Audiovox PPC 6600 - Smartphone - Sprint User manual

PPC6600

PPC6600 User Manual2
PPC6600 User Manual 3

PPC6600 User Manual2
PPC6600 User Manual 3
Welcome
Congratulations on the purchase of a new Windows MobileTM-based PPC6600.
The integrated wireless voice and data capabilities mean that as well as keeping your
important PIM information up-to-date and close at hand, you can make calls, send and
receive e-mail, and look up valuable information from the Internet or your company’s net-
work anytime, anywhere. Also, with Microsoft ActiveSync the power of your device is
increased by allowing you to synchronize the information on your PC with your device.

PPC6600 User Manual 4
Regulatory
Notices
Welcome &
Safeguards
PPC6600 User Manual 5
Regulatory
Notices
Before getting started
Before using and exploring your new PPC6600, some warning notes and regulatory
information are very important for you to go through.
THE DEVICE IS NOT CHARGED WHEN YOU TAKE IT OUT OF THE
BOX. (For information, see Chapter 1 : Getting Started)
DO NOT REMOVE THE BATTERY PACK WHEN THE DEVICE IS
CHARGING.
IN MANY COUNTRIES YOU ARE REQUIRED BY LAW TO TURN
OFF YOUR PHONE WHEN YOU FLY. TURNING OFF YOUR PPC6600
DOESN’T TURN OFF YOUR PHONE; YOU MUST TURN OFF YOUR
WIRELESS CONNECTION TO YOUR OPERATOR’S NETWORK.
YOUR WARRANTY IS INVALIDATED IF YOU OPEN OR TAMPER
WITH THE DEVICE’S OUTER CASING. (For more information, see
the enclosed warranty information)

PPC6600 User Manual 4
Regulatory
Notices
Welcome &
Safeguards
PPC6600 User Manual 5
Regulatory
Notices
Important Safety Precautions
When using this product, the safety precautions below must be taken against possible
legal issues and damages.
n ELECTRICAL SAFETY
This product is intended for use when supplied with power from the battery pack BTR6600
Other usage will invalidate any approval given to this product and may be dangerous.
n SAFETY IN AIRCRAFT
Your phone can cause interference with an aircraft's navigation system and its network.
In most countries, using this product on board an airplane is against the law.
n SAFETY FOR ENVIRONMENTS
Do not use this product in gas stations, fuel depots, chemical plants or where blasting
operations are in progress, or in potentially explosive atmospheres such as fueling areas,
below deck on boats, fuel or chemical transfer or storage facilities, and areas where the
air contains chemicals or particles, such as grain, dust, or metal powders. Please be
aware that Sparks in such areas could cause an explosion or re resulting in bodily injury
or even death.
n SAFETY ON THE ROAD
Vehicle drivers in motion are not permitted to use telephony services with the handheld
device, except in the case of emergency. In some countries, using hand-free devices as
an alternative is allowed.
n SAFETY FOR MEDICAL EQUIPMENT
This product may cause malfunctions of medical equipment. In most hospital or medical
centers, use of this product is forbidden.
n NON-IONISING RADIATION
This product should be operated in the suggested normal condition only to ensure the
radiative performance and safety of the interference. As with other mobile radio transmitting
equipment, users are advised that for satisfactory operation of the equipment and for the
safety of personnel, it is recommended that no part of the human body be allowed to come
too close to the antenna during operation of the equipment.

PPC6600 User Manual6
Contents
PPC6600 User Manual 7
Contents
Contents
Chapter 1 Gettng Started
1.1 Connaître votre appareil........... 12
1.2 Battery...................................... 14
1.3 Accessories.............................. 16
Chapter 2 Knowing Your PPC6600
2.1 Starting Up ............................... 20
2.2 Entering Information................. 26
2.3 Writing on the Screen............... 30
2.4 Drawing on the Screen............. 32
2.5 Recording a Message .............. 33
2.6 Finding Information................... 34
Chapter 3 Using Your PPC6600
3.1 About Your Phone .................... 36
3.2 Making a Call............................ 40
3.3 Receiving a Call ....................... 43
3.4 In-Call Options.......................... 44
3.5 Contacts Information ................ 46
3.6 Additional Dialing Information... 48
3.7 Secure Your Phone .................. 48

PPC6600 User Manual6
Contents
PPC6600 User Manual 7
Contents
Chapter 4 Synchronizing Information
4.1 Using ActiveSync...................... 52
4.2 Synchronizing Information........ 54
4.3 Synchronizing Using an
Infrared Connection ................. 56
4.4 ActiveSync Errors..................... 57
Chapter 5 Personalizing Your PPC6600
5.1 Device Settings ........................ 60
5.2 Phone Settings......................... 68
Chapter 6 Using Outlook
6.1 Calendar.................................. 74
6.2 Contacts .................................. 76
6.3 Tasks ....................................... 79
6.4 Notes....................................... 81
Chapter 7 Getting Connected
7.1 About Connections .................. 84
7.2 Connect to the Internet............ 84
7.3 Terminal Services Client.......... 87
7.4 Bluetooth ................................. 89

PPC6600 User Manual8
Contents
PPC6600 User Manual 9
Contents
Chapter 8 Messaging Features
8.1 E-mail Messages: Using Inbox104
8.2 Messaging............................. 108
8.3 MSN Messenger.................... 109
8.4 Managing Messages and
Folders ...................................111
Chapter 9 Applications
9.1 Pocket Word.......................... 114
9.2 Pocket Excel.......................... 117
9.3 Windows Media Player
for PPC6600 ......................... 119
9.4 Pictures ................................. 120
Chapter 10 Using Camera and Album
10.1 Before Using the Camera ...... 124
10.2 Camera.................................. 125
10.3 Album ................................... 135

PPC6600 User Manual8
Contents
PPC6600 User Manual 9
Contents
Appendix
Adding or Removing Programs...... 146
Managing Memory ......................... 148
Backing Up Files ............................ 150
Reset the PPC6600 and
Clear Memory ............................... 151
Regulatory Agency IDs...................153
FCC Compliance Statement...........153
Important Health and Safety
Information......................................154
Specication....................................160
Troubleshooting...............................162

PPC6600 User Manual10
Contents

Chapter 1
Getting Started
1.1 Knowing Your Device
1.2 Battery
1.3 Accessories

Getting
Started
PPC6600 User Manual12
Getting
Started
PPC6600 User Manual 13
1.1 Knowing Your Device
Front , Top and Left Side Panel Components
Record
Press to record a voice note/
launch voice commander.
Volume
Press up/down to adjust the
volume of your device.
Camera
Press to launch camera
/video program. Press again
to take a picture.
Infrared Port
Enables you to exchange
file(s) or data with other
devices without cables/
wires.
Start
Press to display program
menu.
Send
Press to answer an incoming
call or to dial a number.
Messaging
Press for quick access to
email/MSN messages.
Power Button/Backlight
Press to turn on/off your
PPC6600 or Backlight.
Earphone Plug
Allows you to listen to audio
media or use the phone's
hands-free kit.
Speaker
Listen to audio media or a
phone call from here.
Calendar
Press for quick access
to your calendar.
Touch Screen
Pocket IE
Press for quick access
to WEB and WAP sites.
OK/Close
End
Press to end a call.
MMC/SD cards or SDIO
accessories slot
Insert either MMC/SD cards or SDIO
accessories in this slot.
Contact
Press for quick access
to your Contacts.
Navigation Pad
Press to move up/down and
left/right through any of the
drop down menus or program
instructions; select by pressing
in the center. When in the
dialer screen:
Left - Press once to access
the Speed Dial feature.
Right- Press once to access
the Call History feature.
QWERTY Keyboard
Silde the screen up to
access. Press to enter
letters/symbols.

Getting
Started
PPC6600 User Manual12
Getting
Started
PPC6600 User Manual 13
Back, Bottom and Right Side Panel Components
Built in Flashlight
Preview Mirror
Camera Lens
Back Cover
Fixing Lock
Press to release the back
battery.
Microphone
Speak here when receiving or
making a phone call or voice
recording.
Sync Connector
Use this connector when
synchronizing / transmitting
data or recharging.
Antenna Connector
If available, you can attach your
phone to its antenna and utilize
its superior reception quality.
Stylus and Stylus Slot
Notication LED
Bi-color LED on the right:
• Flashing Green (Every 3
seconds) – CDMA Network
Signal.
• Flashing Red (Every 1.5
second) – Notication/
Alarm/ Reminder/ Missed
call
• NO LED Light – CDMA
Network Detached or Mobile
is OFF.
• Steady Red – Battery empty
when plugged in AC Adapter.
• Flashing Red – Low battery.
• Steady Amber – (DC-in)
Battery charging with AC
Adapter or USB port.
• Steady Green – (DC-in)
Battery fully charged.
Blue LED on the left:
• Flashing Blue (Every 6
seconds) – Blue Tooth is On
• No LED light – BT is OFF.
Soft Reset
Press here with stylus to
reset your device.

Getting
Started
PPC6600 User Manual14
1.2 Battery
Warning : To reduce risk of fire or burns, do
not disassemble, crush, puncture, short external
contacts, heat above 60℃(140℉), or dispose of
in fire or water. Replace only with manufacturer
specified batteries. Recycle or dispose of used
batteries to the local regulations.
Your PPC6600 contains a rechargeable Li-ion polymer battery
under the back cover. Battery power depends on whether you
are talking on the phone, using the PDA functions or if the
device is on standby.
Battery life estimates :
Talk-time: 3 ~ 4 hrs,
PDA: 15 hrs (approx.),
Standby: 168 hrs (approx.),
Data retention time: 72 hrs.
The above times are based on using one function at a time,
interchanging between functions will vary the battery life.
Data Retention
It is vital to keep your battery charged. Because your
PPC6600 does not have a hard drive, all data and any new
programs you install are stored in RAM. If the battery com-
pletely drains any data or new programs you installed will be
erased. Only the default programs on the device when you
bought it will remain.
To prevent this kind of data loss, a portion of the main battery
will keep your data safe for 72 hours if your device runs out
of power. The additional backup is designed to keep your
data safe when you remove the main battery. It will keep this
data safe for 20 minutes.
WARNING : BEFORE REMOVING THE MAIN
BATTERY, MAKE SURE THE BACKUP BATTERY
POWER REMAINS AT 50% OR ABOVE, BY
TAPPING → Settings → System tab →
Power


Getting
Started
PPC6600 User Manual14
Getting
Started
PPC6600 User Manual 15
Recharging your device
You can recharge your device in the following ways:
1
Place your PPC6600 in the cradle and connect
the cradle to an external power source with the
AC Adapter. Before using your PPC6600 for the
rst time, charge the battery for at least 8 hours.
Then, place it in the cradle for a short time each
day to recharge it to its full capacity.
2
Plug the AC Adapter into the optional USB cable
head and then connect your PPC6600 directly
to an external power source.
3
Plug the AC Adapter into the optional AC Adapter
Converter and then connect the sync connector
of your PPC6600 directly to an external power
source without using the cradle.
4
If you have a spare battery for your PPC6600,
you can put the battery into the slot in the cradle
for recharging.
To the sync
connector of your
PPC6600
To AC Adapter
AC Adapter plugs
into the back of the
cradle
Put a spare
unit into
the slot for
recharging
To your
PPC6600
Plug the AC adapter
into a socket
USB
synchronization
cable, connect to
your PC

Getting
Started
PPC6600 User Manual16
When Your Battery is Low
When the low battery-warning message appears, immediately save any data you are
working on, perform a synchronization with your PC, then turn off your PPC6600. If your
device does shut down, the backup portion of your main battery will protect the data for
about 72 hours.
To view the battery status:
Tap →Settings → System tab → Power.
ALWAYS KEEP THE POWER STATUS OF THE BACKUP BATTERY AT
LEAST AT 50% OR ABOVE.
AC Adapter plugs into
the back of the cradle for
battery recharging
1.3 Accessories
USB Cradle
Your PPC6600 comes with a USB cradle. This allows you to
recharge your PPC6600 with the AC ADAPTER, as well as
synchronize information between your PPC6600 and a PC
using ActiveSync.
To synchronize, the USB Cradle must be plugged
into an available USB port on your PC.
For battery recharging, you must plug the AC
Adapter into the back of cradle.

Getting
Started
PPC6600 User Manual16
Getting
Started
PPC6600 User Manual 17
AC Adapter Converter
The AC Adapter converter in combination with the AC Adapter allows you to recharge
your device without the cradle.
USB Sync Cable
The USB cable ( user's optional item) allows you to synchronize with your desktop with-
out the cradle. The AC converter also allows you, in combination with an AC Adapter,
to recharge your device.
Stereo Headset
The stereo headset has a volume control jog dial
and a button to press to answer a phone call.

Getting
Started
PPC6600 User Manual18

Chapter 2
Knowing Your PPC6600
2.1 Starting Up
2.2 Entering Information
2.3 Writing on the Screen
2.4 Drawing on the Screen
2.5 Recording a Message
2.6 Finding and Organizing
Information
