalconnections,adverseexternalconditions(suchas
powersurgesanddips,actsofGod,exposuretoheat,corrosion,insectorvermin
infestation),useofnon-authorisedordefectivepartsorglobes,ortoitemsthat
have been repaired than by a person other than us or a repairer approved by us.
Atom is a registered brand of Evolt Pty Limited.
ForfurtherinformationpleasecallEvolt’sheadofceon13004EVOLT(438658).
EvoltPtyLimitedPOBOX271KINGSGROVENSW1480
ABN 83 112 123 529
DuetochangesinindustrystandardsandEvolt’spolicyofcontinualproductdevelopment,
productspecicationsaresubjecttochangewithoutnotice.
Images are for illustrative purposes only.
For more information please visit our website www.evolt.com.au
0000005_V1.1
