1.0 INTRODUCTION
Thank you for purchasing a Model C-1071 BlueBeam from Audio Authority.
The BlueBeam is designed to allow a Sony Playstation 3 to be integrated into
an IR remote control system. The PS3 accepts only Bluetooth commands, but
the BlueBeam allows any universal IR remote (capable of learning the PS3
commands) to control the PS3. This guide focusses on the Logitech Harmony
remote, but other learning remotes or home control systems may be used.
Audio Authority offers an extensive line of audio and video switchers,
converters, distribution amps and extenders available for purchase online at
www.audioauthority.com or through authorized dealers.
1.1 FEATURES
•
Allows full control of DVD/Blu-ray playback and power on/off
•
Infrared optical receiver and wired IR input (optional IR receiver available)
•
May be powered via two AA batteries (included), USB connection to the PS3, or
an optional 9-12V power adapter (ordered separately, Model 571-013)
• Automatic low-power mode for extended battery life
•
Low battery indicator
•
Easy battery change by removing two o-rings (no tools necessary)
•
Senses PS3 power on and off via USB connection
•
Advanced customization possible using PC software via a USB interface
•
Configurable IR device code avoids conflicts with other Sony DVD players
•
Custom macro capability for power off, etc.
•
Firmware upgrade capable including Bluetooth firmware upgrades
•
Activity indicator LED for user feedback
•
Ultra-compact case design allows small footprint and easy battery change
2.0 CHECKING PACKAGE CONTENTS
Before connecting the C-1071, please make certain the following items are in the
shipping carton:
•
C-1071 BlueBeam converter
•
Two AA batteries
•
User manual
3.0 INSTALLATION
The installation procedure described in this manual is for preparing a Logitech
Harmony remote control for use with the Sony PlayStation 3. Other remotes may
also be used with a similar setup procedure.
Note: Please retain the original packing material
in case you need to return the unit. If you find
any items are missing, contact Audio Authority
immediately. Have the model number and
invoice available for reference when you call.

5
3.1 CONFIGURING THE IR REMOTE CONTROL
Using the Logitech Harmony software:
•
Select the DEVICES tab and then ADD DEVICE.
•
Select GAME CONSOLE > GAME CONSOLE (WITH DVD) from the device
selections box.
• Select AUDIO AUTHORITY from the manufacturer selections box.
•
Enter the name “BLUEBEAM” in the model name box.
•
Select NEXT and NEXT to finish. For information on how to add the BlueBeam
to Activities in the Harmony Remote, see the Harmony manual.
3.2 PAIRING THE BLUEBEAM WITH THE PS3
•
Turn off the BlueBeam by removing the batteries and disconnecting the power
supply and/or USB cable.
•
Turn on the PS3 system and use the PS3 controller to select the following
option: SETTINGS > ACCESSORY SETTINGS > REGISTER BD REMOTE.
•
Set the BlueBeam within 30 feet of the PS3 and power on the BlueBeam (insert
batteries, connect power supply, or USB connection to power).
•
When power is applied, the red LED starts flashing to indicate that the
BlueBeam is ready to be paired with the PS3. Make sure the BlueBeam is the
actively selected device on the Harmony IR remote control. Press and hold the
“2” button on the remote (do this within 20 seconds of BlueBeam power on).
Hold the 2 button down until the PS3 changes screen to REGISTERING.
•
The BlueBeam is now paired with the PS3 and ready to convert IR signals to
Bluetooth.
Which power source is best for my installation?
The BlueBeam can be powered from the PS3 USB port, but the PS3 does
not supply power to its USB port when it is powered off. Therefore you will
not be able to turn on the PS3 from your IR remote control if it does not have
an additional power source. If you do not wish to use an external DC adapter
(Model 571-013), use two AA batteries to power the BlueBeam when the PS3
is off. The BlueBeam will automatically draw power from the USB port when
the PS3 is on. This way you can control the PS3 as normal and you do not
need an external DC adapter. Also battery life will be increased since power
is supplied by the USB port whenever the PS3 is turned on.
Installing or changing batteries
Batteries are not required, but may be important for best functionality (see
above). To change or remove the batteries, remove the two o-rings, lift the
top cover (no tools are required) and lift the batteries from the battery-holder.
Replace them with two AA alkaline batteries, or use external power as
described above.

6
4.0 USING AN EXTERNAL INFRARED RECEIVER
Order the special IR receiver from Audio Authority to work with the BlueBeam if
extended IR is required. Other IR receivers do not function with the BlueBeam.
5.0 USING BLUEBEAM SOFTWARE
In order to use the BlueBeam software, the BlueBeam must be connected to a
PC using a USB 2.0 cable with a mini-USB connector on the BlueBeam end. The
BlueBeam uses existing Windows drivers and does not require any additional
drivers to be installed before using the software.
•
If any changes are made to the configuration, they need to be written to the
device by pressing the “SAVE” button.
•
To restore factory settings select the menu option OPTIONS > RESTORE
DEFAULT SETTINGS. This will erase all custom settings and restore default
values, including any custom macros which may have been defined.
5.1 SETTINGS TAB
Enable status LED
on IR activity
Selects if the LED should light up when receiving valid
IR commands from an IR remote
Flash status LED
on low battery level
Selects if the LED should flash briefly to indicate low
battery level
IR receiver
(Internal / External)
Selects if IR should be received through the internal
IR receiver, OR through an externally connected IR
receiver (both cannot be active at once). If an external
IR receiver is used BlueBeam must be powered by
USB or DC adaptor, not batteries.

7
5.2 MACROS TAB
The macros tab allows the user to define
10 custom macros, which will execute
a sequence of commands by activating
only one IR command. The power-off
macro is a predefined macro, which will
execute a power-off sequence which will
power off the PS3 by pressing only one button on the IR remote.
Select macro
Selects which of the 10 macros to edit
Command
Selects which IR command to execute
Duration
Specifies the time in milliseconds to activate the current
command
Pause
Specifies the time in milliseconds to pause until the
next command should be sent
Default
The default button resets the currently selected macro
to its default values
5.3 IR DEVICE CODE TAB
By default the BlueBeam responds to
IR codes from the device code Sony
DVD1a, but this can be changed to
any Sony device code. For ease, it is
possible to select the most commonly
used device codes directly from the
selection box. Make sure that you
have a remote that is able to transmit
the selected codes, or the BlueBeam
will not respond.
If you have an existing Sony DVD
player that conflicts with the default BlueBeam device code, change the device
code from “DVD1a” to “DVD2a” in the selection box and press “Save”. In the
Harmony Remote software, add a new device with the model name “BlueBeam
DVD2a” to allow control of a BlueBeam with the IR device code DVD2a.
A custom IR device code can be entered by selecting the “Custom” entry from
the selection box, and entering the code manually.
5.4 INSTALL MODULE TAB
Allows for future features to be downloaded as a firmware upgrade.

8
6.0 TROUBLESHOOTING GUIDE
BlueBeam will not pair with my PS3
The BlueBeam must be within 30 feet of the PS3 for operation. Make sure all
power supplies are completely removed (DC adapter, USB and batteries inside
the BlueBeam case) before trying to pair the BlueBeam and PS3. Also make sure
that the PS3 screen says “Press ENTER+START to begin pairing”.
When all power sources are removed the BlueBeam should start flashing for
20 seconds when connecting either: DC adaptor, USB, or batteries. Within 20
seconds (while the LED flashes) press and hold the ‘2’ button on the Harmony
remote, the LED on the BlueBeam should be constant on until the PS3 says
“Registering”. If you let go of the ‘2’ button before the PS3 has registered the
BlueBeam, you must start from the beginning by removing power from the
BlueBeam.
If the above does not work try the following:
•
Change the remote control batteries.
•
Power the BlueBeam directly from a DC adapter or USB.
•
Make sure the BlueBeam device is selected as the active device in the
Universal Remote Control.
•
Hold the remote control in front of the IR window of the BlueBeam with
approximate three inches distance while holding the ‘2’ button.
BlueBeam con icts with my existing Sony DVD player
If you have an existing Sony DVD player that conflicts with the default BlueBeam
IR device code, the BlueBeam can be configured to respond to another IR device
code. In order to do this, connect the BlueBeam to a PC using a USB cable
with a mini-USB connector. Open the BlueBeam software and select the “IR
device code” tab, change the device code from “DVD1a” to “DVD2a” (or other)
in the selection box and press “Save”. In the Harmony Remote software, add
a new device with the model name “BLUEBEAM DVD2a” to allow control of a
BlueBeam with the IR device code DVD2a.
Logitech Harmony selection:
Device: Game Console > Game Console (With DVD)
Manufacturer: Audio Authority
Model: BLUEBEAM DVD2a

9
BlueBeam does not respond to any IR remote commands
•
Make sure that power is supplied to the BlueBeam either by batteries, (check
battery charge) DC adapter, or USB connection.
•
Using an external IR receiver: the BlueBeam must be set up via the BlueBeam
PC software to activate the external IR port (the internal IR receiver is turned
off). Call Audio Authority for the wired IR jack pin-out.
•
Using built-in IR receiver: the BlueBeam PC software must be set to INTERNAL
IR (the default setting) if the front panel IR window is to be used. The IR jack is
inactive under this setting.
•
Make sure that the IR device code specified in the BlueBeam software matches
the IR remote control used. Try loading the factory settings in the BlueBeam
software, to reset all settings to default.
•
If using a Logitech Harmony or other universal remote control, make sure the
BlueBeam device is selected as the currently activated device.
If problems persist, contact the Audio Authority Technical Support department via
email: [e-mail], or call 800-322-8346 (US and Canada) or
859-233-4599.
6.0 SPECIFICATIONS
Dimensions
Unit: 85x45x34mm (3.3x1.8x1.3 inch), Packaging:
112x69x37mm (4.4x2.7x1.5 inch)
Weight
Unit: 53g (1.87oz), Gross: 121g (4.28oz)
Temperature Range
0° - 45° Celcius
Relative Humidity
15% - 95% Non condensing
Placement
Do not place in direct sunlight
Optional DC Power Supply
9-12Vdc, min. 100mA (Audio Authority Part# 571-013)
Batteries
2 x AA alkaline (LR6) standard batteries (included)
Expected Battery Life
6-12 months of normal use. (Expected battery lifetime
is approximate. Actual battery life depends on battery
type, model, usage scenarios etc.)
PC System Requirements
Windows 2000, Windows XP, Windows Vista (32 and
64bit) or later
Min. 2MB free hard disk space
Min. 32MB free memory
Min. 1 free USB 1.1 or 2.0 port

10
7.0 LIMITED WARRANTY
If any consumer product from Audio Authority fails due to defects in materials
or workmanship within one year from the date of the original sale to the end-
user, Audio Authority guarantees that we will replace the defective product at no
cost. Freight charges for the replacement unit will be paid by Audio Authority
(ground service only). A copy of the invoice showing the item number and date
of purchase (proof-of-purchase) must be submitted with the defective unit to
constitute a valid in-warranty claim.
Units that fail after the warranty period has expired may be returned to the factory
for repair at a nominal charge, if not damaged beyond the point of repair. All
freight charges for out-of-warranty returns for repair are the responsibility of the
customer. Units returned for repair must have a Return Authorization Number
assigned by the factory.
This is a limited warranty and is not applicable for products which, in our opinion,
have been damaged, altered, abused, misused, or improperly installed. Audio
Authority makes no other warranties either expressed or implied, including
limitation warranties as to merchantability or fitness for a particular purpose.
Additionally, there are no allowances or credits available for service work or
installation performed in the field by the end user.
7.1 WARRANTY SERVICE PROCEDURES
If you suspect a product defect, contact Audio Authority’s Technical Service
Department at 800-322-8346 or 859-233-4599 for assistance in verifying the
problem. If a defect or potential defect is suspected, a replacement unit will be
shipped immediately on a defect-exchange basis and a Return Authorization
Number will be issued for the return of the defective product. Replacement units
are sent out at the Manufacturer’s Suggested Retail Price which is debited to the
Customer’s Credit Card at the time of shipment. Once we receive the defective
unit back at the factory, it will be evaluated under the conditions of this warranty
and if found to be in-warranty, a full credit will be issued to the Customer’s
Credit Card. Return freight charges for the defective unit are the customer’s
responsibility. Please contact our Technical Service Department for complete
details concerning all in and out of warranty service matters.
We appreciate your confidence in our products and services and will always
strive to meet or exceed your needs.

11
8.0 REGULATORY COMPLIANCE
The C-1071 BlueBeam has been tested for compliance with CE and FCC
rules and regulations. The Power Adaptor/Supply included has been tested for
compliance with UL, CUL, CE, PSE, and GS regulations and guidelines. This
product and its power supply are RoHS compliant.
9.0 CONTACT INFORMATION
If you have questions or require assistance with this product in areas not covered
by this manual, please contact Audio Authority using the information below.
Audio Authority Technical Service
800-322-8346 M-F 8:30 AM to 5:00 PM, EST
International: 859-233-4599 Fax: [phone]
Send email to: [e-mail]
Audio Authority Corporation
2048 Mercer Road
Lexington, Kentucky 40511-1071
USA

2048 Mercer Road, Lexington, Kentucky 40511-1071
Phone: [phone] • Fax: [phone]
Customer Toll-Free USA & Canada: 800-322-8346
www.audioauthority.com
E-088
3/09
