AudioCodes MediaPack Series Assembly instructions

Hardware Installation Manual
AudioCodes MediaPack™ Analog Gateway Series
MP-1288
High-Density Analog Media Gateway

MediaPack Analog Gateways 3 MP-1288
Hardware Installation Manual Contents
Table of Contents
1Introduction .......................................................................................................11
2Unpacking the Device.......................................................................................13
3Physical Description.........................................................................................15
3.1 Physical Dimensions and Operating Environment.................................................15
3.2 Front Panel Description..........................................................................................15
3.2.1 LED Descriptions.....................................................................................................16
3.2.1.1 SYS LED ..................................................................................................16
3.2.1.2 TEL LED...................................................................................................16
3.2.1.3 PWR LED.................................................................................................17
3.2.1.4 FAN LED ..................................................................................................17
3.2.2 Fan Tray ..................................................................................................................18
3.3 Rear Panel Description..........................................................................................19
3.3.1 CPU Module ............................................................................................................20
3.3.2 FXS Blades..............................................................................................................21
3.3.3 Power Supply Module..............................................................................................23
3.3.4 LED Descriptions.....................................................................................................24
3.3.4.1 Ethernet LEDs..........................................................................................24
3.3.4.2 STAT LED ................................................................................................24
3.3.4.3 FXS LEDs.................................................................................................25
3.3.4.4 Power Supply LED...................................................................................26
419-Inch Rack Mounting.....................................................................................27
5Cabling the Device............................................................................................29
5.1 Grounding and Surge Protection............................................................................29
5.2 Connecting Ethernet Interfaces..............................................................................31
5.3 Connecting FXS Interfaces....................................................................................32
5.3.1 Connecting FXS Interfaces using AudioCodes FXS Patch Panel...........................35
5.3.2 Connecting FXS Interfaces using Centronics Cable...............................................38
5.3.3 Connecting FXS Interfaces Directly to an MDF.......................................................39
5.4Connecting the FXS Analog Lifeline ......................................................................41
5.5 Connecting the Serial Interface to a Computer......................................................42
5.6 Connecting to Power..............................................................................................44
6Hardware Maintenance .....................................................................................47
6.1 Preventing Electrostatic Discharge Damage..........................................................47
6.2 Replacing the Fan Tray Module.............................................................................48
6.3 Replacing the Air Filter...........................................................................................50
6.4 Replacing FXS Blades...........................................................................................52
6.5 Adding an FXS Blade.............................................................................................55
6.6 Replacing the CPU Module....................................................................................58
6.7 Replacing Power Supply Modules .........................................................................59

Hardware Installation Manual 4 Document #: LTRT-28030
MP-1288
List of Tables
Table 3-1: Physical Dimensions and Operating Environment................................................................15
Table 3-2: Front Panel Description.........................................................................................................15
Table 3-3: SYS LED Description............................................................................................................16
Table 3-4: TEL LED Description.............................................................................................................16
Table 3-5: PWR LED Description...........................................................................................................17
Table 3-6: FAN LED Description............................................................................................................17
Table 3-7: Rear Panel Description.........................................................................................................19
Table 3-8: CPU Module Description.......................................................................................................20
Table 3-9: FXS Port Specifications ........................................................................................................22
Table 3-10: Power Supply Module Description......................................................................................23
Table 3-11: Ethernet LEDs Description..................................................................................................24
Table 3-12: STAT LED Description........................................................................................................24
Table 3-13: FXS LEDs Description ........................................................................................................25
Table 3-14: Power Supply Module LED Description..............................................................................26
Table 5-1: RJ-45 Connector Pinouts for Ethernet Ports.........................................................................31
Table 5-2: 50-pin Telco Connector Pinouts............................................................................................33
Table 5-3: 50-pin Telco Connector Pinouts for FXS Lifeline..................................................................41
Table 5-4: RJ-45 to DB-9 Serial Cable Connector Pinouts....................................................................42
Table 5-5: Power Specifications.............................................................................................................44

MediaPack Analog Gateways 5 MP-1288
Hardware Installation Manual Contents
List of Figures
Figure 3-1: Front Panel...........................................................................................................................15
Figure 3-2: Fan Tray Module..................................................................................................................18
Figure 3-3: Fan Tray Cover....................................................................................................................18
Figure 3-4: Rear Panel Description........................................................................................................19
Figure 3-5: CPU Module.........................................................................................................................20
Figure 3-6: FXS Blade Showing Three FXS Telco Connectors.............................................................21
Figure 3-7: Chassis Slot Assignment for FXS Blades (Front Panel)......................................................21
Figure 3-8: FXS Blades and FXS Channels per FXS Connector (Rear Panel).....................................22
Figure 3-9: Power Supply Module..........................................................................................................23
Figure 3-10: FXS LED Location on Front Panel per FXS Blade............................................................25
Figure 3-11: FXS LED Location on Rear Panel per FXS Blade.............................................................25
Figure 4-1: Attaching Mounting Brackets to Chassis.............................................................................28
Figure 4-2: Front-Mounting Brackets Flush and Aligned with Front Rack Posts ...................................28
Figure 5-1: Stripped Grounding Wire .....................................................................................................30
Figure 5-2: Removing Screws and Washers..........................................................................................30
Figure 5-3: Attaching Grounding Wire to Grounding Lug.......................................................................30
Figure 5-4: Attaching Grounding Lug to Chassis...................................................................................30
Figure 5-5: Connecting the LAN Ports ...................................................................................................31
Figure 5-6: 50-pin Telco Connector........................................................................................................33
Figure 5-7: Orderable FXS Patch Panel.................................................................................................35
Figure 5-8: Mounting Patch Panel in Rack.............................................................................................36
Figure 5-9: Connecting 50-Pin Telco Connector to Port on FXS Blade.................................................36
Figure 5-10: Connecting Analog Equipment to FXS Patch Panel..........................................................37
Figure 5-11: Connecting FXS Interfaces using FXS Patch Panel..........................................................37
Figure 5-12: Orderable Centronics Cable and Pinouts..........................................................................38
Figure 5-13: Connecting 50-Pin Telco Connector to Port on FXS Blade...............................................38
Figure 5-14: Connecting FXS Interfaces Directly to MDF......................................................................40
Figure 5-15: 50-pin Telco Connector for FXS Lifeline............................................................................41
Figure 5-16: Cabling FXS Lifeline ..........................................................................................................41
Figure 5-17: RJ-45 to DB-9 Female Cable Adapter...............................................................................42
Figure 5-18: Connecting Serial Interface................................................................................................43
Figure 5-19: Swinging Cable Anchor Clip away from Power Inlet..........................................................45
Figure 5-20: Connecting to Power..........................................................................................................45
Figure 5-21: Strain Relief for Power Cord using Cable Anchor Clip......................................................45
Figure 6-1: Location of Screws on Fan Tray Cover ...............................................................................48
Figure 6-2: Removing Fan Tray Cover...................................................................................................49
Figure 6-3: Location of Screws on Fan Tray Module.............................................................................49
Figure 6-4: Location of Handles and Removing Fan Tray Module.........................................................49
Figure 6-5: Removing Fan Tray Cover on Front Panel..........................................................................50
Figure 6-6: Removing Air Filter Cover from Fan Tray Cover.................................................................51
Figure 6-7: Removing Air Filter from Air Filter Cover.............................................................................51
Figure 6-8: Removing 50-Pin Telco Connector......................................................................................52
Figure 6-9: Removing Hex Standoff Screws on Rear Panel (Example FXS Blade S4).........................53
Figure 6-10: Loosening Screws on FXS Blade on Front Panel..............................................................53
Figure 6-11: Removing FXS Blade from Chassis Slot on Front Panel ..................................................54
Figure 6-12: Slot's Guiding Rails for FXS Blade ....................................................................................54
Figure 6-13: Inserting Screwdriver into Cover Plate Hole......................................................................55
Figure 6-14: Removing Cover Plates.....................................................................................................56
Figure 6-15: Slot's Guiding Rails for FXS Blade ....................................................................................56
Figure 6-16: Tightening Captive Screws of FXS Blade on Front Panel.................................................57
Figure 6-17: Removing CPU Module on Rear Panel.............................................................................58
Figure 6-18: Handle and Release Latch on Power Supply Module.......................................................59
Figure 6-19: Removing Power Supply Module from Chassis.................................................................60

Hardware Installation Manual 6 Document #: LTRT-28030
MP-1288
This page is intentionally left blank.

MediaPack Analog Gateways 7 MP-1288
Hardware Installation Manual Notices
Notice
Information contained in this document is believed to be accurate and reliable at the time of
printing. However, due to ongoing product improvements and revisions, AudioCodes cannot
guarantee accuracy of printed material after the Date Published nor can it accept responsibility
for errors or omissions. Updates to this document can be downloaded from
https://www.audiocodes.com/library/technical-documents.
This document is subject to change without notice.
Date Published: December-25-2017
WEEE EU Directive
Pursuant to the WEEE EU Directive, electronic and electrical waste must not be disposed
of with unsorted waste. Please contact your local recycling authority for disposal of this
product.
Customer Support
Customer technical support and services are provided by AudioCodes or by an authorized
AudioCodes Service Partner. For more information on how to buy technical support for
AudioCodes products and for contact information, please visit our Web site at
https://www.audiocodes.com/services-support/maintenance-and-support.
Abbreviations and Terminology
Each abbreviation, unless widely used, is spelled out in full when first used.
Related Documentation
Document Name
SIP Release Notes
MP-1288 Media Gateway User's Manual

Hardware Installation Manual 8 Document #: LTRT-28030
MP-1288
General Notes, Warnings, and Safety Information
Warning: Read and adhere to all warning statements in this document before installing
the device.
Warning: This device is considered as IPX0 non-water ingress protected and therefore,
must be installed only indoors.
Warning: The Ethernet port interface cabling must be shielded and routed only indoors.
Warning: The device must be connected to a grounded power outlet.
Warning: Routing of FXS telephony cables: Routing FXS telephony cables outdoors
can be done only in conjunction with a three-electrode Gas Discharge Tube (GDT) rated
at 350V located at the entry point of the two-wi
re into the building, and properly
grounded. When done correctly, the installation will meet ITU-T K.21 requirements.
Caution Electrical Shock
Do not open or disassemble this device. The device carries high voltage and contact
with internal components may expose you to electrical shock and bodily harm.
Warning: The device must be installed and serviced only by qualified service personnel.
Warning: The device must be installed only in restricted access locations that are
compliant with ETS 300
253 guidelines where equipotential bonding has been
implemented.
Warning: Disconnect the device from the mains and Telephone Network Voltage (TNV)
before servicing.
Warning: Use only the AC power cord that is supplied with the device to connect to the
power source.

MediaPack Analog Gateways 9 MP-1288
Hardware Installation Manual Notices
Document Revision Record
LTRT Description
28020 Initial document release.
28021 Cable anchor clip for power cord; adding FXS blade procedure (removing connector
covers)
28022 Physical dimensions updated; warning bulletin for 19-inch rack cabinet.
28023 AC power cable warning (Japanese).
28024 REN 3 update.
28025 Lifeline activation only upon power outage; FXS off-hook current.
28026 Fan tray section and air filter replacement section updated.
28027 Off-hook loop current and ring voltage updated re ports.
28028 Power surge warning updated.
28029 Air filter replacement statement.
28030 Logo updated

Hardware Installation Manual 10 Document #: LTRT-28030
MP-1288
Documentation Feedback
AudioCodes continually strives to produce high quality documentation. If you have any
comments (suggestions or errors) regarding this document, please fill out the
Documentation Feedback form on our Web site at
https://online.audiocodes.com/documentation-feedback.

MediaPack Analog Gateways 11 MP-1288
Hardware Installation Manual 1. Introduction
1 Introduction
This document provides a hardware description of AudioCodes MP-1288 Analog Media
Gateway (hereafter referred to as device) and step-by-step procedures for mounting and
cabling the device.
The device supports the following:

Up to 288 FXS ports, 72 FXS ports per FXS blade (can house up to four FXS blades)

Two 100/1000 Base-T Gigabit Ethernet ports

Fan Tray module

1+1 AC Power Supply modules
Note: Hardware configurations may change without notice. Currently available hardware
configurations are listed in AudioCodes Price Book. For a
vailable hardware
configurations, contact your AudioCodes sales representative.

Hardware Installation Manual 12 Document #: LTRT-28030
MP-1288
This page is intentionally left blank.

MediaPack Analog Gateways 13 MP-1288
Hardware Installation Manual 2. Unpacking the Device
2 Unpacking the Device
Follow the procedure below for unpacking the carton in which the device is shipped.
To unpack the device:
1. Open the carton and remove packing materials.
2. Remove the chassis from the carton.
3. Check that there is no equipment damage.
4. Ensure that in addition to the chassis, the package contains the following items:
•2 x front-mounting brackets for 19-inch rack mounting
•1 x RJ-45 to DB-9 serial cable adapter for serial communication
•1 x AC power cord (or two if ordered with dual Power Supply modules)
•1 x grounding lug
5. Check, retain and process any documents.
If there are any damaged or missing items, notify your AudioCodes sales representative.

Hardware Installation Manual 14 Document #: LTRT-28030
MP-1288
This page is intentionally left blank.

MediaPack Analog Gateways 15 MP-1288
Hardware Installation Manual 3. Physical Description
3 Physical Description
This section provides a physical description of the device.
3.1 Physical Dimensions and Operating Environment
The device's physical dimensions and operating environment are listed in the table below:
Table 3-1: Physical Dimensions and Operating Environment
Physical Specification Description
Dimensions (H x W x D) 3U high, 19-inch rack wide
132.5 x 438 x 482.5 mm (5.22 x 17.24 x 19 inches)
Weight 21 kg (46.3 lbs.) for fully-populated chassis
Environmental Operational: 0 to 40°C (41 to 104°F)
Storage: -40 to 70°C (-40 to 158°F)
Humidity: 5 to 90% non-condensing
Over-voltage protection and surge immunity: ITU-T K.21
(basic) compliant.
Note: Routing of FXS telephony cables outdoors can only
be done in conjunction with AudioCodes-approved
primary surge protector and proper installation and
grounding.
3.2 Front Panel Description
The device's front panel is shown in the figure below and described in the subsequent
table.
Figure 3-1: Front Panel
Table 3-2: Front Panel Description
Item # Label Description
1 - Fan Tray cover. For more information, see Section 3.2.2 on page 18.
2 SYS /TEL /PWR
/FAN Front-panel LEDs. For more information, see Section 3.2.1 on page 16.

Hardware Installation Manual 16 Document #: LTRT-28030
MP-1288
3.2.1 LED Descriptions
This section describes the LEDs on the front panel of the chassis.
3.2.1.1 SYS LED
The SYS LED indicates the device's operating status, as described in the table below.
Table 3-3: SYS LED Description
Color State Description
Green On LED lit as a result of one of the following:
Device is operating normally
During first stage of boot up when device is powered on
Orange On Chassis is approaching high temperature threshold, but not
yet critical
Red On LED lit as a result of one of the following:
Fault detected in CPU module
Incompatible or faulty software version (.cmp file)
detected during boot up
Approaching critical high temperature threshold
Off No power
3.2.1.2 TEL LED
The TEL LED indicates the status of the FXS blades, as described in the table below.
Table 3-4: TEL LED Description
Color State Description
Green On LED lit as a result of one of the following:
During booting up phase
During normal operation, indicating normal FXS blade
operation
Orange At least one DSP has reached the high temperature threshold
Red On LED lit as a result of one of the following:
During initial phase of power-up
Failure detected in at least one FXS blade
No FXS blades detected in the chassis
- Off No power.

MediaPack Analog Gateways 17 MP-1288
Hardware Installation Manual 3. Physical Description
3.2.1.3 PWR LED
The PWR LED indicates the power status, as described in the table below.
Table 3-5: PWR LED Description
Color State Description
Green On Chassis receiving power and Power Supply modules are
functioning normally. If the device is configured to use only one
Power Supply module, the LED is lit if at least one of them is
operating normally.
Red On One of the Power Supply modules is faulty (if device is configured
to use two Power Supply modules).
- Off No power received by the device.
3.2.1.4 FAN LED
The FAN LED indicates the status of the Fan Tray module, as described in the table below.
Table 3-6: FAN LED Description
Color State Description
Green On Fans are functioning normally.
Red On At least one fan in the Fan Tray module is faulty.
- Off No power.

Hardware Installation Manual 18 Document #: LTRT-28030
MP-1288
3.2.2 Fan Tray
The device provides a Fan Tray module, located on the front panel, which is concealed by
a fan tray cover. The Fan Tray module contains six individual fans which cool the device's
internal components to maintain an acceptable operating temperature inside the chassis.
The Fan Tray module draws air in from the outside through the perforated fan tray cover. A
replaceable air filter, located inside the fan tray cover, removes dust particles from the
sucked in air. The incoming air passes through the chassis, cooling the internal
components and then exits the chassis through the vents on the rear panel.
Figure 3-2: Fan Tray Module
Figure 3-3: Fan Tray Cover
The Fan Tray provides a LED indicating the operating status of the Fan Tray module. For
more information, see Section 3.2.1.4 on page 17.
During system operation, the inner ambient temperature is continuously monitored. Upon
excessive temperature conditions, an SNMP Temperature Alarm is generated
(acBoardTemperatureAlarm). Upon a speed degradation or full stop of any fan, an SNMP
Fan Alarm (acFanTrayAlarm) is generated.
The Fan Tray module is hot-swappable, allowing you to replace it even when the device is
powered on. The Fan Tray module, fan tray cover, and air filter are available as field-
replaceable units (FRU). For replacing the Fan Tray module, see Section 6.2 on page 48.
For replacing the air filter, see Section 6.3 on page 50.
Warning: For replacing the Fan Tray module or any of its components, perform only the
instructions as described in Section 6.2 on page 48.

MediaPack Analog Gateways 19 MP-1288
Hardware Installation Manual 3. Physical Description
3.3 Rear Panel Description
The device's rear panel is shown in the figure below and described in the subsequent table.
Figure 3-4: Rear Panel Description
Note: The figure above is used only as an example. The number of installed FXS blades
and Power Supply modules depends on your ordered hardware configuration.
Table 3-7: Rear Panel Description
Item # Label Description
1 CPU CPU module providing the central processing unit and various
network port interfaces. For more information, see Section 3.3.1
on page 20.
2 PS1 /PS2 Power Supply modules. For more information, see Section 3.3.3
on page 23.
3 Blades:
S1 /S2 /S3 /S4
FXS Ports:
FXS 1-24 /FXS 25-48 /
FXS 49-72
FXS blades providing FXS port interfaces. For more information,
see Section 3.3.2 on page 21.
4 Protective grounding for connecting a grounding lug for chassis
ground connection for ESD-preventive equipment or a grounding
wire.

Hardware Installation Manual 20 Document #: LTRT-28030
MP-1288
3.3.1 CPU Module
The CPU module provides the central processing unit and port interfaces, as shown in the
figure below and described in the subsequent table.
Figure 3-5: CPU Module
Table 3-8: CPU Module Description
Item # Label Description
1 Two 100/1000Base-T (Gigabit) Ethernet ports (RJ-45) for connecting to
the IP network.
The ports support the following features:
1+1 Ethernet port redundancy
Half- and full-duplex modes
Auto-negotiation
Straight or crossover cable detection
The ports provide LEDs to indicate Ethernet status. For more
information, see Section 3.3.4.1 on page 24.
2 Reset pinhole button for resetting the device and restoring factory
defaults:
To reset the device:Using a paper clip or any other similar pointed
object, press and hold down the button for at least 2 seconds but no
longer than 10 seconds.
To restore the device to factory defaults:Using a paper clip or
any other similar pointed object, press and hold down the button for
at least 10 seconds but no longer than 30 seconds
3 STAT LED indicating the status of the CPU module. For more information, see
Section 3.3.4.2 on page 24.
4 |O|O| RJ-45 port for RS-232 serial communication.
5 USB Type-A port which can be used, for example, for various storage
capabilities to an external USB hard drive or flash disk (disk on key).
