Audio Technica Engineered Sound AT845R User manual

Description
The AT845R is a wide-range condenser
microphone with an omnidirectional polar pattern.
It is designed for unobtrusive table, ceiling or
panel-mounted applications for high-quality
sound reinforcement, teleconferencing, profes-
sional recording, television and other demanding
sound pickup applications.
The AT847R is a similar microphone, with a
unidirectional polar pattern. Positioning a properly
designed miniature unidirectional microphone
centrally on a large, flat, unobstructed surface
yields several distinct advantages. The directivity
factor is greatly increased over a comparable
omnidirectional microphone, thus promoting
enhanced gain before feedback and further
suppressing ambient noise. Sensitivity is increased
for improved signal-to-noise ratio. Phase distortion
due to reflected sound energy from the boundary
itself is eliminated.
Both microphones require 9V to 52V DC
phantom power for operation.The microphones
are enclosed in a heavy-duty die-cast case and
protected by two layers of heavy perforated steel.
The low-profile housing has a low-reflectance
black finish. The microphones are also available
in white, as AT845RW and AT847RW. Isolators
are included with each microphone for applications
where mechanical isolation from the mounting
surface is required.
Installation and Operation
Output is low impedance balanced.The bal-
anced signal appears across Pins 2 and 3, while
the ground (shield) connection is Pin 1. Output is
phased so that positive acoustic pressure produces
positive voltage at Pin 2 in accordance with
industry convention.
To mount these microphones in a ceiling or
table top without the isolators, a 13⁄16" diameter hole
is required.To mount these microphones with the
isolators, a 15⁄16" hole is required.The isolators can
be placed on either side of the hole for mechanical
isolation from the mounting surface.
The Audio-Technica round mark ( ) on the
AT847 bezel indicates the “front” of the microphone.
While a modern fixed-charge condenser
microphone is not unduly sensitive to the environ-
ment, temperature extremes can be harmful.
Exposure to high temperature can result in gradual
and permanent reduction of the output level.Avoid
leaving the microphone in the open sun or in areas
where temperatures exceed 110°F (43°C) for long
periods of time. Extremely high humidity should
also be avoided.
Architects and Engineers Specifications
AT845R [AT845RW]
The microphone shall be a fixed-charge
condenser with an omnidirectional polar pattern
designed for use in table, ceiling or panel-mount
applications.The frequency response shall be
30 Hz to 20,000 Hz.The microphone shall operate
from an external 9V to 52V phantom power source.
Nominal open-circuit voltage shall be 7.9 mV at
1 kHz, 1 Pascal. Output shall be low impedance
balanced (200 ohms).
AT845R/RW
Omnidirectional
AT847R/RW
Cardioid
Condenser
Boundary
Microphones
The microphone shall have a self-contained
power module with an XLRM-type output connector.
The microphone shall have a diameter of
1.10" (28.0 mm) and a length of 2.72" (69.0 mm).
Weight shall be 2.1 oz (60 grams). The micro-
phone shall be housed in a die-cast case with a
two-layer perforated steel grille. Finish shall be
low-reflectance black [white].
The Audio-Technica AT845R [AT845RW]
is specified.
AT847R [AT847RW]
The microphone shall be a fixed-charge
condenser with a unidirectional polar pattern
designed for use in table-mount applications.The
frequency response shall be 30 Hz to 20,000 Hz.
The microphone shall operate from an external
9V to 52V phantom power source. Nominal open-
circuit output voltage shall be 7.9 mV at 1 kHz,
1 Pascal. Output shall be low impedance
balanced (200 ohms).
The microphone shall have a self-contained
power module with an XLRM-type output connector.
The microphone shall have a maximum
diameter of 1.18" (30.0 mm) and a length of 2.72"
(69.0 mm). Weight shall be 2.2 oz (62 grams).The
microphone shall be housed in a die-cast case
with a two-layer perforated steel grille. Finish shall
be low-reflectance black [white].
The Audio-Technica AT847R [AT847RW]
is specified.
Frequency in Hertz
Response in dB
10 dB
20k
10k
5k
2k
1k
500
200100
50
LEGEND
12" or more on axis
AT847R Frequency Response
AT845R Frequency Response
Frequency in Hertz
Response in dB
10 dB
20k
10k
5k
2k
1k
500
200100
50
LEGEND
12" or more on axis

Audio-Technica U.S., Inc., 1221 Commerce Drive, Stow, Ohio 44224
Audio-Technica Limited, Old Lane, Leeds LS11 8AG England
One-Year Limited Warranty
Audio-Technica microphones and accessories purchased in the U.S.A. are warranted for one year from date of
purchase by Audio-Technica U.S., Inc. (A.T.U.S.) to be free of defects in materials and workmanship. In event
of such defect, product will be repaired promptly without charge or, at our option, replaced with a new product
of equal or superior value if delivered to A.T.U.S. or an Authorized Service Center, prepaid, together with the
sales slip or other proof of purchase date.
Prior approval from A.T.U.S. is required for return. This warranty
excludes defects due to normal wear, abuse, shipping damage, or failure to use product in accordance with
instructions.This warranty is void in the event of unauthorized repair or modification.
For return approval and shipping information, contact the Service Department, Audio-Technica U.S., Inc.,
1221 Commerce Drive, Stow, Ohio 44224.
Except to the extent precluded by applicable state law,
A.T.U.S. will have no liability for any consequential,
incidental, or special damages; any warranty of merchantability or fitness for particular purpose
expires when this warranty expires.
This warranty gives you specific legal rights, and you may have other rights which vary from state to state.
Outside the U.S.A., please contact your local dealer for warranty details.
Form No. 0309-9200-02-B/W P50880
© 1996 Audio-Technica U.S., Inc. Printed in U.S.A.
Element Fixed-charge back plate
permanently polarized condenser
Polar Pattern AT845R Omnidirectional
AT847R Unidirectional (Cardioid in hemisphere
above mounting surface)
Frequency Response 30-20,000 Hz
Open Circuit Sensitivity –42 dB (7.9 mV) re 1V at 1 Pa*
Impedance 200 ohms
Maximum Input Sound Level 142 dB SPL, 1 kHz at 1% T.H.D.
Dynamic Range (Typical)
AT845R 112 dB, 1 kHz at Max SPL
AT847R 113 dB, 1 kHz at Max SPL
Signal-to-noise Ratio1
AT845R 64 dB, 1 kHz at 1 Pa*
AT847R 65 dB, 1 kHz at 1 Pa*
Phantom Power Requirements 9-52V DC, 2 mA typical
Weight AT845R 2.1 oz (60 grams)
AT847R 2.2 oz (62 grams)
Dimensions AT845R 1.10" (28.0 mm) dia, 2.72" (69.0 mm) length
AT847R 1.18" (30.0 mm) dia, 2.72" (69.0 mm) length
Output Connector Integral 3-pin XLRM-type
Accessory Furnished One pair isolators
†In the interest of standards development, A.T.U.S. offers
full details on its test methods to other industry
professionals on request.
* 1 Pascal = 10 dynes/cm2= 10 microbars = 94 dB SPL
1Typical, A-weighted, using Audio Precision System One.
AT845R, AT847R Specifications†
1 kHz
5 kHz
8 kHz
LEGEND
SCALE IS 5 DECIBELS PER DIVISION
90
60
120
30
150
210
240
270
300
330
180
0
100 Hz
1 kHz
5 kHz
8 kHz
LEGEND
SCALE IS 5 DECIBELS PER DIVISION
90
60
120
30
150
210
240
270
300
330
180
0
AT847R Polar Pattern
AT847R Dimensions
AT845R Polar Pattern
AT845R/RW
AT847R/RW
FRONT OF MIC
LOGO DESIGNATES
1.02"
26.0 mm
30.0 mm
1.18"
ISOLATORS
TABLE
NUT
2.72"
69.0 mm
0.33"
8.5 mm
0.79"
20.0 mm
ISOLATORS
NUT
2.72"
69.0 mm
0.33"
8.5 mm
0.79"
20.0 mm
1.10"
28.0 mm
CEILING
AT845R Dimensions
