Audi Q5 2009 Install guide

Service 6
Service Department. Technical Information
No.
66
Fitting instruction
Audi Q5 2009 
Body
Partition grid with space separator
Edition 11.08

Service
6
All rights reserved.
No reproduction without prior agreement from publisher.
Printed in Germany
Copyright © 2008 Audi AG, Ingolstadt
Contents
1 Information ..........................................................................................
1.1 General information ................................................................................
1.2 Special information about using the partition grid ................................................
2 Parts overview ......................................................................................
2.1 Parts overview of partition grid ....................................................................
2.2 Parts overview of space separator ................................................................
3 Partition grid assembly set .........................................................................
4 Space separator assembly set .....................................................................
1
1
1
3
3
4
5
8

Audi Q5 2009 
No. 66, Body, Edition 11.08
1 Information 1
6
1 Information
1.1 General information
Please read and take note of these DANGER, Caution and
Note descriptions before carrying out maintenance or repair
work.
♦Text with this symbol contains additional useful
information.
♦A Note symbol also contains special and additional notes
on repair measures and associated information.
Audi AG will not accept responsibility in the event of failure
to comply with these assembly instructions.
1.2 Special information about using the
partition grid
♦Improper installation can cause damage to the vehicle or
the partition grid.
♦We reserve the right to make technical changes.
♦Check all screws after a short journey and at regular
intervals and tighten if necessary.
♦Do not tighten too tight or the covering may be damaged.
♦When transporting animals/dogs behind the partition grid,
clean the surface of the partition grid regularly, as e.g. dog
saliva could damage the surface coating of the partition
grid.
Loading long items
To transport lengthy articles (e.g. skis), the load-through
hatch can be opened forwards.
WARNING!
♦Text with this symbol contains information concerning
your safety and how you can reduce the risk of serious
and fatal injuries.
♦Pay special attention to the DANGER symbol. Ensure
that you read this text thoroughly.
Caution!
♦Text with this symbol contains information on how to
avoid damage to the vehicle.
♦A Caution symbol indicates that failure to follow
information could lead to damage to the vehicle.
WARNING!
It is forbidden to transport people behind the partition grid!
Note
Note

Audi Q5 2009 
No. 66, Body, Edition 11.08
1 Information
6
2
–To open, move the backrest forwards (⇒vehicle owners
manual) and loosen both of the star grip screws on the
load-through hatch.
–Open the load-through hatch.
–After pushing the rear seat backrest back, ensure that the
partition grid is not touching the backrest.

Audi Q5 2009 
No. 66, Body, Edition 11.08
2 Parts overview 3
6
2Partsoverview
2.1 Parts overview of partition grid
Partition grid assembly set -8R0 017 221-
Comprising:
1 - Partition grid
2 - Star grip screw
(small head - 6x)
3 - Star grip screw
(large head - 4x)
4 - Bracket for vehicles
with adjustable
fastening rings (2x)
Marked left (L) and
right (R)
5 - Counterhold
bracket (2x)
6 - Bracket for vehicles
with fixed fastening
rings (2x)
Marked left (L) and
right (R)
7 - Pin (2x)
8 - Rubber washer (2x)
9 - Upper retaining
clamp (2x)
10 - Star grip nut (2x)
1
234
5
7
8
ZUB-0095
9
10
6

Audi Q5 2009 
No. 66, Body, Edition 11.08
2 Parts overview
6
4
2.2 Parts overview of space separator
Space separator assembly set -8R0 017 222-
Comprising:
11 - Space separator
12 - Star grip screw
(small head - 2x)
13 - Star grip screw
(large head - 1x)
14 - Support plate (2x)
11
121314
ZUB-0096

Audi Q5 2009 
No. 66, Body, Edition 11.08
3 Partition grid assembly set 5
6
3 Partition grid assembly set
The luggage compartment cover and net partition cannot be
used when the partition grid is installed.
–Check that the assembly set is complete.
–Remove the net partition (if present).
–Remove the luggage compartment cover and fold down
the rear backrest.
–Screw the retaining clamp -9- loosely to the pin -7-, rubber
washer -8- and star grip nut -10-.
–As shown, press the pin of the retaining clamp up into the
cut out (large drilled hole in the roof) -Arrow A-.
–Now move the retaining clamp up slightly and in the
direction of travel -Arrow B-, until the pin hooks into the
small hole.
–Tighten the star grip nut slightly. The upper retaining clamp
must still be moveable.
–Insert the partition grid - tilted slightly as shown - carefully
through the luggage compartment and position roughly in
the installation position.
Note
ZUB-0123
10
9
8
7
A
B
9
ZUB-0097
10
7
ZUB-0098

Audi Q5 2009 
No. 66, Body, Edition 11.08
3 Partition grid assembly set
6
6
–Screw the partition grid -1- and the upper brackets -9-
together loosely using the star grip screws (small head) -2-.
Vehicles without a rack system for loading safety (fixed
fastening rings)
–Lift the fastening ring -A- and insert the bracket -6-.
–Screw the bracket -6- to the partition grid with the star grip
screws (small heads) -2-.
–Straighten the partition grid centrally again and tighten all
of the screws securely.
Vehicles with a rack system for loading safety (adjustable
fastening rings)
–Screw the bracket -4- and the counterhold bracket -5-
together loosely using just one of the star grip screws
(large head) -3- for each.
Ensure that the cut outs and the guides -Arrow- on the
counterhold bracket -5- face towards the bracket -4-
(the narrow end facing up).
–Remove all existing fastening rings from the rails.
ZUB-0099
1
2
9
ZUB-0100
6
A
ZUB-0101
6
2
ZUB-0102
5
34
Note

Audi Q5 2009 
No. 66, Body, Edition 11.08
3 Partition grid assembly set 7
6
–Insert the respective counterhold bracket into the opening
in the rails and push forward -Arrow-.
–Bring the bracket -4- into the installation position and
screw onto the partition grid -1- with the star grip screws
(small head) -2-.
–Set a distance -A- of approx. 1 cm between the partition
grid -1- and the luggage compartment cover.
–Tighten the star grip screws (large head) -3- slightly.
–Screw the last star grip screws (large head) -3- through
the bracket -4- into the counterhold bracket and tighten
slightly.
–Secure the screws -3- into this position.
–Secure all screws on the upper and lower brackets.
–If available, assemble the space separator ⇒“4 Space
separator assembly set” on page 8.
–Push the rear seat backrest back and ensure that the
partition grid is not touching the backrest.
The luggage compartment cover and net partition cannot be
used when the partition grid is installed.
WARNING!
Ensure that the securing pins -A- of the counterhold brack-
et are between the securing pins of the support rail -B-.
ZUB-0103
ZUB-0104
A
34
1
2
ZUB-0105
3
B AA
4
Note

Audi Q5 2009 
No. 66, Body, Edition 11.08
4 Space separator assembly set
6
8
4 Space separator assembly set
–Insert the support plates -14- from below in the drill holes
-A- on the space separator -11-.
–Position the space separator either in the middle or create
a 1/3 and a 2/3 section.
–Loosely screw the top of the space separator to the parti-
tion grid -A- using the star grip screw (large head) -13-.
–Loosely screw the bottom of the space separator
to the partition grid -B- using the star grip screw
(small head) -12-.
–Tighten all screws.
Straighten the space separator:
–Loosen the lock nuts -A-.
–Turn the support foot -B- to adjust it so that the space
separator has a slight bearing preload.
–Secure the lock nuts -C-.
–Push the rear seat backrest back and ensure that the
partition grid is not touching the backrest.
ZUB-0106
14
AA
11
B
A
ZUB-0107
ZUB-0108
A
B
C
