ATOMRC Flying Fish User manual

User Manual
Flying Fish
⼩⻜⻥

Introduction/产品简介
The Flying Fish is special design twin motor glider for close range FPV, the 650mm
wingspan made th glider easy to fly in small room also easy to launch. With 2 in 1
ESC , the wiring is clean and simple, no modification. Twin motor design made
the glider very efficient.
飞鱼是一款专为FPV所设计，650mm的翼展让低空高低速穿越飞行得心应手，
EPP的材质耐摔耐炸, 二合一电调使得安装电子设备方便简洁。双发设计兼顾效率与
机动性。
.
Specifications/配置参数
Version Description/版本描述
Version PNP FPV
Assembled PNP with electronics
installed
PNP version of plane
ATOMRC 1105 5000KV MOTOR*2 FOXEER Razer NANO
ATOMRC Exceed 2 IN 1 BLS 10A ESC
（Input 2~4S Bulit in 5V3A BEC）
ATOMRC Exceed TX500 VTX
ATOMRC 4.3g Servo* 4
T3018 Prop*2
5.8G 2dB Antenna
Description
Packing List
Wingspan/翼展 650mm
Length/长度 570mm
WingArea/翼面积 6.15d㎡
Material/材料 EPP
Motor/电机 1105 5000KV*2
ESC/电调 BLS 2 in 1 10A 2~4S
Propeller/螺旋桨 T3018
Servo/舵机 4.3g Servo*4Pcs
Recommned Battery/推荐电池 3S 750mAh Lipo
Specifications
1

Install the tail, then install the elevator control surface.
安装平尾，并且安装控制舵面
Plug the ESC/Servo connector to the receiver.
将舵机及电调信号线插入接收机
Install the propeller, then install the wing to the fuselage.
安装螺旋桨，然后固定机翼螺丝。
Install the hatch.
安装舱盖。
1
4
2
3
Installation/安装指南
2

3
Tx500 VTX Uermanual/图传说明书
Band
Channel
1
2
3
4
5
6
7
8
Band A
5865
5845
5825
5805
5785
5765
5745
5725
Band B
5733
5752
5771
5790
5809
5828
5847
5866
Band E
5705
5685
5665
5645
5885
5905
5925
5945
Airwave/FS
5740
5760
5780
5800
5820
5840
5860
5880
Race Band
5658
5695
5732
5769
5806
5843
5880
5917
L Band
5362
5399
5436
5473
5510
5547
5584
5621
VTX Specs
Voltage input/电压输入范围: 2~6S Lipo
Frequency/频率:5.3~5.9Ghz
Power/功率: 100/200/500mw Switchable
Power consumption/功耗: 9V 1.1A
VTX Setting
1.Hold button 3 seconds into setting mode. In setting mode. short press
the button to change band.
2.Then hold button 3 seconds into CH setting mode, short press button to
change CH.
3.Hold button 3 second to get into Power setting mode, there is short bar
on LED, short press to switch power, 1 bar means 100mW, 2 bar means
200mW, 3 bar means 500mW.
1，⻓按设置按键三秒，进⼊波段设置模式。在设置模式下，短按按键切换波段。
2，再次⻓按按键三秒钟，进⼊频道切换模式，短按按键切换频道。
3，再次⻓按按键三秒钟，进⼊切换功率模式，短按按键切换功率，数码管⼀条
为100mw，两条为200mw, 三条为500mw。

4
MOTOR Servo
MOTOR Servo
2 in 1 ESC Wiring
GND
Aileron/副翼
Throttle right/右侧油门
Throttle left/左侧油门
GND
5V+
The throttle input are bridged on the cable, if user want differential
throttle, please solder the input on the soldering pads.
电调输入信号在线上已经并联，若想使用油门差速，请将信号输入线焊接在焊盘。
GN D
VCC /2-6S
5V O UT
Ca m GND
Ca m Vid eo
VTX Wiring/图传接线图

Please download the latest user manual at
⽂件若有更新，恕不另⾏通知, 请于以下⽹站下载最新版本
www.atomrc.com/pages/download
The CG is very important for Flying Fish
CG is marked on the bottom of wing.
Check the CG carefully before flight.
重心标在机翼下方，起飞前请确定飞机是否平衡。
Tips/小贴士
This product is not toy, adult
supervision is required for those
under 14 years old!
此产品并非玩具，14岁一下用户请在
成年人指导下飞行。
CG CG
