AUDAC Outdoor Series Guide

WX802MK2/O
Outdoor series
User & Installation
Manual
www.audac.eu

2

3
Introduction
Universal wall speaker
The WXMK2/O are powerful 2-way performance speakers, which are especially
designed for outdoor use, ensuring true-to-nature, high fidelity reproduction of music
and speech in every environement, ranging from modern residential applications to the
most demanding outdoor applications in parks, stadiums, hotels and even clubs.
It features a stunningly designed and elegant looking ABS housing which is fitted with
high quality components. The speaker is available in three sizes, 3”, 5 1/4” and 8”, and
can be used in standard ow impedance systems as well as 100V PA installations. A
special treatment with powder coating provides the necessary protection for all weather
conditions. Because of this, the powder coated aluminum bracket and grill can pass
the 720 hours salt-spray test. A drain hole behind the aluminum grill allows water to
flow out and the rotatable 5 pole waterproof connector with power tap selection makes
sure that the speaker meets the IP55 standard. The included mounting bracket allows
horizontal and vertical mounting as well as focusing of the speaker, and an integrated
advanced protection network protects the tweeter against overload.

4
Precautions
READ FOLLOWING INSTRUCTIONS FOR YOUR OWN SAFETY
• ALWAYS KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE. NEVER THROW THEM
AWAY
• ALWAYS HANDLE THIS UNIT WITH CARE
• HEED ALL WARNINGS AND FOLLOW ALL INSTRUCTIONS
• ONLY USE ATTACHMENTS & ACCESSORIES SPECIFIED BY THE MANUFACTURER.
• ONLY INSTALL THE SPEAKER IN LOCATIONS THAT CAN STRUCTURALLY SUPPORT THE
WEIGHT OF THE SPEAKER. IGNORING THIS CAN BRING THE SPEAKER DOWN.
• DO NOT USE ANY OTHER METHOD THAN SPECIFIED TO MOUNT THE SPEAKER. IF
EXTREME FORCE IS APPLIED TO THE SPEAKER, IT COULD FALL DOWN
• ATTACH A SAFETY WIRE TO THE SPEAKER WHEN IT IS MOUNTED HIGH UP.
ONLY USE INDUSTRY-ACCEPTED RIGGING TOOLS AND METHODS
• CAREFULLY CHECK THE UNIT’S CONDITION AFTER UNPACKING.
IF THERE IS ANY DAMAGE TO THE CARTON BOX OR THE UNIT ITSELF, INFORM YOUR
VENDOR IMMEDIATELY.
• ALWAYS FOLLOW THE LOCAL REGULATIONS AND REQUIREMENTS REGARDING
INSTALLATION, SUSPENSION AND CONNECTION OF THIS LOUDSPEAKER. EVEN WHEN
OTHERWISE SPECIFIED IN THIS DOCUMENT.
• THE INSTALLATION OF THIS LOUDSPEAKER SHALL BE DONE BY QUALIFIED
PERSONNEL ONLY.

5
CAUTION
• USE CABLES OF THE RIGHT GAUGE TO CONNECT THE LOUDSPEAKER
• USE CABLES WITH CLEAR COLOUR CODING INDICATING THE POLARITY AND
MAINTAIN THE SAME POLARITY THROUGHOUT THE WHOLE SYSTEM.
• ONLY USE THE CORRECT AMPLIFIER OUTPUT VOLTAGE AND IMPEDANCE.
EXCEEDING THESE LIMITS COULD CAUSE FIRE OR OTHER FAILURES.
AVOID EXPLOSIONS: DO NOT USE THE SPEAKER AROUND GASOLINE,
THINNER OR OTHER COMBUSTIBLES
• AVOID ELECTRIC SHOCKS: SWITCH OFF THE AMPLIFIER WHEN CONNECTING
THE LOUDSPEAKER
• DO NOT USE THE LOUDSPEAKER FOR AN EXTENDED PERIOD OF TIME AT
DISTORTED SOUND. THIS COULD CAUSE PERMANENT DAMAGE.
CAUTION - SERVICING
This product contains no user serviceable parts. Refer all servicing
to qualified service personnel. Do not perform any servicing
(unless you are qualified to do so.)
EC DECLARATION OF CONFORMITY
This product conforms to all the essential requirements and further
relevant specifications described in following directives: 2014/30/
EU (EMC) and 2014/35/EU (LVD)
WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT (WEEE)
The WEEE marking indicates that this product should not be
disposed with regular houshold waste at the end of its product
life. This regulation is created to protect both the environment
and human health.
This product is developed and manufactured with high quality
materials and components which can be recycled and/or reused.
Please dispose this product to your local collection point or
recycling centre for electrical and electronic waste. This will
make to sure that it will be recycled on an environmentally friendly
manner, and will help to protect the environment in which we all
live.

6
Installing the WX802MK2/O
Step 1: Mount the loudspeaker
The loudspeaker can be mounted both horizontally and vertically by means of the sup-
plied mounting bracket. For mounting the loudspeaker on the desired mounting location,
the mounting bracket should be removed from the loudspeaker. This can be done by
loosening the thumbscrews on either side of the loudspeaker. After this is done, the
mounting holes should be indicated.
For a stable mounting of the loudspeaker it should always be fastened by two screws.
The position of the mounting holes depends on the mounting orientation, horizontally
or vertically. After this, the bracket can be mounted on the desired location. Always use
the proper fasteners depending of the mounting surface. Once the bracket is mounted
on the desired location, the loudspeaker can be fixed to the bracket.
Ø4,5
Ø10,3
248 mm
358 mm

7
ATTENTION
To make sure that no rain or other liquids can enter the loudspeaker when mounted
outside, a special construction is provided at the inner side of the bass port. This
construction is only functional when the loudspeaker is mounted in the correct position.
The loudspeaker must be mounted according to the woofer orientation as shown below.
When mounting upright, the tweeter shall be on top of the woofer, when mounted
sideways the tweeter shall be on the right side of the woofer.
Step 2: Power settings
The power tap of the WXMK2/O speakers can be selected depending on the orienta-
tion of the waterproof connector on the rear side of the loudspeaker. A white dot is
displayed on the cable part of the connector. Depending on the direction of the white
dot, the desired power tap is connected. The corresponding power taps are shown
on the sticker on the rear side of the loudspeaker. The power / impedance of the
loudspeaker can be set in 3 adjustable steps of impedance for 100V and 1 step for
standard low impedance applications.
WX802 MK2
16 Ω
60W15W
Outdoor - IP55
70 Watt RMS / 140 Watt Max
Impedance: 16 Ω
Line transformer power taps (100V) :
60 Watt / 167 Ω
30 Watt / 333 Ω
15 Watt / 667 Ω
30W

8
When the loudspeaker is connected to 70.7V facilities, the power indicated in the image
on the previous page will be reduced to half the power, and when connected to 50V
facilities, the power will be reduced to a quarter.
Step 3: Make the connections
After connecting the AWX5™ connector in the orientation corresponding to your
desired power tap, screw on the outer ring to secure the connector in place and guar-
antee a waterproof connection.
Step 4: Enjoy the music
After the WX loudspeakers have been installed correctly, you deserve to have a short
break, relax and enjoy the sound of the speakers!

9
Additional information
Technical specifications
RMS Power 70 W
Nominal Impedance 16 Ohm
Line transformer power tappings 167 Ohm / 60 W
333 Ohm / 30 W
667 Ohm / 15 W
Sound pressure level 1W / 1m 89 dB
Sound pressure max W / 1 m @ 8 Ohm 108 dB
Sound pressure max W / 1 m @ 100V 106 dB
Frequency response -3 dB 60 Hz - 18 kHz
Frequency response -10 dB 50 Hz - 20 kHz
Cross-over frequency 2400 Hz
Horizontal coverage 110°
Vertical coverage 110°
Drivers 1” HF + 8” LF
Connector AWX5™
Mounting Bracket Powder coated aluminum
Front finish Powder coated aluminum grill
Dimensions (W x H x D) 270 x 360 x 215 mm
Weight 7,5 Kg
Construction ABS
Accessories included Wall bracket
Colors Black / White
