Audiolab 8000Q User manual

audiolab
International Audio Group
IAG house,
Sovereign Court,
Ermine Business Park
Huntingdon, PE29 6XU
Reliable and robust, the ‘Q’ has been a
stalwart of the 8000 series.
Good pre-amplifiers are few and far
between in the audiophile world. To be
considered such an audiophile pre-ampli-
fier, the 8000Q must provide all of the
functionality and control required without
imparting any character of its own to the
delicate audio signals.
It’s this neutrality that is so hard to
achieve, and it is this neutrality that is the
secret of the 8000Qs enduring appeal.
Specification
8000Q
Pre - Amplifier
Input impedance
Input level vs. gain setting
Frequency response (-3 dB)
Frequency response (±0.2 dB)
Channel separation
Crosstalk rejection
Preamplifier output impedance
Preamplifier maximum output
Record output impedance
Operating temperature range
AC supply frequency
AC supply voltage
Power consumption
Dimensions (WxHxD - mm)
20 kΩnominal
500 mV at 0 dB - 350 mV at 3 dB - 250 mV at 6 dB
175 mV at 9 dB - 125 mV at 12 dB - 90 mV at 15 dB
0.1 Hz - 75 kHz
20 Hz - 20 kHz
greater than 100dB at 1 kHz
greater than 100dB at 1 kHz
100Ωnominal
greater than 7.7 V rms (20 dBm)
1 kΩnominal
greater than 10 - 35ºC
50 - 60 Hz
110 - 120 V or 220 - 240 V
less than 25 W
445 x 74 x 335
