ATOMRC Seal User manual

User Manual
Seal

Battery
Cam
GPS Motor
ESC
VTX
Flight Controller
Introduction/简介
The seal is classic glider design,easy for beginners,with detachable wing
design,user can choose 1100mm wing span or use extend wing to 1500mm
wingspan for different style of Fly.Design for FPV,the ESC,FC VTX and
Camera all have installation area.Side door for install Flight controller,easy
to wiring and maintain.Easy to build and maintain.
Specifications/规格
Installation Diagram/安装图
1
Wingspan/翼展: 1100/1500mm
Length/⻓度: 950mm
WingArea/翼⾯积: 17.8/25.7d㎡
Material/材料: EPO
Recommend Motor/推荐电机: 2212 1400KV
Recommend ESC/推荐电调: 30A 2~4S
Recommend Propeller/推荐螺旋桨: 8040
Servo/舵机: 9g Servo*4PCS
Recommned Battery/推荐电池: 21700 4S1P/3~5000mAH 4s
Specifications/规格

KIT Contents/装箱单
Packing List/装箱单
A B CD E F
GH I
Version/版本 KIT LITE PNP FPV PNP
Un-assembled Seal KIT
（User need glue the plane）
Assembled Seal KIT Assembled Seal PNP
Wood Plate ATOMRC 2212 1400KV MOTOR FOXEER Razer NANO 1200TVL
Ballhead Push Rods
ATOMRC Exceed 30A
BLS 2~4S 5V3A BEC ESC
ATOMRC Exceed 1.5W VTX
ATOMRC Exceed 9g Servo* 4
8 Inch Prop
Packing List/装箱单
Battery Strap
5.8G 2dB Antenna
Description
A：Hatch
舱盖
B：Cam hatch
摄像头舱舱盖
C：Side hatch
侧⻔
D：Fuselage
机身
E：Horizontal tail
平尾
F：Tail
机尾
G：Wing
机翼
H：Wing Extend
机翼加⻓件
I：Wing tube hatch
机翼碳管盖
2

Installation/安装指南
G l u e t h e f r a m e , V T X m o u n t a n d M o t o r m o u n t .
Glue the frame to the other side of fuselage，then glue the fuselage.
Install the battery strap , glue the battery mount board to the fuselage.
Install magnet and hatch lock to the side hatch, ESC mount.
3
1
4
2
3
将机身框架⽊⽚和图传固定的⽊⽚粘贴到机身上。
将框架⽊⽚粘贴到另⼀侧，然后粘贴左右机身。
安装电池固定⽊⽚，安装舱盖扣。
安装磁铁、舱盖⽊⽚、舱盖扣，安装电调底座⽊⽚。

Install the rudder control surface, servo and push rod.
安装⽅向舵舵⻆，舵机及拉杆。
Install the elevator control surface, servo and push rod.
安装⽅向舵舵⻆，舵机及拉杆。
Glue the tail.
粘接平尾。
Glue the body,and hatch lock.
粘接机尾，安装舱盖扣。
4
5
6
7
8

Glue the main carbon tube, tube clip.
粘接机翼碳管，管夹。
5
9※
10※
Please do not glue the dark part shown above, otherwise the carton
tube will to tight to install.
粘接管夹时，请勿在灰⾊区域粘接胶⽔，以免胶⽔溢出导致碳管难以插⼊。
Glue the side plate and control surface reinforcement carbon rod.
粘接机翼侧板，舵⾯加强⽚和舵⻆。
Glue the servo, install the push rod.
粘接舵机，安装舵机拉杆。
11
12

Assemble the wing to the body, tighten the screw to lock the wing.
安装机翼，固定管夹螺丝锁定机翼。
6
13
Glue the plastic skid.
粘接机腹防摩⽚。
Install the motor and ESC.
安装电机电调。
Install the Camera, install the camera cable.
安装摄像头，固定摄像头线。
14
15
16

Install the GPS, VTX and Flight Controller.
安装GPS，图传及⻜控。
7
17
How to installation 1100mm Wing Span
⼩翼展模式切换
1100mm 1500mm
10*8mm
600mm 200mm
3mm
If user want use 1100wing span, the wing carbon tube need change 200mm.
若⽤户想使⽤1100mm翼展，需将机翼中间碳管切换⾄200mm.

ESC Information/电调说明
1.The ESC included with the model has a safe start.If the motor battery is
connected to the ESC and the throttle stick is not in the low throttle or off
position,the motor will not start untill the throttle stick is moved to the low
throttle or off position.Once the throttle stick is moved to the low throttle or
off position,the motor will emit a series of beeps.the motor is now armed and
will start when the throttle is moeved.make sure receiver is bind to the radio,
turn on the radio, set throttle stick to the maximum.
2.Power on the ESC(The ESC must connect to the motor and Receiver).
The motor will emit a series of beeps, after the beeps, set the the throttle
stick the the minimum, the motor will emit a series beep again. now the ESC
calibration is done.
8
VTX Uermanual/图传说明书
Band
Channel
1
2
3
4
5
6
7
8
Band A
5865
5845
5825
5805
5785
5765
5745
5725
Band B
5733
5752
5771
5790
5809
5828
5847
5866
Band E
5705
5685
5665
5645
5885
5905
5925
5945
Airwave/FS
5740
5760
5780
5800
5820
5840
5860
5880
Race Band
5658
5695
5732
5769
5806
5843
5880
5917
L Band
5362
5399
5436
5473
5510
5547
5584
5621
VTX Specs/图传参数
Voltage input/电压输⼊范围: 2~6S Lipo
Frequency/频率:5.3~5.9Ghz
Power/功率: 200/800/1500mw Switchable
Power consumption/功耗: 9V 1.1A

VTX Setting/图传设置
1.Hold button 3 seconds into setting mode.
2.In setting mode. short press the button to change band.
3.Then hold button 3 seconds into CH setting mode, short press button to
change CH.
4.Hold button 3 second to get into Power setting mode, there is short bar
on LED, short press to switch power, 1 bar means 200mW, 2 bar means
800mW, 3 bar means 1500mW.
1, ⻓按设置按键三秒，进⼊波段设置模式。
2，在设置模式下，短按按键切换波段。
3，再次⻓按按键三秒钟，进⼊频道切换模式，短按按键切换频道。
4，再次⻓按按键三秒钟，进⼊切换功率模式，短按按键切换功率，数码管⼀条
为200mw，两条为800mw, 三条为1500mw。
9
Please make sure antenna is installed before power on, otherwise
the VTX will fried!!!
图传发射机通电前务必确认天线已安装妥当，否则发射线会烧毁。
Please download the latest user manual at
www.atomrc.com/pages/download
