Audix D6 Installation and operation manual

D6
OVERVIEW:
Designed, machined, assembled and tested by Audix in the USA, the
D6 is a dynamic instrument microphone used for stage, studio and
broadcast applications. The D6, which is characterized with a cardioid
pickup pattern for isolation and feedback control, is equipped with
a VLM™ (Very Low Mass) diaphragm for natural, accurate sound
reproduction.
The D6 is lightweight, compact and easy to position. With a wide
frequency response of 30 Hz - 15 kHz and the ability to handle sound
pressure levels in excess of 144 dB, the D6 is an excellent choice for
miking instruments requiring extended low frequency reproduction such
as kick drums, large toms and bass cabinets.
The D6 includes a precision machined aluminum body, black anodized
nish, laser etched model and serial number, steel mesh grill,
Switchcraft® or Audix XLR connector and is supplied with a tension-t
heavy duty nylon mic clip.
Transformerless design, low impedance and balanced output allow for
interference-free performance even with long cable runs.
FEATURES:
Compact, lightweight
Machined aluminum body
VLM diaphragm
Studio quality sound
Excellent mid-bass transient response
Handles extremely high SPL without distortion
Roadworthy construction
5 year warranty
APPLICATIONS:
Live stage, recording
Kick drum
Floor tom
Bass cabinets
Leslie bottom
SUPPLIED ACCESSORIES:
Tension-fit heavy duty microphone clip (DCLIP)
Carrying pouch (P1)
OPTIONAL ACCESSORIES:
TRIPOD- Tripod microphone stand
DFLEX - All purpose percussion clamp
DVICE - Spring loaded rim mount clamp
STAND-KD - Adjustable kick drum microphone stand
CBL-20 - 20’ XLR-XLR Low noise microphone cable
CBL-DR25 - 25’ Right angle XLR-XLR low noise microphone cable
MODEL VARIATIONS:
D6N - Same as above with a nickel finish
D6S- Same as above with a silver finish
DYNAMIC KICK DRUM MICROPHONE
D6
Dynamic Instrument
D6-NICKEL D-CLIP D6 on KD-STAND DFLEX CBL-DR25

SPECIFICATIONS:
Transducer Type Dynamic
Frequency Response 30 Hz - 15 kHz
Polar Pattern Cardioid
Output Impedance 200 ohms
Sensitivity 0.8 mV / Pa @ 80 Hz
Capsule Technology VLM Type E
Off Axis Rejection >20 dB
Maximum SPL ≥144 dB
Power Requirements None
Connector Switchcraft® or Audix
male
XLR connector
Polarity Positive voltage on pin
2 relative to pin 3 of
output XLR connector
Housing / Finish Machined Aluminum /
Black Hard Coat
Weight 217 g / 7.7 ounces
Length 117 mm / 4.6 inches
FREQUENCY / POLARS:
OPERATION:
The D6 is a low impedance microphone and should be plugged into a “mic level” of
your console, mixer, or recording device. Please note that your microphone does not
require phantom power and will not be effected in any way by phantom power should
it be running simultaneously while the microphone is in operation. Avoid plugging or
unplugging the microphone from the PA system unless the channel is muted or the
volume of the system turned down. Failure to do so may result in a loud “popping”
noise which could seriously damage the speakers in the PA system.
ARCHITECTS AND ENGINEERS SPECIFICATIONS:
The microphone shall be of the dynamic type operating on the moving coil principle
and the capsule shall be VLM Type E. The polar pattern of the microphone shall be
cardioid. The nominal output impedance shall be 200 ohms at 1 kHz. The microphone
shall have a sensitivity of 0.8 mV / Pa at 80 Hz and will handle a sound pressure level
of ≥144 dB. The microphone body shall be machined out of aluminum and the grill cap
shall be steel wire mesh. The overall dimensions shall be 21.5 mm in diameter at the
base, 51 mm in diameter at the widest point and 117 mm in length. The microphone
shall be the Audix D6.
USER TIPS:
The D6 compensates for instruments with extremely high sound pressure levels by
having a very low output stage. For kick drums, as a general rule, start with the mic
positioned centered inside the middle of the drum pointed towards the beater. For
more attack, and less bass boom, move the mic closer to the beater. For less attack
and more bass, move the mic further away from the beater. For kick drums without
hole in front head, place the D6 a few inches from the head for a large dynamic sound.
For toms, position the mic 2 inches from the head and point towards the center of the
drum. For bass cabinets, position the mic 90 degrees to the grill cloth and 1-2 inches
inside the edge of the speaker.
*Further miking techniques may be found on our website at www.audixusa.com
DIMENSIONS (mm):
D6
IMPORTANT: When miking a kick drum with a sound hole
in the head, be sure that the D6 is placed INSIDE the
sound hole. When the head of the grill cap is lined up right
AT the sound hole, there is extreme air turbulence pushing
and pulling on the capsule and this can cause failure. For
more complete miking instructions, go to our web site and
watch “How to Mic Kick Drum.”
SERVICE AND WARRANTY:
This microphone is under warranty for a period of 5 years from
any and all manufacturing defects. Should your microphone
fail in any way, please contact the Audix Service department
at 503-682-6933. A Return Authorization number is required
before returning any products.
CARE AND MAINTENANCE:
The D6 is manufactured to exacting specs with roadworthy construction.
However, the capsule is highly sensitive and should be handled with care.
Avoid extreme temperatures and be sure to store your microphone in the
pouch provided when not in use. Moisture of any kind can adversely affect
the sound and performance of your microphone.
***All specications subject to change without notice.
www.audixusa.com
503-682-6933 Fax: [phone]
Audix Corporation 9400 SW Barber St. Wilsonville, OR 97070
