Audibax BMG20 User manual

Professional Condenser Microphone
Professional
Conference Microphone

Professional Gooseneck Conference Microphone
The gooseneck microphones are suitable for boardrooms and other sites
where aesthetics are important. Their high sensitivity and broad frequency
range make them suitable for recording, as well as sound reinforcement
applications.
Features
●Low profile, aesthetic design
●Choice of red color indicator or light ring
●Wide dynamic range and smooth frequency response
1.Follow signs "+","-", batteries are installed correctly, a nd c onn ect the
audio output line.
2.First, the amplifier volume is controlled in the "0" position. Then turn on
the amplifier and the microphone, adjust the volume slowly until achieve
the best.
3.The best effects of pickup is away from the microphone head 30cm.
How to operate:
1.Microphone head should not be toward speakers, in order to avoid howling.
2.Don't adjust the volume too large, in order to avoid feedback howling.
3.If you don't use the microphone for a long time, remove the batteries to
prevent the battery fluid corrosion microphone.
Note:
Pro Conference Microphone Parameters
●Capsule Type: Condense
●Frequency Response: 40Hz-16KHz
●Polar Pattern: cardioid
●Output Impedance: 75Ω
●Sensitivity: -40dB±2dB
●Power supply: DC3V/ Phantom 48V automatically convert
●Reference sound-receiving distance: 50cm
●Cable: 7m dual-core, female XLR + the public XLR
●Battery: 24 hours（AAA battery）
●Output direction: balance, seat lam，tube lights
●Switch: electronic touch switch
●Configuration: microphone, cable, wind sponge, manual,
certificate, warranty card, conversion plug
