Audio Authority 1362 User manual

User Manual
Model 1362
Composite Video to
YPbPr / VGA
Video Converter
Model 1362
www.audioauthority.com
Composite Video to
YPbPr / VGA Converter

2
3
Table Of Contents
1.0 Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . 3
2.0 Specications . . . . . . . . . . . . . . . . . . . . . . . . . 5
3.0 Checking Package Contents . . . . . . . . . . . . . . . . . 6
4.0 Connecting the Hardware . . . . . . . . . . . . . . . . . . 6
5.0 Operating The Unit . . . . . . . . . . . . . . . . . . . . . . 7
6.0 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . 10
7.0 Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . 11
8.0 Regulatory Compliance. . . . . . . . . . . . . . . . . . . . 12
9.0 Contact Information . . . . . . . . . . . . . . . . . . . . . 12

2
3
1.0 INTRODUCTION
Thank you for purchasing this 1362 Video Converter from Audio
Authority. The 1362 has many uses, but the vital need it answers is
in a mixed signal distribution system. Some high denition signal
distribution systems include one or more standard denition sources.
To distribute these signals to HDTVs, a quality scaler is required.
Model 1362 converts a standard analog NTSC or PAL video signal
to high denition component video (YPbPr). Input may be either
composite, S-Video, standard denition component (YCbCr), or RGsB
format. Output may be YPbPr or RGBHV.
Audio Authority also offers an extensive line of audio and video
switchers, converters and distribution amps (splitters) available for
purchase online at www.audioauthority.com.
1.1 Liability Statement
Every effort has been made to ensure that this product is free of
defects. Audio Authority cannot be held liable for the use of this
hardware or any direct or indirect consequential damages arising
from its use. It is the responsibility of the user of the hardware
to check that it is suitable for his/her requirements and that it is
installed correctly. All rights reserved. No parts of this manual may
be reproduced or transmitted by any form or means electronic
or mechanical, including photocopying, recording, or by any
information storage or retrieval system without the written consent
of the publisher.
Audio Authority reserves the right to revise any of its hardware and
software following its policy to modify and/or improve its products
where necessary or desirable. This statement does not affect the
legal rights of the user in any way.
All third party trademarks and copyrights are recognized. The Audio
Authority logo and Double A logo are the registered Trademarks
of Audio Authority. All other trademarks are the property of their
respective holders.

4
5
1.2 Features
• Composite video, S-Video or YCbCr inputs to PC/HD outputs
• PC Resolutions to 1280x1024
• All HDTV Progressive Scan resolutions
• 32Mb frame memory
• Integral picture adjustments
• On screen display for setup and adjustment
• Locking DC power connector for reliability
1.3 Getting the Best Results
There are many factors affecting the quality of results when scaling
video signals. Some basic precautions will ensure the best possible
performance from your 1362 Video Scaler.
Output Display Device
The quality of the output signal will depend largely upon the
type and quality of display device used. For instance, some video
projectors perform better than others.
Using Compatible Resolutions
Set the output resolution of the 1362 to the resolution and refresh
rate most compatible with the display device. This allows the 1362
to do most of the work, which usually results in a superior picture.
The 1362 HDTV output resolutions include 480p, 720p, and 1080i* at
50Hz or 60Hz.
Distance Between The 1362 And The Display Device
This plays a major role in the nal result. Long distances are possible,
but special measures should be taken in order to avoid cable losses.
These include using high quality (coax-type) VGA cables. Line
ampliers may also be necessary.
Output Connection Cables
Low quality cables are susceptible to interference. They degrade
signal quality due to poor matching and cause elevated noise levels.
Therefore, cables should be of the best quality. Coax-type computer
cables are recommended because of their superior internal shielding
characteristics.
Interference From Nearby Electrical Devices
These can have an adverse effect on signal quality. For example, an
older computer monitor often emits very high electromagnetic elds
that can interfere with the performance of video equipment in its
proximity.

4
5
PC Resolutions Vert Rate Format Scan Type
VGA
SVGA
XGA
WXGA
SXGA
UXGA
640x480
800x600
1024x768
1280x768
1280x1024
1600X1200
50,60,72,75,85 Hz
50,60,72,75,85 Hz
50,60,70,75,85 Hz
50,60 Hz
50,60 Hz
60 Hz
RGBHV
RGBHV
RGBHV
RGBHV
RGBHV
RGBHV
Progressive
Progressive
Progressive
Progressive
Progressive
Progressive
HDTV Resolutions Vert Rate Format Scan Type
480p
576p
720p
1080i*
1080p
720x480
720x576
1280x720
1920x1080
1920x1080
50,60Hz
50,60Hz
50,60Hz
50,60Hz
50,60Hz
YPbPr, RGBHV
YPbPr, RGBHV
YPbPr, RGBHV
YPbPr, RGBHV
YPbPr, RGBHV
Progressive
Progressive
Progressive
Interlaced*
Progressive
* The 1080i Output is actually a doubled 540p signal. It will appear as 1080i on most displays, however, it
is not technically 1080i signal format.
2.0 SPECIFICATIONS
Input Format Composite Video, S-Video or YUV (Y,R-Y,B-Y)
Input Signal Levels Composite Video @ 1V p-p, 75Ω S-Video @Y 1V p-p, C 0.7 V p-p, 75Ω Pb, B-Y,
Pr, R-Y @ 0.7V p-p, 75Ω
Output Format RGBHV, YPbPr
Output Signal Levels RGB @ 0.7V p-p, 75Ω. H&V Sync @ 3-5V p-p, TTL
Y @ 1V p-p, 75Ω. Pb, Pr @ 0.7V p-p, 75Ω
Input Connectors Composite Video via RCA, S-Video via 4 Pin DIN, YUV via 8-pin Mini-DIN and
breakout cable
Output Connector HD15
Control Front Panel Buttons
Information Display On Screen Display
Video Adjustments Brightness, Contrast, Color, Tint, Sharpness, H&V Peaking
Weight 280 g (0.62 lbs)
Dimensions–HxWxD 30x133x76mm (1.2”x5.25”x3”)
Environmental Operating Temperature 0° to +50° C (+32° to +122° F)
Operating Humidity 10% to 90%, Non-condensing
Storage Temperature -10° to +60° C (+14° to +140° F)
Storage Humidity 10% to 90%, Non-condensing
Power Source 100~240VAC to [email protected] In-Plug Switching Adapter
Accessories Included Power adapter, composite video cable, 8 pin Mini DIN to 3 RCA cable, 6 ft
HD15M cable, user manual
Output Signal Specications

6
7
3.0 CHECKING PACKAGE CONTENTS
Before attempting to use this unit, please check the packaging and
make certain the following items are contained in the shipping
carton:
• Model 1362 scaler unit
• 100~240VAC AC/DC power adapter
• Composite video input cable
• 8 Pin Mini-DIN to 3 RCA cable
• 6 ft HD15M cable (a.k.a. VGA to VGA)
• User manual
Note: Please keep the original packing material in case the unit
ever needs to be returned. If you nd any items are missing,
contact Audio Authority immediately. Have the model number,
serial number and invoice available for reference when you call.
4.0 CONNECTING THE HARDWARE
The rst step is to connect a video source to one of the inputs of
the 1362 and to connect its output to a display device. The drawing
of the unit shows the location of the inputs, output and power
connectors.
4.1 Connecting an Input
The 1362 can accept composite Video, S-Video or YCbCr inputs.
Composite video is connected to the scaler via the RCA connector, S-
video connects via the 4-Pin Mini-DIN connector and YCbCr connects
via the 8-Pin Mini-DIN connector using the 3-RCA to 8-Pin Mini-DIN
cable provided.
Proper signal levels are very important to the operation of this
product so make sure your inputs are of the levels specied on page
4. If the unit does not seem to function correctly after all instructions
in this manual are followed, and the unit has power, the most likely
cause of the problem is high or low signal levels or the use of the
wrong input cable. Be sure to follow instructions in 5.0.
YCbCr
IN
SV
IN
CV
IN
DC 5V
PC/HD OUT 480p XGA
MENU

6
7
4.2 Connecting the Output
The 1362 scaler can output analog RGBHV or YPbPr formats up to
UXGA and 1080p. RGBHA and YPbPr are both available on the HD-
15 output connector. When a PC (RGBHV) output is used, select an
HD-15 to HD-15 cable to connect the 1362 output to the destination
device. When an HDTV (YPbPr) output is used, select an HD-15 to 3-
RCA cable to connect the 1362 output to the destination device.
YCbCr
IN
SV
IN
CV
IN
DC 5V
PC/HD OUT 480p XGA
MENU
4.3 Connecting Power to the Unit
The 1362 is shipped with an in-plug power adapter to convert
100~240VAC@50-60Hz to 5VDC. Connect the DC output cord from
the power adapter to the back of the unit and then plug the power
adapter into an AC receptacle; the power LED indicator illuminates.
5.0 OPERATING THE UNIT
The 1362 does not automatically sense the input you have
connected. You must identify the active input by pressing the + key
before you activate the menu. Power all components in the signal
path and press the + key until the correct input name appears in the
upper right corner of the screen: composite, S-video, YCbCr, RGsB.
5.1 Settings
The 1362 is controlled via three buttons with status indicated by OSD
(On Screen Display). See the menu map on page 9.
• Menu Button: This button displays the menu options via the OSD
on the display device connected to the output.
• + and – Buttons: These buttons allow navigation within the menu
and adjustments of the parameters available.
• XGA Reset: Simultaneously pressing the – and + buttons returns
settings to factory defaults and sets the output to XGA for PC
monitors.
• 480p Reset: Simultaneously depressing the menu and – buttons
returns settings to factory defaults and sets the output to 480p for
HDTV displays.

8
9
5.2 Menu Map
Level 1 Options Level 2 Options Description
Picture Adjust Brightness Adjust image brightness
Contrast Adjust image contrast
Color Adjust image color
Tint Adjust image tint
H. Peaking Filter NA
Sharpness Adjust image sharpness
V. Peaking Gain NA
Reset Reset to factory defaults
Exit Return to main menu
Display Setup Timing Adjust output resolution
C S C Adjust output format (YPbPr/RGBHV)
Exit Return to main menu
Advanced Setup Film Mode Select between auto or off for lm
detection
OSD Display Turn On Screen Display on or off
No Signal Select blue or black screen when no
signal is detected
Exit Return to main menu
System Information Input Mode Displays current input format
Display Timing Displays current output resolution
Exit Return to main menu
Pressing the menu button displays the main
menu. Move the cursor to the desired setup
option by using the + and – buttons. When
you reach the option you desire, press the
menu button again to select that option.
Once the desired option is reached and selected, a new menu
appears; use the + and – keys to select the parameter you wish to
change or adjust.
Picture Adjust
Display Setup
Advanced Setup
System Information
Exit

8
9
5.3 Setup Example
If you select the rst item on the main
menu, Picture Adjust, a secondary menu
shows these items:
If you want to change the color level for
example, you would use the + and – keys, to
navigate to that Item on the menu and press
the menu key again to select that option.
When color is selected, a sub-menu for the adjustment appears:
Color 48
Use the + and – buttons to increase or decrease the value of the
setting. Press menu again to leave the setting. Move the arrow to
exit and press menu/enter again to exit.
5.4 Display Setup
When this is selected, an output resolution sub-menu appears:
PC HDTV
UXGA 1600x1200@50/60Hz 720p-YPbPr 1280x720@50/60Hz
SXGA 1280x1024@50/60Hz 576p-YPbPr 720x576@50/60Hz
WXGA 1280x768@50/60Hz 480p-YPbPr 720x480@50/60Hz
XGA 1024x768@50/60/70/75/85Hz 1080i-YPbPr 1920x1080@50/60Hz
SVGA 800x600@60/72/75/85Hz 1080p-YPbPr 1920x1080@50/60Hz
VGA 640x480@60/72/75/85Hz (1080i is actually 540p doubled - see Note on Page 4)
Use the + and – buttons to choose the desired PC or HDTV output
resolution from the available selections in the sub-menu.
5.5 Advanced Setup
Advanced setup allows you to turn off the Film Mode (3:2 pull
down), turn off the OSD (On Screen Display), and set the “no signal”
display to either blue or black.
5.6 System Information
When this is selected, the OSD allows changes to be made to the
1362’s current output resolution and vertical refresh rate.
Brightness
Contrast
Color
Tint
H Peaking Filter
Sharpness
V Peaking Filter
Reset
Exit

10
11
6.0 TROUBLESHOOTING
• First check for faulty cables or bad connections.
• If you see no video image, the 1362 may be set to the wrong
input. If it is on, turn off the OSD menu (left corner) by pressing
the menu button, or cycle power on the 1362. Press the + button
until you see a picture on the display (you should see the input
menu in the upper right of the display). If you cannot see the input
menu, try switching picture modes, or try a different 1362 output
resolution such as 720p that may better t your screen.
• If you still see no video image, simultaneously press menu and –
buttons to reset the 1362 to 480p (for HDTV). If your display device
is a PC monitor, reset to XGA by pressing the + and – buttons.
• If all connections are correct, the output setting is most likely
the problem. Make sure the display is capable of accepting the
resolution and refresh rate selected and make sure the output
format selected (RGB or YPbPr) is appropriate for the type of cable
being used at the output.
If none of these measures solve the problem, call Audio Authority
Technical Support at 800-322-8346 Monday through Friday, 8:30am
to 5:00 pm EST, or e-mail [e-mail].

10
11
7.0 LIMITED WARRANTY
Should any consumer product from Audio Authority fail due to
defects in materials or workmanship within one year from the date
of the original sale to the end-user, Audio Authority guarantees that
we will replace the defective product at no cost. Freight charges for
the replacement unit will be paid by Audio Authority (Ground service
only). A copy of the invoice showing the item number and date of
purchase (proof-of-purchase) must be submitted with the defective
unit to constitute a valid in-warranty claim.
Units that fail after the warranty period has expired may be returned
to the factory for repair at a nominal charge, if not damaged beyond
the point of repair. All freight charges for out-of-warranty returns
for repair are the responsibility of the customer. Units returned for
repair must have a Return Authorization Number assigned by the
factory.
This is a limited warranty and is not applicable for products which,
in our opinion, have been damaged, altered, abused, misused, or
improperly installed. Audio Authority makes no other warranties
either expressed or implied, including limitation warranties as to
merchantability or tness for a particular purpose. Additionally,
there are no allowances or credits available for service work or
installation performed in the eld by the end user.
Warranty Service Procedures
If you suspect a product defect, contact Audio Authority’s Technical
Service Department at 800-322-8346 or 859-233-4599 for assistance in
verifying the problem. If a defect or potential defect is suspected, a
replacement unit will be shipped immediately on a defect-exchange
basis and a Return Authorization Number will be issued for the
return of the defective product. Replacement units are sent out at
the Manufacturer’s Suggested Retail Price which is debited to the
Customer’s Credit Card at the time of shipment. Once we receive
the defective unit back at the factory, it will be evaluated under the
conditions of this warranty and if found to be in-warranty, a full
credit will be issued to the Customer’s Credit Card. Return freight
charges for the defective unit are the customer’s responsibility.
Please contact our Technical Service Department for complete details
concerning all in and out of warranty service matters.
We appreciate your condence in our products and services and will
always strive to meet or exceed your needs.

8.0 REGULATORY COMPLIANCE
This product complies with the relevant standards for FCC and CE
approval.
The Power Adaptor/Supply has been tested for compliance with UL,
CSA & CE Regulations.
9.0 CONTACT INFORMATION
Should you have questions or require assistance with this product in
areas not covered by this manual, please contact Audio Authority
using the information below.
Audio Authority Technical Service
800-322-8346 M-F 8:30 AM to 5:00 PM, EST
International: 859-233-4599 Fax: [phone]
Send email to: [e-mail]
Audio Authority Corporation
2048 Mercer Road
Lexington, Kentucky 40511-1071
USA
2048 Mercer Road, Lexington, Kentucky 40511-1071
Phone: [phone] • Fax: [phone]
Customer Toll-Free USA & Canada: 800-322-8346
Website: http://www.audioauthority.com
752-524
2/08
