Audi Q5 2009 User manual

Audi
2009 Audi as
Quick Reference Guide

Fuel
(see label) Fuel filler flap Opening:
Press the left side of the fuel filler flap.
Closing:
Press the fuel filler flap in until it latches .
,;z::,
Tire pressures
(driver's side B-pillar)
Visible when the door
is open.
qr'?'
Engine oil
The engine oil
specification is in the
"Checking and filling"
chapter and the
engine oil capacity is in
the "Data" chapter.

0 ![I AUDI]
,1/
Dear driver,
This Quick Reference Guide provides
you with a brief overview of selected
procedures and functions in your vehicle.
It does not replace the Owner's Manual
with its important explanations and
warnings.
The Owner's Manual provides detailed
information about your vehicle. You can
find everything you need to know about
the radio, CDplayer, navigation system
and telephone in the Infotainment/
MM/ Owner's Manual or Radio System
Owner's Manual.
We hope you enjoy driving your new
Audi and we wish you safe and pleasant
motoring.
Sincerely, AUDI AG
Welcome

Cockpit
0 Hood release
f) Release button for luggage compartment
8 Data Link Connector for On Board Diagnostics (OBD II)
0 Power windows
Setting the desired position:
Press/pull as far as the first level and hold.
Automatic up/down function:
Briefly press/pull as far as the second level.
_& WARNING
Be careful when closing the windows. Check to see that no
one is in the way, or serious personal injury could result.
C, Adjusting the exterior mirrors
Adjust the knob:
~ Left exterior mirror
Ci[) Heating the exterior mirror
~ Right exterior mirror
~ Folding the exterior mirror
The mirror glass moves in the direction that the knob is pressed.
0 Memory seat buttons V •

0 Door handle and central
locking switch
[JiD locked
(A) unlocked
0 Side assist warning display
0 Button for side assist
~ Light switch and
Instrument lighting
~ Cruise control
ft) Turn signal and
high beam lever
G) Multifunction steering
wheel controls
~ tiptronic shift buttons
~ Instruments and
indicator lights
~ Windshield wiper controls
and trip computer buttons
'f>Ignition lock
~ Sound system/MMI display
~ Button and indicator light
for:
(.@)) Emergency flashers
(ffi Passenger airbag
deactivated
e Sound system/
Audi multimedia
G, Audi drive select buttons :
You can select from the
following settings:
COMFORT
Choose this setting when
you want a more comfortable
driving style (for example,
when driving long distances
on the expressway)
AUTO
Choose this setting for
everyday driving.
DYNAMIC
Choose this setting when
you want a more sporty
driving style.
e Buttons for:
~ Parking system advanced
~ Electronic Stabilization
Program
(@ ] Hill descent assist
On vehicles equipped with a
sound system , buttons a,and e
are located on the shift gate.
G) Climate control system
a, Shift lever for automatic
transmission
e MMI terminal
~ Engine START/STOP button
~ Electromechanical
parking brake
e Steering wheel position
adjuster
&, WARNING
The column should only be adjusted
when the vehicle is at a complete
standstill.

•
(
Opening and closing the vehicle
With convenience key, you can lock and
unlock your vehicle without using the
remote control key.You only need to
carry the remote control key with you.
Unlocking the vehicle:
Grasp one of the door handles or the handle
recess on the luggage compartment lid.
Locking the vehicle:
Place the selector lever in the P position.
Press the lock button Oon one of the door
handles.
Closing the luggage compartment lid
automatically:
Press the ~,81 ~ button in the open luggage
compartment lid.
_& WARNING
When you leave the vehicle, always remove the
ignition key and take it with you. This will prevent
passengers (children, for example) from
accidentally being locked in the vehicle should
they accidentally press the power locking switch
in the front doors.
,& WARNING
When you lock your vehicle from the
outside, do not leave anyone -espe-
cially children -inside the vehicle.
Remember, when you lock the vehicle
from the outside the windows cannot
be opened from the inside.
_& WARNING
Always ensure that no one is within
range of the rear lid when it is moving,
in particular close to the hinges -
fingers or hands can be pinched.
Starting the enaine
Switching the ignition on and off:
Insert the key into the ignition lock.
Do not depress the brake pedal. Press on the key.
The key can only be removed when
the ignition is switched off .
Starting the engine:
Insert the key into the ignition lock.
Depress the brake pedal and move
the selector lever into P or N.
Briefly press on the key.
Stopping the engine when the vehicle is standing:
Move the selector lever into P or N.
Briefly press on the key.
Convenience key:
You can switch on the ignition and start/stop the
engine using the START/STOPbutton without having
the key inserted in the ignition lock.

Adjusting the seats
0 Adjusting the lumbar support :
Press on the respective area of the switch.
f) Adjusting seat height and forward /
back position :
Fl Front of the seat cushion up/down
....
q Back of the seat cushion
up/down
.......
B Seat up/down
•c:i•Seat forward/back
0 Adjusting the backrest :
•a• Backrest forward/
back
Adjusting the headrests :
The top edge of the
headrest should be
at eye level or
higher.
,& WARNING
Thoroughly review your Owner 's Manual for
warnings and other important information about
proper restraint use and what you can do to
reduce the risk of injury in accidents. Failure to
properly use restraint systems can cause serious
personal injury.
&, WARNING
Never install rear facing child seats or infant
carriers on the passenger seat .A child will be
seriously injured or killed when the passenger
airbag inflates .
,& WARNING
Always fasten safety belts before driving off .
Always make sure passengers are properly
restrained. Children 12 years old and younger
must ride in the rear seat and be properly
restrained as indicated in the Owner's Manual.
The airbag is supplemental and does not replace
safety belt use.
,& WARNING
Front seat passengers must never ride in a
moving vehicle with the seatback reclined . The
risk of personal injury increases with increasing
rearward angle of the seatback. Safety belts only
offer protection when the seatback is upright and
belts are properly positioned on the body. Adjust
your seats only when the vehicle is at a complete
standstill.
,& WARNING
The airbag system cannot protect you properly
if you are seated too close to any of the airbag
locations. When adjusting their seat positions,
it is important that both the driver and front
passenger keep their upper bodies at a minimum
safe distance of 10 inches (25 cm) between the
chest and the steering wheel/instrument panel.
Introduction

-
0
~
...,
C \0
(J \
Q)
...,
ca
E
·-
-
(J
(J
·-
...,
ca
E
0
...,
::,
<(
-- )
_______________,
Climate control switch
Left switch - driver's side
Right switch - passenger's side
Rotary switch: Temperature selection
~ Automatic mode
Set the desired temperature and press the button.
( ;C;i ~ Recirculation mode
Circu late and filter the air inside the passenger
compartment
(I) Fan speed
(I) Air distribution
~ Defrost the windshield/side windows
(]mDRear window defroster
Gii[JHeated seats
(]iJ Switch the air conditioning system on/off
(]ID Switching on/off
Panoramic sliding sunroof
Comfort position :
Rotate the switch to O .
Opening: Rotate the switch
in the direction euntil the
desired posit ion is reached.
'-------- ____,/
Closing: Rotate the switch to Ci).
Tilting/closing: Briefly press/pull
the switch in the Ci)position . _Ci)_ ----
Press/pull longer to adjust the tilt height individually.
Sun shade, opening and closing: Push the switch in the direction
of arrow. Intermediate position: Push the switch again in direct ion
of the arrow .
& WARNING
Be careful when closing the panoramic sliding
sunroof. Check to see that no one is in the way,
or serious personal injury could result.

0-
:JI
Electromechanical
parking brake
Cruise control svstem
The CRUISE/ 0 indicator light appears in the
instrument cluster when the system is
switched on.
Switching on/off: Pull/press the lever f) .
Storing the speed: Press the button O.
Changing the stored speed: Press the lever
up (faster) or down (slower).
_& WARNING
Improper use of the cruise control system can
cause collisions, other accidents and serious
personal injury. Always read and heed the
Warnings in the Owner's Manual.
Stopping and engaging the parking brake: Pull the (g) button .
Releasing the parking brake: Press the brake pedal and press the (liID button.
Releasing automatically: The parking brake releases itself automatically
when the safety belt is fastened and you begin driving.
Technolo

Multi Media Interface/
Sound system
Components
0 Driver information system
f) Multifunction steering wheel
Roll the left menu thumbwheel to mark a menu item
in the driver information system. Press the thumbwheel
to confirm the menu item.
Press the MODE button to switch between the active
radio source, navigation system and telephone.
Press the ~ button briefly to switch voice
commands on.
For example, after the <Beep>, say <Help> to call up the
system announcement with the possible speech
commands. Hold the Talk button down to switch voice
commands off .
Roll the right menu thumbwheel to control the volume.
Press the right thumbwheel to repeat the last navigation
announcement.

c Qd t u;:.;: I
8 Sound system/MMI display
0 On/Off knob
Switching on: Press briefly.
Adjusting the volume: Rotate.
Muting: Tap.
Switching off: Press and hold.
0 Function buttons
Press the desired button (such as MEDIA)
to activate that mode.
8 Control knob
Marking a menu item in the display 8 :Rotate the
control knob.
Confirming the selection: Press the control knob.
G Control buttons
To call up one of the functions shown in the four corners
of the display, press the corresponding control button
that is assigned to that corner of the display.
e Joystick
To move the
crosshairs in a map
view (navigation)
or to control the DVD
menu.
_&.WARNING
Distraction causes accidents:
-Never enter data while driving!
-Obey traffic laws & road signs!
-Referto the Owner's Manual!
Operating concept
All functions are controlled
using the same operat ing
concept.
0 Calling up menus in the
display corners: Press the
corresponding button.
0 Marking: Rotate the knob.
8 Confirming: Press the knob.

C
0
·-
...,
ctJ
...,
U)
0
·-
~ 0 Press the RADIO function button.
"-
m
Cl
C
·-
"-
0
...,
en
C, Press the "Presets" control button.
0 Rotate the control knob and mark
"Store <station name>".
f) Rotate the control knob and mark the
desired station.
8 Press the control knob. The next free
memory preset is marked.
8 Press the control knob to confirm.
f) Rotate the contro l knob and mark the
desired preset.
0 Press the control knob to confirm.

C
0
·-
...,
m
C)
·-
>
m
C
C)
C
·-
0 Press the NAV function button.
Cl)Continue entering the remaining letters
of the destination name using the same
procedure until the desired location
name is displayed.
f) Rotate the control knob and mark
"City/ZIP ".
8 Press the control knob to confirm.
0 Press and hold the control knob longer
when the city appears in the list.
0 Rotate and press to select the city and
enter detai led destination information
if necessary.
0 Rotate the control knob to mark the
first letter of the destination.
C!)Press the control knob to confirm.
0 Mark the menu item
"Start route guidance".
~ Press the control knob to confirm.
The route is calculated.
Infotainment

Driver assistance
systems
Use the CAR button to adjust or operate
many driver assistance systems in your
Audi.
For detailed information on this, please see
your vehicle Owner's Manual.
Infotainment
Establishing a Bluetooth TM cell phone connection
You can quickly connect your Bluetooth-
compatible cell phone with the MMI or
radio system.
Connecting to the MMI:
• Switch the ignition, MMI and cell phone
on.
• Activate "Bluetooth" and "Access to
SIM card" on the cell phone.
• Press the TEL function button.
• Mark the menu item
"Search for new cell phones".
• Press the SETUPfunction button.
• Press the "Bluetooth" control button.
• Highlight the menu item "Search for
Bluetooth devices" and confirm.
• Mark and confirm your cell phone
in the display.
• Mark "Handsfree" and confirm.
• Confirm the PIN number with "Yes" .
• Enter the PIN number on the cell phone .
• Also confirm the system prompt on the
cell phone if necessary.
Connecting with the radio system:
• Switch the ignition, radio system and
cell phone on.
• Select the menu in the cell phone that
searches for Bluetooth-compatible
devices (such as the cell phone prep
or handsfree system).
• Connect the cell phone with the
cell phone prep.
• Enter the PIN number on the
cell phone.

Indicator lights
~
Dynamic steering
~
EP Electronic power contro l1
1 -D
Electronic Stabilization CRUISE
Program (ESP)
AIR Airbag system (USA)11
~
BAG
eo-
~/J Airbag system (CAN)11 AB
w Tire pressure low (~
(check immediately)
¢¢ Turn signals/ PARK
Emergency flasher BRAKE
¢1¢ Trailer turn signal (®)
assembly
,./'
* Safety belt
Malfunction Indicator
Lamp11
High beam
Cruise control activated
(USA)
Cruise control activated
(CAN)
Anti-lock brake system
(USA)11
Anti -lock brake system
(CAN)11
Parking brake (USA)
Parking brake (CAN)
Warning symbols
D Alternator malfunction
BRAKE Brake malfunction
(USA)
((D) Brake malfunction
(CAN)
_f_ Cooling system
malfunction
-
~
Engine oil pressure
too low
~ N Refill engine oil now
@--e Steering defective
't'--e Ignition switch
\V defective 2008 AUDI AG
11 If th is illuminates while driving, contact your authori zed Audi dealer immediately.
If one of these red symbols appears in the
display while driving, pull over immediately,
stop the engine, and check the Owner's Manual.
Audi is constan tly imp roving their products. Modi-
ficat ions in form, equipment, and technology are
possible. No legal comm itmen t is imp lied by the
information, illustrat ions, and descript ions in this
Quick ReferenceGuide. Reprinti ng, reproduction or
translation, in w hole or in part, is not permi tted
witho ut wri tten permission from Aud i of Ameri ca,
Inc. Reprinting, reproduct ion or translatio n, in
whole or in part, is not permitted without written
permissio n from Audi of America, Inc. Subject to
modification w ithout notice. Concept and design:
Pfrie mer GmbH. Printed in Germany.
Indicator Ii hts and warnin s mbols

www.audi.com
Audi05
Kurzanleitung
Nordamerika
englisch 10.08
291.562.862.21
