AUDIOLINE PHONE EASY User manual

PHONE EASY
Big Button Telephone
User guide
Downloaded from: http://www.guardianalarms.net

VOL
M2 M3 M1
1 2 3
456
7 8 9
0
+
1
2
3 4 56 7
8
9
10
STORE/MUTE MEMORY RECALL REDIAL
1
LOCATION OF CONTROLS
1Handset hanger hook 6Recall button
2Memory card 7Last number redial
3Direct memories M1, M2, M3 8Visual ring indicator
4Store/Mute button and indicator 9Keypad 0-9, *, #
5Memory button (Indirect) 10 Volume controls

2
CONNECTING
## Connect the line cord to the telephone and to the telephone socket.
## Lift the handset and check for a dial tone.
WALL MOUNTING
The Audioline Phone Easy can be wall mounted directly onto the standard wall plate
or to the wall by following the instructions below:
## Mark the position of the two holes 83 mm apart, one above the other.
#Ensure there are no hidden cables, water pipes, etc., before drilling holes. Check
that the intended mounting point is within reach of a telephone socket.
## Drill the holes.
## Fit the screws (not supplied) to the wall, leaving 5 mm protruding (use wall plugs if
necessary, not supplied).
## Place the telephone in position and locate the two holes on the base of the
telephone over the screws, then slide into place.
#The handset hanger hook (item 1 on page 1) must be removed, rotated 180 degrees
and replaced.
TO MAKE A CALL
PLift the handset and wait for dial tone.
PDial the phone number.
PReplace the handset to terminate the call.
LAST NUMBER REDIAL
To redial the number called, lift the handset and press the [REDIAL] button. The
number will be dialled automatically.
The number will be retained in memory until another number is dialled.
The [REDIAL] button will not operate if the number dialled was from memory.
MUTE
To speak privately to a third party while on a call, press the [MUTE] button (the small
red LED will flash). When you wish to resume your telephone conversation, press the
[MUTE] button again.

3
DIRECT MEMORY
The telephone has 3 direct dial memories (M1-M3). When a phone number is stored
into these memories you need to press only one button to make the call.
STORING DIRECT MEMORIES
PLift the handset and press [STORE] button (ignore any sound in the earpiece).
PSelect the desired direct memory button M1 - M3 by pressing the corresponding
button.
PEnter the phone number (max 21 digits).
PPress [STORE] button again.
PReplace the handset. The number is now stored.
DIALLING DIRECT MEMORIES
PLift the handset and wait for a dial tone.
PSelect the desired direct memory M1-M3 by pressing on the corresponding
button. The telephone will automatically dial the stored number.
INDIRECT MEMORY
The telephone has 10 indirect memories (keypad 0-9). When a phone number is stored
in a memory you need to press two buttons only to make the call.
STORE INDIRECT MEMORY
PLift the handset and press [STORE] (ignore any sound through the earpiece).
PPress [MEMORY] button.
PSelect the desired indirect memory (0-9) by pressing on the corresponding button.
PDial the phone number (max 21 digits).
PPress [STORE] button again.
PReplace the handset. The number is now stored.
DIALLING INDIRECT MEMORIES
PLift the handset and wait for a dial tone.
PPress [MEMORY] button.
PSelect the desired indirect memory (0-9) by pressing on the corresponding button.
The telephone will automatically dial the stored number.

4
VOLUME CONTROL
The volume level in the earpiece can be increased or decreased using the
volume buttons on the base unit during a call.
ADJUSTABLE RINGER
There are three different ringing tones available and three different volume settings for
each ringer
PLift the handset and press the [STORE] button .
PPress [#].
PSelect a ring signal by pressing 0 - 9 according to the table below.
PPress the [STORE] button again.
PReplace the handset. The ringer type is now selected.
Keypad digit Ringer type Setting
1Melody A Low
2Melody A Normal
3Melody A High
4Melody B Low
5Melody B Normal
6 (factory setting) Melody B High
7Melody C Low
8Melody C Normal
9Melody C High
0-
Off *(see below)
*If setting 0 is selected, the ringer type will be turned off until the handset is lifted
again. After that, the ringer type reverts to the previous setting.

5
ADDITIONAL NETWORK SERVICES
Network services such as call waiting, reminder calls, charge advice, etc., can be
accessed via the [RECALL], [#] and [*] buttons. For further information, contact your
Network Operator.
HEARING AID COMPATIBLE
The phone is hearing aid compatible. When used with a suitable hearing aid set to the
T mode.
TROUBLESHOOTING
In the unlikely event of a fault occurring, proceed as follows:
## Check that telephone is plugged into telephone socket.
#Check telephone operation in master telephone socket. There may be a fault with
the line in which case contact your Network Operator.
## Check that total of REN numbers does not exceed 3 (the Phone Easy has a REN of
1.)
## If the telephone does not ring, lift and replace the handset (the ringer may be
programmed off).
WARNING
It is recommended that you disconnect your telephone during a thunderstorm as you
can get a shock from your telephone (and other electrical appliances). We recommend
you follow these simple precautions during a thunderstorm:
#Do not use your telephone unless the call is urgent.
#If you must use your telephone, make the call as brief as possible and keep clear of
electrical equipment and metal fixtures.
#Do not stand in bare feet on uncovered concrete floors.
#Do not touch brick or concrete walls.
NOTE: Do not install your telephone in damp or high humidity locations, such as a
laundry or bathroom. If any damage is caused by such elements it is not covered by
the manufacturers warranty.

6
CLEANING
The casing should be cleaned by wiping with a damp cloth.
#Do not use abrasives, solvents or spray polish that may enter through holes in the
earpiece and mouthpiece and cause damage.
#Do not place the telephone in direct sunlight or use in extreme humidity.
REN (RN for New Zealand)
The REN (Ringer Equivalance Number) or RN is of significance only if you wish to
connect more than 1 telephone to your telephone line. Your telephone line has a
maximum REN capacity of 3 (RN of 5). Your Audioline Phone Easy has a REN of 1
(RN of 1), thus it is feasible to connect 2 (4) more telephones of a value of 1 to your
system. You should not exceed a value of 3 (5) on the complete system, otherwise the
volume of the ringer in any phone will decrease and one telephone may not ring at all.
GUARANTEE
If you believe your Phone Easy is malfunctioning, please refer to the relevant section
and/or consult the troubleshooting guide in this manual to ensure that you have
followed the instructions carefully.
The Phone Easy is guaranteed for a period of 12 months from the date of purchase. In
the unlikely event of a fault during this period, please contact us for assistance. If the
product is then found to be faulty you will be asked to return it directly to us with a
copy of the purchase receipt.
AUSTRALIA NEW ZEALAND
DORO Australia Pty Ltd Atlas Gentech (NZ) Limited
PO Box 6760 Private Bag 14927, Panmure
Baulkham Hills BC NSW 2153 Australia Auckland
Helpline Consumer Support
Ph: [phone] Ph: 0900 50-025 (Toll Call)
Fax: [phone] Fax: [phone]
Email: [email protected] Email: [email protected]
NOTE: The guarantee does not extend to damage caused by misuse, negligence, excessive voltage, faults on the telephone line
or lightning. This guarantee in no way affects your statutory rights. DORO is the trademark of DORO AB.
Notes For Operation In New Zealand
The grant of a Telepermit for any item of terminal equipment indicates only that Telecom has accepted that the item complies with the minimum
conditions for connection to its network. It indicates no endorsement of the product by Telecom, nor does it provide any sort of warranty. Above all, it
provides no assurance that any item will work correctly in all respects with another item of Telepermitted equipment o f a different make or model, nor
does it imply that any product is compatible with all of Telecom’s network services.
This equipment shall not be set to make automatic calls to the Telecom “111" Emergency Service.
This Equipment may not provide for the effective hand-over of a call to another device connected to the same line .
