Audiovox D1809 - DVD Player - 8 User manual

D1809
8"LCD MONITORWITHDVDPLAYER
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

2
ImportantSafetyInstructions
Someofthe following information maynotapplytoyourparticularproduct;
however,aswithanyelectronicproduct,precautionsshouldbe observed
duringhandlinganduse.
lRead theseinstructions.
lKeeptheseinstructions.
lHeedallwarnings.
lFollowall instructions.
lDonotusethisapparatusnearwater.
lClean onlywithdrycloth.
lDonotblock anyventilationopenings.Install inaccordancewiththe
manufacturer sinstructions.
lDonotinstall nearanyheatsourcessuchasradiators,heat
registers,stoves, orotherapparatus(includingamplifiers)thatpro-
duceheat.
lDonotdefeatthesafetypurposeofthepolarizedorgrounding-type
plug.Apolarizedplughastwobladeswithonewiderthanthe other.
Agroundingtypeplughastwobladesandathirdgroundingprong.
Thewidebladeorthethirdprongisprovidedforyoursafety.Ifthe
providedplugdoesnot fitintoyouroutlet, consult anelectricianfor
replacementofthe obsoleteoutlet.
lProtect thepowercordfrombeingwalked on orpinched particu-
larlyatplugs,conveniencereceptacles, and thepointwherethey
exitfromtheapparatus.
lOnlyuseattachments/accessoriesspecified bythe manufacturer.
lUseonlywiththecart, stand,tripod,
bracket, ortablespecifiedbythe
manufacturer,orsoldwiththeapparatus.
Whenacart isused,usecaution when
moving the cart/apparatuscombinationto
avoidinjuryfromtip-over.
lUnplug thisapparatusduringlightningstormsorwhen unused for
long periodsoftime.
lReferall servicing toqualified servicepersonnel.Servicing isre-
quired when theapparatushasbeen damagedinanyway,suchas
power-supplycordorplug isdamaged, liquidhasbeen spilled or
objectshavefallenintotheapparatus,theapparatushasbeenex-
posed torainormoisture, doesnotoperatenormally,orhasbeen
dropped.
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

3
Additional SafetyInformation
lApparatusshall notbe exposed todrippingorsplashing and no
objectsfilledwithliquids,suchasvases,shallbeplacedonthe
apparatus.
lAlwaysleavesufficientspacearound theproductforventilation.Do
notplaceproductinoronabed, rug,inabookcaseorcabinetthat
maypreventairflowthroughvent openings.
lDonotplacelightedcandles,cigarettes,cigars,etc.ontheproduct.
lConnect powercordonlytoACpowersourceasmarked on the
product.
lCareshouldbetaken sothatobjectsdonotfallintothe product.
lDonot attempttodisassemblethecabinet. Thisproductdoesnot
containcustomerserviceablecomponents.
lDonot usetheunitimmediatelyaftertransportation fromacold
placetoawarm place;condensation problemsmayresult. Wait
foraboutonehourtillthe moistureevaporatesbeforeoperating
theunit.
lWhen using yourportableDVDplayer, donotsitorstandtoo
closetothe screen.
lTouseaheadsetsafely,pleasekeepthefollowing inmind:
-Donotplayyourheadset at ahigh volume.Hearingexperts
adviseagainstcontinuousextendedplay.
-Ifyouexperienceringing inyourears,turndownthevolumeor
stop usingtheheadset.
-Donotuseaheadset whiledriving amotorizedvehicleorriding
abike.It maycauseatraffichazardandisillegalinmanyareas.
-Evenifyourheadsetisanopen-airtype designedtoletyouhear
outside sounds, don tturnupthevolumesohigh thatcan t hear
soundsaroundyou.
lCAUTION!CD andDVDproductsutilizealaser. Donot tryto
open the product.Referallservicingtoqualifiedservice
personnel.
lCAUTION!Dangerofexplosion ifbatteryisincorrectlyreplaced.
Replaceonlywiththesameorequivalenttype.
lWarning:YourDVDplayercontainsabatteryandcharging sys-
temwhichisdesigned toworkintemperaturesthatdonotex-
ceed50oC(122oF).Leavingthisproductinaclosed automobile
orinthetrunkofan automobilewheretemperaturemayexceed
50oCmayresultinpermanentbatterydamage, fire,orexplosion.
Pleaseremoveyourproductfromtheautomobilewhen youexit,
donotplaceyourproductinthetrunkofyourautomobile, and do
notleaveyourproduct inanylocationwheretemperaturemay
exceed50oC.
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

4
WARNING: TOPREVENTFIREORELECTRICALSHOCKHAZARD,DONOT
EXPOSETHISPRODUCTTORAINORMOISTURE.
FCC Information
Thisdevicecomplieswithpart15oftheFCCrules. Operation issubject
tothe following twoconditions: (1)Thisdevicemaynot causeharmful
interference,and(2)Thisdevicemustacceptanyinterferencereceived,
including interferencewhichmaycauseundesired operation.
Thisequipmenthasbeentestedandfound tocomplywiththelimitsfora
ClassBdigitaldevice,pursuant toPart 15oftheFCCRules.These
limitsaredesignedtoprovidereasonableprotectionagainstharmful
interferenceinaresidentialinstallation.Thisequipmentgenerates,uses
andcan radiateradiofrequency energyand, ifnotinstalled andused in
accordancewiththe instructions,maycauseharmfulinterferencetoradio
communications. However,thereisno guarantee that interferencewill
not occurinaparticularinstallation.
Ifthisequipment doescauseharmfulinterferencetoradioortelevision
reception,whichcanbedeterminedbyturning theequipmentoff andon,
theuserisencouraged totrytocorrect theinterferencebyone ormore
ofthe followingmeasures:
-Reorientorrelocatethe receiving antenna.
-Increasethe separationbetween theequipmentand receiver.
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

5
Service Information
Thisproductshouldbeservicedonlybythosespeciallytrainedinappro-
priateservicing techniques.Forinstructionson howtoobtainservice,
refertothewarrantyincluded inthisusermanual.
Manufacturer/ResponsibleParty
AudiovoxElectronics Corp.,
150MarcusBlvd., Hauppauge,NY11788
ForYourRecords
Keep yoursalesreceipt forproofofpurchasetoobtainwarrantyparts
and service.
Intheeventthatserviceshouldbe required,you mayneedboththemodel
numberandthe serialnumber.Inthe spacebelow,recordthedateand
placeofpurchase,and theserialnumber:
ModelNo.
DateofPurchase
PlaceofPurchase
SerialNo.
-Connectthe equipmentintoanoutleton acircuitdifferentfromthat to
whichthe receiverisconnected.
-Consultthe dealeroranexperiencedradio/TVtechnicianforhelp.
InaccordancewithFCCrequirements,changesormodificationsnot
expresslyapproved bymanufacturercouldvoidthe user sauthorityto
operatethisproduct.
ThisclassBdigitalapparatuscomplieswithCanadianICES-003.
Cetappareil numérique de laclasseBest conforme àlanorme
NMB-003 duCanada.
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

6
Content
A.Introduction............................................................................7
B.DVDandDiscInformation.....................................................7
C.Contents...............................................................................8
D.Poweringandinstallation.....................................................8
E.Controls,Indicators,and Connectors............................ 9
F.LoadingandPlayingaDisc.................................................10
G. BasicOperation......................................................................11
H. Menu.................................................................... 12
I. Display...................................................................................12
J.PlayingAudioCDs................................................................18
K.PlayingJPEGFiles..............................................................19
L.Connecting toOtherEquipment............................................20
M.Setup....................................................................................21
N.Specifications......................................................................29
O.RechargeableBuilt-inBatteryuse.......................................29
P.Troubleshooting ................................................................. 31
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

7
A. Introduction
Thankyou forchoosing the D1809portableDVDplayer. The main
featuresinclude a8"wide Screen (16:9AspectRatio)LiquidCrystal
Display(LCD)monitorandaDVDplayer.Theunitappliesthelatest
stateofthe art electronics and isdesigned foruseinhotels, offices
oryourhome.The unitisconstructedtoprovide yearsofreliable,
trouble-free serviceand iscompact sothatyoucan takeit withyou
anywhereandisdesignedforquickandeasy installation.Pleaseread
theentireinstruction manualsuppliedwiththisproductpriortousing.
Thedocumentationwillassistyouinusingthesystemproperlyto
obtainthe bestequipmentperformance.Pleasesavethismanualfor
lateruse.
B.DVDandDisc Information
DVDCopyProtection -ThisProductincorporatescopyright
protection technologythatisprotectedbymethod claimsofcertain
U.S.Patentsand otherintellectualpropertyrightsownedby
Macrovision Corporation and otherrightsowners.Useofthis
copyrightprotection technologymustbe authorized byMacrovision
Corporation,and isintended forhomeand otherlimitedviewing
usesonlyunlessotherwiseauthorized byMacrovision Corporation.
Reverseengineeringordisassemblyisprohibited.
DVDRegionalCode - YourDVDplayer
hasbeen designed toprocess regional
managementinformation thatisstored
on DVDdiscs.The regionalcode foryourplayeris1(The U.S.,U.S.
TerritoriesandCanada).OnlyDVDdiscsthathaveregionalcodesof
1orALL(forall regions)can beplayed byyourplayer.
Disc- Donotuseirregularlyshaped discs suchasheartorstar-
shapeddiscsastheymaycausetheunittomalfunction.Donotstick
paper, tape orglueon thedisc.Donotexposethe disctodirectsun-
lightorheatsourcessuchashotairducts.Donot touchthe surface
ofdisc.Handlethediscbyitsedge.Cleanthe disc bywipingthedisc
fromthe centerout withacleaning cloth.Removethe disc fromthe
unitandstoreitinitscaseafterplaying.Someplaybackoperationsof
discsmaybeintentionallyfixedbysoftwareproducers.Sincethis
unitplays discs according tothe disc contentsthesoftwareproduc-
ersdesigned,someplaybackfeaturesmaynotbeavailable.Also
refertothe instructionssupplied withthe discs.
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

8
C. Contents
1.1x8 LCDMonitorand DVDPlayer
2.1xRemoteControlwithBattery(CR2025)
3.1xAudio/VideoCable
4.1xACtoDC Adapter
5.1xDC PowerAdapter
6.1xInstruction Manual
7.1xProduct Registration Card
8.1xeMusicCard
D.PoweringandInstallation
1. Powering theSystemIndoors (RefertoFigure1)
PlugoneendoftheACtoDCadapterintothe DCinputjackonthe
rightsideofthemainunit, then plugthe otherendintothe 100~240V
ACpowerreceptacle.
2. Powering theSysteminaCar
Plugone end ofthe DCPoweradapterintothe DC inputjackon
theunit,thenplug theotherend intothevehiclepoweroutlet.
Figure1
3.ToChargetheBuilt-inBattery
Plug oneendofthe ACtoDC adapterintotheDCjack on theside
oftheplayer,asshowninFigure1,thenplugtheotherendintothe
100~240VACpoweroutlet.Makesurethatthe player spowerslide
switchisinthe “OFF/CHG.”position,Thechargelightwillflashfor
about3seconds,then itturnstored.Oncefullycharged,the LED
indicatorwill be green,thenremovetheACtoDCadapterwallplug.
NOTE: Yournewbatterymust be charged aminimumof8hours
beforethefirstusage. Eachfullrechargetakesapproxi-
matelyfivehoursandonefullchargecanprovidepowerto
theplayerforapproximately2hours.
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

9
E.Controls, Indicators,andConnectors
1. UnitView (RefertoFigure2)
Figure2
1)LCD PanelShutOff Switch
2)Wide Screen Button
3)StopButton
4)PreviousButton
5)NextButton
6)Play/PauseButton
7)Menu Button
8)UpButton
9)RightButton
10)OKButton
11)DownButton
12)Left Button
13)Open DoorSwitch
14)IRSensor
15)PowerLED
16)Poweron/off Switch
17)VolumeControl
18)Headphone 1*
19)Headphone2
20)ChargeIndicator
21)AVOutJack
22)DC 9-12VInputJack
*Usingheadphone jack1will disabletheinternalspeakers.
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

10
2. RemoteControl (RefertoFigure3)
F.LoadingandPlayingaDisc
a.Afterconnecting powertotheunit, applypowertotheDVDplayer
bysliding the POWERON/OFF switchtoON.The powerindica-
torwill be green.
b.Open the disctraybyslidingcoverOPENswitchandplaceadisc
ontothetraywiththelabelsidefacing up.
c. Closethe traybypressing the area marked “PUSHTO CLOSE”.
The unitwill loadthe disc and startplaying.
d.RotateVOLUMEcontroltoadjustthe DVDplayer svolume.
e.Tostop playing adisc,press theSTOPbutton.
f. Toturnoffthe DVDplayer,slide the POWERON/OFF switchto
OFF.
Figure3
1)SETUPButton
2)UPButton
3)PREVIOUSButton
4)ENTERButton
5)REVERSE/LEFT Button
6)DOWNButton
7)NUMERICButtons
8)DISPLAYButton
9)ZOOMButton
10)SUBButton
11)NEXTButton
12)A-BREPEATButton
13)FORWARD/RIGHTButton
14)1/AllREPEATButton
15)STOPButton
16)MENU Button
17)AUDIOButton
18)ANGLEButton
19)PLAY/PAUSEButton
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

11
G. BasicOperation
POWER
OPEN
PLAY
PAUSE
STOP
NEXT
PREVIOUS
FORWARD
REVERSE
LEFT/RIGHT/UP/DOWN
ENTER
NUMBERS
MENU
REPEAT
A-B
DISPLAY
ANGLE
SUBTITLE
AUDIO
ZOOM
SETUP
Turnthe uniton/off
Remove/load the disc
StartPlay/Executeitemorsetting
StillPicture
(1time)Stopatthe presentplaying point/
(2times)Stopplaybackofthe DVD/CD
Gotothenextchapter,track orscenedur-
ing playback
Goback tothepreviouschapter,track or
sceneduringplayback
Scanforwardat2,4, 8,16 or32xtimes
speed
Scan backwardat2,4, 8,16 or32xtimes
speed
UsedforMenu Navigation
Executeitemorconfirmsetting
Selectitemorsetting
Displaythemain menuofthedisc
Repeatplayingtitle,chapter,ortrack
Repeataspecificportion frompointAto
pointBofthedisc
Displayinformation(title,chapter, track,
time,etc.)
Change the viewing anglesonthescene
Selectthesubtitle languageandturniton/
off
Selectthe audiolanguage
Enlargeanimageto2,3,or4timesthe
originalsizeduringDVDplayback.
Displaythe setup menu toselectand set
items,and exitthe setup menu.
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

12
H. Menu
ADVDisdividedintosectionscalledtitlesandchapters.Whenyou
playaDVD,aroot menu ofthediscwillappearon thescreen ofyour
TVorMonitor.Thecontentsofthemenuvaryfromdisctodisc.Press
MENUduring playbacktodisplaythemenu.SomeDVDsonlyallow
you toselect disc playback optionsusing the DVDrootmenu.
I.Display (Displaycontentsvaryfromdisctodisc.)
1. Playing Timeand Remaining Time
a.During playbackpresstheDISPLAY buttontodisplaythe current
TitleNumber(1),the totalNumberofTitles(2),the currentChap-
terNumber(3),thetotalNumberofChapters(4),andtheelapsed
playingTimeforthetitle(5).Theheadingwilldisappearautomati-
callyafter3secondsifno buttonsarepressed.
b. Press DISPLAYbutton againtodisplaythe Remaining Timeof
the title. The heading will disappearautomaticallyin3seconds.
TitleRemainingTimeScreenDisplay
Title,ChapterNumberandTimeScreenDisplay
Tt0101Ch021700000//::
Tt0101Ch021700000// ::
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

13
c. PressDISPLAYbutton athirdtimetodisplaythe Elapsed Time
forthechapter. Theheadingwilldisappearautomaticallyin3
seconds.
d.PressDISPLAY buttonafourthtimetodisplaytheRemaining
Timeforthechapter.The headingwilldisappearautomaticallyin
3seconds.
e.PressDISPLAYbuttonafifthtimetoexit, ‘DISPLAYOFF willbe
displayed and willdisappearautomaticallyin3seconds.
NOTE: Toselect theChapteryouwant, enterthenumberofthe
Chapteryouwantontheremotewhileinanydisplaymode.
The information forChapterand Titlewillbe displayedand
thenumberoftheChapteryouselected willbe highlighted.
Press ENTERbutton toconfirm the selection.
ChapterElapsedTimeScreenDisplay
ChapterRemainingTimeScreenDisplay
Tt0101Ch021700000// ::
Tt0101Ch021700000// ::
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

14
*SomeDVDsonlyallowaccesstothisfunctionthroughtheDVD
menu.
3. Subtitle
DuringdiscplaybackpressSUBbuttontoselectthe subtitle
language you desire*,withthe currentSubtitleLanguageNumber
(1)and thetotalNumberofSubtitleLanguages(2)displayed.If
therearemultiplelanguagespressSUBbuttonagaintoselect
anothersubtitlelanguage.ToturnsubtitlesOFF,press the SUB
button until ‘SUBTITLEOFF isdisplayed.The Subtitledisplaywill
disappearautomaticallyifthe SUBbutton isnotpressed againwithin
3seconds.
AngleScreenDisplay
Subtitle0102/
SubtitleScreenDisplay
2.Angle
Duringplaybackofadisc,pressANGLEbuttontodisplaytheavail-
ableanglesfordiscscontaining multi-angles*,withthecurrentangle
number(1)andthe totalnumberofangles(2)displaying.Press
ANGLEbuttontoselectotherangles.
*NOTE:Notalldiscscontainthisfeature.
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

15
4.Audio
During playback pressAUDIObutton toselectthe audiolanguage
youdesire*,withthe current AudioChannelNumber(1)and the
totalnumberofAudioChannels(2)displayed.Press AUDIOagain
toselectanotheraudiolanguage. The audiodisplaywill disappear
automaticallyifthe AUDIO buttonisnotpressedwithin3seconds.
AudioLanguageScreenDisplay
*SomeDVDsonlyallowaccess tothisfunctionthrough theDVD
menu.
5.Zoom
During playback press ZOOMbutton toenlarge thepictureby2x,
3xor4Xwiththe current zoommultiple. Press ZOOMbuttonone
time,thepicturewill be enlarged 2X.PressZOOMbuttonasecond
time,the picturewillbeenlarged 3X.PressZOOMbuttonathird
time,the picturewill be enlarged 4X. Press ZOOMbutton afourth
time,the picturewill returntonormalsize.
ZOOMScreenDisplay
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

16
6.A-BRepeat
a.Duringplayback pressA-BbuttontosettheStartingPointA.
A-BRepeatStartingPointScreenDisplay
b.PressA-Bbuttonasecond timetosetthe Ending PointBand
theplayerwillrepeatedlyplaythepartbetweenPointAand
PointB.
A-BRepeatCancelledScreenDisplay
A-BRepeatEnding PointScreenDisplay
c. Press A-Bbutton athirdtimetocancelA-Brepeatand resume
normalplayback.
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

17
All
7. Repeat
a.Duringplaybackpress1/ALL buttononcetorepeatedlyplaythe
currentchapter.
ChapterRepeatONScreenDisplay
b.During playbackpress 1/ALLbutton againtorepeatedlyplaythe
currenttitle.
TitleRepeatONScreenDisplay
c.Duringplaybackpress1/ALLbutton athirdtimetorepeatall
chaptersand titles.
AllRepeatONScreenDisplay
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

18
d.Press 1/ALL button afourthtime,toresumenormalplayback.
RepeatOff ScreenDisplay
8. Forward/Reverse Scan
a. During playback press uu toscanforwardat2x,4x,8x,16x,
32xand normalspeed.
b.During playback press tt toscanbackwardat2x,4x,8x,16x,
32xand normalspeed.
J. PlayingAudioCDs
WhenanCDdiscisputintotheunit,theMenuScreenappears.Youcan
useUpand DOWNbutton tochoosethe song you desired.Press ENTER
buttontoplay.
Menu Screen
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

19
1.UsingtheRepeatFeature
ThedefaultmodefortheRepeatfeatureisOFF.Pressing1/ALLbutton
consecutivelychangestherepeatoptions:
•RepeatOne-repeatsthe track thatisplaying.
•RepeatAll- repeatsthe discthatisplaying.
•RepeatOff
Asyoutogglethroughtheoptions,therepeatoptionchanges. The
selectedrepeatoption loopsrepeatedlyuntil you turnitoff.
2.A-BRepeat
a.During playback press A-Btosetthe Starting PointA.
b.Press A-Basecond timetosetthe Ending PointBand the
playerwill repeatedlyplaythepartbetween PointAandPointB.
c.Press A-BathirdtimetocancelA-Brepeat and resumethe
normalplayback.
3. Forward/Reverse Scan
a.Duringplaybackpress uu toscanfowardat2x,4x,8x,16x,32x
and normalspeed.
b.During playback press tt toscan backwardat2x,4x,8x,16x,
32xand normalspeed.
K.PlayingJPEG Files
1)LoadaJPEGdiscontothedisctray.
2)Ascreen showing foldersorpicturefilescontainedon the disc
willbedisplayed automaticallyafterloading.
3)Press UP,DOWNandENTERbutton toselectafolderora
picture. Ifapictureisselected, photoslideshowwill startwiththe
selected picture.
4)Press theDOWNbutton torotatethe pictureclockwise.
5)Press the ZOOMbutton toenlarge the picturesizeby125%,
150%, 200%orzoomoutby75%,50%and then returntothe
originalsize.When the image isenlarged,youcanusethe
navigation buttonstoviewblockedpartsofthe picture.
6)Press UPorSTOPbutton toreturntothescreen showing
foldersorpicturefiles.
7)PressPLAY/PAUSE button thenthe slideshowwill pause.Press
thebuttonagaintoresumethe slideshowplayback.
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

20
L.ConnectingtoOtherEquipment
1.AVOut
Connecting toaTVorAnotherMonitor (RefertoFigure4)
Connecttheblack end(1/8”plug)ofthe audio/videocableintothe
unit sDVD sA/VOUTjack,andconnectthe otherendtothe
AUDIOINPUTjacksonyourTVorMonitorusing an additionalsetof
AVcable(notincluded)(white=left audiochannel,red=rightaudio
channel,yellow=video).
Figure4
2.ConnectingHeadphones(Notincluded)
SimplyplugtheheadphonesintoeitherHeadphonejack 1or
Headphonejack 2onthe leftside oftheDVDPlayer.
(RefertoFigure5)
Figure5
Plugging intoHeadphonejack1willdisablethe internalspeakers.
notincluded
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com
