The information within this guide must be used in conjunction with the information in the Audi Owner’s Manuals. Refer to your vehicle’s Owner’s Manual for all information and warnings.
By using this guide, you acknowledge that you are aware of and have read the warnings and information provided in the Owner’s Manual on the topics in this guide and will use this
information to augment that material.

MMI® Controls
BLUETOOTH® Pairing
Audi connect®
Navigation
Automatic Climate Control
Cruise Control
Start-Stop System
Tire Pressure Monitoring System (TPMS)
Clock Setting
Brakes
Table of Contents
1
7
11
15
19
25
27
29
31
33
LEARN MORE AT
auditechnology.com
Audi Explore
Welcome
Your new A6 is equipped with many features designed to accentuate
your driving experience and create an environment that is refined,
elegant and supremely functional. This guide will assist you in better
understanding some of the features of your A6 and provide you with
the knowledge needed to enjoy your new Audi to its fullest.
When you see this symbol, you can
discover more with your smart phone
by texting the letter keys to the code
provided. A video tutorial will be sent
to further explain the topic.
Standard messaging and data rates charged by your phone
service provider will apply.

MMI®Controls
Audio & Navigation
1
Pressing one of the six function buttons such as
or displays that features options in each corner of
the MMI® screen.
The four control buttons surrounding the control knob
correspond to the four corners of the MMI® display.
Selecting the desired button will access sub menus.
To make a selection or confirm a request, simply
turn the control knob and press to select the option.
While operating the menus and functions, you can return
to a previous screen by pressing the button.
RADIO
NAV
BACK
TEXT A6AUDIO to 38981
Do not text and drive. Message and data rates may apply.
The MMI® system consists of the MMI® display
screen and the MMI® control panel. This panel is
composed of a control knob, control buttons and
function buttons.
The MMI® Touch can be used to write letters and
numbers or access Preset Radio stations. To enter
a space, drag your finger from left to right on the
pad. To delete a character, drag your finger from
right to left. While in Navigation mode, after
pressing the control knob, the touch pad can be
used to move along the map in the desired
direction.
2
MMI® Controls

MMI®Controls
cont.
3
Volume
Pressing the volume dial will mute audio when in Radio mode
and pause when playing media. Holding it down will turn the
system o.
Track Advance Buttons
The arrow buttons allow you to move through the audio tracks
and radio stations.
Media Function Button
• Access available media from connected sources.
• BLUETOOTH® Audio, SD card, DVD, Jukebox,
and Audi Media Interface (AMI).
• The AMI connection can be found in your glove box.
Steering Wheel Controls
In addition to the MMI® control
panel you can use the multifunction
steering wheel controls to display
specific MMI® features in the Driver
Information System.
Simply press the buttons
to display the MMI® modes.
The thumbwheel can be used
to scroll through the options.
Press it to make a selection.
Press the button to display
submenu options for that mode.
The button is used to
activate Voice Recognition.
The volume thumbwheel is
used to adjust the volume,
pressing it will mute audio.
Pressing the button will
repeat the last Navigation
announcement when
navigation is active.
The is used to access
a programmable stored
function.
NAV
*
4
MMI® Controls

You can set any mix of up to 50 Presets from FM, AM or Sirius options.
Setting Station Presets
1. Press the function
button multiple times to
toggle between FM, AM
or SIRIUS.
Do not text and drive. Message and data rates may apply.
TEXT A6SOUND to 38981
4. Or press and hold the center
control knob until the
Presets screen shows
the Preset list.
2. Tune to the desired
station using the control
knob and pressing
to select.
3. Press and hold the desired
number on the touchpad
until you hear the tone that
the station has been stored.
MMI®Controls
cont.
RADIO
5
To access your Presets:
• Press the function button
then the Presets control button.
• Use the MMI® control knob to scroll
through your Presets.
• Press the center button of the control
knob to select a Preset.
• Using voice recognition, press the
button, after the beep, say, “Presets”.
NOTE: Occasionally, tall buildings and tunnels may interrupt the satellite signal. For more information, please refer to the SiriusXM® brochure in your glove box.
5. Scroll to the numbered list position
where you want to save your selection.
6. Press the center control knob again;
the station is saved to this position.
RADIO
6
MMI® Controls

3. Select Audi MMI® when it
appears on the phone’s
screen.
To pair a phone:
1. Switch ignition to accessories mode.
2. Activate your phones BLUETOOTH® function
and set to Pairing or Search mode.
BLUETOOTH®Pairing: MMI®
Initial Setup
BLUETOOTH® pairing is a one-time procedure. Once paired via BLUETOOTH®, your phone will
automatically connect when you start your vehicle and your phone’s contacts automatically
synchronize, allowing you to retrieve contacts and make and receive calls through the
infotainment system. For more information regarding phone compatibility visit audiusa.com/bluetooth.
NOTE: See your phone’s owner’s manual for specific BLUETOOTH® activation instructions.
Vehicle should be stationary with the parking brake engaged while performing this operation.
TEXT A6PAIR1 to 38981
Do not text and drive. Message and data rates may apply.
7
4. Use the MMI® control knob
to select Yes.
5. Confirm the six-digit PIN
displayed matches the PIN
displayed on your phone,
and select Yes.
NOTE: Once paired, the BLUETOOTH® symbol appears in the MMI® screen along with network strength bars and it will be displayed whenever a paired phone is connected to the infotainment system.
6. Select Pair on your phone
to complete the pairing
process.
7. • Contacts synchronizing.
• BLUETOOTH® active and
network strength bars.
Important Warnings and Safety Information, which you must read are listed on the last panel under BLUETOOTH® Pairing. 8
BLUETOOTH®
Pairing

Voice Recognition: MMI®
Call By Name
1. Press the button.
A beep will sound.
2. Say, “Call” <Name from directory>
(e.g., “Call John Smith”).
3. To confirm the request, say “Yes”. The number
will be dialed.
NOTE: If multiple numbers are stored for a given contact, the system will ask
which number you wish to dial. When calling by name using voice recognition,
you must say the name as it is stored in your phone book.
TEXT A6VOICE1 to 38981
Do not text and drive. Message and data rates may apply.
9
You may also speak natural language commands using the button.
Verbal destination commands can be given while in any screen.
Your Audi MMI® Navigation system has many Global Voice
Recognition commands available. This means that you can access
any function or while another function or mode is active.
Commands such as:
• Enter Number • Redial
• Enter Destination • Online Destination
• Presets • FM, AM
• Media
You can begin your request from any screen.
Important Safety Instructions and Warnings which you must read, are listed on the last panel under Voice Recognition.
Natural Language Commands
Once your requested function is active, you can continue
with commands for that mode.
For example:
• Enter Number
• Dial
• Repeat
• Correction
To cancel Voice Recognition while active, say “Cancel” after
the beep or press the button until system responds
with cancelled.
Refer to your owner’s manual for further commands.
10
BLUETOOTH®
Pairing

11
1. Ensure SIM card (provided by dealer) is
present in the SIM slot.
2. Press the function button.
3. Press the Settings control button.
Audi connect®
Configuration:
Vehicle should be stationary with the parking brake engaged while performing this operation.
Audi connect®
Initial Setup
Audi connect® can provide you with Google Earth™, Google Voice™
Local Search, Wi-Fi Hotspot, Online Services (fuel prices, weather
information, travel information, news feeds) and myAudi
Destinations.
TEXT A6CONNECT to 38981
Do not text and drive. Message and data rates may apply.
TEL
12
Audi connect®

Audi connect®
cont.
13
Wi-Fi Configuration
6. Select a password that is at least eight characters long.
The default password can be used. Or a new password can
be entered.
4. Select Wi-Fi settings. 5. Then select Wi-Fi active
and choose Visible.
NOTE: Most devices use Encryption type WPA2 as the default.
14
9. Press the Back button,
scroll to Data connection
and select.
7. Select Apply settings to
save your password.
8. On your device, search for
Wi-Fi networks, select SSID
and enter your password to
establish a connection.
NOTE: You may connect up to eight wireless
devices at one time.
10. Select Without request.
Press the back button to
exit.
Data Configuration
Audi connect®
Important Safety Instructions and Warnings which you must read, are listed on the last panel under Audi connect®.
Always pay careful attention to the road, and do not drive while distracted. The features and technologies discussed are optional, may require an additional subscription with separate terms and conditions, and should be used only
when it is safe and appropriate. The Wi-Fi hotspot feature is intended for passenger use only.
Audi connect® services are only available where there is mobile network coverage. You can obtain more information from your current service provider.

Your MMI® Navigation system has extraordinary capabilities
to enhance your drive with user-definable views, routing
selections and more. Get started with setting destinations
and discover more as you become familiar with the interface.
1. Press the function button.
2. Select the Destination control button.
To set a destination:
Audi Navigation
Setting a Destination
NAV
15
Important Safety Instructions and Warnings which you must read, are listed on the last panel under Navigation & Infotainment.
3. Select Address from the
Navigation Menu.
4. Select City/Zip code field
and enter information.
5. Continue by entering the
Street and House number.
6. When complete, select
Start route guidance.
TEXT A6NAV7 to 38981
Do not text and drive. Message and data rates may apply.
16
Navigation
Please drive safely. Enter destinations while vehicle is stationary away from trac. Always pay careful attention to the road, and do not drive while distracted.

1. Press the button.
2. Say “Enter Address.”(Other commands are available on screen.)
See Owner’s Manual for complete list of commands.
3. After the beep, speak the address; for example “2024 Main St, Los Angeles, California.”
(Speak street number as single digits.) The system will respond with repeating the
address for confirmation.
4. System will respond, “The list is being loaded,” it will repeat the address, and then ask if
you would like to start route guidance; after the beep say, “Yes” and guidance will begin.
To set a Destination with voice commands:
Audi Navigation
cont.
Setting a Destination (Voice Recognition)
NOTE: The MMI® will display the most frequently used voice commands while waiting for your response. When pressing the button, the last navigation announcement will be repeated.
NAV
17
TEXT A6NAV8 to 38981
Important Safety Instructions and Warnings which you must read, are listed on the last panel
under Voice Recognition.
Cellular connectivity is dependent on available cellular signal.
Do not text and drive. Message and data rates may apply.
*Google Voice™ Local Search requires Audi connect®, and may require an additional subscription with separate terms and conditions.
The features and technologies discussed are optional, and should be used only when it is safe and appropriate.
Google Voice™Local Search (Online Destinations)*:
1. Press the button.
2. Say
“Online Destinations” followed
by a keyword such as “Coee Shop”,
(e.g., bookstore, museum, pizza, etc.)
The system will respond with “retrieving
requested information” and display a list.
3. Make your selection from the list
displayed by speaking the line
number, (for example 1, 2, 3, or 4).
The system will confirm your selection.
4. Say “Start route guidance” to start
the navigation to your destination.
18
Navigation

Automatic Climate Control 19
3-Zone Climate Control
AUTO Setting
The setting of your Climate Control System maintains the cabin temperature
to your selected temperature by regulating the temperature, fan speed and airflow.
Once activated, there is no need to alter the settings.
When is selected, will come on automatically to condition the air.
NOTE: AC is used to dehumidify the air.
ACAUTO
Dual Temperature Settings
Temperature and airflow can be operated independently for each side of the cabin using
the control knobs. will maintain separate temperatures for the driver and front
passenger.
AUTO
Important Safety Instructions and Warnings which you must read, are listed on the last panel under Automatic Climate Control.
TEXT A6CLIMATE3 to 38981
Do not text and drive. Message and data rates may apply.
20
Automatic
Climate Control
AUTO

3-Zone Climate Control
cont.
Airflow
The airflow selectors directs air to the floor,
panel or defrost vents, or a combination.
Recirculation
The recirculation function prevents outside air
and odors from entering the cabin. It may also be used
in conjunction with AC to cool the cabin more quickly.
Fan Speed
Fan speed is the same for both zones. Fan speed can be
adjusted by turning the control knob.
21
Important Safety Instructions and Warnings which you must read, are listed on the last panel under Automatic Climate Control.
Dual Temperature Settings
Temperature settings can be operated independently for each
side of the cabin using the control knobs. will maintain
separate temperatures for the driver and front passenger.
4-Zone Climate Control
AUTO Setting
The setting of your Climate Control System maintains the
cabin temperature to your selected temperature by regulating the
temperature, fan speed and airflow. Once activated, there is no need
to alter the settings. When is selected, will come on
automatically to condition the air.
NOTE: AC is used to dehumidify the air.
AC
AUTO
AUTO
Synchronize Zones
Pressing the button will synchronize the driver and passenger side controls along with the rear settings to the same temperature, fan
speed and airflow. The Synchronization disengages once a passenger adjusts their temperature setting.
22
Automatic
Climate Control
AUTO
SYNC

4-Zone Climate Control
cont.
Airflow
The airflow selector directs air to the floor, panel or defrost vents,
or a combination.
Recirculation
The recirculation function prevents outside air and odors from
entering the cabin. It may also be used in conjunction with AC to cool
the cabin more quickly.
Fan Speed
Fan speed can be operated independently. To change the speed, press
the button followed by turning either the Driver or Passenger
control knob.
23
TEXT A6CLIMATE4 to 38981
Do not text and drive. Message and data rates may apply.
Important Safety Instructions and Warnings which you must read, are listed on the last panel under Automatic Climate Control.
Temperature Fan speed Airflow directions
MMI®Display
Your climate control adjustments such as Temperature, Fan speed and Airflow can be seen on your display for convenience.
NOTE: Temperature display only shown with MMI® Navigation system. The ideal fan speed to heat or cool your interior will be displayed with a on the fan speed level.
24
Automatic
Climate Control

At your desired speed, press the button
at the end of the stalk. The set speed and the
illuminated icon are shown in the
Driver Information Display.
To activate, pull the control stalk toward you.
Cruise Control
Activate
Set Cruising Speed
SET
CRUISE
TEXT A6CRUISE to 38981
Do not text and drive. Message and data rates may apply.
25
Changing Speed
To cancel and resume cruise control:
1. Press the brake pedal or push the stalk
slightly away from you.
2. The light will go o.
3. To resume, pull the stalk towards you;
you will return to your set speed.
Your most recently set speed appears as a
small icon in the Driver Information Display.
It remains in memory until you turn your
Audi o.
Cancel/Resume
There are three ways to change your
speed:
1. Accelerate or decelerate, then press
again.
2. To increase/decrease speed in 1 mph
increments, or 2.5 mph increments
with adaptive cruise control, tap the
stalk up or down.
3. Hold the stalk up or down to
increase/decrease speed in 5 mph
increments; release when desired
speed is reached.
NOTE: Refer to your Owner’s Manual for additional information about Adaptive Cruise Control.
Important Safety Instructions and Warnings which you must read, are listed on the last panel under cruise control.
SET
CRUISE
26
Cruise Control

This advanced Audi technology is design to help save fuel and reduce
CO2emissions at the same time. It shuts o the engine when you stop
at trac signals or during certain stop-and-go driving conditions.
When the system shuts o the engine, the Start-Stop System light
appears in the Driver Information System in the instrument cluster.
Releasing the brake pedal instantly restarts the engine and makes
power available before your foot even reaches the accelerator.
Simply drive as you normally would and it works seamlessly.
Start-Stop System
TEXT A6START to 38981
Do not text and drive. Message and data rates may apply.
27
Important Safety Instructions and Warnings which you must read, are listed on the last panel under Start-Stop System.
If you wish to turn o the Start-Stop system, simply press
the button located below the Audi multimedia panel
or MMI® display. The button will illuminate to tell you the
Start-Stop is o. The engine will continue to run when the
vehicle is stopped at trac signals or during stop-and-go
driving. Of course, you will not receive the potential fuel
savings or CO2reduction benefit. Once you have turned o
Start-Stop, it will remain o until you press the
button to turn it back on.
Start-Stop ON or OFF?
The choice is yours.
NOTE: This feature is available on A6 3.0T only.
A
OFF
A
OFF
28
Start-Stop
System

Tire Pressure Monitoring System (TPMS)
Correct Tire Pressure
If the TPMS indicator light is on:
1. Check the tire pressure in all tires as soon as possible.
2. Inflate your tires to the specifications on the door jamb label.
29
Important Warnings and Safety Information, which you must read, are listed on the last panel under Tire Pressure Monitoring System (TPMS).
Reset TPMS Indicator Light
NOTE: Tire pressure is aected by temperature changes. When dramatic weather changes occur and the TPMS indicator light is activated follow proper tire maintenance instructions.
Once tires have been properly filled, reset the system.
30
Tire Pressure
Monitoring System
1. Press the function
button.
2. Select the Car Systems
Control button.
3. Select Servicing & checks. 4. Select Tire pressure
monitoring.
5. Select Store tire pressures.
6. Then select Yes, store now.
CAR

Clock Setting: MMI®
1. Press the function button.
2. Press the Time control button.
3. Using the control knob, scroll to Time source.
4. Make sure the Time source is set to GPS.
5. Ensure your time zone is accurate for your location.
To set time with GPS*:
*Vehicles equipped with Navigation only.
NOTE: Turn on Daylight Savings time to allow the clock to change automatically.
MENU
TEXT A6CLOCK1 to 38981
Do not text and drive. Message and data rates may apply.
31
Vehicle should be stationary with the parking brake engaged while performing this operation.
1. Refer to Set Time with GPS and follow Steps 1 - 3.
2. Rotate the control knob to Manual and select.
3. Turn the knob until you reach Time; select to activate.
4. Turn the knob to the desired hour and press to set.
5. The minute display is now highlighted; repeat the selection process.
6. Save the time by pressing the control knob.
To manually adjust the time:
32
Clock Setting

The majority of today’s vehicles use semi-metallic brake pads, which oer
excellent performance. Because of the metal-to-metal contact involving
semi-metallic pads, the sounds generated by the brake system under
normal operation can be greater than the sounds produced by vehicles
equipped with previous-generation brake pads. Depending on the local
environment, weather conditions and individual driving patterns, sounds
from the braking system may be more or less apparent.
Frequent, aggressive brake application increases the wear of brake
components and can reduce the potential for brake noise. Frequent, light
brake application allows glazing to develop on the brake surface, which
increases the potential for brake noise.
Brake Noise
Brakes 33
Brake dust is a result of friction created by brake pads
and discs during braking. As brake pads and discs
make contact during braking, they wear down, which
causes dust particles to be expelled. This is a normal
characteristic of all brake systems and is not an indicator
of a defect.
Brake Dust
Important Safety Instructions and Warnings which you must read, are listed on the last panel under Brakes. 34
Brakes
