INSTALLATION INSTRUCTIONS
This unit is designed for installation in GM and Chrysler cars, trucks, and vans with a 1-1/2 DIN
radio opening. In some cases, a special installation kit will be required to mount the radio to the
dashboard. These kits are available at electronics supply stores and car stereo specialty shops.
Always check the kit application before purchasing to make sure the kit works with your vehicle.
If you need a kit but cannot find it available, call our toll-free “HELP” line at 1-800-645-4994.
PRE-INSTALLATION CONSIDERATIONS
IMPORTANT: Disconnect the ground cable from the negative terminal of the battery.
a.Dash Disassembly:
NOTE:Locations and types of fasteners will vary depending on the make and model of the
vehicle. Carefully check the dash for all fasteners that may require removal in order
to remove the factory radio from the sub-dash.
1. Remove the screws securing the upper and/or lower portion of the dash panel.
2. Remove the screws above the instrument cluster and all screws from the trim panel that
may surround the factory radio.
3. Remove the ash tray and open the glove box to see if there are any screws that need to
be removed from the dash panel. Do not discard any screws!
NOTE:The gear shifter may need to be in low gear to allow for dash panel removal.
4. Gently unclip and remove the dash panel.
b.Removing the Factory Radio:
1. Removeanyhardwaresecuringthefactoryradioassemblytothesub-dash.Donotdiscard
any hardware!
2. Disconnect the wiring and antenna cable from the factory radio.
c. Removing the Factory Radio Brackets (If Applicable):
1. Remove all nuts that secure the original factory brackets to the radio.
2. Remove and retain the original mounting brackets from the factory radio.
NOTE:Notall radioshaveremovablemountingbrackets. For GMradioswith non-removable
brackets, use the two enclosed. These will satisfy most 1993 and up GM radio
mountingapplications. Ifthisisnotthecase,itwillbenecessarytopurchaseaspecial
installation kit. Please consult your local car stereo installation shop or consumer
electronic store.
d.On the ACD-75, remove the detachable front panel, if it is attached to the chassis, by
pressing the RELEASE button and pulling the panel assembly straight off the panel
mounting plate. Store the panel in the case provided with the radio.
e.Check the dashboard opening size by measuring the height and width. If the opening is not
largeenough,carefullycutorfileasnecessaryuntiltheopeningslightlyexceeds theradiosize.
Check that there will be sufficient space behind the dashboard for the radio chassis.
INSTALLATION INSTRUCTIONS
2

WIRING COLOR CODES
FUNCTION COLOR
+ 12 V Acc/Ignition Red
+12 V
Battery/Memory Yellow
Ground Black
Dimmer Orange
Cellular Mute Pink
LF + Speaker White
LF - Speaker White/Black
LR + Speaker Green
LR - Speaker Green/Black
RF + Speaker Gray
RF - Speaker Gray/Black
RR + Speaker Violet
RR - Speaker Violet/Black
INSTALLATION INSTRUCTIONS
3
f. Remove the two transport screws installed through the top of the radio chassis; you cannot
insert a CD into the player until these screws are removed.
NOTE: After confirming fit, place the ACD-75 aside and proceed with wiring instructions.
USING A WIRING ADAPTER
The easiest wiring method to connect the ACD-75 to the vehicle is to buy a wire harness adapter
fromyourdealer,a carstereoinstallation shoporan electronics store.Ifyou useawiring adapter,
all wires can be connected to your ACD-75 even before your old radio is removed from the car.
Connecting the Wires
Splice,crimporsolderthewiresfromtheAudiovoxACD-75radioconnectortothewiringadapter.
Match the wires according to the function vs color code relationship expressed in the following
table and the wiring adapter instructions.
Attach Wires to Radio (See Figures 1 and 2.)
a. After splicing the wiring adapter to the radio connector, attach the connector to the back of
the radio.
b. Attach an antenna extender cable (not supplied) and antenna adapter, if needed.

Install Wiring Inside the Car (See Figures 1 and 2.)
a. Connect wiringadapterto the car’sexistingwiring harness.
b. Connect anantennaextender cable(notsupplied) tocarantenna lead,ifneeded.
TYPICAL GM APPLICATION (See Figure 1.)
Radio Preparation :
NOTE:For GM car installations, use the GM Hardware Kit, Part Number 150-1331, which is
furnished with the radio.
1. Match quickie bolt locations on the ACD-75 radio to the factory radio bolt locations, and
snap the short quickie bolts (Item #2) into the appropriate locations.
2. Attach the original factory brackets or those from the radio mounting kit (if required) to the
ACD-75 radio using the supplied flange nuts (Item #4) or use the enclosed bracket
(Item # 6) if the original factory brackets are not removable.
3. Some vehicle applications incorporate a rear mounting support. Match the rear quickie
bolt on the ACD-75 radio to the rear factory radio bolt location and snap the long quickie
bolt (Item #3) into place. Thread the plastic rear bushing (Item #5) fully onto the quickie
bolt.
4. Plug supplied wire harness (Item #1) into the mating socket on the rear of the ACD-75.
Installation :
1. Connect the wiring harness from the radio to the vehicle side radio harness.
2. Plug the factory antenna cable into the antenna socket on the radio.
NOTE:GM vehicles 1992 and up will require an antenna adapter cable to convert the vehicle
mini connector to standard connector. Antenna adaptor cables are available at car
stereo speciality shops.
3. If a compatible CD changer is to be used with this radio, connect the DIN cable from the
changer to the mating socket on the radio. If an external amplifier will be used for the rear
speakers, connect the low-level output RCA leads from the radio to the low-level inputs on
the amplifier.
4. Reconnect the battery and perform a brief functional test of the radio to verify proper
performance.
5. After verification, turn off the ignition switch and fasten the radio to the sub-dash using the
mounting hardware previously removed from the factory radio.
6. Re-assemble the dash using the reverse of the disassembly procedure.
INSTALLATION INSTRUCTIONS
4

SPESPE SPESPE
SPEAA
AA
AKK
KK
KER WIRINGER WIRING
ER WIRINGER WIRING
ER WIRING
INSTALLATION INSTRUCTIONS
5
WIRING DIAGRAM-TYPICAL INSTALLATION FOR GM
(Figure 1)
ITEM# 1
ITEM # 6

TYPICAL CHRYSLER APPLICATION (See Figure 2.)
Radio Preparation:
NOTE: For Chrysler car installations, use the Chrysler Hardware Kit, Part Number 150-1332
1. Select two of the three mounting tabs provided (Items # 7, # 8 and # 9) and match the radio
mounting style of the vehicle as shown in Figures 3, 4 and 5.
NOTE: The tab number is stamped on the bottom of the tab.
2. Attach the mounting tabs to the radio chassis with the four 1/4” hex head screws provided.
3. Attach the 12-pin connector from the harness to the radio.
4. Plug the antenna cable into the antenna socket on the radio.
Installation:
1. Attach the ring lug on the ground wire (black) from the radio side harness along with the
vehicle side grounding strap to the rear of the radio chassis using the short quickie bolt
(Item #2) and the flange nut (Item # 4) provided.
2. Connect the mating side of the harness to the vehicle side wiring harness.
3. Connect the vehicle antenna cable to the radio antenna connector.
4. If a compatible CD changer is to be used with this radio, connect the DIN cable from the
changer to the mating socket on the radio. If an external amplifier will be used for the rear
speakers, connect the low-level output RCA leads from the radio to the low-level inputs on the
amplifier.
5. Re-connect the battery and perform a brief functional test of the radio to verify proper
performance.
6. After verification, turn off the ignition switch and install the radio into the sub-dash of the
vehicle using either the two 10mm hex-head screws (Item #10) provided, or the existing
factory hardware.
7. Re-assemble the dash using the reverse of the disassembly procedure.
RR RR
RAA
AA
ADIO WIRINGDIO WIRING
DIO WIRINGDIO WIRING
DIO WIRING
6
INSTALLATION INSTRUCTIONS

INSTALLATION INSTRUCTIONS
7
TYPICAL INSTALLATION FOR CHRYSLER
(Figure 2)
ITEM #’S7, 8, and 9
(2 PLACES)
OR
10mm HEX-HEAD SCREWS
(ITEM # 10)

INSTALLATION INSTRUCTIONS
8
POWER
COMPACT DISC PLAYER EJECT
VOL
TUNE/SKIP
VOL
DIGITALAUDIO
COMPACT
LOUD
T/F
EQ
MODE
BAND
MUTE
1
TOP SCN
2
RPT
3
RND 4
MONO LOC
ACD-75
CD+
6
CD-
5
100 WATT
POWER
COMPACT DISC PLAYER EJECT
VOL
TUNE/SKIP
VOL
DIGITALAUDIO
COMPACT
LOUD
T/F
EQ
MODE
BAND
MUTE
1
TOP SCN
2
RPT
3
RND 4
MONO LOC
ACD-75
CD+
6
CD-
5
100 WATT
POWER
COMPACT DISC PLAYER EJECT
VOL
TUNE/SKIP
VOL
DIGITALAUDIO
COMPACT
LOUD
T/F
EQ
MODE
BAND
MUTE
1
TOP SCN
2
RPT
3
RND 4
MONO LOC
ACD-75
CD+
6
CD-
5
100 WATT
Figure 3
Figure 4
Figure 5
TAB #1
TAB #2
TAB #3
TAB #2
TAB #2
TAB #2

1POWER ON-OFF BUTTON
Pressthisbuttonto turntheunit on oroff.Theunit
will also turn on automatically when a compact
disc is inserted if the ignition switch is “on”.
2VOLUME (LEVEL) CONTROL
To increase the volume level, press the VOL
button. The volume will increase and the level
will be shown on the display panel from a
minimum of VOL 00 to a maximum of VOL 39.
To decrease the volume level, press the VOL
button. The display will automatically return
to the normal indication 5 seconds after the last
volume adjustment or when another function is
activated. This control is also used in conjunction
withthe Select(SEL) button to adjust the bass,
treble, balance and fader levels as described in
4, 5, 6and 7.
3SELECT (SEL) CONTROL BUTTON
Thisbutton isused toselect the audio function
(volume, bass, treble, balance, or fade) whose
setting is adjusted using the VOL 2
buttons. Pressing the SEL control button once
will set the unit for bass adjustment (BAS will
appear on the display panel) and an audible
beep will occur. Pressing the button additional
times will select treble adjustment (TRE on the
display), balance (BAL), or fader (FAD), each
accompanied by a beep tone. The display will
automatically return to the normal indication 5
seconds after the last adjustment or when
another function is activated.
4BASS CONTROL
To adjust the bass level, first select the Bass
modebypressing the SELbutton3so theBAS
indication appears on the display panel. Within
5 seconds of choosing the Bass mode, press
the VOL 2button to decrease the bass
response or the VOL button to increase it as
desired. The level will be shown on the display
panel from a minimum BAS -12 to a maximum of
BAS +12 (BAS 00 indicates flat response). The
display will automatically return to the normal
indication 5 seconds after the last adjustment or
when another function is activated.
5TREBLE CONTROL
To adjust the treble level, first select the Treble
modebypressingthe SEL button3so theTRE
indication appears on the display panel. Within
9
OPERATING INSTRUCTIONS
H

5 seconds of choosing the Treble mode, press
the VOL button 2to decrease the treble
response or the VOL button to increase it as
desired. The level will be shown on the display
panel from a minimum TRE -12 to a maximum of
TRE +12 (TRE 00 indicates flat response). The
display will automatically return to the normal
indication 5 seconds after the last adjustment
or when another function is activated.
6LEFT/RIGHT BALANCE CONTROL
To adjust the left-right speaker balance, first
select the Balance mode by pressing the SEL
button 3so the BAL indication appears on the
display panel. Within 5 seconds of choosing
the Balance mode, press the VOL button 2
to adjust the stereo balance to the left channel
speakers or the VOL button to adjust it to the
right channel speakers. The balance position
willbeshownon the displaypanelfrom BAL L16
(fullleft)toBAL R16 (fullright). When thevolume
levelbetween theleft andright speakersis equal,
BAL 00 will be shown on the display panel. The
display will automatically return to the normal
indication 5 seconds after the last adjustment
or when another function is activated.
7FRONT/REAR FADER CONTROL
To adjust the front-rear speaker balance, first
select the Fader mode by pressing the Select
button 3so the FAD indication appears on the
display panel. Within 5 seconds of choosing
theFadermode,press the VOL button 2to
adjustthefront-rear speaker balancetothe rear
speakers or the VOL button to adjust it to the
frontspeakers. Thefader positionwillbe shown
on the display panel from FAD R16 (full rear) to
FAD F16 (full front). When thelevelbetweenthe
front and rear speakers is equal, FAD 00 will be
shown on the display panel. The display will
automatically return to the normal indication 5
seconds after the last adjustment or when
another function is activated.
8LOUDNESS CONTOUR (LOUD)
When listening to music at low volume levels,
thisfeaturewill boostthebass andtrebleranges
to compensate for the characteristics of human
hearing. Press the button momentarily to
activate this feature and the indication LOUD
will appear on the display panel. Pressing the
button again momentarily will deactivate the
feature(theLOUD indicationwilldisappear from
the display panel).
9AUDIO MUTE SELECTOR (MUTE )
Press this button momentarily to mute the
volume from the system (MUTE will appear
blinking on the display panel). Pressing the
button again, adjusting the VOL buttons 2, or
pressing the LOUD button, equalizer (EQ)
button, or select (SEL) button, will return to the
volume level setting in use before the Mute
function was activated.
bl AM/FMBAND SELECTOR(RADIOBAND)
Eachtimethisbutton is pressed,theradio band
is changed. The indication AM1, AM2, FM1,
FM2 or FM3 will appear on the display panel
according to your selection.
During integral CD player operation, pressing
this button will stop play of the disc and switch
to radio operation without ejecting the disc.
During this time, the DISC IN indication will
remainonthedisplay panel to show thatadisc
is still loaded in the unit. Press the MODE
button toreturn to disc play from the beginning
of the last track in play.
bm MANUAL UP/DOWN TUNING (+ / -)
AUTOMATIC SEEK TUNING (SEEK)
To manually select a radio station, momentarily
press the (+) side of the TUNE/SKIP button
to advance the unit one digit higher or the
(-) side of the button to tune one digit lower.
Pressingeitherside ofthebutton forlongerthan
0.5 second will activate the Automatic Seek
Tuning function. The radio will seek the next
10
OPERATING INSTRUCTIONS

station in the selected direction and stop at that
frequency.
Press either side of the button again to resume
seektothe nextstationinthe selecteddirection.
bn LOCAL/DISTANT SELECTOR (LOC)
This feature is used to select the strength of the
signals at which the radio will stop during
AutomaticSeekTuning. Pressingthe buttonwill
select the Local setting (LOC will appear on the
display panel) and only strong (local) stations
will be received. Pressing the button again will
select the Distant setting (LOC will disappear
from the display panel) and the radio will stop at
awiderrange ofsignals,includingweaker(more
distant) stations.
bo FM MONO/STEREO SELECTOR (MON)
During FM radio operation, this button is used
to select mono or stereo reception of the
broadcast signal. Under normal reception
conditions, the unit should be left in the stereo
mode as indicated by the ST indication on
the display panel when tuned to an FM stereo
signal. If the stereo signal is too noisy for
comfortable listening, press the MON button to
switch to monaural reception (the ST
indicationwilldisappear fromthedisplay panel).
To return to stereo reception mode, press the
button again so that the ST indication
appears in the display panel.
bp PRE-SET SCAN (PS)
AUTO-STORE TUNING (AS)
Pressthisbuttonmomentarilytoscanthestations
pre-set into the six memories of each of the
AM bands or each of the FM bands. On each
selected band, the unit will stop at each pre-set
station for 5 seconds before continuing to the
next pre-set station (the pre-set number on the
display panel will flash during Pre-Set Scan
operation). Press the button again momentarily
to stop Pre-Set Scan operation and remain on
the selected frequency. If no buttons are
pressed during the scan, the unit will return to
the original station before the scan.
When the button is pressed and held for longer
than 2 seconds, the unit will beep and activate
the Auto-Store Tuning feature. The radio will
automatically scan and enter up to 6 stations
into the pre-set memories on the band in use.
If you have already set the pre-set memories to
yourfavoritestations,activating the Auto-Store
Tuning feature will erase those stations and
enter the new ones. This feature is most useful
when travelling in a new area where you are
not familiar with the local stations.
bq STATION PRE-SET MEMORIES
To set any of the 6 pre-set memories in each
band, use the following procedure:
1. Turn the radio on and select the desired
band.
2. Select the first station to be pre-set using the
Manual TUNE/SKIP Controls bm.
3. Press thepre-setbutton tobesetandcontinue
to hold it in for approximately 2 seconds. The
pre-set number will appear on the display
panel and two beeps will sound, indicating
that the station is now set into that pre-set
memory position. The station can now be
recalled at any time by pressing that button.
4. Repeat the above procedure for the remaining
5 pre-sets on that band and for the other 4
bands on the unit.
br LIQUID CRYSTAL DISPLAY PANEL
TheLiquidCrystal Display(LCD)paneldisplays
the frequency, time, and activated functions.
NOTE:It is a characteristic of LCD panels that,
if subjected to cold temperatures for an
extended period of time, they may take
longer to illuminate than under normal
conditions. In addition, the visibility of
the numbers on the LCD may slightly
decrease. The LCD read-out will return
to normal when the temperature
increases to a normal range.
11
OPERATING INSTRUCTIONS

bs FUNCTION DISPLAY (LEVEL METER)
The Function Display consits of five bar graphs
which provide a visual representation of the
volumeleveland thechannelsignal levels. The
volume level is represented by three thin bar
graphs. Asthevolumeisincreased, thenumber
of illuminated segments will increase. The
channel signal levels are represented by the
wider bar graphs. As the strength of the signal
applied to either the left or right channel
increases, the number of illuminated segments
will increase.
bt MODE SELECTOR (MODE)
This button is used to select the radio, or the
CD player/CD changer (if installed) playback
mode. Each press of the button will select a
differentmode asindicated onthedisplay panel.
During CD player operation, this button may be
used to change to radio or CD changer mode
without ejecting the disc. The DISC IN
indication will remain on the display panel to
showthatadisc is stillloadedin the unit. When
the CD changer is operating, the disc symbol
() will appear on the display panel. Press
the button again to return to radio or CD player
mode (DISC play resumes from the point at
which it was stopped).
bu DISC SLOT
Gentlyinsertthedisc into theslot(label surface
facing up) until the soft-loading mechanism
engages and pulls the disc in. The LOAD
indicationwillmomentarilyappearonthedisplay
panel followed by the total playing time of the
disc. The ( ) symbol illuminates and
becomes animated, and the PLAY indication
momentarily appears followed by the track
number and elapsed time.
CAUTION:This unit is designed for play of
ONLY. Do not attempt to use 3"
(8cm) CD-Singles in this unit, either
with or without an adapter, as
damage to the player and/or disc can
occur. Such damage will not be
covered by the Warranty on this
product.
cl TRACK SELECT (+ / - )
The Track Select functions are used to quickly
access the beginning of a particular track. Each
time the Forward Track Select (+) side of the
TUNE/SKIP button is pressed, the next higher
track number will be selected as shown on the
displaypanel. Similarly, eachtimethe Backward
TrackSelect( - ) sideofthebuttonis pressed,
the next lower track number will be selected as
shown on the display panel.
cm CUE/REVIEW FUNCTIONS (+ /-)
High-speed audible search to any section of the
disc can be made by the Cue and Review
functions. Press and hold the Cue (+) side
of the TUNE/SKIP button to advance rapidly in
theforwarddirection.(Theadvancingdiscplaying
time will be shown on the display panel) or the
Review ( -) side of the button to advance
rapidlyinthebackwarddirection (Thedecreasing
disc playing time will be shown on the display
panel). During either function, the elapsed time
within each track will automatically be shown on
the display panel.
cn TRACK ONE POSITION (TOP)
When the Track One Position (TOP) button is
pressed during disc play, play is quickly returned
to the begining of the CD, Track 1.
co TRACK SCAN SELECTOR (SCN)
Duringdiscplay,pressthis buttontoplay the first
10 seconds of each track on the disc (SCN will
appear on the display panel). When a desired
track is reached, press the SCN button again to
cancel the function (SCN will disappear from the
display panel) and play of the selected track will
continue. Scan mode will also be canceled by
activating the Repeat Play cp, Random Play cq,
MODE bt,TOPcn,orTrackSelect cl functions.
12
OPERATING INSTRUCTIONS

cp REPEAT PLAY SELECTOR (RPT)
During disc play, press this button to repeat the
play of the selected track (RPT will appear on
thedisplaypanel). Playofthe trackwill continue
to repeat until the button is pressed again and
the RPT indication disappears from the display
panel. RepeatPlaymodewill alsobecanceled
by activating the Scan co, Random Play cq, or
TOP cn functions.
cq RANDOM PLAY SELECTOR (RND)
During disc play, press this button to play the
tracks on the disc in a random shuffled order
(RND will appear on the display panel). In
Random Play mode, the Track Select function
cl will also select tracks in the random order
insteadofthenormalprogression. TheRandom
play mode can be canceled by pressing the
buttonagain(RND indicationwilldisappearfrom
the display panel) or by activationg the Repeat
Play cp, Scan co, or TOP cn functions.
cr DISC SELECT UP/DOWN (CD+/CD-)
DuringCDchangeroperation,these buttonsare
used to select the desired disc for play. Refer
tothesection describing CDChangerControls.
cs DISC EJECT ( )
Disc play is stopped and the disc is ejected
whentheEJECT( )buttonispressed(EJECT
appears on the display). Radio or CD changer
operation will automatically resume. If the disc
is not removed from the unit within 15 seconds
ofbeing ejected,itwillautomaticallybere-loaded
intotheunit topreventit frombeingaccidentally
damaged (DISC IN will appear on the display
panel to indicate that a disc is loaded in the
player). Play of the disc can be resumed by
using the MODE button bt to choose the CD
player function.
13
ct TIME/FREQUENCY SELECTOR (T/F)
During radio operation, press this button to call
thetimedisplayontheincorporatedquartzclock.
The display will return to the radio frequency or
discplayelapsed timeindicationafter5seconds
if the time is not being re-set.
cu EQUALIZER BUTTON (EQ)
The EQ button applies preset sound effects to
the unit’s audio output signal. The EQ
button,when pressed, will activate one of four
operating modes (no equalization, ROCK,
CLAS,orPOP). When theEQ function isactive,
the bass and treble levels cannot be changed.
When the EQ function is not active, the unit
returns to the user set bass and treble levels.
dl THEFT-DETERRENT LED
Located on the chassis behind the front panel,
a light-emitting diode (LED) will flash when the
panel is removed. The flashing light serves as
a visual warning to the would-be thief that the
unit has been disabled by removal of the front
panel.
dm RESET BUTTON
A RESET button is also accessible when the
front panel is removed, and can be used to
activate theresetcircuitry.However,thisfeature
should only be used under the following
circumstances as it will erase the time and
pre-set memories:
1.Upon initial installation after all wiring is
completed.
2.If thereisamalfunctionofanyof theswitches,
on the unit, pressing the RESET button may
clearthesystemandpermitareturntonormal
operation.
OPERATING INSTRUCTIONS

14
OPERATING INSTRAUCTIONS / SETTING THE CLOCK
1. Switch the vehicle ignition and radio “on”.
2. Press the Time/Frequency button to call the time display.
3. Press and hold the Time/Frequency Selector button ct, and then press the Down Tuning
(-) button to adjust the hours and AM/PM indication or the Up Tuning (+ ) button to
adjust the minutes to the correct time.
4. Five seconds after the button is released, following the last hour or minute adjustment, the
time will be set in the unit and the display will return to the normal indication.
SETSET
SETSET
SETTT
TT
TING THE CLOCKING THE CLOCK
ING THE CLOCKING THE CLOCK
ING THE CLOCK
dn FRONT PANEL RELEASE BUTTON
(RELEASE )
This button is used to release the mechanism
that holds the front panel to the chassis. To
detach the front panel, press the button so that
the panel releases on the right side. Then
carefully swing the right side out until the left
edge disengages. To re-attach the panel,
engage the left side first and then gently press
in the right side until the it clicks into place.
NOTES ON USE OF FRONT PANEL
1.Make sure the front panel is right-side-up
when attaching it to the chassis as it cannot
be attached when up-side down.
2.Do not press very hard on the front panel
when attaching it to the chassis. No more
than light to moderate pressure should be
needed.
3.When attaching the front panel, insert the
left side first, making sure it is properly
engaged in the chassis frame. Then
carefully press the right side into place until
the panel clicks into position.
4.When taking the front panel with you, please
use the supplied carrying case to protect the
panel from dirt and damage. Make sure
there is no dust or dirt on the electrical
terminals on the back of the panel as this
could cause intermittent operation or other
malfunctions.

Size: 7.875" W x 3.125" H x 6.5" D
200.025 mm x 79.375 mm x 165.1 mm
Operating Voltage: 12 volts DC, negative ground
Fuse Ratings: Constant (Yellow wire): 15 AMP.
Switched (Red wire): 0.5 AMP.
Output Power: 160wattsmaximum
(40 watts x 4 channels)
Output Wiring: Floating-ground type designed for 4 speaker use.
Front and rear channels CANNOT be combined
(bridged) for use with 2 speakers.
RCA low-level outputs (rear channels).
Output Impedance: Compatible with 4 – 8 ohm speakers.
Low-Level Output: 500 mv.
Tuning Range: AM: 530 – 1,710 kHz. (10 kHz. step)
FM: 87.5 – 107.9 MHz. (200 kHz. step)
Sensitivity: AM: 20 uv.
FM: 1.5 uv.
FM Stereo Separation: >20 dB
CD Frequency Response: 17 – 20 kHz. +0/-3 dB
CD Signal/Noise Ratio: >65 dB
CD Channel Separation: >65 dB
CD Distortion: 0.2%
*Specifications are subject to change without notice.
*SPECIFICATIONS*SPECIFICATIONS
*SPECIFICATIONS*SPECIFICATIONS
*SPECIFICATIONS
If a problem should develop while operating the CD player, an error code (ER-1, ER-2, ER-3,
etc.) may appear on the display panel. This can indicate a number of problems with the unit,
including a mechanical error or an error in the microprocessor control of the player. If an error
code should appear, try ejecting and re-loading the disc into the player. While the disc is out of
the unit, make sure it is clean, undamaged, and loaded correctly (label surface up). You may
also try activating the RESET button dm on the unit, but this will also erase the time and pre-set
memories.
If the suggested measures do not solve the problem, contact an approved warranty station near
you for further assistance.
CD PLCD PL
CD PLCD PL
CD PLAA
AA
AYER ERRYER ERR
YER ERRYER ERR
YER ERROR CODESOR CODES
OR CODESOR CODES
OR CODES
ERROR CODE / SPECIFICATIONS
15

16
CD CHANGER CONTROLS
the next higher track number will be selected
as shown on the display panel. Similarly, each
time the Backward Track Select ( -) sideof
the button is pressed, the next lower track
number will be selected as shown on the
display panel.
dsCUE/REVIEWFUNCTIONS(+ / -)
During disc play, high-speed audible search
to any section of the disc can be made by the
Cue and Review functions. Press and hold
the Cue (+) side of the button to advance
rapidly in the forward direction (the disc play
symbol will rotate forward on the display panel)
or the Review ( -) side of the button to
advance rapidly in the backward direction (the
disc symbol will rotate backwards on the
display panel).
dt TRACK/DISCSCAN SELECTOR(SCN)
During disc play, when the SCN button is
pressed, the SCN indication will appear on the
display panel, and the first 10 seconds of each
track on the disc will be played in order. When
a desired track is reached, press the SCN
button twice and play of the selected track will
continue (SCN will disappear from the display
panel). The Track Scan mode will also be
canceled by activating the Repeat, Random
Play, TOP, or MODE functions.
When the SCN button is pressed twice, the
DISC and SCN indications will appear on the
display panel and the first 10 seconds of the
first track on each disc in the magazine will be
played. When a desired disc is reached, press
the SCN button again and play of the selected
disc will continue (DISC and SCN will disap-
pear from the display panel). The Disc Scan
mode will also be canceled by activating the
Repeat Play, Random Play, TOP, or MODE
functions.
du DISC/TRACKREPEATPLAY (RPT)
During disc play, when the RPT button is
CD CHCD CH
CD CHCD CH
CD CHAA
AA
ANGER CONTRNGER CONTR
NGER CONTRNGER CONTR
NGER CONTROLOL
OLOL
OLSS
SS
S
Built into this radio are controls to operate an
optional CD changer. Please check with your
Rampage/Audiovox car stereo specialist or call
1-800-645-4994 for recommendations of the
models that will work with this radio.
Adjustment of the audio functions (volume,
tone, balance, and fader) for the CD changer
operate in the same manner as they do for
radio play. The following controls will operate
the CD changer when it is installed and
connected to this radio. Refer to the owner’s
manual included with the CD changer for
instructions on the installation and correct
loading and use of the CD magazine.
do CDCHANGER MODESELECTOR
(MODE)
During radio or CD player operation, press this
button to select operation of the CD changer
as shown by CdC on the display panel. Disc
play will begin and the disc and track number
will be shown on the display panel, as well as
the Cd-c indication. If a new magazine has
been loaded into the changer, play will begin
from the first track of the first disc in the magazine.
If a magazine was already in the changer, play
will resume from the track on the disc previ-
ously in play.
dp & dq DISC SELECT (CD+ & CD-)
During CD changer operation, these buttons
are used to select the desired disc for play.
To advance to a higher number disc, press
the CD+ button dp. To return to a lower number
disc, press the CD- button dq. The number of
the disc on play will be shown on the display
panel.
dr TRACK SELECT (+ / -)
During disc play, the Track Select functions are
used to quickly access the beginning of a
particular track. Each time the Forward Track
Select (+) side of the button is pressed,

1414
1414
14
If a problem should develop while operating the CD changer, the following error codes may
appear on the display panel.
ER-1: Indicates that there is no magazine loaded in the CD changer.
ER-2: Indicates a problem with the magazine eject function.
ER-3: Indicates an error in the disc loading function.
ER-4: Indicates an error in the disc un-loading function.
ER-5: Indicates an error in the magazine position.
ER-6: Indicates an error in the laser pick-up position.
ER-7: Indicates an error in the laser focus on the disc.
In any of the above situations, try ejecting the CD magazine from the changer and make sure
the discs are clean, undamaged, and loaded correctly (refer to the Owner’s Manual of the CD
changer). Re-load the magazine and check for proper operation. You may also try activating
the RESET button dm on the unit, but this will also erase the time and pre-set memories.
If the suggested measures do not solve the problem, contact an approved warranty station near
you for further assistance.
CD CHCD CH
CD CHCD CH
CD CHAA
AA
ANGER ERRNGER ERR
NGER ERRNGER ERR
NGER ERROR CODESOR CODES
OR CODESOR CODES
OR CODES
17
CD CHANGER CONTROLS / CD CHANGER ERROR CODES
pressed, the RPT indication will appear on the
display panel and play of the selected track
will be continually repeated until the Rrack
Repeat mode is canceled by pressing the RPT
button twice or by activating the Scan dt or
Random Play el functions.
WhentheRPTbuttonispressedtwice,theDISC
and RPT indications will appear on the display
panel and play of the selected disc will by
continuallyrepeateduntil theDiscRepeatmode
is canceled by pressing the RPT button again
orbyactivatingthe Scan, Random PlayorTOP
functions.
elDISC/TRACK RANDOMPLAY (RND)
During disc play, when the RND button is
pressed, the RND indication will appear on the
display panel and the tracks on the disc will be
played in a random, shuffled order. The Track
Select button dr will also select tracks in the
shuffledorder insteadofthe normalprogression.
The Random Track mode can be canceled by
pressing the RND button twice or by activating
the Scan dt or Repeat Play eu functions.
WhentheRNDbuttonis pressedtwice,the DISC
and RND indications will appear on the display
panel and the discs in the magazine will by
played in a random, shuffled order, as well as
the tracks on each disc. After playing a track
selectedatrandomfrom a disc inthemagazine,
the unit will select another disc at random and
play a randomly selected track on it. This will
continue until the Random Disc mode is
canceled by pressing the RND button again
or by activating the Scan dt, Repeat Play du
or TOP functions.

CARE AND MAINTENANCECARE AND MAINTENANCE
CARE AND MAINTENANCECARE AND MAINTENANCE
CARE AND MAINTENANCE
The radio section of your new sound system does not require any maintenance. We recommend
that you keep this manual for reference on the many features found in this unit as well as how to
set the clock.
The compact disc player section also requires no routine maintenance, but proper understanding
of its use and handling will help you obtain maximum enjoyment of its capabilities. The following
points should be observed:
lWhen cleaning the interior of the vehicle, do not get water or cleaning fluids on the unit.
lThe CD player is a precision instrument and will not operate properly in extreme heat or cold.
In case of such conditions, wait until the interior temperature of the vehicle reaches a normal
temperature before using the player.
lIf the temperature inside the player gets too hot, a protective circuit will automatically stop
play of the disc. In this case, allow the unit to cool off before operating the player again.
lNever insert anything other than a 5" (12 cm) compact disc into the player as the mechanism
can be damaged by foreign objects.
lDo not attempt to use 3" (8 cm) CD-Single discs in this unit, either with or without an adaptor,
as damage to the player and/or disc may occur. Such damage will not be covered by the
Warranty on this product.
lWhen not using the disc player, always remove the compact disc. Do not leave an ejected
disc sitting in the disc slot as this can expose it to sunlight and other causes of damage.
lDo not attempt to open the unit chassis. There are no user serviceable parts or adjustments inside.
lWhen the vehicle warms up during cold weather or under damp conditions, moisture may
condenseonthelens of thediscplayer. Should this occur, theplayerwill not operateproperly
until the moisture has evaporated.
lThe unit is designed with a vibration dampening CD mechanism to minimize interruption of
disc play due to normal vibration in a moving vehicle. When driving on very rough roads,
however, occasional sound skips may occur. This will not scratch or damage the disc and
normal play will resume when the rough conditions cease.
HANDLING COMPACT DISCS
Dirt, dust, scratches, and warpage can cause skips in the playback and deterioration of sound
quality. Please follow these guidelines to take care of your compact discs:
lUse only compact discs with the mark .
lFingerprints, dust, and dirt should be carefully wiped off the disc’s playing surface (shiny side)
with a soft cloth. Wipe in a straight motion from the inside to the outside of the disc.
lNever use chemicals such as record sprays, household cleaners or thinner to clean compact
discs. Such chemicals can irreparably damage the disc’s surface.
lDiscs should be kept in their storage cases when not in use.
lDo not expose discs to direct sunlight, high temperatures or high humidity for extended periods.
lDonotstick paper,tape,or labelsonthe discsurfacesnor writeonthem withanytype ofmarker.
CD CHCD CH CD CHCD CH
CD CHAA
AA
ANGER CONTRNGER CONTR
NGER CONTRNGER CONTR
NGER CONTROLOL
OLOL
OLSS
SS
S
CARE AND MAINTENANCE
18

AUDIOVOXCORPORATION(theCompany)warrantstotheoriginalretailpurchaserof
this product that should this product or any part thereof, under normal use and
conditions, be proven defective in material or workmanship within 12 months from the
date of original purchase, such defect(s) will be repaired or replaced with new or
reconditioned product (at the Company's option) without charge for parts and repair
labor.
To obtain repair or replacement within the terms of this Warranty, the product is to be
delivered with proof of warranty coverage (e.g. dated bill of sale), specification of
defect(s), transportation prepaid, to the warranty center at the address shown below.
ThisWarrantydoesnotextendtotheeliminationofcarstaticormotornoise,tocorrection
of antenna problems, to costs incurred for installation, removal, or reinstallation of the
product,ordamagetotapes,compactdiscs,speakers,accessories,orvehicleelectrical
systems.
This Warranty does not apply to any product or part thereof which, in the opinion of the
Company, has suffered or been damaged through alteration, improper installation,
mishandling,misuse,neglect,accident,orbyremovalordefacementofthefactoryserial
number/bar code label(s). THE EXTENT OF THE COMPANY'S LIABILITY UNDER
THIS WARRANTY IS LIMITED TO THE REPAIR OR REPLACEMENT PROVIDED
ABOVE AND, IN NO EVENT, SHALL THE COMPANY'S LIABILITY EXCEED THE
PURCHASE PRICE PAID BY PURCHASER FOR THE PRODUCT.
This Warranty is in lieu of all other express warranties or liabilities. ANY IMPLIED
WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY,
SHALL BE LIMITED TO THE DURATION OF THIS WRITTEN WARRANTY. ANY
ACTION FOR BREACH OF ANY WARRANTY HEREUNDER INCLUDING ANY
IMPLIED WARRANTY OF MERCHANTABILITY MUST BE BROUGHT WITHIN A
PERIOD OF 30 MONTHS FROM DATE OF ORIGINAL PURCHASE. IN NO CASE
SHALL THE COMPANY BE LIABLE FOR ANY CONSEQUENTIAL OR INCIDENTAL
DAMAGES FOR BREACH OF THIS OR ANY OTHER WARRANTY, EXPRESS OR
IMPLIED, WHATSOEVER. No person or representative is authorized to assume for the
Company any liability other than expressed herein in connection with the sale of this
product.
Some states do not allow limitations on how long an implied warranty lasts or the
exclusionorlimitationofincidentalorconsequentialdamageso theabovelimitations or
exclusions may not apply to you. This Warranty gives you specific legal rights and you
may also have other rights which vary from state to state.
12 MONTH LIMITED WARRANTY
U.S.A. : AUDIOVOX CORPORATION, 150 MARCUS BLVD., HAUPPAUGE, NY 11788 l1-800-645-4994
CANADA: CALL 1-800-645-4994 FOR LOCATION OF WARRANTY STATION SERVING YOUR AREA
128-4270E
WARR ANT Y
19

© 2000 Audiovox Electronics Corp., Hauppauge, NY 11788 128-5812A
