Attop W10 User manual

1
2 3
X1
X4 X4 X4 X1
X1 X2 X1
X1
1
2
1
1
2
3
2
1
2
W10 QUICK START GUIDE
1. Package contents
2.Charging
3.Install and disassemble
(1) Stander installing
(2) Protective frames installing
Insert the stander into specified position.
1
Insert the frames into specified position.
Press up the frame buckle, and pull
back to take it out.
2
1
2
Pull the standers to take them out.
(3) Camera installing
1
2
3
Insert the camera onto the bottom
of the drone.
Plug the camera cable into specified
position.
To take it out, pull out the connecting
cable then pressing the button and pull
the camera
(4) Drone battery installing
(4) Remont controller battery installing
(6) Mobile device holder installing
Insert the battery into specified position.
Press the battery buckle button, and
pull back to take it out.
Insert the Mobile Device Holder into
specified position.
Press the Mobile Device Holder and
pull back to take it out.
1
2
Open the controller’s battery case
with the screw driver.
Accurately insert 3xAA battery into it
and lock the base up.
1
2
1
2
1
2
5V
Low battery warning
When the drone is flying, the LED indicator on the drone flashes, and the remote
control handle emits a "beep" alarm sound, indicating that the drone power is too low.
At this time, the drone needs to return and charge.
Charging guide for drone
Step1. Connect the USB cable to the adapter.
Step2. Connect the other end of USB cable to battery.
Step3. Connect the adapter to the socket. If the LED light of the USB plug is on, the
charging is completed. Otherwise, it means charging. Please use the drone
when fully charged.
Note：The connected USB Adapter should be less than or equal to 5V 2A, the voltage
not be greater than 5V, otherwise there is a risk of overloading the USB cable.
The flight time is approx 9 minutes (Battery full charge state) and the charging time
is about 60 minutes.
AA 1.5V
AA 1.5V
AA 1.5V
+
+
+

4 5
6 7
（5）One Key Take Off / Landing
（6）Headless Mode
（1）
（2）（3）
（6）
（9）
（10）
（5）
（8）
（7）
（4）
（4）One Key Take off / Landing
(1) Speed mode
Left Control Stick
(2) Headless mode
4. Remote controller
5. Preparing to fly
8. Aircraft functions
7. Toss to taunch
6.Using the remote controller
（1）Antenna
（2）Left Control Stick
（3）Right Control Stick
（4）Power Button
（7）Mobile Device Holder
（8）One Key Return
（9）Take Photos / Video
（10）Battery case
After calibration succeed, Push the Left Control Stick up and then release
(OR push the Left Control Stick to the lowest left, and meanwhile push the
Right Control Stick to the lowest right), the rotors start rotating slowly, which
means motors unlock succeed. Release Control Stick and push the Left
Control Stick slowly to take off the drone.
(1) Switch on the power
(2) Calibration
Switch on the drone Switch on the Remote
(3) Unlock the aircraft for take-off
Left Control Stick Right Control Stick
Ascend / Descend Forward / Backward
Turn left / Turn Right Left Side / Right Side
Or After unlock the motors, press button to
take off automatically.
When flying in the air, press button to land
automatically.
In case of emergency status, Press and Hold
the button about 2 seconds, the drone will
immediately stop functions and drop off.
One Key Take off / Landing
Headless Mode: When the head of drone torwards the front, press button
to activate Headless function.The drone will fly according to the controlled
direction on remote, no matter which direction the head of drone torwards to,
it will fly according to your controlled direction on remote controller.
Press button again to deactivate Headless function.
Headless mode
Place the drone onto a flat surface and push
the Left and Right Control Stick as the image
and the controller would make a sound “beep”.
The LEDs of drone are flashing, and then stop
flashing, that means calibration succeed.
Press the Left Control Stick to change the speed mode when flying.
The default speed is the most slowly one, when press one time you will hear
"beep beep", then go into the second speed acceleration, and press again with
"beep beep beep" to the final fastest speed. Totally 3 speeds and repeat by
pressing the button.
Remark: Beginners would be suggested to use the default speed firstly to
play until skillful.
Note：Please make sure head of drone torwards the front and remote
torward to the tail of drone before activate Headless function.
ATTENTION: Please finish the aboved 2 steps within 10 seconds!
1. Hearing a beep from controller, and the LEDs of drone stop flashes,
mean is automatic syncing success between Drone and Controller.
2. Now, the drone is contolled by Controller, the smart phone APP could not
control the drone.
Please place the drone onto a flat surface before Switch on the
drone power!
OR
Emergency Stop
After frequency matching and calibration finished, you can hold the aircraft
in your hand, and then horizontally throw it out. The aircraft will automatically
unlock the blades and fly in the air.
Note: It is better to operate the calibration step again after operating
Throw to fly for several times. The function will be more stable.
(Please make sure to open the App on your smart
phone before using it, then you can review the
videos taken in the media file of App.)

8 9
10 11
Left Control Stick Right Control Stick
(3) Trimming on the flying actions
(6) Photograph and Video
Take Photos / Video
One Key Return
When the drone drifts to the forward / backward / left or right side unintentionally,
you can correct it by press vertically and keep the Left Control Stick, you will
hear "beep" to enter Trimming mode, then push the Right Control Stick in the
opposite direction until it evens out. Please release the Left Control Stick after
trimming completion.
(4) 360° Flip
Fly the drone to a height over 6 feet, then press the Right Control Stick vertically
to activate 360° Flip function. Now you hear “beeps”, and then move the Right
Control Stick to flip the drone accordingly.
Notes:
. There are continuous beeps from the remote when you activate this function. If you do not move the
Right Control Stick approx 5 seconds after press the Right Control Stick vertically, the function will
be cancelled and the remote will stop beeping.
. This function can’t be activated when the battery of the drone is low power.
9.End of the flight
10.How to change the propellers
11.Flight safety
.When the flight is finished, please have a long press on the power switch for
2 seconds to shut off the power of the drone, and make it into a habit to
remove the battery from the aircraft to avoid any damage.
.When the flight is finished, please power off the remote controller and make
it into a habit to avoid any damage.
Right Control Stick
To take photo, short press button as picture.
To take video, press and hold the button approx 2 seconds of
"take video", press and hold this button again approx 2 seconds to finish
and save the video.
Please make sure to open the App on your smart phone before using it,
then you can review the videos taken in the media file of App.
(5) One Key Return
The remote toward the tail of drone and press the button, then the drone
will fly toward its back following a path parallel to remote direction. The LEDs
on the drone keep flashing when the drone is returning.
Press the button again or move the Right Control Stick, forward to cancel
this function, or the drone will keep flying back.
Note: Please deactivate Headless function and make sure the remote
toward the tail of drone before activate the Return function .
Fly in
Open Areas
Strong
GPS Signal
Maintain
Line of Sight
Fly Below
400 feet (120 m)
Avoid flying over or near obstacles, crowds, high voltage power lines, trees or
bodies of water.DO NOT fly near strong electromagnetic sources such as power
lines and base stations as it may affect the onboard compass.
DO NOT use the aircraft in adverse weather conditions such as rain, snow, fog
and wind speeds exceeding 10 m/s or 22 mph.
Stay away from the rotating
propellers and motors.
No Fly Zone
Clockwise
A
A
B
B
Counterclockwise
The front of drone
Counterclockwise Clockwise
.All drones have two rotors that spin clockwise
and two rotors that spin counter-clockwise.
.Make sure to place the propellers on the correct
axis or they will not spin correctly and the drone
will not lift.
.Each propeller is marked on its underside with
A or B. There may be a number after the letter
but you can ignore the number.
.Make sure to follow the graphic as above to see
where to place the propellers.

12 13
14 15
Remote-control models of quadcopter are dangerous merchandise. Their flight must be
operated away from the crowd. Such factors as man-made improper assembly or mechanical
damage, poor control of the electronic equipment, as well as the unfamiliar manipulation may
lead to unexpected flight accidents, such as uncontrolled flight and aircraft damage. Users are
advised to pay attention to the flight safety and understand that they are held responsible for
any accident caused by negligence.
CAUTION CAUTION
CAUTION
CAUTION
CAUTION
CAUTION
Special aircrafts for Indoor and
outdoor should stay away from
barriers
This product is a remote-control aircraft suitable for use in indoor and
outdoor environments (the outdoor wind power less than Force 4). To fly the
aircraft, please choose appropriate obstacle-free indoor and outdoor sites
with proper distance kept from the crowd or pet animals. Please don’t
operate the product in any unsafe environments, such as places of heat,
wires, power supply, etc., so as to prevent the quadcopter from the risks of
fire and electric shock resulting from collision, ditching, and entangling of
the quadcopter.
Safe usage of the lithium battery
Away from moist environments
Never misuse the product
The interior of the aircraft is also composed of many sophisticated electronic
components so it must absolutely be kept away from moisture or water vapor.
Don’t operate the aircraft in the bathroom or on rainy days; otherwise water
vapor may get inside of the aircraft and cause mechanical parts and
electronic components to malfunction leading to expected accidents.
Please do not disassemble or modify the product. For any upgrade, repair
or maintenance, please use the parts specified in our catalog to ensure the
safety of the structure. Please make sure the product is used within the
limits of operation. Don’t overload the product, and don’t use it in any other
illegal ways than prescribed by safety concerns and laws.
Lithium batteries are more dangerous than others. Be sure to read carefully
and follow the following precautions before using it. We will not be held
responsible for any damages caused by any improper use of the battery.
To avoid the danger of explosion or fires, it is forbidden to use other
chargers than the one made by our factory. Such actions done to the
battery as impact, dismantling, reverse connection of the positive and
negative poles, and burning are forbidden. Avoid metal objects from
contacting the positive and negative poles of the battery, which may cause
short circuit. Please prevent sharp items from piercing the battery, and
avoid the risk of battery fire. Please be careful when charging the battery.
Make sure that the battery is charging within your sight. Keep it out of the
reach of young children so as to avoid dangers. Don’t charge the battery
when the battery is heated after use. Otherwise, it may cause the battery to
expand, change, explode or even catch fire, threatening the safety of life
and property. To dispose of the battery, please recycle the battery in strict
compliance with the waste disposal laws and regulations of local countries
or regions in order not to pollute the environment.
SAFETY AND PRECAUSTIONS
Please make sure of the positive and negative
poles when installing the battery. Please don’t mix
the old and new batteries in use at the same time
so as to avoid damaging the battery life. If the
product is not to be used for a period of time,
please remove the battery so as to avoid battery
leakage or malfunction. Do not use the battery if it
is leaking. To dispose of the battery, please recycle
the battery in strict compliance with the waste
disposal laws and regulations of local countries or
regions in order not to pollute the environment.
The aircraft is mostly made of PA fiber or
polyethylene as well as other main materials for
electronic products. Therefore, it must be kept
from the source of heat and exposure to sunlight
so as to avoid possible damage of deformation or
even meltdown due to high temperatures.
This product is suitable for users over 14 years
old. Since the remote-control quadcopter may pose
a certain degree of difficulty for learners at the
beginning, it is recommended for it to be operated
under the guidance of experienced people for the
sake of safe flight.
Safe usage
of the battery
Keep away from
source of heat
Never operate the
product alone
CAUTION
CAUTION
Please read carefully this manual and operate the product as instructed
in this manual.
1.Prior to the flight, please learn and follow the local laws and regulations.
2.Please check whether each part is in good condition. Don’t start the flight
if any part is found damaged or incomplete.
3.Please follow the instructions to install the propellers and make sure they
are correctly and securely attached so as to avoid fall-off in flight and the
subsequent crash and unnecessary damages.
4.Make sure that the batteries of the remote controller, camera, and drone
are full charged before each flight.
5.It is suggested to operate the flight in a wide and open space with few
buildings in the surroundings so as to avoid radio jam or intervention from
communication stations, WiFi, high-voltage power lines, and so on.
6.Be sure to power on the aircraft firstly, then power on the controller next
before operating the flight.
7.When prepared to fly, make sure no personnel is inside the radius of 10
meters around the take-off/landing area, and try to avoid any unsafe
factors (such as obstacles, crowds, high-voltage power lines, trees, water
surface, etc.).
8.Before taking off, please calibrate the compass; it is suggested to take off
with GPS signal available (switch to GPS mode and the rear light of the
aircraft will flash in green). On taking off, the location where the GPS
signal is initiated will be saved as the defaulted take-off point; the return
mode will navigate the aircraft to land at this defaulted initial place.
9.Do not operate the flight in bad weather, such as gusty wind (over Force
3), snow, rain, foggy days, and the like.
10.Do not operate the flight in no-flight zones (such as airports and crowded
areas) restricted by laws.
11.Do not operate the flight in poor mental conditions (such as being drunken,
heartbroken, etc.).
12.Please keep the aircraft and all its parts out of the reach of children.
In the case children swallowing parts by accident, they should be taken
to the hospital immediately.
13.Please remove the battery and place it in a dry, moisture-proof, fog-proof
and explosion-proof environments with no electromagnetic interference.
14.Please do not disassemble, re-group, or modify the aircraft.
Please read carefully this manual and operate the product as instructed in
this manual. If don’t follow these instructions to operate, ATTOP will not
responsible for any troubles occurred.
INSTRUCTIONS TO USE
Length of main wing: 97mm
Aircraft: 240X235X70mm
Total weight: 83g
Battery: 3.7V 450mAh
Charging time: 1 hours
Flight time(Battery full charge state): Approx 9 mins
Gyroscope: Built-in
Working temperature: -10°C to 40°C
Remoter controller: 2.4G
Motor: 7X16
Working frequency: 2.4G
Power supply: 3XAA
Effective Control Distance: 50-60m
(In Wide/No Interference Signal Environment)
Aircraft parameters
Remote controller parameters

16 17
18 19
Description of ATTOP GO drone WIFI Version
How to connect the WIFI Signal
This version of drone comes with the WIFI Live Stream Camera.
1, Download the app “ATTOP GO ” from App Store / Google Play.
2, Power on the drone.
3, Go to the WIFI setting on phone/device, choose the WIFI signal
of the drone (W10-1080P+No.) , and connect it.
4, Now open the app of the drone, and Slip to Select The Drone “W10”
then enjoy to play it.
SCAN,AND DOWNLOAD APP
Attention: When the drone is at the statue of low battery, it might
unable to be connected successfully.
pic 1
1
Enter to the Interface of this drone after selection.
2
3
Media Folder : After taking photos and videos, you can review them
from this folder.
Settings: Language settings.
After connecting the WIFI signal between the drone and mobile device,
and open the APP, we can
Slip to Select The Drone “W10” see the screen
as image above.
Ready to fly
After connecting the WIFI signal and enter into the operation interface,
press the “”ON/OFF button” to open the sticks.
Wait for 2 seconds till the lights of the drone stop flashing then press the
“Calibration button” to calibrate the drone if first time play.
Push the Left Control Stick to the lowest left, and meanwhile push the
Right Control Sticker to the lowest right , and the rotors of the drone start
rotating, that unlock the motors. (see pic 1)
Press the “One Key Take Off ” to fly up the drone (or push up the Left Contol
Stick slowly), to take off. Press the “One Key Landing ” (or keep pushing
down the Left Control Stick directly) to land the drone.
2
1
3
4
Ascend / Descend / Turn left / Turn right
Go forward / Go backward / Left side flying / Right side flying
On/Off for control interface
Speed mode: 30%,60%,100%
360° flip
Headless mode
Gravity Control (press it to perform this function, by changing
your action of shaking device to control the drone flying)
Flight path mode
Voice control
VR mode
Return home page
One key take off
One key landing
Calibration
EMERGENCY STOP !!!
Switch to take photo
Switch to take video
Action switch for taking photo and video
Go Forward / Backward trimmer
Left / Right side flying trimmer
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
1
2 3
3
33
4 5 6 7 8
12
13
14
15
16
17
19
18
20
910 11
1
1
2
4
5
5
2

20 21
22
2, Control with the remote controller
(IF your drone with controller)
1, Power on the drone and power on the remote, after matching the
frequency between the remote and drone (the lights of the drone
and remote become permanent), then connect the WIFI signal
between your device and the drone.
2, Put the device to the clamp of the remote controller, then go to the
app interface to play the FPV flying.
3, Press the “Picture”button on interface or on controller, to take
picture. Press the “Video” button on interface or on controller, to
take video. After taking you can review the files from the media
folder, or from your album file of your device.
APP operation method
Ascend / Descend / Turn left / Turn right
Go forward / Go backward / Left side flying / Right side flying
On/Off for control interface
Speed mode: 30%,60%,100% three speed gear optional.
360° flip: Press this button and push the right stick to any direction,
the drone will flip as that direction.
Headless mode: Please refer to drone manual to operate.
Gravity Control: Switch “Gavity Sense Mode ”, no need
control by sticks, wave the mobile phone as image showed below,
the dronewill move as same direction movement.
Flight path mode: Press and you can draw a flying
route plan on the screen, the drone will fly according to the route
you designed.
Voice control: Unlock the motors and the rotors of the drone start
rotating, then press and say “Take off ” / “Landing” /
“Forward” / “ Backward” / “Left side” / “Right side” six voice
instructions, the drone will reflect correspondent actions.
VR mode: Suitable for VR glasses using.
Return home page
One key take off
One key landing
Calibration
EMERGENCY STOP: In case of an emergency, press
the drone will immediately stop functions and drop off.
Switch to take photo
Switch to take video
After taking photos and videos, you can review them from
Home page Media Folder or your album file of your mobile device.
Action switch: Select the Take Photo or Take Video then press
to execution this function.
Go Forward / Backward trimmer
Left / Right side flying trimmer
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
1.Turn Right 2.Turn Left 3. Forward 4.Backward
Note: The APP needs your access allowance to use
microphone,when first activate this function.
Note: The APP needs your access allowance to phone album,
when first activate this function.
