The Audi A3 Cabriolet

Pricing and Specification Guide

Valid from September 2009

ntroduction

The Audi A3 Cabrio et

Engines 6

Model details and prices

Standard models 8

Sport models 10

S line models 12

Black Edition models 14

Transmission 16

Colour and upholstery

Paint finishes 18

Hood colours 19

Upholstery options 20

Colour and trim guide 24

nlays 28

Options

Wheels and tyres 30

Audio and communication 32

Seats 34

Safety and security 35

Steering wheels 36

nterior equipment 38

Exterior equipment 39

Audi exclusive

Audi exclusive options 40

Technical details

Technical data 46

Dimensions 48

Additional information 49

This guide has been designed to help you tailor

and price your A3 Cabriolet quickly and logically.

At the back of this guide you will find information

on CO2emissions-based vehicle excise duty and

the other services offered by Audi, including

Finance and nsurance.

Alternatively, you can go to audi.co.uk and

configure your A3 Cabriolet online.

A Use ’s Guide Table of content Page number

With the Audi A3 Cabriolet, we’ve taken all the qualities you’d associate

with Audi – stunning design, sporty looks and progressive styling –

and brought them one step further. From the sweeping, expressive

lines of the body to the smooth silhouette of the canvas hood, it’s got

all the dynamic character and appeal of a coupé. And even more

impressively, we’ve combined this with the everyday practicality of

increased luggage capacity and space for four people.

Stylish and practical, the A3 Cabriolet’s dynamic shape and alloy

wheels make an immediate impact. And with a Z-fold hood that

opens in just 9 seconds, it doesn’t take much longer for this car

to impress you with its ever-changing profile. n fact, you can lower

its Sport hood with just the touch of a button, at speeds of up to

19mph. The model is available now with a choice of five engines,

including the turbocharged 2.0 TFS and the new efficient 1.6 TD

with common-rail injection technology. What’s more, along with

considerable power you can enjoy impressive control, thanks to a

choice of manual transmissions or the revolutionary Audi S tronic

transmissions. And no matter which options you select, from styling

to multimedia, you can look forward to a comprehensive range of

equipment to make your driving experience complete.

The Audi A3 Cab iolet

Petro Diese

We introduced TD to the roads in 1989, marking a departure from the noisy, fuel-thirsty

diesel engines of the past. And since then, we've continuously refined it, recently

developing common-rail technology for even more efficiency and power. Under this

system, a series of piezo injectors use electrical charge to precisely control the amount

of fuel injected into the engine. As well as reducing noise, this allows combustion to

happen at a lower temperature, with less oxygen, which cuts down emissions. So not

only does common-rail technology help to protect the environment, it also enables us

to future-proof our cars.

The A3 Cabriolet includes an impressive turbocharged direct-injection TFS engine.

TFS is a unique Audi innovation, combining turbo-charging with the FS technology

originally developed for the Le Mans 24-hour endurance race to deliver increased power

and torque, as well as enhanced fuel efficiency. Precisely the right amount of fuel and

air are injected directly into the combustion chambers, ‘unthrottling’ the engine and

enabling it to ‘breathe’ more easily. At the same time, electronics monitor the engine

load and adjust the injection process. The result – reduced heat-loss and increased

output, with around a 15% reduction in fuel consumption and significantly lower exhaust

emissions. deal for someone who’s looking for an uncompromising, exhilarating drive.

Engines

Automatic start/stop function for greater fuel and CO2

efficiency. Comprising:

– Recuperation for optimal energy utilisation

– Energy-saving tips feature in Driver’s nformation System;

including gearshift indicator (if fitted)

(Only available on 1.6 TD manual engines)

Wheels, ty es and suspension

16 x 6.5J ‘7-arm’ design alloy wheels with 225/55 R16 tyres

Space-saving spare wheel

Audio and communication

Audi Chorus radio/single CD player with front speakers

Seats

Driver and front passenger seat-height manually adjustable

Easy entry front seats

'Frequency' cloth upholstery

Seat belts –3-point on all four seats

Split-folding rear seats (50:50)

Safety and secu ity

Anti-theft wheel bolts

Audi backguard head restraints for front seats (adjustable)

Daytime running lights

Driver, front passenger and side airbags for front seats

Electronic Stability Programme (ESP), including ABS, EBD,

ASR and EDL

Halogen headlights

Front and rear SOF X child seat preparation (front passenger

with airbag deactivation switch)

Rear fog light

Rear head restraints

Remote-control central locking

Roll-over protection bars

Servotronic – electromechanical, speed-sensitive,

power-assisted steering

Thatcham Category 1 Alarm and mmobiliser

Warning triangle

Tool kit and car jack

Inte io equipment

4-spoke leather steering wheel (not on S tronic models)

3-spoke leather Sports steering wheel with gear-change

paddles (S tronic models only)

Electric front and rear windows

Front and rear floor mats

Granite or Umbra inlays and door trim (depending on

upholstery colour, see page 28)

Heated rear glass screen

Heat-insulating glass

lluminated vanity mirrors

Manual air conditioning

Manual headlight adjustment

Steering wheel adjustable for height and reach

Washer fluid level indicator

Exte io equipment

Body-coloured door mirrors with integrated indicators

Electrically-operated and heated door mirrors

Semi-automatic electrically-operated soft-top

A A3 Cabrio et mode s have the fo owing items of Standard equipment:

Standa d model equipment

16 x 6.5J ‘7-arm’ design alloy wheels Driver, front passenger and side airbag for front seats Split-folding rear seats (50:50)

Standard mode prices

Engines Power Transmission Basic RRP

Recommended

OTR

1.6 102PS 5-speed manual £16,643.48 £19,140.00 £19,935.00

1.8 TFS 160PS 6-speed manual £18,608.70 £21,400.00 £22,170.00

2.0 TFS 200PS 6-speed manual £19,765.22 £22,730.00 £23,525.00

Petro

Tota RRP inc.

VAT Engines Power Transmission Basic RRP

Recommended

OTR

1.6 TD 105PS 5-speed manual £17,382.61 £19,990.00 £20,645.00

2.0 TD 140PS 6-speed manual £19,039.13 £21,895.00 £22,635.00

Diese

Tota RRP inc.

VAT

Recommended On-The-Road (OTR) retail prices include: delivery charge, half a tank of fuel, number plates at £565.00 (inc. VAT),

Road Fund Licence (which may vary depending on model/transmission –see page 49 for details) and first registration fee at £55.00.

Please note: images shown are for illustration purposes only and do not necessarily depict UK specification.

RRP – Recommended Retail Price. VAT is calculated at 15% but this may alter to reflect any change in the applicable VAT rate.

Model details and prices

In addition to Standard mode equipment:

Spo t model equipment

Wheels, ty es and suspension

17 x 7.5J ‘5-spoke star’ design alloy wheels with

225/45 R17 tyres

Sports suspension (lower by 15mm)

Audio and communication

Audi Concert radio with single front-loading CD player, MP3

file compatibility and active front and rear speakers.

ncludes AUX- N socket in front-centre compartment

Seats

Front Sports seats

'Dynamic' cloth upholstery

Safety and secu ity

Front fog lights

Inte io equipment

3-spoke leather Sports steering wheel

Aluminium medial silver inlays and door trims

Door sills with aluminium inlays

Dual-zone electronic climate control

Driver's nformation System with outside temperature display

Wind deflector

Exte io equipment

Exterior aluminium design trim; roll bars, shoulder line trim

and trim strips on door handles

Fully automatic, acoustic hood; with one-touch and key

operation –opens in nine seconds

17 x 7.5J ‘5-spoke star’ design alloy wheels Door sills with aluminium inlays Exterior aluminium design trim (roll bars)

Basic RRP Tota RRP

£1,573.91 £1,810.00

inc.

VAT

Sport mode prices

Recommended On-The-Road (OTR) retail prices include: delivery charge, half a tank of fuel, number plates at £565.00 (inc. VAT),

Road Fund Licence (which may vary depending on model/transmission –see page 49 for details) and first registration fee at £55.00.

RRP – Recommended Retail Price.

VAT is calculated at 15% but this may alter to reflect any change in the applicable VAT rate.

Engines Power Transmission Basic RRP

Recommended

OTR

1.6 102PS 5-speed manual £18,217.39 £20,950.00 £21,745.00

1.8 TFS 160PS 6-speed manual £20,182.61 £23,210.00 £23,980.00

2.0 TFS 200PS 6-speed manual £21,339.13 £24,540.00 £25,335.00

Petro

Tota RRP inc.

VAT Engines Power Transmission Basic RRP

Recommended

OTR

1.6 TD 105PS 5-speed manual £18,956.52 £21,800.00 £22,455.00

2.0 TD 140PS 6-speed manual £20,613.04 £23,705.00 £24,445.00

Diese

Tota RRP inc.

VAT

Wheels, ty es and suspension

18 x 7.5J ‘7-twin-spoke’ design alloy wheels with

225/40 R18 tyres

Seats

Black Sprint cloth/leather upholstery with embossed

S line logo

Inte io equipment

Black leather handbrake trim

Black perforated leather gear knob

Black headlining

Door sills with aluminium inlays and S line lettering

Floor mats with black or silver stitching

Front centre armrest

Matt-brushed aluminium inlays

S line leather multi-function steering wheel

(with gear-change controls on S tronic models)

Exte io equipment

Chrome-trimmed exhaust tailpipes

S line badges on front wings

S line body styling comprising front bumper with enhanced

fins and chrome front foglight surrounds. Rear bumper with

platinum grey diffuser insert

In addition to Sport mode equipment:

S line model equipment

Black Sprint cloth/leather upholstery with embossed S line logo Door sills with aluminium inlays and S line lettering S line leather multi-function steering wheel

Basic RRP Tota RRP

£1,317.39 £1,515.00

inc.

VAT

S ine mode prices

Recommended On-The-Road (OTR) retail prices include: delivery charge, half a tank of fuel, number plates at £565.00 (inc. VAT),

Road Fund Licence (which may vary depending on model/transmission –see page 49 for details) and first registration fee at £55.00.

Please note: images shown are for illustration purposes only and do not necessarily depict UK specification.

RRP – Recommended Retail Price. VAT is calculated at 15% but this may alter to reflect any change in the applicable VAT rate. 13

Engines Power Transmission Basic RRP

Recommended

OTR

1.6 102PS 5-speed manual £19,534.78 £22,465.00 £23,260.00

1.8 TFS 160PS 6-speed manual £21,500.00 £24,725.00 £25,495.00

2.0 TFS 200PS 6-speed manual £22,656.52 £26,055.00 £26,850.00

Petro

Tota RRP inc.

VAT Engines Power Transmission Basic RRP

Recommended

OTR

1.6 TD 105PS 5-speed manual £20,273.91 £23,315.00 £23,970.00

2.0 TD 140PS 6-speed manual £21,930.43 £25,220.00 £25,960.00

Diese

Tota RRP inc.

VAT

Wheels, ty es and suspension

18 x 7.5J ‘7-twin-spoke titanium finish’ alloy wheels*

with 225/40 R18 tyres

Audio and communication

BOSE®surround sound system: 8 high-performance

loudspeakers, 6-channel amplifier, total output of 222 Watts

with specially tuned acoustics

Safety and secu ity

Acoustic parking system rear – aids parking by acoustically

indicating distances to obstacles behind your car

Inte io equipment

Flat-bottomed S line multi-function steering wheel

(with gear-change controls on S tronic models)

Piano Finish black inlays

Exte io equipment

Black styling package, radiator grille-frame in highly-polished

black, with radiator grille and number plate holder in matt

black. ncludes black shoulder line trim and roll bars

Xenon Plus headlamps, with automatic headlamp

adjustment, dynamic range control, headlamp washers and

LED running lights

In addition to S ine mode equipment:

*Standard S line Silver finish alloy wheels are available as a no-cost option.

Black Edition model equipment

Basic RRP Tota RRP

£786.96 £905.00

inc.

VAT

18 x 7.5J ‘7-twin-spoke titanium finish’ alloy wheels Piano Finish black inlays

Flat-bottomed S line multi-function steering wheel

Engines Power Transmission Basic RRP

Recommended

OTR

1.8 TFS 160PS 6-speed manual £22,286.96 £25,630.00 £26,400.00

2.0 TFS 200PS 6-speed manual £23,443.48 £26,960.00 £27,755.00

Petro

Tota RRP inc.

VAT Engines Power Transmission Basic RRP

Recommended

OTR

2.0 TD 140PS 6-speed manual £22,717.39 £26,125.00 £26,865.00

Diese

Tota RRP inc.

VAT

Recommended On-The-Road (OTR) retail prices include: delivery charge, half a tank of fuel, number plates at £565.00 (inc. VAT),

Road Fund Licence (which may vary depending on model/transmission –see page 49 for details) and first registration fee at £55.00.

Please note: images shown are for illustration purposes only and do not necessarily depict UK specification.

RRP – Recommended Retail Price. VAT is calculated at 15% but this may alter to reflect any change in the applicable VAT rate.

B ack Edition mode prices

T ansmission

Audi offers a variety of different transmission options to

suit your requirements and driving style. n addition to the

classic manual gearbox are two innovative, semi-automatic

transmission options. To help you come to an informed

decision, each of these is described in detail opposite.

The revolutionary S tronic gearbox combines the agility

and responsiveness of a conventional 6-speed manual

gearbox with the convenience and smooth, uninterrupted

power of an automatic transmission. The technical basis

of the S tronic gearbox is the double clutch. This consists

of two lubricated plates with hydraulically-regulated

contact pressure. One engages the odd-numbered gears,

the other the even-numbered, enabling gear-shifts to be

made in a fraction of a second, with no disruption to the

power flow. Depending on how the mood takes you, you

can either allow gear-changes to take place automatically

or, for a sportier driving style, operate the S tronic system

using the gear lever or steering wheel shift-paddles.

The choice is yours.

The 1.8 TFS model is available with the 7-gear version

of our highly-acclaimed S tronic gearbox. The extra gear,

along with a dry-clutch set-up, results in improved fuel

economy and lower CO2emissions. As with the 6-speed

S tronic gearbox, this gear system can be operated in fully

automatic mode, or using the gear lever or steering wheel

gear-change controls for an even more engaging drive.

S tronic (6-speed) S tronic (7-speed)

Options are subject to availability and may extend delivery.

–= Not available •= Available

RRP – Recommended Retail Price.

VAT is calculated at 15% but this may alter to reflect any change in the applicable VAT rate.

T ansmission

6-speed S tronic (includes steering wheel gear-change controls) – – • – • £1,234.78 £1,420.00

7-speed S tronic (includes steering wheel gear-change controls) – • – – – £1,234.78 £1,420.00

1.8 TFS

2.0 TFS

1.6 TD

2.0 TD

Tota RRP

Basic RRP inc.

VAT

1.6

Basic RRP Total RRP

£426.09 £490.00

inc.

VAT

Deep green, pearl effect 3W

Paint finishes

Ibis white* T9

Brilliant black* A2

Brilliant red C8

Dakar beige, metallic 9X Garnet red, pearl effect 9C

Standard colours Optional colours

All the above colour swatches are matched as accurately as possible to the actual paint colours used.

However, due to print processes, Audi UK cannot guarantee that colours shown are 100% accurate.

*Available in limited range of Black Edition colours.

Condor grey, metallic 5Q

Meteor grey, pearl effect X5 Glass blue, pearl effect 5G

Sphere blue, metallic 9F

Deep sea blue, pearl effect 8A

Ice silver, metallic P5

Phantom black, pearl effect* 8

Hood colours

Colour and upholstery

Red hood SF

Black hood* PA

Blue hood PB

Aruba blue, pearl effect Q9

Tungsten grey, metallic 1J

Options are subject to availability and may extend delivery.

RRP – Recommended Retail Price. VAT is calculated at 15% but this may alter to reflect any change in the applicable VAT rate.

Misano red (only available on S line models)* N9

Monza silver, metallic (only available on S line models)* U7

S – – – No charge No charge

•–––£869.57 £1,000.00

Frequency cloth, Black JN/CA Frequency cloth, ight grey

Upholstery

Standard seats

BJ/BR

Vienna leather, ight grey BJ/BR Vienna leather, uxor beige TBVienna leather, Black JN/CA

All leather upholstery choices include seats, head restraints and front centre armrest (if fitted) in leather. All leather upholsteries have heat-resistant properties.

Alcantara/leather choices includes head restraints, seat side bolster and front centre armrest in leather with the seat centres and door panels in Alcantara.

Standard

Sport

S line

Total RRP

Basic RRP inc.

VAT

Black Edition
