Audi TT 2007 Operating instructions

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
Repair Manual
Audi TT 2007 ➤
Maintenance Procedures
Edition 08.2011
Service
Service Department. Technical Information

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
List of Workshop Manual Repair GroupsList of Workshop Manual
Repair GroupsList of Workshop Manual Repair Groups
Repair Group
03 - Maintenance, Diagnosis
Technical information should always be available to the foremen and mechanics, because their
careful and constant adherence to the instructions is essential to ensure vehicle road-worthiness and
safety. In addition, the normal basic safety precautions for working on motor vehicles must, as a
matter of course, be observed.
Service
All rights reserved.
No reproduction without prior agreement from publisher.
Copyright © 2011 Audi AG, Ingolstadt D3E8026E6A3

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
Contents
03 - Maintenance, Diagnosis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1 General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.1 Engine Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.2 Type Plate and VIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.3 Raising Vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.4 Tow Starting/Towing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.5 Vehicle Checks during Inspection and Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2 Maintenance Procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.1 Strut Tube Cap, Lubricating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
2.2 Measured Values Block 32, Reading . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.3 Battery, Checking Level Using Guided Fault Finding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.4 Battery, Checking No Load Voltage before Starting Engine . . . . . . . . . . . . . . . . . . . . . . . . 15
2.5 Battery, Check Fluid Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
2.6 AGM Battery, Checking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
2.7 Battery, Checking Cables for Secure Seating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
2.8 Tires, Checking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
2.9 Brake System, Inspecting for Leaks and Damage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
2.10 Brake Pads, Checking Thickness . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
2.11 Brake Fluid, Checking Depending on Brake Pad Wear . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
2.12 Brake Fluid, Changing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
2.13 Fuel Injector Cleaner G17 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
2.14 Key, Check Functionality . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
2.15 DTC Memory, Checking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
2.16 Engine Compartment Front Noise Insulation Cover, Removing and Installing . . . . . . . . . . 28
2.17 Coolant System, Checking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
2.18 Instrument Cluster, Selecting Language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
2.19 Air Filter, Cleaning Housing and Removing and Installing Filter . . . . . . . . . . . . . . . . . . . . 31
2.20 Haldex Clutch Oil, Changing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
2.21 Hood Safety Catch, Lubricating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
2.22 Engine Cover, Removing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
2.23 Engine and Engine Compartment from Underneath, Inspecting for Leaks and Damage . . 39
2.24 Engine Oil, Draining/Extracting and Removing and Installing Filter . . . . . . . . . . . . . . . . . . 40
2.25 Hood Hinge, Lubricating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
2.26 Engine Oil, Filling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
2.27 Engine Oil Level, Checking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
2.28 Navigation Eject Button, Unlocking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
2.29 Radio, Entering Security Code to Activate Anti-Theft Coding . . . . . . . . . . . . . . . . . . . . . . 44
2.30 Road Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
2.31 Wheel Bolts, Tightening Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
2.32 Tire Pressure Monitoring Display, Adapting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
2.33 Windshield Washer System, Checking and Adjusting Spray Nozzles . . . . . . . . . . . . . . . . 46
2.34 Headlamp Washer System, Checking Spray Nozzles . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
2.35 Windshield Wiper Blades, Checking End Position and for Damage . . . . . . . . . . . . . . . . . . 49
2.36 Service Display, Resetting or Adapting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
2.37 Install Fuse for Headlamp Washer System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
2.38 Dust and Pollen Filter, Removing and Installing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
2.39 Tie Rods, Control Arms, Ball Joint and Driveshafts, Checking Play, Fit and Sealing Boots
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
2.40 Transport Mode, Deactivating using VAS 5051/5052 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
2.41 Door Arrester, Door Hinge and Lock Cylinder, Lubricating . . . . . . . . . . . . . . . . . . . . . . . . 55
2.42 Transport Protection, Removing Front and Rear Suspension Strut Protectors . . . . . . . . . . 56
2.43 Underbody Protection, Inspecting for Damage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
2.44 Plenum Chamber Water Drain, Checking and Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Audi TT 2007 ➤
Maintenance Procedures - Edition 08.2011
Contents i

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
2.45 Factory-Equipped Winter Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
2.46 Clock, Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
2.47 Spark Plugs, Removing and Installing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Audi TT 2007 ➤
Maintenance Procedures - Edition 08.2011
ii Contents

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
03 – Maintenance, Diagnosis
1 General Information
⇒ “1.1 Engine Overview“, page 1
⇒ “1.2 Type Plate and VIN“, page 4
⇒ “1.3 Raising Vehicle“, page 6
⇒ “1.4 Tow Starting/Towing“, page 7
⇒ “1.5 Vehicle Checks during Inspection and Maintenance“, page
9
1.1 Engine Overview
Code letters CBRA
Displacement liter 3.189
Output kW at RPM 184/6300
Torque Nm at RPM 320/2500 to 3000
Bore dia. mm 84
Stroke mm 95.9
Compression ratio 10.85
RON at least 98 1)
Fuel injection and ignition system Motronic
Ignition sequence 1-5-3-6-2-4
Emissions values LEV2
Exhaust gas recirculation no
Turbocharger, G-Charger no
Oxygen sensor regulation 4 sensors
Variable valve timing yes
Variable intake manifold yes
Secondary Air Injection System yes
Valve per cylinder 4
•1) Super unleaded RON 95 is permissible, although with reduced power.
Engines ⇒
Engine Code BUB
Displacement 3.2L
Number of cylinders/valves per cylinder 6/4
Emissions category EU IV
Output kW at RPM 184 / 6333
Torque Nm at RPM 320 / 2500
Bore ∅ mm 84.0
Stroke mm 95.5
Compression ratio 10.85:1
Fuel injection/Ignition MPI
RON minimum. 98 unleaded 1)
Audi TT 2007 ➤
Maintenance Procedures - Edition 08.2011
1. General Information 1

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
1) 95 RON Super unleaded gasoline is permissible, however with
decreased power output
Engines ⇒ Gasoline engines
Engine Code CCZA CDMA
Displacement liter 2.0 2.0
Number of cylinders/valves per cylin‐
der
4/4 4/4
Emissions category EU V EU IV
Output kW at
RPM
147 / 5100 - 6000 195 / 6000
Torque Nm at
RPM
280 / 1800 - 5000 350 / 2500 … 5250
Bore ∅ mm 82.5 82.5
Stroke mm 92.8 92.8
Compression ratio 9.8:1 9.8:1
Fuel injection/Ignition TFSI TFSI
RON mini‐
mum. 98 unleaded 1) 98 unleaded 1)
1) 95 RON Super unleaded gasoline is permissible, however with
decreased power output
Code letters CETA
Displacement liter 1.984
Output kW
at
RPM
155/4200
Torque Nm
at
RPM
350/1500
Bore dia.
mm
82.5
Stroke mm 92.8
Compression ratio 9.6
RON 95 1)
Fuel injection and igni‐
tion system
FSI
Ignition sequence 1-3-4-2
Knock control yes
Turbocharger yes
Exhaust gas recircula‐
tion
no
Variable intake manifold no
Variable valve timing yes
Secondary air injection
(AIR)
no
•1) Unleaded RON 91 is also permissible, although with re‐
duced power.
Audi TT 2007 ➤
Maintenance Procedures - Edition 08.2011
2 Rep. Gr.03 - Maintenance, Diagnosis

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
Code letters CEPB
Displacement liter 2.480
Output kW
at
RPM
265/5700 to 6300
Torque Nm
at
RPM
465/1750 to5300
Bore dia.
mm
82.5
Stroke mm 92.8
Compression ratio 10
RON 98 1)
Fuel injection and igni‐
tion system
Bosch Motronic
Ignition sequence 1-2-4-5-3
Knock control 2 Sensors
Turbocharger yes
Exhaust gas recircula‐
tion
no
Exhaust temperature
control
1 Sensors
Charge air cooler yes
Oxygen sensor regula‐
tion
yes
Valves per cylinder 4
Variable intake manifold no
Secondary air injection
(AIR)
no
•1)Super Unleaded RON 95 is also permissible, although with
reduced power.
Code letters CCTA
Displacement liter 1.984
Output kW
at
RPM
147/5100
Torque Nm
at
RPM
280/1700
Bore dia.
mm
82.5
Stroke mm 92.8
Compression ratio 9.6
RON 98 1)
Fuel injection and igni‐
tion system
FSI
Ignition sequence 1-3-4-2
Knock control yes
Turbocharger yes
Exhaust gas recircula‐
tion
no
Variable intake manifold no
Audi TT 2007 ➤
Maintenance Procedures - Edition 08.2011
1. General Information 3

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
Code letters CCTA
Variable valve timing yes
Secondary air injection
(AIR)
no
•1) Unleaded RON 95 is also permissible, although with re‐
duced power.
Code letters BWA BPY
Displace‐
ment
liter 1.984 1.984
Output kW at 1/rpm 147/5100 147/5700
Torque Nm at rpm 280/1800 280/2000
Bore Diameter in
mm
82.5 82.5
Stroke mm 92.8 92.8
Compression ratio 10.3 10.5
RON 98 1) 98 1)
Fuel injection and ignition
system
FSI FSI
Ignition se‐
quence
1-3-4-2 1-3-4-2
Knock control yes yes
Charging yes yes
Exhaust gas recirculation no no
Variable intake manifold no no
Variable valve timing yes yes
Secondary air injection
(AIR)
no no
•1) Unleaded RON 95 is also permissible, although with re‐
duced power.
1.2 Type Plate and VIN
A - Type plate
- It is secured on the right suspension strut tower.
B - Vehicle Identification Number
- It is stamped in the upper wheel housing right longitudinal mem‐
ber near the reservoir.
WAU ZZZ 8J Z 7 A 000 001
Manufacturer
code
Filler charac‐
ter
Type Filler charac‐
ter
Model year
2007
Producing
Factory
Serial number
Vehicle Data Label
The vehicle data label is in the customer's Maintenance booklet
and in the vehicle in the spare wheel recess or on the floor panel.
Audi TT 2007 ➤
Maintenance Procedures - Edition 08.2011
4 Rep. Gr.03 - Maintenance, Diagnosis

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
The label contains the following vehicle data:
1 - Vehicle Identification Number (VIN)
2 - Model identification number/Production control number
3 - Model explanation
4 - Engine output/Emissions standard/Transmission
5 - Engine and transmission codes (no information for certain
countries)
6 - Paint number/interior equipment identification number
7 - Optional equipment identification numbers
8 - Curb weight/Consumption/CO2 emissions (no information for
certain countries)
Engine Code and Engine Identification
Note
The “engine code“ is on the vehicle data label in the Maintenance
booklet and in the spare wheel recess or on the floor panel.
A label with engine code and engine number is also applied to the
toothed belt guard.
4-Cylinder Engines:
Engine number (“engine code“ and “serial number“) is located at
front of engine/transmission connecting point.
6-Cylinder Engines:
The engine number and engine code -arrow- are stamped on the
cylinder block near the vibration damper.
Audi TT 2007 ➤
Maintenance Procedures - Edition 08.2011
1. General Information 5

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
1.3 Raising Vehicle
WARNING
♦ Before driving the vehicle onto a workshop hoist, make
sure there is enough clearance between any low-lying
components and the hoist.
♦ On the Audi TT's and on the S line vehicles, we recom‐
mend using ramps T 40081 if the lift arms on a vehicle
hoist are too thick to prevent damage.
♦ Before driving a vehicle onto a lifting platform it must be
ensured that the vehicle weight does not exceed the per‐
missible lifting capacity of the platform.
♦ Vehicle may only be lifted at points indicated in illustration
in order to avoid damaging vehicle floor pan and to prevent
vehicle from tipping.
♦ Never start engine and engage a gear with vehicle lifted
so long as even one wheel has contact with the floor!
There is a risk of an accident if this is not observed!
♦ If work is to be performed under vehicle it must be sup‐
ported by suitable stands.
Floor Jack
Always use a suitable rubber or wooden block between the jack
and the vehicle.
A floor jack must be attached only at the mounting points depicted
in the illustration.
Do not lift the vehicle at the engine oil pan, transmission, or on
front or rear axles as serious damage may result.
Hoist and Floor Jack Lifting Points
Front:
On the floor longitudinal reinforcement in the area of the marking.
Rear:
On aluminum case part in front of rear axle mounting point
Audi TT 2007 ➤
Maintenance Procedures - Edition 08.2011
6 Rep. Gr.03 - Maintenance, Diagnosis

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
1.4 Tow Starting/Towing
– Attach tow rope or bar only at following eyes:
Front Towing Eyes
– Open cover.
Screw towing eye in by hand and tighten counter-clockwise using
wheel bolt wrench.
Audi TT 2007 ➤
Maintenance Procedures - Edition 08.2011
1. General Information 7

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
Rear Towing Eye
The rear towing eye is located under the bumper cover on the rear
right.
– Screw towing eye in by hand and tighten counter-clockwise
using wheel bolt wrench.
Tow starting or towing vehicle
Note
♦ Tow-ropes or bars should be attached at above mentioned
points only.
♦ The tow-rope should be able to stretch to reduce the risk of
damage to both vehicles. Therefore only ropes of synthetic
material or rope from similarly flexible material should be used.
However it is safer to use a tow bar!
♦ Avoid excessive towing effort and do not jerk. During towing
operations on unsurfaced roads there is always a danger that
the attachment points will be overstressed and damaged.
♦ Vehicle towing should only be done if it is not possible to start
the engine with the starting assist cable.
If the vehicle must ever tow or be towed, observe the following:
♦ Legal regulations concerning towing must be observed.
♦ Both drivers must be familiar with towing procedures. Inex‐
perienced drivers should not attempt to tow start or tow.
♦ When using a tow rope the driver of the towing vehicle must
engage the clutch very gently when moving off and changing
gear.
♦ The driver of the vehicle being towed must ensure that the tow
rope is always taut.
♦ Both vehicles must have the emergency flasher switched on -
if necessary observe any other regulations.
♦ The ignition must be switched on, so that the steering wheel
is not locked and the turn signals, horn, windshield wipers, and
windshield washer system can be operated.
♦ Since the brake booster only works with the engine running,
the brake pedal must be stepped on with substantially more
force when the engine is switched off.
♦ With the engine switched off, the power steering also does not
work, increasing the amount of steering effort.
♦ Without lubricants in the manual transmission and/or auto‐
matic transmissions the car may only be towed with raised
drive wheels.
Important notes concerning tow starting a vehicle:
It is generally recommended not to tow start vehicles. Instead,
jumper cables should be used.
There are several reasons to not tow start:
♦ During tow starting, the risk of an accident occurring is high,
e.g. driving into vehicle towing.
♦ Vehicles with gasoline engines can be damaged by unburned
fuel entering the catalytic converter.
♦ Tow starting of vehicles with automatic transmission is not
possible for technical reasons.
Audi TT 2007 ➤
Maintenance Procedures - Edition 08.2011
8 Rep. Gr.03 - Maintenance, Diagnosis

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
If a vehicle should be tow started at any time, observe the follow‐
ing:
– Before tow starting, push in clutch pedal and hold, and select
gear 2 or 3.
– Switch ignition on.
– When both vehicles are in motion, release the clutch pedal.
– As soon as the engine is started, push in the clutch and take
the car out of gear to avoid running into the towing vehicle.
Note
Vehicles with catalytic converter (gasoline engine only) must not
be started when the catalytic converter is at operating tempera‐
ture and pulling the vehicle over a longer distance of more than
50 m. Otherwise, the vehicle could be damaged by unburned fuel
entering the catalytic converter.
When towing a vehicle with automatic transmission the following
additional points must be observed:
♦ Selector lever must be in the “N“ position.
♦ Do not tow at speeds greater than 30 mph (50 km/h).
♦ The maximum towing distance is 30 miles (50 km).
For longer distances, the front end of the vehicle must be raised.
Reason: With engine switched off, the transmission oil pump does
not work. Therefore the transmission is not sufficiently lubricated
at higher speeds and longer distances.
When towing with a tow truck, the vehicle may only be towed with
raised front wheels.
Reason: With car raised in the back, the driveshafts turn back‐
wards. This would cause the planetary gears in the automatic
transmission to achieve such high RPM that the transmission
would be heavily damaged within a very short time.
Note
If normal towing of the vehicle is not possible, the vehicle must be
transported with a special transporter or trailer. This also applies
to towing distances of over 30 miles (50 km)
1.5 Vehicle Checks during Inspection and
Maintenance
For vehicle checks, we recommend interactive acceptance VAS
5000 and performance test stand V.A.G 1858.
Brakes, Testing
Information for checking brakes on FWD and AWD vehicles is in
the corresponding brake system repair manual.
Performance Check
Perform performance check on performance test stand recom‐
mended by Audi. The corresponding correction factors for auto‐
matic transmissions and AWD are provided in these test stands.
Vehicles with AWD may only be tested on a four-wheel perform‐
ance test stand.
Audi TT 2007 ➤
Maintenance Procedures - Edition 08.2011
1. General Information 9

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
Tachometer Check
With the tachometer test, the vehicle wheels are driven. Vehicles
with AWD may only be tested on a four-wheel test stand.
Shock Absorber Check
Information on testing shock absorbers can be found in the sus‐
pension repair manual.
Audi TT 2007 ➤
Maintenance Procedures - Edition 08.2011
10 Rep. Gr.03 - Maintenance, Diagnosis

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
Audi TT 2007 ➤
Maintenance Procedures - Edition 08.2011
2. Maintenance Procedures 11

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
2 Maintenance Procedures
⇒ “2.1 Strut Tube Cap, Lubricating“, page 13
⇒ “2.3 Battery, Checking Level Using Guided Fault Finding“, page
14
⇒ “2.4 Battery, Checking No Load Voltage before Starting En‐
gine“, page 15
⇒ “2.5 Battery, Check Fluid Level“, page 17
⇒ “2.6 AGM Battery, Checking“, page 19
⇒ “2.7 Battery, Checking Cables for Secure Seating“, page 20
⇒ “2.8 Tires, Checking“, page 20
⇒ “2.9 Brake System, Inspecting for Leaks and Damage“,
page 22
⇒ “2.10 Brake Pads, Checking Thickness“, page 22
⇒ “2.11 Brake Fluid, Checking Depending on Brake Pad Wear“,
page 23
⇒ “2.12 Brake Fluid, Changing“, page 24
⇒ “2.13 Fuel Injector Cleaner G17“, page 27
⇒ “2.14 Key, Check Functionality“, page 28
⇒ “2.15 DTC Memory, Checking“, page 28
⇒ “2.16 Engine Compartment Front Noise Insulation Cover, Re‐
moving and Installing“, page 28
⇒ “2.17 Coolant System, Checking“, page 29
⇒ “2.18 Instrument Cluster, Selecting Language“, page 30
⇒ “2.19 Air Filter, Cleaning Housing and Removing and Installing
Filter“, page 31
⇒ “2.20 Haldex Clutch Oil, Changing“, page 37
⇒ “2.21 Hood Safety Catch, Lubricating“, page 37
⇒ “2.22 Engine Cover, Removing“, page 37
⇒ “2.23 Engine and Engine Compartment from Underneath, In‐
specting for Leaks and Damage“, page 39
⇒ “2.24 Engine Oil, Draining/Extracting and Removing and In‐
stalling Filter“, page 40
⇒ “2.25 Hood Hinge, Lubricating“, page 43
⇒ “2.26 Engine Oil, Filling“, page 43
⇒ “2.27 Engine Oil Level, Checking“, page 44
⇒ “2.28 Navigation Eject Button, Unlocking“, page 44
⇒ “2.29 Radio, Entering Security Code to Activate Anti-Theft Cod‐
ing“, page 44
⇒ “2.30 Road Test“, page 45
⇒ “2.31 Wheel Bolts, Tightening Specifications“, page 46
⇒ “2.32 Tire Pressure Monitoring Display, Adapting“, page 46
⇒ “2.33 Windshield Washer System, Checking and Adjusting
Spray Nozzles“, page 46
⇒ “2.34 Headlamp Washer System, Checking Spray Nozzles“,
page 49
⇒ “2.35 Windshield Wiper Blades, Checking End Position and for
Damage“, page 49
⇒ “2.36 Service Display, Resetting or Adapting“, page 49
⇒ “2.37 Install Fuse for Headlamp Washer System“, page 52
⇒ “2.38 Dust and Pollen Filter, Removing and Installing“,
Audi TT 2007 ➤
Maintenance Procedures - Edition 08.2011
12 Rep. Gr.03 - Maintenance, Diagnosis

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
page 53
⇒ “2.39 Tie Rods, Control Arms, Ball Joint and Driveshafts,
Checking Play, Fit and Sealing Boots“, page 54
⇒ “2.40 Transport Mode, Deactivating using VAS 5051/5052“,
page 54
⇒ “2.41 Door Arrester, Door Hinge and Lock Cylinder, Lubricat‐
ing“, page 55
⇒ “2.42 Transport Protection, Removing Front and Rear Suspen‐
sion Strut Protectors“, page 56
⇒ “2.43 Underbody Protection, Inspecting for Damage“,
page 56
⇒ “2.44 Plenum Chamber Water Drain, Checking and Cleaning“,
page 56
⇒ “2.45 Factory-Equipped Winter Tires“, page 56
⇒ “2.46 Clock, Setting“, page 57
⇒ “2.47 Spark Plugs, Removing and Installing“, page 57
2.1 Strut Tube Cap, Lubricating
Special tools and workshop equipment required
♦ Lubricant G 000 405 A2
♦ Brush
Audi TT 2007 ➤
Maintenance Procedures - Edition 08.2011
2. Maintenance Procedures 13

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
Coat the plastic cap on the strut tube on the contact surface
-arrow- with lubricant G 000 405 A2.
Note
After removing the spring clip and the spacer and lubricating the
strut tube cap, make sure that the boot in the strut bearing is in
the correct position as with the shock absorber tube.
2.2 Measured Values Block 32, Reading
Note
Applies to certain countries only. Refer to the Maintenance table.
– Follow these steps in sequential order.
♦ Connect VAS 5051/5052
♦ On Board Diagnostic
♦ Engine electronics
♦ Measured value blocks
♦ Select measured values block 32
♦ Display field 2 (4-cylinder engines)
♦ Display field 2 and 4 (V6 and V8 engines)
Note
If the values deviate by > 15%, then the Fuel Injector Cleaner G17,
refer to ⇒ “2.13 Fuel Injector Cleaner G17“, page 27 must be
increased by a factor of 4.
2.3 Battery, Checking Level Using Guided
Fault Finding
– Follow these steps in sequential order.
Audi TT 2007 ➤
Maintenance Procedures - Edition 08.2011
14 Rep. Gr.03 - Maintenance, Diagnosis

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
♦ Connect VAS 5051/5052
♦ Guided Fault Finding or Guided Functions
♦ Select brand and type.
♦ Service Work
♦ Check the battery -A-
♦ Continue following the instructions.
♦ Send the diagnostic protocol online.
Note
If tester display shows charge or replace battery. Refer to ⇒
Electrical Equipment; Rep. Gr. 27 ; Removal and Installation
2.4 Battery, Checking No Load Voltage be‐
fore Starting Engine
Note
For delivery inspection only for vehicles without battery monitor‐
ing control module -J367- or energy management control module
-J644- .
Special tools and workshop equipment required
♦ Portable multimeter -V.A.G 1526C-
– Make sure the following points are observed - otherwise a
correct measurement cannot be guaranteed.
Audi TT 2007 ➤
Maintenance Procedures - Edition 08.2011
2. Maintenance Procedures 15

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
♦ Battery must not be loaded by connected electrical compo‐
nents for at least 12 hours before testing.
♦ The batter must not be charged for at least 12 hours before
measuring.
Remove rear molded insert -3- for tools under luggage compart‐
ment floor cover.
– Remove battery compartment cover -arrow-.
– Remove molded insert under battery.
Audi TT 2007 ➤
Maintenance Procedures - Edition 08.2011
16 Rep. Gr.03 - Maintenance, Diagnosis
