ATV A-PRO-4 User manual

This manual details the functions and specications of the A-PRO-4.
For information on product usage, please refer to the Start Up Manual.
A-PRO-4 Version1.3
AV mixer
Reference Manual
ATV Logo
pantone151
(DIC120)
Index 2
Onscreen menu 3
Screen names and operation 3
Display method 4
Remote set-up 5
USB remote software 5
System requirements ................. 5
Installation ...........................6
Screen names and operation ..........7
Network remote 9
System requirements ................. 9
Browser connection ...................9
Screen names and operation .........10
Parameter 12
Tree conguration 12
Parameter list 13
TELNET Command 28
Support 35
Click the blue title or page number to jump to that page.

2AV mixer A-PRO-4 Reference Manual
Index
Numerals
3G SDI Type ............... 20
A
AOI ................ 13, 14, 16
Audio Delay ................ 23
Audio Follow .... 14, 15, 18, 19
C
Color Correct .... 13, 15, 17, 23
F
Factory Reset .............. 27
Fade Color ................. 26
Fade Time ................. 25
G
GPI ................... 19, 24
H
HDMI Color ......... 14, 16, 21
HDMI Color Depth .......... 21
HDMI Mode ................ 21
I
Input Gain ................. 19
Input Impedance ............ 19
Input Position .......... 13, 14
L
LAN ....................... 27
LOS Mute Clear Delay ...... 26
LOS Threshold ...... 13, 14, 16
M
MAC Adrs.................. 27
Maximum Output Level ...... 24
N
No Signal Color ............ 25
NTSC Setup Level .......... 16
O
Output Position ............. 22
P
Panel Lock ................. 26
PGM ............... 20, 21, 22
Power on select ............ 25
PVW ............... 20, 21, 22
S
Scaling Type ............... 17
SDI Color .................. 20
Switching Mode ............ 25
Sync Reference ............ 25
T
T-bar Adjust ................ 27
TELNET Command ......... 28
Transition Time ............. 25
U
USB Audio Level ........... 22
Z
Zoom ...................... 17

3
AV mixer A-PRO-4 Reference Manual
Top Panel
Output video: PVW output
MENU
Input ENTER
Ext Audio Input ENTER
Output ENTER
Ext Audio Output ENTER
System ENTER
Input
Parameter value
Display the parameter value.
ENTER: Press the Enter button to display menu for
that group.
RESET: Press the Enter button to reset the parameter
values for that group to default.
Parameter name
Display parameter groups and parameter
names.
The selected item is highlighted.
MENU VALUE button
When a parameter name is selected: Select an item.
When a parameter value is selected: Select the value.
MENU ENTER button
When the onscreen menu is hidden: Display the onscreen menu.
When a parameter name is selected: Edit the parameter value.
When a parameter group is selected: Move down one level.
When a parameter value is selected: Store the current value.
MENU EXIT button
When at the top of the hierarchy: Hide the onscreen menu.
When a parameter name is selected: Move up one level.
When a parameter value is selected: Cancel editing.
Screen names and operation
Onscreen menu

4AV mixer A-PRO-4 Reference Manual
Top Panel
2
Display method
1Disconnect the PVW output from other equipment before turning on
the power.
PVW output: Factory setting is HDMI OUT connector
2Press the MENU ENTER button.
Onscreen menu is displayed.
Refer to the parameter list for information on setting content and items.
Start Up Manual Refer to Connecting to a video output connector
Refer to Turning on the power.
Refer to P.13 Parameter list

5
AV mixer A-PRO-4 Reference Manual
Top Panel
2
USB remote software
Remote set-up
System requirements
Windows Mac
OS Windows10 (32bit/64bit) OS X 10.11 (El Capitan)
CPU As per OS configuration As per OS configuration
Memory As per OS configuration As per OS configuration
Free hard disk space 2MB min. 20MB min.
USB port USB 2.0 or 3.0 USB 2.0 or 3.0
Resolution 1024 x 768 or higher 1280 x 800 or higher
Refer to the Start Up Manual for information on connecting the mixer to the PC.
Start Up Manual Refer to Other connections
Caution

6AV mixer A-PRO-4 Reference Manual
Installation
Refer to the parameter list for information on setting content and items.
Windows
1Download the USB remote application for Windows from our website.
http://www.atvcorporation.com/en/products/videos/a-pro-4/support.html
2Unpack the downloaded ZIP file to any directory.
Move the unpacked file to the desired directory.
3Run MS-USB-RS.exe.
USB remote program will run.
(The "exe" extension may not display on your machine.)
Depending on how your computer is set up, the first time you launch MS-USB-RS it may be terminated with an error
message saying the PC is protected by Windows. In this case, select the le and right-click to select "Run."
Caution
Mac
1Download the USB remote application for Mac OS X from our website.
http://www.atvcorporation.com/en/products/videos/a-pro-4/support.html
2Unpack the downloaded DMG file to any directory.
Move the unpacked file to the desired directory.
3Run MS-USB-RS.app.
USB remote program will run.
(The "app" extension may not display on your machine.)
Depending on how your Mac is set up, the rst time you launch MS-USB-RS it may be terminated with an error message
reading "MS-USB-RS" can't be opened because it is from an unidentied developer." In this case, depress the "control" key
and click "Open." The system will ask for your verication to run the program.
This procedure is only needed the rst time you run the program.
Caution
Refer to P.13 Parameter list

7
AV mixer A-PRO-4 Reference Manual
Device
Displays the device name.
Serial No
Displays the serial number.
Firmware Version
Displays the firmware version.
Main FPGA Version
Displays the Main FPGA version.
USB3.0 FPGA Version
Displays the USB 3.0 FPGA version.
Device Select button
Displays the Device Select screen.
Selects the device.
Parameter Setting button
Displays the Parameter Setting screen.
Sets parameters.
The device must be selected before parameters can
be set.
Software Update button
Displays the Software update screen.
Used to update software.
The device must be selected before software can be
updated
Exit button
Exit USB Remote software.
Select button
Select the device.
Selects the device. Device List Update button
Refreshes the list of A-PRO-4 and MS-8 devices
connected to the PC.
Cancel button
Exit the Device Select screen.
Screen names and operation
All screens shown are for Windows.
Menu screen
Device Select screen
Refer to P.8 Parameter Setting screen
Refer to P.7 Device Select screen
Refer to P.8 Software Update screen

8AV mixer A-PRO-4 Reference Manual
Browse...button
Select the desired update file.
Update File
Displays the selected update file.
Now Version
Displays the versions of installed
programs.
Update Version
Displays the versions of the selected update files.
Exit button
Exist the Software Update screen.
UPdate Execute button
Update the software.
Parameter name
Display parameter groups and
parameter names.
The selected item is highlighted.
Parameter value
Display the parameter value.
Exit button
When top level is selected:
Exits the Parameter Setting screen.
When parameter name or value selected:
Move up one level.
Up button, Down button
When a parameter name is selected: Select an item.
When a parameter value is selected: Select the value.
Enter button
When a parameter group is selected: Move down one level.
When a parameter name is selected:
Edit the parameter value.
When a parameter value is selected: Move up one level.
Software Update screen
Parameter Setting screen
Download the needed update le from our website.
http://www.atvcorporation.com/en/products/videos/a-pro-4/support.html
Caution

9
AV mixer A-PRO-4 Reference Manual
Browse...button
Select the desired update file.
Update File
Displays the selected update file.
Now Version
Displays the versions of installed
programs.
Update Version
Displays the versions of the selected update files.
Exit button
Exist the Software Update screen.
UPdate Execute button
Update the software.
Parameter name
Display parameter groups and
parameter names.
The selected item is highlighted.
Parameter value
Display the parameter value.
Exit button
When top level is selected:
Exits the Parameter Setting screen.
When parameter name or value selected:
Move up one level.
Up button, Down button
When a parameter name is selected: Select an item.
When a parameter value is selected: Select the value.
Enter button
When a parameter group is selected: Move down one level.
When a parameter name is selected:
Edit the parameter value.
When a parameter value is selected: Move up one level.
Network remote
System requirements
Supported browsers
Windows
Google Chrome Version 50.0 for Windows
Microsoft Internet Explorer for Windows 7 Version 11.0
Microsoft Edge for Windows 10 Version 25
Mac Apple Safari for OS X Version 9.0.3
Refer to the Start Up Manual for information on connection the device to the network.
Start Up Manual Refer to Other connections
Caution
Browser connection
1Use a browser on a PC running on the same network.
2Connect the browser to the device using the IP address (http://192.168.1.1).
The network remote set-up screen will be displayed.
If the device is not displayed, check the network connections and IP address.
Refer to the parameter list for information on setting content and items.
Refer to P.13 Parameter list
Refer to P.27 IP Adress
Start Up Manual Refer to Other connections

10 AV mixer A-PRO-4 Reference Manual
Screen names and operation
All screens shown are for Windows.
Version display/Parameter save/reset screen
Firmware Version
Displays the firmware version.
Main FPGA Version
Displays the Main FPGA version.
USB3.0 FPGA Version
Displays the USB 3.0 FPGA version.
Video Input Select button
Selecs the input signal.
Factory Reset button
Resets all parameters to the factory settings.
Parameters Save button
Saves the updated parameter settings.

11
AV mixer A-PRO-4 Reference Manual
Parameter Setting screen
Press the apply button to save the new parameter value.
Caution
Displays the parameter
settings for selected
parameter group.
Parameter value
Display the parameter value.
Input and select a value to change it.
Parameter name
Display parameter groups and
parameter names.
apply button
Saves the updated parameter settings.
reset button
Resets group parameters to the
factory settings.

12 AV mixer A-PRO-4 Reference Manual
Tree configuration
Parameter
InputX (SDI) →Format P.13
LOS Threshold P.13
AOI P.13
Input Position P.13
Color Correct P.13
Audio P.14
Input3 (HDMI) →Format P.14
HDMI Color P.14
LOS Threshold P.14
AOI P.14
Input Position P.14
Color Correct P.15
Audio P.15
Input4 (HDMI/VIDEO) →Format P.16
HDMI Color P.16
NTSC Setup Level P.16
LOS Threshold P.16
AOI P.16
Scaling P.17
Color Correct P.17
Audio P.18
Ext Audio Input MENU →Stereo P.19
Output MENU →Format P.20
SDI Settings P.20
HDMI Settings P.21
USB3.0 Settings P.22
Output Position P.22
Color Correct P.23
Audio P.23
Ext Audio Output MENU →Mode P.24
Maximum Output Level P.24
Monitor Select P.24
System MENU →Switching Mode P.25
Power on select P.25
Sync Reference P.25
Transition Time P.25
Fade Time P.25
REF IN P.25
No Signal Color P.25
Fade Color(WHITE) P.26
Fade Color(BLACK) P.26
LOS Mute Clear Delay P.26
Panel Lock P.26
LAN P.27
T-bar Adjust P.27
Version P.27
MAC Adrs P.27
Factory Reset P.27

13
AV mixer A-PRO-4 Reference Manual
Parameter list
InputX (SDI)
InputX(SDI) 1/3
Parameter name Range Unit Remarks
Format [InHsize]x[InVsize]/[InFrameRate][i/P/sF] Displays the input signal format.
LOS Threshold 0,,5,,10
Sets the threshold for loss-of-signal action.
The lower the value the higher the sensitivity, and the higher the
value the better the system will resist noise.
AOI RESET
Sets the effective region for the input video.
The area outside this region is masked in black.
Press reset to restore the initial value.
H size 0,,[InHsize] pixel Sets effective region width.
V size 0,,[InVsize] line Sets effective region height.
H position 0,,[InHsize]-1 pixel Sets effective region horizontal position.
V position 0,,[InVsize]-1 line Sets effective region vertical position.
Input Position RESET Adjusts the input video position.
Press reset to restore the initial value.
H position -2048,,0,,2048 pixel Adjusts the input video horizontal position. *2
V position -1200,,0,,1200 line Adjusts the input video vertical position. *2
*2 Adjustment is limited by the e󰀨ective region.
InputX (SDI) 2/3
Parameter name Range Unit Remarks
Color Correct RESET Adjusts the input video color.
Press reset to restore the initial value.
Brightness 0,,100,,200 % Adjusts the brightness.
Contrast 0,,100,,200 % Adjusts the contrast.
Saturation 0,,100,,200 % Adjusts the saturation.
Red Brightness 0,,100,,200 % Adjusts the black balance (red).
Green Brightness 0,,100,,200 % Adjusts the black balance (green).
Blue Brightness 0,,100,,200 % Adjusts the black balance (blue).
Red Contrast 0,,100,,200 % Adjusts the white balance (red).
Green Contrast 0,,100,,200 % Adjusts the white balance (green).
Blue Contrast 0,,100,,200 % Adjusts the white balance (blue).

14 AV mixer A-PRO-4 Reference Manual
Input3 (HDMI)
Input3 (HDMI) 1/3
Parameter name Range Unit Remarks
Format [InHsize]x[InVsize]/[InFrameRate][i/P/sF] Displays the input signal format.
HDMI Color Auto,RGB(Full),RGB(Limit),YCC(SD),YCC
(HD) Input color space can be set to auto-detect or a specific setting.
LOS Threshold 0,,5,,10
Sets the threshold for loss-of-signal action.
The lower the value the higher the sensitivity, and the higher the
value the better the system will resist noise.
AOI RESET
Sets the effective region for the input video.
The area outside this region is masked in black.
Press reset to restore the initial value.
H size 0,,[InHsize] pixel Sets effective region width.
V size 0,,[InVsize] line Sets effective region height.
H position 0,,[InHsize]-1 pixel Sets effective region horizontal position.
V position 0,,[InVsize]-1 line Sets effective region vertical position.
Input Position RESET Adjusts the input video position.
Press reset to restore the initial value.
H position -2048,,0,,2048 pixel Adjusts the input video horizontal position. *2
V position -1200,,0,,1200 line Adjusts the input video vertical position. *2
*2 Adjustment is limited by the e󰀨ective region.
InputX (SDI) 3/3
Parameter name Range Unit Remarks
Audio
Audio Follow Off,On
Selects the audio selection method.
Off: Output at the set mixing level at all times.
On: Output at the set mixing level only when a video is selected.
Channel Level -INF,,0.0,,+6.0 dB Displays the mixing level set with the AUDIO LEVEL fader on the top
panel.
Channel Select 1+2,,15+16 Selects one channel from multi-channel (1–16).

15
AV mixer A-PRO-4 Reference Manual
Input3 (HDMI) 2/3
Parameter name Range Unit Remarks
Color Correct RESET Adjusts the input video color.
Press reset to restore the initial value.
Brightness 0,,100,,200 % Adjusts the brightness.
Contrast 0,,100,,200 % Adjusts the contrast.
Saturation 0,,100,,200 % Adjusts the saturation.
Red Brightness 0,,100,,200 % Adjusts the black balance (red).
Green Brightness 0,,100,,200 % Adjusts the black balance (green).
Blue Brightness 0,,100,,200 % Adjusts the black balance (blue).
Red Contrast 0,,100,,200 % Adjusts the white balance (red).
Green Contrast 0,,100,,200 % Adjusts the white balance (green).
Blue Contrast 0,,100,,200 % Adjusts the white balance (blue).
Input3 (HDMI) 3/3
Parameter name Range Unit Remarks
Audio
Audio Follow Off,On
Selects the audio selection method.
Off: Output at the set mixing level at all times.
On: Output at the set mixing level only when a video is selected.
Channel Level -INF,,0.0,,+6.0 dB Displays the mixing level set with the AUDIO LEVEL fader on the top
panel.
Channel Select 1+2,,7+8 Selects two channels from multi-channel (1–8).

16 AV mixer A-PRO-4 Reference Manual
Input4 (HDMI/VIDEO)
Input4 (HDMI/VIDEO) 1/4
Parameter name Range Unit Remarks
Format [InHsize]x[InVsize]/[InFrameRate][i/P/sF] Displays the input signal format.
HDMI Color Auto,RGB(Full),RGB(Limit),YCC(SD),YCC
(HD) Input color space can be set to auto-detect or a specific setting.
NTSC Setup Level 0IRE,7.5IRE Selects the NTSC set-up level.
LOS Threshold 0,,5,,10
Sets the threshold for loss-of-signal action.
The lower the value the higher the sensitivity, and the higher the
value the better the system will resist noise.
Format Fix Off,On
When on, input format detection is disabled and the input format
fixed.
EDID is rewritten for Fix Format.
Fix Format
2K/59p/50p/29p/25p/24p/23p,1080/59p/50
p/29p/25p/24p/23p,1080/59i/50i,720/
59p/50p,480/59p, 76/50p,480/59i,576/50i
Format Fix=On: EDID is rewritten to this value.
Format Fix=Off: EDID is rewritten to a general-use value.
AOI RESET
Sets the input video effective region.
Video outside this region will be stripped.
Press reset to restore the initial value.
H size 0,,[InHsize] pixel Sets effective region width. *1
V size 0,,[InVsize] line Sets effective region height. *1
H position 0,,[InHsize]-1 pixel Sets effective region horizontal position.
V position 0,,[InVsize]-1 line Sets effective region vertical position.
*1 The maximum zoom is 12 times of the total processed pixel equivalent.
The minimum zoom is 1/12th of the total processed pixel equivalent.

17
AV mixer A-PRO-4 Reference Manual
Input4 (HDMI/VIDEO) 2/4
Parameter name Range Unit Remarks
Scaling RESET Sets the input video scale.
Press reset to restore the initial value.
Scaling Type Full,Box,Crop,Thru
Sets the input video aspect ratio.
Full: Input/output aspect ratios are ignored, and full-screen video is
used.
Box: Depending on differences between input and output aspect
ratios, there is an area masked in black.
Crop: The aspect ratio is preserved and part of the input video is
cropped.
Thru: Output without scaling.
Zoom 10,,100,,1000 % Sets the scale (magnification) for input video. *1
H position -2048,,0,,2048 pixel Adjusts the input video horizontal position. *2
V position -1200,,0,,1200 line Adjusts the input video vertical position. *2
*1 The maximum zoom is 12 times of the total processed pixel equivalent.
The minimum zoom is 1/12th of the total processed pixel equivalent.
*2 Adjustment is limited by the e󰀨ective region.
Input4 (HDMI/VIDEO) 3/4
Parameter name Range Unit Remarks
Color Correct RESET Adjusts the input video color.
Press reset to restore the initial value.
Brightness 0,,100,,200 % Adjusts the brightness.
Contrast 0,,100,,200 % Adjusts the contrast.
Saturation 0,,100,,200 % Adjusts the saturation.
Red Brightness 0,,100,,200 % Adjusts the black balance (red).
Green Brightness 0,,100,,200 % Adjusts the black balance (green).
Blue Brightness 0,,100,,200 % Adjusts the black balance (blue).
Red Contrast 0,,100,,200 % Adjusts the white balance (red).
Green Contrast 0,,100,,200 % Adjusts the white balance (green).
Blue Contrast 0,,100,,200 % Adjusts the white balance (blue).

18 AV mixer A-PRO-4 Reference Manual
Input4 (HDMI/VIDEO) 4/4
Parameter name Range Unit Remarks
Audio
Audio Follow Off,On
Selects the audio selection method.
Off: Output at the set mixing level at all times.
On: Output at the set mixing level only when a video is selected.
Channel Level -INF,,0.0,,+6.0 dB Displays the mixing level set with the AUDIO LEVEL fader on the top
panel.
Channel Select 1+2,,7+8 Selects two channels from multi-channel (1–8).
Disabled when composite input selected.

19
AV mixer A-PRO-4 Reference Manual
Ext Audio Input MENU
Parameter name Range Unit Remarks
Stereo Mono,Stereo Sets whether the AUDIO IN connector is monaural or stereo.
Mode Audio Input,GPI Input1-4,GPI Output1-4
Sets GPI/AUDIO IN connector function:
Audio Input: Used as the audio input connector.
GPI Input 1-4: Used as GPI input connector 1-4.
OPEN and CLOSE pulsewidths must be at least 100 ms.
GPI Output 1-4: Used as GPI output connector 1-4.
Current 20 mA max., external supply +5 V.
* Left-ch tip is GPI1 and ring is GPI2, right-ch tip is GPI3 and ring is
GPI4.
GPI1 IN: VIDEO INPUT SELECT1 button
GPI1 OUT: INPUT 1 PGM (red) tally
GPI2 IN: VIDEO INPUT SELECT2 button
GPI2 OUT: INPUT 2 PGM (red) tally
GPI3 IN: VIDEO INPUT SELECT3 button
GPI3 OUT: INPUT 3 PGM (red) tally
GPI4 IN: VIDEO INPUT SELECT4 button
GPI4 OUT: INPUT 4 PGM (red) tally
Input Gain -13.50,,0.00,,33.75 dB
Adjusts AUDIO IN connector input gain.
Recommended settings:
North America: 0.0dB (+4dBu=-20dBFS)
Europe: 6dB (+0dBu=-18dBFS)
Private broadcasting: 12dB (-10dBV=-20dBFS)
Audio Follow Off,IN1,IN2,IN3,IN4
Sets the video input to be synched with the audio from the AUDIO IN
connector.
Off: Always output as set mixing level.
IN1-4: Output as the set mixing level when the set input is selected.
Channel Level -INF,,0.0,,6.0 dB Displays the audio mixing level for the AUDIO IN connector.
Set with the EXT INPUT knob on the front panel.
Input Impedance Hi-Z,600ohms Sets the input impedance for the AUDIO IN connector.

20 AV mixer A-PRO-4 Reference Manual
Output MENU
Output MENU 1/4
Parameter name Range Unit Remarks
Format 2K/59p/50p,1080/59p/50p,1080/59i/50i,
720/59p/50p,480/59i,576/50i Sets the output format.
SDI Settings RESET SDI output settings.
Press reset to restore the initial values.
SDI Output Select PGM,PVW
Selects the signal output to SDI OUT.
PGM: Program (PGM) bus.
Outputs signal with the VIDEO INPUT SELECT button
showing red.
On-screen menu is not displayed.
PVW: Preview (PVW) bus.
If Switching Mode=Direct, outputs signal with the VIDEO
INPUT SELECT button showing red.
If Switching Mode=Preview, outputs signal with the VIDEO
INPUT SELECT button showing green.
On-screen menu is displayed.
* I f HDMI Output Select=PGM and this parameter set to PGM, the
HDMI Output Select setting will switch to PVW.
SDI Color YCC422,RGB444,YCC444,
Sets SDI output color sampling.
YCC422: 10-bit YCC 4:2:2 output.
RGB444: 10-bit RGB 4:4:4 output.
YCC444: 10-bit YCC 4:4:4 output
* When set to RGB444 or YCC444, 2K 1080p output is 6G-SDI,
and 1080i 720p output is 3G-SDI. 480i and 576i are always 10-bit
YCC4:2:2 output.
3G SDI Type LevelA,LevelB
Sets the output method for 3G-SDI output.
Level-A: Commonly used in facility equipment
Level-B: Commonly used in broadcast equipment.
