Audio Authority IR Converter C-1024A User manual

The Model C-1024A makes it possible for multiple
BOSE sound and video components to respond to the
commands issued by a single Pronto®or Harmony 880
learning remote control. Small enough to be easily hidden, the C‑1024 is
designed for placement behind the video display in the home theater room. Only the
small IR sensor remains visible near the front of the display where it receives the remote
control commands. System control is achieved through a serial jack connection from the
C‑1024A to the rear panel of the LIFESTYLE®system. The C‑1024 is compatible with the
Bose music center models LIFESTYLE 20, 25 and 30 and the MRI LIFESTYLE 40 and 50.
This one-of-a kind converter allows
a compatible learning IR remote to
communicate with Bose Lifestyle systems
IR Converter for Bose®Lifestyle®
and MRI Systems
SPECIFICATIONS:
Model Number:
IR Input Connectors:
TTL Output Connector:
RS-232 Output Connector:
IR Input Pinout (shaft, ring, tip):
Data Pinout (shaft, ring, tip):
2. 5 x 5 x 1.1
One Year Replacement
12 volts DC
FCC
IR receiver, power supply, 3.5mm cord, Manual
Size (H x W x D):
Warranty:
Power Requirements:
Regulatory Approvals:
Accessories Included:
C‑1024A
(2) 3.5mm
3.5mm
3.5mm
ground, data, +5V
ground, data out, data in
Remote not
included
Bose and LifeStyle are trademarks of Bose Corporation.
C-1024 Home
Theater Controller
Back of Music Center or MRI
SERIAL
DATA
IR SENSOR
SERIAL DATA
CABLE (TTL)
TV
POWER
Included accessories
Product Focus
Model C-1024A
2048 Mercer Road, Lexington, KY 40511‑1071 USA
Phone: [phone] • Fax: [phone]
Customer Toll‑Free USA & Canada: 800‑322‑8346
www.audioauthority.com
EXPERT AUDIO/VIDEO SOLUTIONS SINCE 1976
10/09
