ATZ HDBT-E70-WPVD User manual

Model : ATZ HDBT-E70-WPVD
Description : HDBaseT Sender Wall Plate for HDMI/VGA/DP/Audio 70m)
pg. 1
Notes : - All brand names and trademarks are properties of their respective holders and are referred to here for descriptive purpose only. Photo attached is for reference only, it may be slightly varied in items of colour,
shape from the actual item delivered from time to time.
All specifications are subject to change without prior notice.
© Copyright A Z
ATZ HDBT-E70-WPVD is a multiple functional switcher that switches input from different
formats to display via HDBaseT. It supports 1x DP, 1x HDMI and 1x VGA+3.5mm audio
inputs. It supports selection between HDMI, VGA and DP manually or automatically last-
in-first-out or Last-input priority* if the current input device is turned off or unplugged).
Supports resolution up to 4k@30hz, with POC power over cable), and POE function,
power only required at either end of HDBaseT Sender or Receiver. It can transmit up to
70m at 1080p@60, and 4K@30 to 40m.
*Prority mode feature to fix to last input even with new input detected.
Features:
•Supports 1080P 3D, and up to 4K30
•Supports HDCP1.4
•Transmission distance: 70m at 1080P60, 40m at 4K30 via Cat5e/Cat6
•Supports POC power over Cable)
•LED working indicator

Model : ATZ HDBT-E70-WPVD
Description : HDBaseT Sender Wall Plate for HDMI/VGA/DP/Audio 70m)
pg. 2
Notes : - All brand names and trademarks are properties of their respective holders and are referred to here for descriptive purpose only. Photo attached is for reference only, it may be slightly varied in items of colour,
shape from the actual item delivered from time to time.
All specifications are subject to change without prior notice.
© Copyright A Z
Specifications:
Video
HDMI Compliance HDMI 3D, 4K
VGA Compliance VESA
HDCP Compliant Yes
Distance
70m on 1080p@60Hz
40m on 4Kx2K@30Hz@24bit
Max Resolution 4K*2K
Bandwidth 10.2Gbps
Connectors
Input
1x HDMI
1x DP
1x VGA
1x Audio
Output 1x HDBaseT RJ45)
Mechanical
Control Button, Automatic
Dimensions UK type
Net Weight 195g
Package Size 204 x 151 x 60mm L/W/H)
Gross Weight 1.257lbs[330g]
Power
Power Supply DC 12V 1.5A
Environmental
Operation
Temperature 32~131°F [0~55°C]
Storage Temperature -4~185°F [-20~85°C]
Relative Humidity 5~95% RH [no condensation]

Model : ATZ HDBT-E70-WPVD
Description : HDBaseT Sender Wall Plate for HDMI/VGA/DP/Audio 70m)
pg. 3
Notes : - All brand names and trademarks are properties of their respective holders and are referred to here for descriptive purpose only. Photo attached is for reference only, it may be slightly varied in items of colour,
shape from the actual item delivered from time to time.
All specifications are subject to change without prior notice.
© Copyright A Z
Panel:
Name Functions
Indicator
VGA
VGA
signal indicator, flashing means connected, stable
light means being selected
HDMI
HDMI
signal indicator, flashing means connected, stable
light means being selected
DP
DP
signal indicator, flashing means connected, stable
light means being selected
LINK Stable light means connected with Receivers successfully
MANUAL press button HDMI / VGA / DP)
AUTO
Automatic mode Long
press the DP button for 5S, you can
switch to AUTO mode )
PRIOR
Priority
mode Long press the DP button for 5S, you
can switch to PRIOR mode)
POWER When power either by adapter or POC from Rx will light up
Ports
VGA PORT Female VGA input port
HDMI PORT Female HDMI input port
DP PORT Female DP input port

Model : ATZ HDBT-E70-WPVD
Description : HDBaseT Sender Wall Plate for HDMI/VGA/DP/Audio 70m)
pg. 4
Notes : - All brand names and trademarks are properties of their respective holders and are referred to here for descriptive purpose only. Photo attached is for reference only, it may be slightly varied in items of colour,
shape from the actual item delivered from time to time.
All specifications are subject to change without prior notice.
© Copyright A Z
AUDIO 3.5mm audio embedded for VGA input
Rear Panel
OUT POC out
IN
POC IN
POC PoC function jumper
POE POE function jumper
B 12V POC jumper
R 24V POC jumper
Switchin instruction:
This is the simple version, support to select the input port by manual, and also support
automatically detect the last one input. If unplug the currently active input, there are
still two input sources connected, then need to select by manual.
Manual mode, the MANUAL light is on, users can press buttons to manually
switch the HDMI, VGA, DP signals.
AUTO mode: Press the DP button for 5 seconds: From manual mode to automatic
mode, the AUTO light is on.
Under this mode It will automatically recognize the last one input.
The HDMI light is green indicating that the signal is recognized. You can distinguish
whether there is a signal according to the color of the indicator.
PRIOR mode: Long press DP 5 seconds from automatic to priority mode.
Under this mode it will automatically recognize the last one input.
Users also can set the priority signal, only this priority signal can be recognized.
Long press HDMI 12 seconds setting to read external EDID, long press HDMI 10
seconds default internal EDID is 4K30, long press VGA10S default internal EDID is
1080P.
Steps:
1. Check the usage environment. You can connect the monitor directly through
the notebook to ensure that the signal source sound is normal and the monitor
can recognize the sound normally.
2. Internal and external EDID switch

Model : ATZ HDBT-E70-WPVD
Description : HDBaseT Sender Wall Plate for HDMI/VGA/DP/Audio 70m)
pg. 5
Notes : - All brand names and trademarks are properties of their respective holders and are referred to here for descriptive purpose only. Photo attached is for reference only, it may be slightly varied in items of colour,
shape from the actual item delivered from time to time.
All specifications are subject to change without prior notice.
© Copyright A Z
Connect the computer directly to the monitor to determine whether the monitor
can recognize the external EDID.
When the monitor can be recognized by the TX RX normally, the model of the
back-end monitor can be seen in the computer display settings, and the
sound is displayed normally at this time.
If EDID recognition fails, you need to call the internal EDID
Long press P1 for 10 seconds to switch to internal EDID, the resolution of internal
EDID setting is 4K30.
Long press P2 for 10 seconds to switch to internal EDID, the resolution of internal
EDID setting is 1080P
Product Dia ram:

Model : ATZ HDBT-E70-WPVD
Description : HDBaseT Sender Wall Plate for HDMI/VGA/DP/Audio 70m)
pg. 6
Notes : - All brand names and trademarks are properties of their respective holders and are referred to here for descriptive purpose only. Photo attached is for reference only, it may be slightly varied in items of colour,
shape from the actual item delivered from time to time.
All specifications are subject to change without prior notice.
© Copyright A Z
Packa e contents:
1x DP+HDMI+VGA Wallplate Sender)
1x Power adapter
1x User Manual
Warranty: 2 Years
Warranty is effective from the date of original delivery.
This warranty shall be void if a serial number has been removed from the product.
