WOWITEC LARK V3 EC20 User manual
EC20
WWW.WOWITOYS.COM
RZLWHF
w
INSTRUCTIONS FOR USE
Disclaimer & Warnings
Safety Guidelines
1
2
3
4
14
17
7
6
11
Contents
Use of Battery
4
Packing list
Drone Blades Details
Controller Functions
Download the APP
Preparation for Flight
Flying the Drone
Features
APP
8
23
24
Specification
Trouble Shooting
1
Disclaimer & Warnings
1. Please read this Disclaimer & Warning and Safety Guidelines
carefully before using our product. This product is not recommended
for people under the age of 14. By using this product, you hereby
agree to this disclaimer and signify that you have read it fully. You
agree that you are responsible for your own conduct and any damages
caused while using this product, and its consequences. You agree to
use this product only for purposes that are proper and in accordance
with local regulations,terms, and all applicable policies and guidelines.
2. When using this product, please be sure to strictly abide by the
specification requirements and safety guidelines stated in this
document. Any personal injury, property damage, legal disputes and
all other adverse events caused by the violation of the safety
instructions or due to any other factors, will not be WOWITOYS's
responsibility.
off, and ensure the drone is always flying in excess of 1.5 meters
from yourself and others
is risk of burns
rubbish, all parts should be taken to the local recycling centre
high temperature or disposed of in a fire
2
1.Check Before Use
2.Safe flight Environment
GPS signal
is good
Fly in Open Areas Maintain Line
of Sight
Fly Below
1640 feet(500 m)
Safety Guidelines
(1). This product is not a toy, it is a high precision drone that
integrates various electronic stability and control mechanisms. Please
be sure to setup this drone carefully and correctly to ensure safe,
accident-free operation.
(2). Please be sure that the batteries of the drone and controller are
clean, undamaged and have enough power.
(3). Please be sure that all the propellers are undamaged and are
installed in the right direction.
(4). Please do a thorough check of the product before each use:
Check for firmness of the parts, any signs of cracks and wear of the
propeller,battery power and effectiveness of the product until the issue
has been dealt with.
(1). Make sure the surrounding area is free of people, pets or other
obstacles before starting to fly the drone.
(2). The drone is designed for indoor and outdoor use. However, it is
not recommended to fly the drone inside if there is limited space, or
outside if there is any wind.
(3). Keep a safe playing distance from the drone at all times.
3
3. Use of Battery
(1).Ensure batteries are fitted in the correct direction as shown
in the instruction manual.
(9).Do not attempt to disassemble or modify the battery in any way.
Li-Po Battery Disposal & Recycling
Waste Lithium-polymer batteries must not be placed with household garbage.
Please contact local environmental or waste agency or the supplier of the
product or the nearest Li-Po battery recycling center.
(10).Do not use the battery if it gives off an odor, generates heat,
becomes discolored or is deformed, or appears abnormal in any
way. If the battery is in use or being charged, remove it from the
device or charger immediately and discontinue use of it.
(8).Do not connect the battery directly to wall outlets or car
cigarette-lighter sockets.
(7).It is recommended to only use the USB charging cable that comes
with the drone to charge the battery.
(6).If the device is not going to be used for an extended period of time,
remove batteries to prevent potential damage from battery leakage.
(4).Dispose used batteries carefully.
(3).Do not mix new and old batteries as this can lead to a poor
performance of the product.
(5).Keep dead batteries away from heat and fire.
(2).Avoid short circuits by fitting the batteries incorrectly, and do not
crush or squeeze the batteries as this could carry the risk of
explosion.
4
It is crucial that all the blades are installed in the correct
position (Pay attention to the letter A or B printed underneath
each blade.)
Drone’s details
Blade A
(Clockwise)
Blade A
(Clockwise)
Blade B
(Counter Clockwise)
HEAD
Camera
Blade B
(Counter Clockwise)
Packing list
USB charger x 1Controller x 1Drone x 1 Battery x 1
Blade x 4 Screwdriver x 1 User Manual x 1
5
Charging the drone battery
Do not leave the battery unattended while charging & only use
the supplied battery or plug charger.
WARNING
Computer USB Port
Battery
USB Adapter
(5V/0.5-2.0A)
1. Remove the battery from the drone & insert the charging wire
into the battery charging slot
2. Connect the USB charger (square socket) to a computer, the
USB indicator will glow red
3. The red light will go out when the battery is fully charged
insert the battery
into drone
6
auto return
Home
speed-select
button
Controller functions
camera up
camera down
antenna
calibration/
emergency Stop
right stick
one key start/stop
normal/GPS mode
throttle
left stick
power switch
picture/LED
video/
headless mode
phone holder
1.Unscrew the battery cover,and insert 4xAAA batteries(not included),
make sure to insert them following the correct polarity as shown.
2.Replace the battery cover.
Always use alkaline batteries
Never mix old and new batteries
.
.
4xAAA batteries
(not included)
7
Preparation for Flight
power switch
1.Boot up
Turn on the power of the remote control; turn on the power of
the drone (long press for 2 seconds to turn on/off)
2.Pair the Drone to the Remote Control
(1).After the remote control and the drone are properly loaded with
batteries, place the drone on a horizontal surface and turn on the
remote control power switch. At this time, the remote control power
indicator flashes red. Turn on the drone, the remote control will
beep twice to indicate that it is ready to pair, at this time the front
green lights and rear red lights flash.
(2).Slowly push the left lever of the remote control up to the top and
then down to the bottom. At this time, the remote control sends
out a pairing command and the power indicator light is always
green.
power indicator
8
4.Calibration
Gyro Calibration
(1).Place the drone on a horizontal surface, push the left lever of
the remote control to the bottom, simultaneously move the right
lever of the remote control to the left and right quickly, and
release the lever when the front and rear indicators of the drone
flash simultaneously (don’t move the drone during this process).
(3).Wait for about 10 seconds, the red light on the rear of the drone
flash and turn into a steady light, which means that the drone
has received the pairing instruction and completed the self-check.
The pairing is successful.
3.Download the APP
(1).Turn on the drone.
(2). Enter the Settings menu of your mobile device.
(3). Activate WIFI connection, search for the drone's wifi network and
connect to it.
(4).Click on the ICON to open the interface of the APP, the video
image from the drone's camera is displayed on the screen.
Connect to the APP:
Search and download"WOWI FLY"
from Google Play.Or scan the QR code
on the left to download.
Search and download"WOWI FLY"
from App store.Or scan the QR code
on the left to download.
9
(2).Wait for about 10 seconds, the indicator light on the rear of
the drone is always on, indicating that the calibration is
successfully completed.
Geomagnetic Calibration
(1).Press the calibration compass button on remote control, wait for
the remote control to make a beeping sound and release the
button. The front green light of the drone will flash quickly, and
the rear red light will be steady on, indicating that the compass
calibration is started. (Please be noted that long pressing this
button for 3 seconds will activate emergency stop function)
(2).Pick up the drone and keep it horizontal, then rotate the drone
clockwise at a constant speed (approximately 3-5 rotations),
wait until the front green light is on, the rear red light flashes
quickly, and the remote control will beep once, indicating the
horizontal direction Calibration is completed.
30cm
10
(3).Hold the drone in hand with the nose down, and then slowly
rotate the drone clockwise (about 3-5 rotations), wait until the
red light on the rear of the drone is off and the remote control
beeps twice, indicating that the vertical calibration is completed.
(4).Place the drone horizontally and wait for the red light on the
rear of the drone to keep on to indicate that the compass
calibration is completed.
GPS search Satellites
Switch the remote control to GPS mode, at this time GPS signal
light on the remote control flashes red, The front green light of the
drone flashes to indicate that the drone is searching for GPS
satellite signals.
When the drone is flying in outdoor GPS mode, it must have
enough GPS signal before it can take off. The normal outdoor
search time for satellites without interference is about 3-5 minutes.
When the front green light of the drone is always on and the GPS
signal light of the remote control is always on, it means that at
least 8 satellites have been searched before the flight can be
carried out.
30cm
11
5.Taking-off and landing methods
Taking-off method 1
(1) Press and hold the one key start/stop button for 1 second, the
drone will automatically take off at an altitude of about 1.2 meter.
(2) Manual take-off: pull the left and right levers at the same time (as
shown in the figure), and then push the left throttle lever upwards
to take-off.
Taking-off method 2
Take off method 1
Take off method 2
Flying the Drone
GPS mode
GPS signal
12
Landing method 1
Press and hold the one key start/stop button for 1 second, and the
drone will land on its own.
Landing method 2
Pull the left throttle lever of the remote control to the bottom and the
drone will land by itself.
Landing method 1
Landing Method 2
6.Drone Operations
(1). Ascend / descend / turn left / turn right
Use “the left lever”
to control the altitude &
rotation during flight.
13
(2) Forward / Backward / Leftward / Rightward
Use “the right lever” to
control forward,
backward,left & right
movement during flight.
7.Indoor Flight Normal Mode(Non-GPS)
(1).Place the drone on an open horizontal surface to pair the remote
control to the drone.
(2).Select normal mode on remote control. (as shown in the figure).
(3).The drone is ready to take off and can be operated by the remote
control.
DO NOT switch between normal mode/GPS mode during flight. Such
operation will lead to flight anomalies of the drone; failure of GPS
positioning; deviation of reverse flight and other serious faults.
normal mode
14
Features
2
13
1.To take a photo:
Press once, take one picture.
Press once to start the video mode, press one time again to stop
the video mode.
(Remark: because the drone comes with a wifi camera, it can
only take pictures or videos after connected with mobile phone.
Since the wifi board is built with a memory card slot, so the
pictures and videos can be stored in both mobile phone and
memory card inserted in the card slot.)
2.To record a video:
4
5
Long press the camera button to turn on/off the LED light
To activate headless mode, long press the video button & the
drone will fly in the desired selected direction, regardless of the
direction the drone is facing.Long press the video button again to
exit the headless mode.
3.Geomagnetic Calibration/Emergency Stop
Please refer to the description of this function on page 9.
Note: When the drone is flying within 3 meters, long press this
button is to activate Emergency Stop function, the drone will stop
flying immediately and the motors will stop working!
GPS signal
power indicator
15
7
68
9
Press the Normal Mode Button, the drone will fly in the normal
mode, no GPS function
5.Normal/GPS mode
After the drone is paired sucessfully and started to fly, press the
GPS mode button, the drone will fly in the GPS mode.
8.Speed-select button
Two speeds for the drone, fast and slow.
When the drone is flying in the GPS mode, press the return button
for 2 to 3 seconds, the drone will return to the position where GPS
mode started.
9.Auto return home
7.Camera down
6.Camera up
Long press the "one key start/stop" button, hear a short "beep",
the drone will take off slowly and hover at an altitude of about 1.2
meters.
4.one key start/stop
16
When the drone flies too far in GPS mode, users can't tell the
directions of the drone, then users can operate it in below 2 ways to
fly back the drone to the takeoff place:
1. Long press the auto return home button for 2-3 seconds, the drone
will fly back to the takeoff place automatically;
2. Directly switch off the power of the remote control, the drone will
return to the takeoff place.
Remark: When the drone is out of the range of the remote control, the
drone will fly back to the takeoff place automatically.
Auto return home:
17
WOWIFLY APP
1.APP Interface
1.Return home
2.Altitude Mode
3.Flight record
4.GPS signal
5.Controller signal
6.Drone Power
7.Show/Hide set up menu
8.Hide
9.3D view
10.Reverse lens
11.V-Sign
12.Waypoint flight
13.Follow me
14.Surround flight
15.Add music
16.One key start
17.One key stop
18.Automatic return
19.Photo/Video
20.Shutter
21.Replay
22.Map
23.Distance
24.Filter
25.Zoom
18
2. Smart Flight Mode
Tap the icon to enter the surround mode (surround flight)
Under normal flight conditions (flight altitude more than 5 meters),
GPS signal is more than or equal to 8 satellites, the drone will orbit
clockwise defaulting to the current position as the center of the orbit,
with a radius of 10 meters, and a speed of 3 meters per second.
Follow-me Mode:
Surround Mode:
Tap the icon to activate follow-me flight mode.
Normal flight altitude is above 5 meters, GPS signal is more than or
equal to 8 satellites, the drone will follow the mobile phone to move
position.
Waypoint Flight Mode:
Tap the icon to activate the waypoint flight mode.
Set multiple location points on the map, and the drone will fly in the
order of the set location points. A total of 1-15 points can be set. The
serial number of each point will be marked on the map.
Table of contents
