Audiovox Prestige 5BLCR Operating instructions

128-6690
1 of 8
Model 5BLCR &
5BLCRA
ProgrammingGuide
The 5BLCR is designed to work with most Audiovox two way remote start unit
and may be programmed differently for other models. For the APS-55TW, the
recommended transceiver programming is shown below.
Note: A total of 4 transmitters may be programmed into any receiver channel.
1 Lock
2 Unlock
3 Remote Start/Stop
4 Option
The 5BLCRA is designed to work with most Audiovox two way alarm sys-
tems and may be programmed differently for other models. For the APS-590,
the recommended transceiver programming is shown below.
1 Lock
2 Unlock
3 Trunk Release (Optional)
4 Option
The intent of the Option button is to facilitate operation of other Audiovox RF
devices such as a second vehicle or a Garage Door Interface unit.
In the case of the APS-590, there is also an additional output on the control
module in the vehicle which may be programmed to operate from the Opt.
Button. Please check with your installation center for the programming of your
unit.
A total of 4 transmitters may be programmed into any receiver channel.
Force programming a transmitter, removing a transmitter, or reprioritizing a
transmitter is covered later in this manual.
Also, if you do not program a transmitter button into channel 2 which is the
separate unlock/disarm channel, then whatever button is programmed into
channel 1 will serve as both lock/arm & unlock/disarm.
Note: The “F” Button serves as a function button in combination with other
buttons explained in your owners manual. This button may not be used to
operate a receiver channel.
Note: Alarm units have a sounding device, siren or horn, keyless entry units
may or may not include a sounding device. Where mentioned, you may or may
not hear a chirp from the siren or horn. In the case of a keyless entry unit,
when entering a code, the unit will flash the parking lights to indicate the code
is learned.

128-6690
2 of 8
As mentioned above, the program mode refers to a Keyless Entry unit which
has no sounding device, you will note mention of a long chirp from the siren.
This reference is for those who program this transmitter into a security
system or into a unit with a sounding device.
TOENTERTHEPROGRAMMODE:
1 Turn the ignition switch to the “ON” position.
2 Within 10 seconds, Press and release the valet/program switch three
times.
(Siren emits 1 short chirp indicating channel 1 has been entered)
3 Within 10 Seconds, Press and hold the Lock button of the first transmitter
you wish to control the Lock & Arm feature of your system until the lights
flash or a long chirp is heard from the siren.
(Repeat this for each transmitter you wish to operate the Lock/Arm feature).
4 Within 10 seconds, press and release the valet program switch one time.
(Siren emits 2 short chirps indicating channel 2 has been entered)
5 Within 10 Seconds, Press and hold the Unlock button of the first transmitter
you wish to control the Unlock/Disarm feature of your security system until
the lights flash or a long chirp is heard from the siren.
NOTE: This channel is used only if you desire separate control of the Lock/
Unlock feature. If you wish to operate the Lock/Unlock features from a single
button, move onto step 6 as whatever button is programmed into channel 1
will control both Lock & Arm/Unlock & Disarm.
(Repeat this for each transmitter you wish to operate the Unlock/Disarm
feature).
6 Within 10 seconds, press and release the valet program switch one time.
(Siren emits 3 short chirps indicating channel 3 has been entered)
7 Within 10 Seconds, Press and hold the Start button, (APS-55TW) or Key
button, (APS-590), of the first transmitter you wish to control Channel 3
output, until the lights flash or a long chirp is heard from the siren.
(Repeat this for each transmitter you wish to operate the Channel 3 output
Remote Start & or Trunk Release)
APS-55TW Programming is complete, Turn Off The Ignition Switch to exit the
program mode.
Note: If programming the APS-590 you may continue onto step 8 if you are
operating a device in the vehicle controlled from the optional output. If not,
Turn off the ignition switch to exit the program mode.
8 Within 10 seconds, press and release the valet program switch one time.
9 Within 10 seconds, Press and hold the Opt. button of the first transmitter
you wish to operate the Optional device of the APS-590.
(Repeat this for each transmitter you wish to operate the Optional output
(APS-590 Only)
APS-590 Programming is complete, Turn Off The Ignition Switch to exit the
program mode.
2

128-6690
3 of 8
NOTE: If the program switch is operated again, the circuit will recycle
through the program mode. In other words, press 1 time to access the lock
function, 2 times to access the unlock function, 3 times to access the start
function. When programming is complete, simply turn off the ignition switch
to exit the program mode.
ERASING TRANSMITTERS IF THEY HAVE BEEN LOST OR STOLEN:
NOTE: Before you begin to erase the lost or stolen transmitter(s), have all
transmitters available that you wish to remain programmed. These will be
used during the program process to identify transmitters that will continue to
be used.
Enter the transmitter program mode:
1 Turn the ignition switch to the “ON” position.
2 Within 10 seconds, press and release the valet/program switch three
times. (Siren emits 1 short chirp indicating channel 1 has been entered)
3 Within 10 Seconds, Press and hold the ARM or ARM/DISARM button of the
first transmitter you wish to remain stored into the control unit until a single
chirp is heard from the siren.
(Repeat this for each transmitter you wish to remain stored in the control
unit).
The receiver stores up to four transmitters. To be certain all transmitter slots
in the receiver are occupied with transmitters you wish to continue to use,
and all others are erased, you will have to fill all four receiver slots. If in step
3 you identified one transmitter, you will have to fill the additional 3 slots. If in
step 3 you identified two transmitters, you will have to fill the additional two
slots, etc...
4 Press and hold any unused button or combination of buttons until a long
chirp is heard from the siren. Release and press the button or button combi-
nation again and again until all remaining slots are full.
Repeat this procedure with the appropriate transmitter buttons for all other
receiver channels.
REPRIORITIZING A TRANSMITTER’S PROGRAMMING:
To reprogram a receiver channel with a different transmitter button once a
code has been stored, there will be two options:
1 Enter the transmitter program mode of the receiver channel to be repro-
grammed. Using any unused button or combination of buttons, push out the
stored code by pressing the unused button until a long chirp is heard, then
repeat 3 additional times. After this, you can add any desired unused trans-
mitter button. This action erases only that particular receiver channel, all
other codes will remain stored.
3

128-6690
4 of 8
2 Enter the transmitter program mode. Using any transmitter button press
and hold until a long chirp is heard. If a single chirp or multiple chirps, (up to
7 chirps), are heard, the unit is indicating that the transmitter has already
been programmed elsewhere in the receiver. Release the transmitter button
and within 5 seconds press and hold until a long chirp is heard. This action
forces the unit to erase all stored codes of that transmitter.
The unit then exits the program mode the siren emits the program mode exit
chirp pattern. All transmitter buttons for that transmitter must now be repro-
grammed. Any other transmitter stored in the unit’s memory still remain
operational. If the button is released and not pressed again within the 5
second period, no change in programming has been made to the receiver
channel. The programmer can move onto a different channel or erase the
transmitter codes as described in 1 above.
REPLACINGTHEBATTERY:
You will notice a decrease in transmitter range as the battery condition
deteriorates.
The low battery indicator shown left, also the top LED on the transmitter
willlightGreenwhen any button is pressed indicatingthatthebatterycondition
is good. If the LED Lights Red when any transmitter button is pressed, this is
aindicationthatthebatteryislowandneedstobereplaced. Transmitterbattery
replacement is recommended at least every 6 to 8 months, depending upon
how frequently the transmitter is used.
To replace the transmitter battery:
1.Slidebackthelocktabonthebacksideofthe transmittercaseinthedirection
shown.
2. Slide back the battery case cover in the direction shown.
4

128-6690
5 of 8
3. Remove the discharged battery, making note of the location of the + and -
contacts shown, and replace with a new type alkaline 1.5 volt AAA Battery.
4. Making note of the location of the (+) and (-) contacts, insert a new AAA
battery alkaline 1.5 volt.
5. Replace battery cover being certain to close the battery case lock clip to
prevent accidential opening.
5

128-6690
6 of 8
Attention: Transmitter Ordering Department
Important: To help us expedite your order, please print all of the information
legibly and mail this form and your payment according to the instructions
below. Specify 5BLCR ______ or 5BLCRA ______
1) Name:___________________________________________
2) Address:_________________________________________
3) City:________________State:________Zip Code:__________
4 Telephone Number:( )_____________________
5) Total Number Of Transmitters Required:_______
Cost Per Transmitter is: $85.00
Multiply By Number Of Transmitters X
6) Enter Total Amount Enclosed _______
(New York State Residents must include the appropriate sales tax)
7) Method of Payment:
Mastercard Visa Check or Money Order (do not send cash)
Make Checks Payable To Audiovox Corporation
Credit Card Number:___________________________________
Credit Card Expiration Date: ____/___/____
8) Mail this form along with your payment to:
Transmitter Ordering Department
Audiovox Corporation 150 Marcus Blvd., Hauppauge N.Y. 11788
Credit card purchasers can order additional or replacement
transmittersby phone. Simply dial1-800 - 645-4994,and follow
the instructions from the operator interface
ORDERFORMFORTRANSMITTER

5BLCRA5BLCR
6

128-6690
7 of 8
THISPAGELEFT BLANKINTENTIONALLY
7

128-6690
8 of 8
128-6690
© 2003 Audiovox Electronics Corp., 150 Marcus Blvd., Hauppauge, NY, 11788
