Supplementary Manual for SYL-53X2P
(RS-485/Modbus_RTU)
Version 1.2 (Sep, 2020)
CAUTION!
This controller is intended to control equipment under normal operating conditions. If failure or malfunction of it could lead to an abnormal operating
condition that could cause personal injury or damage to the equipment or other property, other devices (limit or safety controls) or systems (alarm
or supervisory) intended to warn of or protect against failure or malfunction of the controller must be incorporated into and maintained as part of the
control system.
1. Introductory
This controller is using RS485 Modebus_RTU (Remote Terminal Unit) mode for the data transfer. Up to 255 meters can be connected at same time.
The format for each byte in RTU mode is:
Coding system:
8-bit binary, hexadecimal 0-9, A-F
Two hexadecimal characters contained in each 8-bit field of the message
Bits per Bytes:
Baud rate (bps): 1200, 2400, 4800 and 9600
Stop bit: 1 bit
Data length: 8 bits
Parity check: None
Error Check Field: Cyclical Redundancy Check (CRC-16)
Other spec when use third party PLC/comm software
Timeout interval: 300ms.
Retries: >2 times
2. RTU Message Frame:
A typical message frame is shown below.
Table 2.1 RTU data frame.
Target Address
Function
Data
CRC-16
8 Bits
8 Bits
n x Bits
16 Bit
Target address field: This field contains 8-bit data (RTU). Its range is 0 - 255 decimal. Address 0 is for broadcasting data to all receiving devices. To
contact a PID controller, the sender unit/computer/PLC will put the address of that PID controller in the address field of the message. When that
PID controller replies, it will put its address in the address field of the message as well.
Function field: This field contains 8-bit data. Its range is 1 - 64 decimal. This function field will tell what operations are requested for this data frame.
For example, updating the value for set temperature, fetching the current reading temperature, etc.
Data field: This field contains multiple 8-bit data. It contains all the additional information, which is needed to complete the requested function. Such
as the target parameter address, or the new set temperature.
CRC: 16-bit or two 8-bit bytes for error checking. Cyclical Redundancy Check (CRC) value is appended to the end of this data frame. Low-order
byte will be sent in prior to the high-order byte. For example, if the data frame is 010310010001, and its CRC16 is D10A. So its complete data
frame is 010310010001D10A.
Note: RTU message is in hexadecimal format.
Instruction Manual

AUBER INSTRUMENTS WWW.AUBERINS.COM
2020.09 P2/5
3. Parameter set
Table 3.1 System Parameters
Code
Description
Setting Range
Initial Setting
Data Type*
Register Absolute
Address
Holding Register
Address
SP
Set Point (Single Step
mode only)
PuL ~ PuH
100
Decimal
0x00
40001
AL1
Alarm 1 Setting
-1999 ~ +9999
200
Decimal
0x01
40002
AL2
Alarm 2 Setting
0 ~ 200
10
Decimal
0x02
40003
Pb
Input offset
± 20.0
0
Integral
0x03
40004
P
Proportional Constant
0 ~ 5000
0
Integral
0x04
40005
I
Integral Time
0 ~ 3000
500
Integral
0x05
40006
D
Derivative Time
0 ~ 2000
100
Integral
0x06
40007
t
Cycle Time
2 ~ 120
10
Integral
0x07
40008
FILt
Digital Filter
0 ~ 50
20
Integral
0x08
40009
Hy
Hysteresis Band
0.1 ~ 50.0
0.5
Decimal
0x09
40010
dP
Decimal Point Position
0 ~ 1
1
Integral
0x0A
40011
OUTH
Output High Limit
outL ~ 200%
200%
Integral
0x0B
40012
OUTL
Output Low Limit
0 ~ outH
0
Integral
0x0C
40013
At
Auto Tuning
0 ~ 1
0
Integral
0x0D
40014
LocK
Configuration Privilege
0 ~ 50
0
Integral
0x0E
40015
Sn
Input Sensor Type**
K
Integral
0x0F
40016
OP-A
Reserved
0x10
40017
CF
Display Temp Unit
C, F
C/0
Integral
0x11
40018
ALP
Alarm Output Definition
0 ~ 10
1
Integral
0x12
40019
COOL
System Function Selection
0 ~ 1
0
Integral
0x13
40020
PuH
Display High Limit
PuL ~ 9999
1300
Decimal
0x14
40021
PuL
Display Low Limit
-1999 ~ PuH
0
Decimal
0x15
40022
Addr
Communication address
0 ~ 255
1
Integral
0x16
40023
bAud
Communication baud rate
3 for 9600
Integral
0x17
40024
Table 3.2 Ramp Soak Profile Parameters
Code
Description
Setting Range
Initial Setting
Data Type*
Register Absolute
Address
Holding Register
Address
SEC
Timer Unit
0 ~ 1
0 for min.
Integral
0x19
40026
LOOP
Program Cycling
0 ~ 1
1
Integral
0x1A
40027
PDE
Power Outage Mode
0 ~ 3
2
Integral
0x1B
40028
SsB
Safety Start Band
0 ~ 100.0
100
Decimal
0x1C
40029
RUN
Program Control
0 ~ 3
0
Integral
0x1D
40030
PRO
Program Step Jump
0 ~ 64
0
Integral
0x1E
40031
te
Run Time
Integral
0x1F
40032
R01
Ramp Time 1
0 ~ 2000
0
Integral
0x20
40033
T01
Soak Time 1
0 ~ 9999
0
Integral
0x21
40034
C01
Set Temp 1
PuL ~ PuH
0
Decimal
0x22
40035
…
R32
Ramp Time 32
0
Integral
0x7D
40126
T32
Soak Time 32
0
Integral
0x7E
40127
C32
Set Temp 32
0
Decimal
0x7F
40128

AUBER INSTRUMENTS WWW.AUBERINS.COM
2020.09 P3/5
Table 3.3 Status parameters (read only)
Description
Data Type*
Register Absolute Address
Holding Register Address
Reading Temp
Decimal
1001
44098
Current Set Temp
Decimal
1002
44099
Main Output (0-200%)
Integral
1101
44354
Alarm Status***
Integral
1201
44610
Note*: Parameter Data Type
Some parameters in this controller may display in decimal number (number with one decimal digit) rather than integral number. For example, your
display temperature can be 20.1 degree (decimal number) and your step 2 ramp timer is 10 minutes (integral number). For decimal number, its
actual stored value in controller’s memory will be 10 times larger than its display value. For example, if your display temperature is 20.1, it will be
stored as 201 (Decimal) or C9 (Hex) in its register. For integral number, its actual stored value in the controller’s memory will be the same as its
display value.
This controller uses signed 16-bit number and it cannot read floating point numbers.
Note**: Input Sensor Type
This PID controller can read the following 9 different temperature sensor types. Please find the table below. Sn code is the Sn value used in its
software. Sn symbol is the display value on the PID controller.
Table 3.4 Value table for input sensor type
Sn Code
Sn Symbol
Definition
0
CU50
Cu50 (RTD)
1
PT1
Pt100 (RTD), -200~200C
2
PT2
Pt100 (RTD), -200~600C
3
K
K (thermocouple)
4
E
E (thermocouple)
5
J
J (thermocouple)
6
T
T (thermocouple)
7
S
S (thermocouple)
8
R
R (thermocouple)
Note***: Alarm Status
This parameter shows the status of both AL1 and AL2 relay outputs. See table below:
Table 3.5 Value table for alarm status
Value
Alarm status
0
AL1 OFF, AL2 OFF
1
AL1 ON, AL2 OFF
2
AL1 OFF, AL2 ON
3
AL1 ON, AL2 ON

AUBER INSTRUMENTS WWW.AUBERINS.COM
2020.09 P4/5
4. Function code examples
Note: Two function codes are available for this controller: 03 (0x03) and 06 (0x06). Function code 03 (read holding registers) and 06
(present single register/write register). For details, please check ModBus Protocol.
4.1. Function code 03: Read parameter value from the controller
Function code 03 is used to read the parameter value from the controller. Please note, the query message (sent by host) has a length of 8-byte and
the response message (sent by PID) has a length of 7-byte.
Example: Read the current PV value from the controller:
Data sent by host (query): 01 03 10 01 00 01 D1 0A
Data received from PID (response): 01 03 02 03 7A 39 57
Table 4.1 Example for function code 03
Query Message
Target Address
Function
Parameter Address
Number of words
CRC16
01
03
1001
0001
D10A
Response Message
Target Address
Function
Data Length
Data
CRC16
01
03
02
037A
3957
By the response message, the current stored PV value was 037A (hex) or 890 (decimal). PV is in decimal format, so the actual display temperature
is 89.0 degree.
4.2. Function code 06: Write new parameter value to the controller
Function code 06 is used to write new parameter value to the controller. The query message (sent by host) and the response message (sent by
PID) both have a length of 8-byte. After the controller received the query message correctly, controller will reply the exact same message to the
host.
Example #1: Write 550.5 degree as new alarm 1 temperature (AL1) value to the controller. AL1 parameter is in decimal format, so the stored value
is 5505 (decimal) or 1581 (hex). The replied data will be the same as sent data.
Data sent by host (query): 01 06 00 01 15 81 16 FA
Data received from PID (response): 01 06 00 01 15 81 16 FA
Table 4.2.1 Example 1 for function code 06
Query Message
Target Address
Function
Parameter Address
Number of words
CRC16
01
06
0001
1581
16FA
Response Message
Target Address
Function
Parameter Address
Number of words
CRC16
01
06
0001
1581
16FA
Example #2: Change the display temperature unit from Celsius to Fahrenheit. The address for parameter CF is 0011. Change it to 0 for Celsius
display and change it to 1 for Fahrenheit display.
Data sent by host (query): 01 06 00 11 00 01 18 0F
Data received from PID (response): 01 06 00 11 00 01 18 0F

AUBER INSTRUMENTS WWW.AUBERINS.COM
2020.09 P5/5
Table 4.2.2 Example 2 for function code 06
Query Message
Target Address
Function
Parameter Address
Number of words
CRC16
01
06
0011
0001
180F
Response Message
Target Address
Function
Parameter Address
Number of words
CRC16
01
06
0011
0001
180F
5. Common Error
Q: Why I get no response from this controller?
A: 1). Please check the controller’s address in the query message is correct, CRC code for message is correct and data frame format is correct.
2). Every command can only read one resistor at one time. User cannot read multiple registers at same time.
3). Please check the time interval between query messages is over 300ms.
Auber Instruments Inc.
5755 North Point Parkway, Suite 99,
Alpharetta, GA 30022
www.auberins.com
Email: [email protected]
Tel: [phone]
Copyright © 2019 Auber Instruments Inc. All rights reserved.
No part of this datasheet shall be copied, reproduced, or transmitted in any way without the prior, written consent of Auber Instruments. Auber
Instruments retains the exclusive rights to all information included in this document.
