Audiovox D8000IP User manual

D8000IP
8" LCD MONITOR AND PORTABLE DVD WITH DOCK FOR
IPOD
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

2
AnLCDpanel and/or videomonitormaybeinstalled in amotor vehicle
and visible to the driver ifthe LCD panelor videomonitor is used for
vehicle information, system control, rear or side observationor
navigation.If the LCDpanelor video monitor is usedfortelevision
reception, video or DVD play, the LCDpanel or video monitor must be
installedsothat these featureswill onlyfunction when the vehicle is in
park”orwhenthevehicle’s parkingbrake isapplied.
AnLCD panelor video monitor used for television reception, videoor
DVDplay thatoperateswhenthevehicleis ingear or whentheparking
brakeis not appliedmust be installedtothe rearofthe driver’sseat
where itwill notbevisible, directly or indirectly, to theoperator of the
motor vehicle.
Notice:
This Productincorporates copyrightprotection technologythat is pro-
tectedby methodclaims of certain U.S. Patents andotherintellectual
property rights ownedby Macrovision Corporationandother rights own-
ers. Use ofthiscopyright protectiontechnologymust be authorizedby
MacrovisionCorporation,andisintendedforhomeandotherlimitedview-
inguses onlyunless otherwise authorized byMacrovision Corporation.
Reverse engineeringor disassemblyis prohibited.
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

3
Content
A. Introduction............................................................................4
B.CautionsandWarnings........................................................4
C.Contents ...............................................................................6
D. PoweringandInstallation .......................................................6
E. Controls,Indicators, and Connectors ....................................7
F.Loadingand PlayingaDisc ...................................................8
G.Basic Operation......................................................................9
H.DockforiPod and Playing FilesStored inYouriPODPlayer.........10
I. Menu .......................................................................................12
J.Display......................................................................................12
K.Playing Audio CDS..................................................................15
L.PlayingMP3 Discs................................................................16
M.Connectingto aTVor another monitor...................................18
N.Setup ....................................................................................20
O.Specifications ........................................................................23
P.Rechargeable Battery Installation and Use ..........................23
Q. Troubleshooting .....................................................................26
Warranty.....................................................................28
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

4
A.Introduction
Thank youfor choosingtheD8000IPportableDVDplayer. The main
features include a8" Screen (16:9Aspect Ratio) LiquidCrystal Dis-
play (LCD) monitorandaDVDplayer with a dockfor yourIPod. The
unit is designed for usewith SD/MMC,MS memorycardsand USB
memory devices. The unit appliesthe lateststate oftheart electron-
icsand isdesigned for use inhotels, offices or yourhome. Theunit
isconstructedto provideyearsofreliable, trouble-freeservice,andis
compact so that you can take itwith you anywhereand isdesigned
forquick andeasyinstallation. Pleaseread theentireinstruction
manual supplied withthis product prior to using.The documentation
willassistyouin installingthe system properly to obtain the bestequip-
mentperformance. Please save this manual for later use.
B. Cautions and Warnings
1. Placement
Toprevent fireorelectric shock,donotexpose this appliance to
rain or moisture.Donot place the set on an unstable cart, stand,
tripod, bracket ortable toprevent it fromfalling. Keeptheunit away
from strongmagnets,heatsources,directsunlight, excessive dust.
Ifthe unit is brought directlyfrom a cold to a warm location, mois-
ture maycondense inside the unit. When you move it from a cold
toa warm location, wait forabout one hourbefore operating the
unit, or removethe discandleave theunitturnedonuntilthemois-
ture evaporates.
2. Installation
Ensure that the 8”portable DVD player withadock for youriPod is
usedin accordance with the instructions and illustrations provided
in this manual.
3. Caution
Do not push objects ofany kindinto the unit throughopenings;
do not spill or sprayliquid ofanykind on or in the system (this
mayresult in a fire or electric shock). Do not place anything
heavy onthe unit. Toensure proper ventilation and proper
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

5
operation,never cover or blocktheslots and openings with acloth
or other material. Keepthe unit awayfrom an open flame such as
fire,candle etc. Itishazardous toreplacethe batteryincorrectly.
Replacethe batteryonly with thesame or equivalenttype, in order
to protect the environment, please dispose the batteryproperly.
Do not use the unit in temperatures higher than 95 degrees Fahr-
enheit or 35 degrees Celsius.
4.Disassembly
Do not attempt to disassemble the cabinet. There is ariskofelec-
tricshock and/orexposure to LaserRadiation. Contact qualified
service personnel ifyour system needs repair.
5.Cleaning Unit
Whencleaning,makesurethesystem isunplugged fromthepower
source. Donotuseliquid cleaners or aerosolcleaners. Usea cloth
lightly dampenedwith waterfor cleaningtheexterior ofthe system
only.
6. Disc
Do not use irregularlyshaped discs such asheart orstar-shaped
discs as theymay cause the unittomalfunction.Donotstickpaper,
tapeor glue on the disc. Do not expose thedisc to direct sunlight
or heat sources. Do not touchthe surface ofdisc. Handle thedisc
by itsedge. Cleanthedisc bywipingthedisc from the center out
with acleaning cloth. Removethe disc from the unit and store it in
its case after playing. Some playbackoperationsofdiscs maybe
intentionally fixed bysoftwareproducers. Since this unitplays discs
according to the disc contentsthesoftwareproducers designed,
some playbackfeatures maynot be available. Also refer to the in-
structionssuppliedwiththediscs.
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

6
7.RegionalCoding
Both theDVDplayer and disc are coded by region. These
regional codes must match inorder for thedisc toplay.Ifthe
codesdon’t match, the disc won’t play. This unit’s code is region
1. DVD is with other regional codes cannot be played in thisunit
C. Contents
1. 1 x 8’’ LCD Monitor & DVD Player Combo with dockfor iPod
2. 1 xRemote Control with battery(CR2025)
3. 1xAudio/Video Cable
4. 1 xAC to DCAdapter
5. 1x Cigarette LighterAdapter
6. 1x Rechargeable battery
7. 1x30 gigabyteiPodAdapter
8. 1x Instruction Manual
D. Powering and installation
1. Powering the system indoors (Refer to Figure 1)
Plug one end of theAC to DC adapterinto the DCinputjackon the
left side ofthe mainunit, then plugthe otherend intothe 110~240V
AC power receptacle.
2. Powering the systemin a car
Plugoneend ofthecigarette lighteradapter into the DC inputjack
on the unit, then plugthe otherendintothe cigarettelightersocket.
Figure1
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

7
E. Controls, Indicators, and Connectors
1. UnitView (Refer to Figure2)
Figure 2
1) SD/MMC/MS Slot
2)Power/Charge LED
3)Remote Control Sensor
4) DC 9V InputJack
5) Brightness Up/Down Control
6)AVInJack
7)AVOut Jack
8) USB Port
9) Headphone Jack 1
10)HeadphoneJack 2
11) Volume Up/Down Control
12) PowerOn/Off SW
13) Up Button
14) DownButton
15) OK/Play/Pause Button
16) LeftButton
17) Right Button
18) LCD Panel shut off
19)Source Button
20) Wide Button
21)MenuButton
22) Previous Button
23) NextButton
24) Dockfor IPod
25) Open Button
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

8
2.Remote Control (Refer to Figure3)
1) Setup Button
2) UpButton
3) Skip- Button
4) Enter Button
5) Reverse/Left Keypad
6)DownButton
7)Numeric Buttons
8) DisplayButton
9) Zoom Button
10)Source Button
11) Skip+ Button
12) A-B Repeat Button
13) Forward/Right Keypad
14) 1/AllRepeat Button
15) Stop Button
16) Menu Button
17) Subtitle Button
18) Audio Button
19) Play/Pause Button
F. Loading and Playing a Disc
a.After connecting powerto theunit, poweron DVDplayer”with the
power switch. The powerindicator will light.
b. Open the disc tray by pressing theOPENButton, andplace adisc
into the tray with the labelside facing up.
c. Close thetray bypressingthe area marked CLOSE”.Theunitwill
load the discand start playing.
d. Rotate VOLUME to adjust the DVD player’s volume.
e. To stopplaying adisc,pressSTOP.
Figure 3
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

9
G. Basic Operation Select respective sources: iPod /USB/SD
/AVIN/DVD
Turns theunit on/off
Remove/load the disc
Start Play/Execute item or setting
Still Picture
(1time) Stopatthepresentplaying point /
(2 times) Stop playing
Goto thenextchapter, track or scene
during play back
Gobacktothe previouschapter, track
or scene duringplayback
Scan forward at 2, 4, 8,16 or
32 times speed
Scan backward at 2, 4, 8, 16or
32 times speed
Used forMenu Navigation
Execute item or confirm setting
Select item or setting
Display the mainmenu ofthe disc
Repeat playingtitle, chapter, or track
Repeat a specific portionfrom
point A to pointBof thedisc
Displayinformation (title, chapter,
track, time, etc.).
Select thesubtitlelanguage andturn it
on/off
Selecttheaudio language
Displaythe setup menuto select and
set items, and exit the setup menu.
On the player only: change between wide
screen and 4:3 picture aspectratio.
SOURCE
POWER
OPEN
OK/PLAY/PAUSE
STOP
NEXT
PREVIOUS
FORWARD
REVERSE
LEFT/RIGHT/UP/DOWN
ENTER
NUMBERS
MENU
REPEAT
A-B
DISPLAY
SUBTITLE
AUDIO
SETUP
WIDE
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

10
H.Dock for iPod and Playing files storedin your iPod
1. Determinewhich iPod you have.
Note: This unit is for video iPods only. Ifyou have a30 gigabyte iPod
insert the 30 gigabyte adapter (Figure4) intothe iPod dock. Youcan
dock youriPod for playback ofstoredfilesandrecharging.Only 30G,
60Gand 80G iPodswith video are supported.
2. Tilt the iPod dockupward(Figure 5). If the iPod hitsthe DVD player
screen, tilt the screen backwards.
3. SlidetheiPod into thedock (Figure6) 30-pin connector facingdown.
4. Press down ontheiPod to engage the 30-pin connector.
5. The iPoddockcan now betiltedbackuntil it isflush withthe surface
of the DVD player.
Figure4
Figure5
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

11
NOTE: If thetopofthe iPod hitsthesurfaceofthe DVD player it is not
fullyseated. RemovetheiPod andre-insert it.
6. Set theDVDplayer to the power-on mode.
7. Press the SOURCE button repeatedlyfor the iPod input.
8. Select a video andsettheiPodto TV OUT”to watchit on the DVD
player’s screen. To playphotos in your iPod, youneed topress the
buttononyour iPod otherwise there will be no picture on the screen
when you playvideo files in your iPod. (See your iPod user’smanual
for detailedoperation.)
9.You can playfilesstored intheiPod usingthe buttons
onthe DVD player oron your iPod directly.
10.To remove theiPod, tilt the DVD player’s screen backwards and tilt
iPod upwards. Slide the iPodout of thedock.
NOTE:
1. Please remove the adaptermarked for 30G iPod”from the dockif
you wantto docka60Gor 80G iPod.
2. Torechargeyour iPod, youmust connect your DVDplayer to
theDC power adapter or anAC source andensure your DVD player is
isset to power off or if your DVD player is set to power on, the
sourceis set to iPod”.
3. When playingmusicon the iPod, the information of themusic will
bedisplayedon the screen ofthe iPod and not theDVD screen.
4.IniPod/AV IN mode, ifthere isnosignal in put, the monitor will shut
offautomatically.
Figure6
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

12
I.Menu
A DVD is divided into sections called titlesandchapters. When you
play a DVD,aroot menu ofthedisc will appearonthescreen ofyour
TVor Monitor. Thecontentsofthe menu varyfrom disc to disc.
Press MENU duringplaybackto display the menu. Some DVDs only
allowyou to select disc playbackoptions using the DVD root menu.
J.Display
1. PLAYINGTIME AND REMAININGTIME
a. Duringplaybackpress the ‘DISPLAY’button to displaythe cur-
rent Title Number (1), the total Number ofTitles (2), the current
ChapterNumber (3), thetotal Numberof Chapters (4), andthe
Playing elapsedTimefor thetitle (5). Theheadingwill disappear
automaticallyafter 3 seconds ifDISPLAYbuttonis not pressed.
Title, Chapter Number, and TimeScreenDisplay
b. Press ‘DISPLAY’constantlyto choosetheoptionsbelow in
sequence.
TitleElapsed: The elapsedtime ofthe title
Title Remain:The remaining time ofthe title
Chapter Elapsed: The elapsed time ofthe chapter
Chapter Remain: The remainingtime ofthe chapter
Display Off: The DVD’stime Information will not be displayed.
Title Elapsed
TitleRemain
Chapter Elapsed
Chapter Remain
DisplayOff
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

13
Audio Language
2. SUBTITLE
Duringdisc playbackpress ‘SUBTITLE’toselectthe subtitle language
youdesire*,withthecurrentSubtitle LanguageNumber(1) andthe
total Number of Subtitle Languages(2)displayed. Ifthere are mul-
tiplelanguagespress ‘SUBTITLE’againto selectanother subtitlelan-
guage.Toturn subtitles OFF,press the ‘SUBTITLE’button until ‘Sub-
titleOff’isdisplayed.TheSubtitledisplay willdisappearautomatically
ifthe ‘SUBTITLE’button is not pressed again within 3 seconds.
*Some DVDsonly allowaccessto this functionthrough theDVDmenu
3. AUDIO
During playbackpress ‘AUDIO’to select theaudio languageyou de-
sire*, with the current Audio Channel Number (1) and the total num-
ber of AudioChannels(2)displayed.PressAUDIOagain to select
anotheraudio language. The audiodisplaywill disappear automati-
callyifthe ‘AUDIO’button is not pressed within for 3 seconds.
*SomeDVDsonly allow accessto this functionthrough theDVD menu.
Subtitle
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

14
4. A-B REPEAT
a. Duringplaybackpress a first time ‘A-B’to set the StartingPoint
A.
b. Press ‘A-B’asecond time to set the EndingPoint Band the
playerwill repeatedly playthe partbetween PointAand Point B.
c.PressA-Bathird time to cancelA-Brepeat and resume
normalplayback.
A-B Repeat Starting Point
A-BRepeatEnding Point
A-B Repeat Cancelled
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

15
5.REPEAT
a.Duringplaybackpress ‘REPEAT’constantly tosee therepeatmode
as right.
Chapter: Repeat the current chapter
Title: Repeat the current title
All: Repeat all chapters and titles
Repeat Off: Resume normal playback
The ‘Chapter’repeat displayshows belowfor example:
K. PlayingAudio CDs
Whenplayingan audio CDpressthe DISPLAYbuttonconstantly on
theremoteto viewtimeinformation.Theoptions belowappear on
screendisplayinsequence toshow youwhatinformationis available
usingthis function.
CD Display Mode
SingleElapsed: The current track playingand playingtime ofthat
trackwill displayon the screen.
Single Remain: The current trackplayingand the amount oftime
left.
Single Elapsed
SingleRemain
TotalElapsed
TotalRemain
Display Off
Single Elapsed When Playing Audio CDs
Chapter Repeat
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

16
Total Elapsed: The current track playingand the total time that the
CD has been playing.
Total Remain: The current track playingand the amountoftime
remainingon the CD.
Display Off:The CD time Information will notbe displayed.
Take ‘Single Elapsed’display as a example shown above:
USING THEREPEATFEATURE
Thedefaultmode forthe Repeat feature isOFF.PressingREPEAT
consecutively changes the repeat options:
•Track-repeats the track that isplaying.
•All-repeats the disc that isplaying.
•Repeat Off
Asyou toggle throughthe options,the repeatoptionchanges. The selected
repeat option loops repeatedly until you turn itoff.
L. Playing MP3 Discs
MP3isa format for storingdigital audio.AnaudioCD-quality songis
compressed into theMP3 format with very littleloss ofaudio quality
whiletaking up much less disc space.CD-R/RWdiscs that have
beenencoded in MP3formatare compatible with this system.
Whenan MP3discis insertedintothe unit, themenuscreenappears
automatically.Youcanuse themenuscreentoselect your desired
foldersandsongs orthesystem plays thesongs in theorder they
were burned onto the disc.
1.Press the or buttontochoosea folderfrom thefolder liston
the leftsideof the screen.
2. Press ENTERto select thehighlighted folder. The songs avail-
able under the folder willbe listed.
3.Use or buttontochooseasongfromthe list. PressENTER
to select and begin playback ofthehighlightedsong.
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

17
4. Use the ( NEXT ) button to move to the nextsong. Press the
(PREVIOUS) button to moveto the beginningofthe previous
song.
USINGTHEREPEATFEATURE
Thedefault modefor the Repeat feature isOFF. Pressing REPEAT
consecutively changes the repeat options:
•Repeat One (repeat playback ofa song)
•Repeat Folder (repeatplaybackofa specific folder)
•RepeatOff (normal playback)
As you toggle throughthe options, the repeat mode changes. The
selected repeat mode loops repeatedly until you turn it off.
NOTICE
”iconinfront ofafilenameindicatesthatthisisafolder, not an
MP3file.
MP3”iconinfrontofafilenameindicates that thisis aMP3 file.
Note:
Due tothe company’s policy ofconstant improvement and technical re-
finement, the company reservestheright to changeor alter software.
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

18
M. Connecting toother Electronical Equipment
1. Connecting toa TV oranother monitor (Refer to Figure7)
Connect oneend of the audio/video cable’s black(1/8”plug)plug
intotheunit’s DVD AVOutjack,and connect theotherendtothe
AUDIO INPUTjacks onyourTV or Monitor throughAVadapter cable
(white = left channel, red = right channel, yellow=video).
Figure7
Note:ConnecttheTVorMonitortoAVOutjackonthis unitdirectly
(Nosetting needed in theSource button)
2. Connecting toa Game or Camcorder (Refer toFigure 7)
a) Press theSource button to select the AV IN”source.
b)Connect one end oftheaudio/video cable’sblack (1/8”plug) plug
into theunit’s DVDAVIN jack, andconnectthe other end to theAV
Outputjackson yourCamcorderorotherDVDthroughtheAVadapter
cable(white = left channel, red= right channel, yellow=video).
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

19
3. SD/MMC/MSCardand USB device
Plug theSD/MMC/MSCard orUSB deviceintotheSD/MMC/MSSlotor
USB slotand press SOURCE buttonrepeatedly on the unit (oron the
remote control) to select the USB /SD source.
4.Connecting headphones
Connect theheadphonesinto the headphone 1jackor theheadphone2
jack ofyour unit. ( Referto Figure 8)
Design and Specificationsaresubjectto change
forproduct improvementwithoutnotice
*
*
Plugginginto Headphone jack1and 2disables theinternal speakers.
Figure8
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

20
N.Setup
1. GeneralSetup Page
1)With no discinsidethe player,press‘SETUP’todisplaythe Mainscreen
ofthe Setup Menuon the screen and General Setup Page”appearsand
” ishighlighted. Press ‘SETUP’againto exittheSetupMenu.
2) Press the ENTERbutton, TV Display”ishighlighted.
3) Press the or button to select the other menus in general setup
page.
4) Press to enter the submenu.
5) Press the or button to select the sub menu and press the
ENTER to confirm your selection.
6) Repeat steps 3-5 for other menus.
Note: Press toreturn theprevious menu.
a) TVDisplay
Normal/PS:When the player outputssignal toa normal TV,anormal
picture is shown on the full screen.
Normal/LB: When the player outputs signal toa normalTV, a normal
picture is shownon the screen with ablackstrip at both thetop and
bottom ofthe screen.
Wide: When the player outputssignal toa wide screen TV, awide
picture is shown on the full screen.
b) Angle Mark
On:Thescreen will showthe anglemark icon. (Ifanangle optionis
available).
Off: The screen will not displaytheangle mark.
c) Screen Saver
On: Enablesscreensaver.
Note: TheDVD playerwillenterthe Screen Saver mode after ap-
proximately fiveminutes ifthe same imageremains on thescreen.
Off: Disables screen saver.
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com
